Mono Harmony FG257 UK User manual

© 2023, Mono Equipment Limited FG257-UK-MAN-0001 | Rev. B23 (Aug 2023)
Installation and Operation Manual
Deck 1
Deck 2
Deck 3
Enter Serial Nos. here.
MonoEquip.com
MONO Modular Deck Oven
with Integrated Prover
EN
Product Version
UK specification
Modular decks
ECO Touch controller
Prover base unit
In the event of an enquiry please quote these
serial numbers.

MONO ECO Touch Modular Deck and Prover (UK) Installation and Operation Manual
2MONO Rev. B23 (Aug 2023)
Safety Symbols
The following safety symbols are used throughout this product manual. Before using your new equipment, read the
instructions carefully and pay special attention to the information marked with the following symbols:
DANGER Indicates an immediate hazard with a high risk of death or serious
physical injury if not avoided.
WARNING Indicates a potential hazard with a medium risk that could result in death
or serious physical injury if not avoided.
CAUTION Indicates a hazardous situation that could result in minor or moderate
injury if not avoided.

Installation and Operation Manual MONO ECO Touch Modular Deck and Prover (UK)
Rev. BA23 (Aug 2023) MONO 3
Electrical Safety Notice
Electrical safety and advice regarding supplementary
electrical protection
Commercial kitchens and food service areas are environments where electrical appliances may be located close to
liquids, operate in and around damp conditions or where restricted movement for installation and service is evident.
The appliance installation and periodic inspection should only be undertaken by a qualified, skilled, and competent
electrician and connected to the correct power supply suitable for the load as stipulated by the appliance data label.
The electrical installation and connections should meet the mandatory requirements of the local electrical wiring
regulations and any safety guidelines.
We recommend:
Supplementary electrical protection with the use of a residual current device (RCD)
Fixed wiring appliances should also incorporate a locally situated switch disconnector to connect to, which
is easily accessible for switching off and safe isolation purposes. The switch disconnector must meet the
specification requirements of IEC 60947.
Your attention is drawn to the following:
BS 7671:2018 – Guidance Note 8 – 8.13: Other locations of increased safety risk
It is recognised that there may be locations of increased risk of electrical shock other than those specifically
addressed in Part 7 of BS 7671. Examples of such locations could include laundries, where washing and drying
machines are nearby, and water is present, and commercial kitchens with stainless steel units where, once again,
water is present. Where, because of the perception of additional risks being likely, the installation designer decides
that an installation or location warrants further protective measures, the options available include:
Automatic Disconnection of Supply (ADS) using a residual current device having a residual operating
current not exceeding 30 mA;
Supplementary protective equipotential bonding; and
Reduction of maximum fault clearance time.
The provision of RCDs and supplementary bonding must be specified by the host organisation’s appointed
installation designer or electrical contractor and installed by a suitably qualified and competent electrician to comply
with Regulations 419.2 and 544.2.
WARNING Separate supplies to each deck must all be protected by a 30mA-rated
Type ‘A’ Residual Current Device (RCD).
Before installation, it is recommended that a qualified and competent
electrician first tests the electrical outlets for electrical safety.

MONO ECO Touch Modular Deck and Prover (UK) Installation and Operation Manual
4MONO Rev. B23 (Aug 2023)
Water Leak Safety Notice
WARNING Take action immediately to get a water leak fixed and prevent death or
serious injury from electrocution.
It is essential to regularly check for any signs of a water leak from an oven installation. If there is evidence of a water
leak, do not ignore it. Immediately report it to a manager or as applicable to your organisation.
Furthermore:
Disconnect or completely isolate the oven from the electrical supply
(see Emergency Instructions section on page 14).
Place an out-of-service notice on the oven.
Contact your oven supplier or MONO Equipment for technical assistance.
Ovens must be maintained and serviced at appropriate intervals to ensure the oven operates at optimum levels.
See the Maintenance section on page 59.

Installation and Operation Manual MONO ECO Touch Modular Deck and Prover (UK)
Rev. BA23 (Aug 2023) MONO 5
General Notices
CAUTION Users with Implantable Cardioverter Defibrillators and Pacemakers
– Several common types of devices and machinery may interfere with
implantable cardioverter defibrillators (ICDs) and pacemakers, including
mobile phones, headphones, radios, machinery, and magnets.
– The electromagnetic waves generated by these devices can keep your
ICD or pacemaker from functioning correctly. Try to avoid them, or at
least minimise your exposure to them.
– Your healthcare professional can advise you about specific devices and
machinery to avoid.
NOTICES Warranty information
– Ambient working temperatures for electrical components, such as
solenoid switches, circuit breakers and motors, should not exceed 40 °C
(115 °F). Manufacturers of these, and other electrical components,
advise that any ambient temperature above this affects the functionality
of the components. Any related guarantees become void.
– It is the owners’ responsibility to ensure adequate ventilation is
provided. Any component malfunctioning during the guarantee period
found to have been subjected to excessive humidity or ambient working
temperatures is not covered by the component manufacturer’s or
MONO Equipment’s product warranty.
– Failure to adhere to the cleaning and maintenance instructions detailed
in this User Manual also could affect the warranty of this machine.
– Visit the MONO Parts and Labour Warranty page for further information.
Continuous improvements
– Our policy is to improve our machines continuously, and we reserve the
right to change specifications without prior notice.
Engineers/Electricians-only sections of the User Manual
– Technical sections of this User Manual are for suitably experienced and
qualified persons (SEQP) only. Customers must never make any
modifications or repairs to MONO’s machines.

MONO ECO Touch Modular Deck and Prover (UK) Installation and Operation Manual
6MONO Rev. B23 (Aug 2023)

Installation and Operation Manual MONO ECO Touch Modular Deck and Prover (UK)
Rev. BA23 (Aug 2023) MONO 7
Contents
Page
1. Introduction ...................................................................................................... 9
2. Overall Dimensions........................................................................................ 10
3. Specifications ................................................................................................. 11
Electrical specifications ........................................................................................................... 11
Environmental specifications .................................................................................................. 11
Mechanical specifications ........................................................................................................ 11
4. Safety .............................................................................................................. 12
General safety messages ......................................................................................................... 12
Oven safety messages.............................................................................................................. 12
Emergency instructions ........................................................................................................... 14
5. Installation ...................................................................................................... 15
General ....................................................................................................................................... 15
Electrical connections .............................................................................................................. 15
Fit earth straps (part no. 158-25-11200) .................................................................................. 15
Fit the tile retaining brackets (part no. 257-06-00015) ........................................................... 16
Water supply requirements ...................................................................................................... 16
Oven’s water system setup procedure ................................................................................... 17
Exhaust Connections (if canopy fitted) .................................................................................. 18
6. Before First Use of the Deck Oven ............................................................... 20
Operating conditions ................................................................................................................ 20
Baking tile ‘seasoning’ instructions........................................................................................ 21
Baking principles ...................................................................................................................... 22
7. Touchscreen Operation ................................................................................. 24
Basic operation ......................................................................................................................... 25
Baking using the “Favourites” menu...................................................................................... 26
Baking using the “Manual Bake” menu .................................................................................. 29
Baking using the “Programmes” menu .................................................................................. 32
Creating a program ................................................................................................................... 35
7-Day timer ................................................................................................................................. 40
Settings ...................................................................................................................................... 42
8. Using the USB port ........................................................................................ 47
9. Diagnostics..................................................................................................... 52
10. Passcodes ...................................................................................................... 54
11. Cleaning .......................................................................................................... 55
Daily cleaning instructions....................................................................................................... 55
Weekly cleaning instructions................................................................................................... 55

MONO ECO Touch Modular Deck and Prover (UK) Installation and Operation Manual
8MONO Rev. B23 (Aug 2023)
12. Troubleshooting ............................................................................................. 56
13. Service and Spares ........................................................................................ 57
Oven spares ............................................................................................................................... 57
Service Information................................................................................................................... 58
Disposal...................................................................................................................................... 58
14. Maintenance.................................................................................................... 59
General maintenance ................................................................................................................ 59
Light bulb replacement............................................................................................................. 59
15. Oven Electrics ................................................................................................ 61
Electrical drawings.................................................................................................................... 63
Electrical panel main components .......................................................................................... 70
16. Prover Operating Instructions....................................................................... 72
Prover controls.......................................................................................................................... 72
17. Prover Electrics.............................................................................................. 73
Electrical drawings.................................................................................................................... 73

Installation and Operation Manual MONO ECO Touch Modular Deck and Prover (UK)
Rev. BA23 (Aug 2023) MONO 9
1. Introduction
The electric modular Deck Oven is an easy-to-use practical, good-looking oven, giving an excellent heat recovery
rate and an even bake across a wide range of bread and confectionery products.
Good looking and completely reliable
Conceived with the no-nonsense requirements of both the independent and in-store baker in mind, designed to be
visually pleasing and give reliable service for many years visually. This oven will more than satisfy the most
discerning customer.
Top-quality specification
The external and internal contact surfaces are stainless steel.
Each modular deck has durable reinforced one-piece tiles and increased high-grade insulation and high-
temperature ceramic sealant to make the oven more efficient.
The oven comes with a patented integral steaming system, which reduces energy consumption and the overall size
of the oven. The system produces natural steam with the advantages of spray steam. Pre-steam is also available
to reduce the effects of long loading times.
No drainage is required.
Eco-touch ovens are supplied with TOUCH displays for user-friendly control. This display can show pictures of
product types or program numbers that have been set by the user. When not being used, the screen can show
your company logo. A voice-prompt facility is also available for basic instructions like “Bake over”.
The lights are low voltage, sealed from the chamber and easily accessed from outside the oven.
Fitted with a choice of hinged easy to clean glazed doors (using low energy-loss reflective glass for high visibility)
or metal doors, means low energy consumption and the high kW rating gives good recovery.
(0-100% heating available both top and bottom).
As it is our policy to improve our machines continuously, we reserve the right to change
specifications without prior notice.
ECOTOUCH
SCREEN
CONTROLS

MONO ECO Touch Modular Deck and Prover (UK) Installation and Operation Manual
10 MONO Rev. B23 (Aug 2023)
2. Overall Dimensions
NOTE All dimensions are in mm (inches) and are approximated.
Oven 2-trays wide
Width 1416 mm (55¾ inches)
Depth including handles 1325 mm (52.2 inches)
Height (to first deck) 824 mm (32.4 inches)
Prover
Number of trays 8
Size of trays 600 mm x 400 mm

Installation and Operation Manual MONO ECO Touch Modular Deck and Prover (UK)
Rev. BA23 (Aug 2023) MONO 11
3. Specifications
Electrical specifications
WARNING Separate electrical supplies to each deck and the prover base must have their own
30mA Type ‘A’ Residual Current Device (RCD).
Table 1: Electrical loading per modular deck (2 trays wide)
Voltage Power
400 Vac (50 Hz), 3-phase + neutral + earth 6 kW, 9 Amps
Table 2: Electrical loading for prover unit
Voltage Power
230 Vac (50 Hz), 1-phase 1.8 kW, 8 Amps
Environmental specifications
The noise level is less than 80 dB.
Mechanical specifications
Table 3: Weights for standard-size deck oven
Specification Nominal trays wide Modular decks
Weight
(2)
Lbs Kg
Total oven weight (including base prover) 2 3 (1) (1)
Weight per oven chamber module 2 - 421 191.5
Weight per oven canopy module 2 - 31 14
Weight per fan module 2 - 62 28
Weight of product (maximum) per deck 2 - 86 39
Weight of prover 2 - (1) (1)
(1) To be advised. Contact MONO Equipment for information.
(2) All weights are approximate.

MONO ECO Touch Modular Deck and Prover (UK) Installation and Operation Manual
12 MONO Rev. B23 (Aug 2023)
4. Safety
General safety messages
CAUTION Magnets information:
−Magnetic fields in magnets, used in devices and machinery, can inhibit pulse
generators for Implantable Cardioverter Defibrillators (ICDs) and pacemakers.
Magnets can activate a switch prohibiting the ICD from delivering vital signals
such as lifesaving shocks.
−If you have an ICD or pacemaker, avoiding close or prolonged contact with
magnets or their magnetic fields is advisable. Keep magnets at least six inches
from where your device is implanted. If you feel any interference in any way,
immediately move away from the source.
Oven safety messages
Only fully trained and authorised persons are permitted to work on the oven. Qualified electricians must carry out
all repairs and maintenance. Always disconnect or isolate the power supply before starting maintenance or
cleaning work on the oven.
A responsible Bakery Manager or Supervisor must carry out daily safety checks. Bakery staff must not, under
any circumstances, remove covers or panels to access any part of the oven.
DANGER Never use the USB port to power or recharge electronic devices, e.g. mobile
phones. Incorrect usage causes damage to the oven and could result in a fire.
WARNING Before using the oven:
−Ensure all covers, panels, cables, and pipe fittings are secure.
−Visually examine the oven for apparent damage or signs of tampering.
If the oven is damaged or malfunctioning, or missing parts:
−Stop using it.
−Do not attempt any repairs.
−Contact MONO Equipment for technical assistance.
Never operate the oven with any covers or panels removed.
All utility connections to the oven must comply with the statuary requirements of
the country where the oven is installed.
Ensure this product manual is read thoroughly before operating the oven. Operate
and maintain the oven only as described in this product manual.

Installation and Operation Manual MONO ECO Touch Modular Deck and Prover (UK)
Rev. BA23 (Aug 2023) MONO 13
WARNING Separate electrical supplies to each deck and the prover base must be protected by
their own 30mA Type ‘A’ Residual Current Device (RCD). The RCDs must be fitted
before installation and commissioning of the oven and prover base.
Always fit a wall-mountable isolator switch to isolate the oven entirely from the
electrical supply in an emergency. The isolator must be visible, labelled as an
emergency shutdown device, and easily accessible.
Check that the electrical requirements on the oven’s information plate match the
supply before connecting the power cable and turning the power on for the first time.
Before installation, it is recommended that a qualified and competent electrician
first tests the electrical outlet for electrical safety.
Always ensure your hands are dry before touching any electrical components,
including cables, switches, and plugs.
CAUTION Be aware of hot surfaces:
−Do not touch the oven door with bare skin.
−Always use oven gloves when loading or unloading the oven.
−Allow time for the oven to cool down before cleaning it.
−While the oven is in operation (and for some time after use), touching the oven
door or the surrounding panels is inadvisable because of the conducted heat.
When removing products from the oven, ensure the following:
– Tins are knocked out and stored directly onto a tin storage trolley or rack.
Do not leave hot tins on the floor or tables.
– Trays are put into a rack and then wheeled to a safe cooling area.
Fully train operatives before they use the oven. Anyone undergoing training must
be under the direct supervision of someone experienced.
Ensure there are no trip hazards around the oven, e.g. trailing cables.
Check that the floor around the oven is not slippery, e.g. no liquid spills.
Do not store items on top of or behind the oven.
Never climb onto the roof of the oven.
Only use the oven for baking bread, pastries, and cakes.
Contact MONO Equipment for other product-baking machines.
No unauthorised modifications to the oven are permitted.

MONO ECO Touch Modular Deck and Prover (UK) Installation and Operation Manual
14 MONO Rev. B23 (Aug 2023)
Emergency instructions
To stop the oven in an emergency, switch it off using the main isolator on the oven.
A wall-mounted isolator switch, rated for the specific model of oven installed, must also be available to isolate the
oven entirely from the electrical supply in an emergency. The isolator must be visible, labelled as an emergency
shutdown device, and easily accessible.
Figure 1: Main isolator switch on the oven
W

Installation and Operation Manual MONO ECO Touch Modular Deck and Prover (UK)
Rev. BA23 (Aug 2023) MONO 15
5. Installation
General
A solid, smooth, level floor is recommended on which to position the oven, and access for maintenance
should be considered.
The oven is not a “built-in” design. Sufficient clearance must be left in front of the access panels (right-
hand side) for servicing.
If not chosen as an oven option, an extraction hood should be sited above the oven to disperse excess
steam and heat, which could adversely affect the bakery ceiling and ambient temperature.
A chain retainer, shorter than the power cables, should be fitted to protect them from strain if the oven
moves. Fit it to the wall or floor and the base, using the hole in the castor fixing corner plates.
Only trained engineers are authorised to install this oven. All water and electrical connections must
comply with local and national regulations.
Electrical connections
The main connection point for all deck supplies is at the top of the oven.
A wall isolator must be available to isolate the oven completely. This isolator must be easily accessible
to the oven operator.
Read the Safety section on page 12.
Electrical loadings are in the Specifications section on page Error! Bookmark not defined..
Fit earth straps (part no. 158-25-11200)
NOTE Factory-built ovens already have them fitted, but always check that they are fitted.
Figure 2: Connect earth (ground) straps between each modular deck

MONO ECO Touch Modular Deck and Prover (UK) Installation and Operation Manual
16 MONO Rev. B23 (Aug 2023)
Fit the tile retaining brackets (part no. 257-06-00015)
NOTE Only deck ovens built on-site need this procedure, but always check that they
are fitted.
Procedure
1. Find the brackets and screws loose in a supplied plastic bag.
2. Position the bracket to touch the tile (as shown in the photograph)
3. Fix the bracket using two screws.
4. Repeat steps 1to 3for both sides of each deck.
Figure 3: Installing the tile retaining brackets
Water supply requirements
NOTE The setup procedure on the next page must be followed to allow the steaming
system to function correctly.
Oven
All ovens with steam require a ¾” BSP hot or cold water supply at a pressure of 2 to 3 bar (29 to 44 psi).
Only one water supply is required per oven and must comply with local water regulations.
All decks are supplied from one connection point on the rear of the oven.
For proper operation of the steam system, it is recommended that the water supply has the following
specifications:
Hardness 0 to 4 grains per gallon
PH range 7.0 to 8.5
Chloride concentration 0 to 20 ppm
Consult MONO for proper water filtration system information.
No drain is required for this oven.
A non-return check valve is supplied and fitted to the water inlet manifold.
Prover
The Prover Base requires a ¾” BSP cold water supply at a pressure of 2 to 3 bar (29 to 44 psi).
Washing-machine-type hose
Retaining brackets in two positions on each deck
Positioning of bracket

Installation and Operation Manual MONO ECO Touch Modular Deck and Prover (UK)
Rev. BA23 (Aug 2023) MONO 17
Oven’s water system setup procedure
The water delivery to the deck oven must be checked for the steam system to
operate correctly.
Note that dynamic pressure, not static pressure, is being measured.
Procedure
1. Flush out the main feed pipe to be used until water runs clear and free from debris.
2. Connect the main feed to the oven.
3. Connect flexible hoses to each deck.
4. Place a container under the test valve (B).
5. Slowly open test valve (B) fully and, with the water flowing, set the regulator (C) to 0.75 bar using the
screw underneath (D).
−Never use the oven above this setting.
6. When the pressure has stabilised, shut the test valve (B).
7. Repeat steps 4 to 6 at the end of the installation.
Figure 4: Water regulator setup (located on the rear of the oven)
A. To ovens
B. Test valve
C. Regulator
D. Adjusting screw to 0.75 bar
E. Filter
F. Dual check valve backflow prevention device
G. Stop tap

MONO ECO Touch Modular Deck and Prover (UK) Installation and Operation Manual
18 MONO Rev. B23 (Aug 2023)
Exhaust Connections (if canopy fitted)
Ideally, an exhaust duct should rise 2 metres above the bakery roof and be protected from wind and birds
by a duct protector.
It should be of a suitable material to take the high temperatures and humidity expected.
It should be flexible and easily removable at the oven connection point.
This allows the oven to be moved for cleaning when required.
Figure 5: Canopy (without fan) dimensions
Dimensions are in mm (inches)

Installation and Operation Manual MONO ECO Touch Modular Deck and Prover (UK)
Rev. BA23 (Aug 2023) MONO 19
Figure 6: Canopy (with fan) dimensions
Dimensions are in mm (inches)
Table 4: Canopy parts
Item Part number
A Extraction fan assembly 247-08-04900
B Inlet ring 247-08-05100
C Flue assembly 257-10-00010
D Canopy assembly 257-10-00016
E(1) Extraction duct assembly for 2-tray oven width 257-10-00022
(1) Contact MONO Equipment for the availability of other extraction duct assemblies.

MONO ECO Touch Modular Deck and Prover (UK) Installation and Operation Manual
20 MONO Rev. B23 (Aug 2023)
6. Before first use of the deck oven
Operating conditions
Leave a clear space of at least 2 to 3 metres (6 to 10 ft.) in front of the oven for practical and safety
reasons.
Do not use bakery utensils to operate the control panel buttons.
Ensure that the locking casters are locked into position.
For hygiene reasons, MONO Equipment highly recommends thoroughly wiping the inside of the oven and
all accessories with a clean cloth soaked in warm, soapy water before using the oven for the first time.
Although the utmost care is taken during assembly and pre-delivery inspection, there is always a possibility
of residue contaminating the first bake if this is not done.
Baking tile ‘seasoning’ instructions
THIS PROCEDURE MUST BE FOLLOWED FOR THE OVEN’S WARRANTY TO REMAIN VALID.
For the oven to give good, reliable service, the deck tiles must initially be brought up to temperature as stated
below; this ensures all residual moisture in the tiles has been removed.
This procedure must be actioned once before the deck oven is used for the first time. After the tile seasoning
procedure has been run, the oven can be used as required.
Tile seasoning procedure
1. From the Main Menu, select the Settings icon.
2. Enter the default password 123456 (unless changed) and touch OK.
