Monogram ZV1050 User manual

1
Installation
Instructions
monogram.com
42" Island
Vent Hood
ZV1050

2
Safety Information
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK OR
INJURY TO PERSONS, OBSERVE THE FOLLOWING:
A. Use this unit only in the manner intended by the
manufacturer. If you have any questions, contact the
manufacturer.
B. Before servicing or cleaning unit, switch power o at
the service panel and lock service panel to prevent
power from being switched on accidentally. If the
service panel cannot be locked, fasten a tag or
prominent warning label to the panel.
AVERTISSEMENT :
POUR RÉDUIRE LE RISQUE D’INCENDIE, DE CHOC
ÉLECTRIQUE OU DE BLESSURES, IL FAUT OBSERVER LES
REGLES SUIVANTES :
A. Utiliser cet appareil uniquement de la maniére
prévue par le fabricant. En cas de question, consulter
le fabricant.
B. Avant toute intervention ou nettoyage, couper
l’alimentation électrique au disjoncteur et verrouiller
le panneau du disjoncteur pour éviter la mise
sous tension accidentelle. S’il n’est pas possible de
verrouiller
le panneau du disconcteur, attacher un placard ou une
étiquette trés visible au panneau.
• For general ventilating use only. Do not use to exhaust
hazardous or explosive materials or vapors.
• Structural framing, installation work and electrical
wiring must be done by qualied person(s) in
accordance with all applicable codes and standards
including re-rated construction.
• Sucient air is needed for proper combustion and
exhausting of gases through the ue (chimney) of fuel
burning equipment to prevent back drafting. Follow the
heating equipment manufacturer’s guideline and safety
standards such as those published by the National Fire
Protection Association (NFPA), the American Society for
Heating, Refrigeration and Air Conditioning Engineers
(ASHRAE), and the local code authorities.
• Local codes vary. Installation electrical connections and
grounding must comply with applicable codes. In the
absence of local codes, the vent should be installed in
accordance with National Electrical Code ANSI/NFPA
70-1990 or latest edition.
CAUTION: To reduce risk of re and to
properly exhaust air, be sure to duct air outside—do not
vent exhaust air into spaces within walls or ceilings or into
attics, crawl spaces or garages.
PRUDENCE : Il faut prendre soin
d’installer un conduit vers l’extérieur pour réduire le risque
d’incendie et pouvoir évacuer l’air correctement. Il ne faut
pas évacuer l’air correctement. Il ne faut pas évacuer l’air
dans l’espace entre les parois d’un mur, un plafond
ou un grenier, un espace sanitaire ou un garage.
BEFORE YOU BEGIN
Read these instructions completely and carefully.
• IMPORTANT – Save these instructions for local
inspector’s use.
• IMPORTANT – Observe all governing codes and
ordinances.
• Note to Installer – Be sure to leave these instructions
with the Consumer.
• Note to Consumer – Keep these instructions for
future reference.
• Skill Level – Installation of this vent hood requires basic
mechanical and electrical skills.
• Completion time – 1 to 3 hours.
• Proper installation is the responsibility of the installer.
• Product failure due to improper installation is not
covered under the Warranty.
CAUTION:
Due to the weight and size of this vent hood and to reduce
the risk of personal injury or damage to the product, we
recommend at least three people install
this hood.
PRUDENCE :
À cause du poids et de la taille de la hotte et pour
réduire les risques de blessures ou de dommages de
l’équipement, nous recommandons que trois personnes
installent cette hotte.
WARNING:
To reduce the risk of re or electrical shock, do not use
this range hood with any external solid-state speed
control device. Any such alteration from original factory
wiring could result in damage to the unit and/or create an
electrical safety hazard.
AVERTISSEMENT :
Pour réduire le risque d’incendie ou de choc électrique,
il ne faut pas utiliser cette hotte avec un régulateur
de vitesse électronique externe. Toute modication de
ce type du branchement d’usine peute endommager
l’appareil ou créer un risque de choc électrique.
TO REDUCE THE RISK OF FIRE, USE ONLY METAL
DUCTWORK.

3
Design Information
PRODUCT DIMENSIONS
This vent hood is designed to be used in vented ceiling-
mounted installations. It can be installed over any Mono-
gram cooktop or range, including Professional models.
CONTENTS
Design Information
Product Dimensions ..............................................................................3
Duct Cover Accessories ..................................................................3, 4
Determine Installation Height .........................................................4
Advance Planning
Tools and Materials Required ...........................................................5
Power Supply ............................................................................................5
Duct Fittings ..............................................................................................6
Installation Instructions
Step 1, Construct Ceiling Support ..............................................7–9
Step 2, Remove Packaging.............................................................. 10
Step 3, Check Installation Hardware ..........................................10
Step 4, Mount Template.................................................................... 11
Step 5, Install Support Frame ........................................................ 11
Step 6, Secure Wiring ......................................................................... 12
Step 7, Size and Install Ductwork ................................................. 12
Step 8, Install Decorative Duct Covers ...................................... 13
Step 9, Install Hood ............................................................................. 13
Step 10, Connect Electrical ............................................................. 14
Step 11, Slide Duct Cover Down ...................................................14
Step 12, Install Filters, Finalize Installation ..............................15
10"
*Height
to Ceiling
42"
31-1/2"
*20" to an 8-ft. ceiling using supplied duct cover
32" for 9-ft. ceiling using ZX1059SFSS Accessory
44" for 10-ft. ceiling using ZX10510SFSS Accessory
This vent hood is supplied with a decorative duct cover
to reach 8-ft. ceiling height, or between 7'11" and 8'1".
DUCT COVER ACCESSORIES
A Duct Cover Accessory may be required for your hood
installation height. Order accessory duct covers for 9-ft.
and 10-ft. ceilings.
ZX1059SFSS – For 9-ft. ceiling height
This kit includes a decorative duct cover and support
frame to reach a 9-ft. ceiling height.
ZX10510SFSS – For 10-ft. ceiling height
This kit includes a decorative duct cover and support
frame to reach a 10-ft. ceiling height.

4
ZV1050 Duct Cover Dimensions
A B
ZV1050 11-1/2" 12"
ZX1059 19" 20"
ZX10510 25" 26"
Design Information
DUCT COVER ACCESSORIES
Order the accessory at the same time as the vent hood
and have on-site before installation begins.
Use this chart to accurately determine the need for a Duct
Cover Accessory.
Installation Heights
Actual *Possible Hood
Ceiling Height Installation Height Duct Cover
7'11" 29" Supplied
8'0" 30" Supplied
8'1" 30" Supplied
8'2" 25-1/2" to 30" ZX1059SFSS
8'3" 25-1/2" to 30" ZX1059SFSS
8'4" 25-1/2" to 30" ZX1059SFSS
8'5" 25-1/2" to 30" ZX1059SFSS
8'6" 25-1/2" to 30" ZX1059SFSS
8'7" 25-1/2" to 30" ZX1059SFSS
8'8" 25-1/2" to 30" ZX1059SFSS
8'9" 25-1/2" to 30" ZX1059SFSS
8'10" 25-1/2" to 30" ZX1059SFSS
8'11" 25-1/2" to 30" ZX1059SFSS
9'0" 25-1/2" to 30" ZX1059SFSS
9'1" 25-1/2" to 30" ZX10510SFSS
9'2" 25-1/2" to 30" ZX10510SFSS
9'3" 25-1/2" to 30" ZX10510SFSS
9'4" 25-1/2" to 30" ZX10510SFSS
9'5" 25-1/2" to 30" ZX10510SFSS
9'6" 25-1/2" to 30" ZX10510SFSS
9'7" 25-1/2" to 30" ZX10510SFSS
9'8" 25-1/2" to 30" ZX10510SFSS
9'9" 25-1/2" to 30" ZX10510SFSS
9'10" 25-1/2" to 30" ZX10510SFSS
9'11" 25-1/2" to 30" ZX10510SFSS
10'0" 25-1/2" to 30" ZX10510SFSS
DETERMINE INSTALLATION HEIGHT
*30"
Recommended
36" Min.
*9-ft. to 10-ft. ceilings may be 25-1/2" to 30" clearance.
The distance between the cooking surface and the bottom
of the hood must be at least 25-1/2". The 30" recommended
installation height, above the standard 36” countertop, will
ensure duct cover t to the ceiling. For 9-ft. and 10-ft. ceil-
ing heights, the hood may be lowered to 25-1/2" over the
cooking surface.
• When installing the Island Hood above a Monogram Profes-
sional Range or Rangetop, installation clearance must be
at least 30".
IMPORTANT: Clearances may vary due to type of cooking
product and local codes. Check with local inspectors to be
sure standard is applicable.
DUCT COVER DIMENSIONS

5
Advance Planning
TOOLS AND MATERIALS REQUIRED
(not supplied)
• Tape measure
• Knife
• Spirit level
• Wire cutter
• Wire stripper
• Wire nuts
• Electric drill and 5/32" bit
• Phillips screwdriver
• Flat-blade screwdriver
• Hammer
• Pliers
• Safety glasses
• Tape to mount template
• Gloves to protect against sharp edges
• 120V, 60Hz., 15- or 20-Amp, 2 wire with ground, properly
grounded branch circuit
• Strain relief for junction cover
• Plumb bob
• Center punch
POWER SUPPLY
IMPORTANT – Please read carefully.
WARNING: FOR PERSONAL SAFETY, THIS
APPLIANCE MUST BE PROPERLY GROUNDED.
AVERTISSEMENT :
POUR DES RAISONS DE SÉCURITÉ, CET APPAREIL DOIT
ÊTRE CORRECTEMENT MIS À LA TERRE.
Remove house fuse or open circuit breaker before
beginning installation.
Do not use an extension cord or adapter plug with this
appliance. Follow National Electrical Code or prevailing
local codes and ordinances.
Electrical supply
This vent hood must be supplied with 120V, 60Hz,
connected to an individual, properly grounded branch
circuit, and protected by a 15- or 20-amp circuit breaker
or time-delay fuse.
• Wiring must be 2-wire with ground.
• If the electrical supply does not meet the above
requirements, call a licensed electrician before
proceeding.
• Route house wiring in the ceiling, as close to the
installation location as possible. Allow an additional
3-feet length from ceiling joists to reach the junction
box on the hood.
• Connect the wiring to the house wiring in accordance
with local codes.
Grounding instructions
The grounding conductor must be connected to
a ground metal, permanent wiring system, or an
equipment-grounding terminal or lead on the hood.
WARNING: The improper connection
of equipment-grounding conductor can result in a risk
of electric shock. Check with a qualied electrician or
service representative if you are in doubt whether the
appliance is properly grounded.
AVERTISSEMENT :
Le mauvais branchement du l de mise à la terre peut
causer un choc électrique. En cas de doute, consulter
un électricien qualié ou un technicien pour déterminer
si l’appareil est à la terre.

6
Advance Planning
DUCT FITTINGS Total
Equivalent Quantity Equivalent
Duct Piece Dimensions Length* Used Length
Round, 1 ft.
straight (per foot
length)
1 ft.
3-1/4" x 12" (per foot
straight length)
90° elbow 17 ft.
45° elbow 10 ft.
3-1/4" x 12"
90° elbow 43 ft.
3-1/4" x 12"
45° elbow 26 ft.
3-1/4" x 12"
90° at elbow 102 ft.
8" round to
3-1/4" x 12" transition 2 ft.
3-1/4" x 12"
to 8" round transition 5 ft.
8" round
to 3-1/4" x 12"
transition 90° elbow 6 ft.
3-1/4" x 12" to 8"
round transition 90° elbow 13 ft.
Round
wall cap
with damper 32 ft.
3-1/4" x 12" wall cap
with damper 75 ft.
Round
roof cap 44 ft.
Use this chart to compute maximum
permissible lengths for duct runs to
outdoors.
NOTE: Do not exceed maximum permissible
equivalent lengths!
Maximum duct length: 100 ft. for range hoods.
Flexible ducting:
If exible metal ducting is used, all
the equivalent feet values in the table
should be doubled. The exible metal
duct should be straight and smooth and
extended as much as possible.
Do NOT use exible plastic ducting.
Total Duct Run
NOTE: Any home ventilation system, such as a
ventilation hood, may interrupt the proper ow of
combustion air and exhaust required by replaces,
gas furnaces, gas water heaters and other naturally
vented systems. To minimize the chance of inter-
ruption of such naturally vented systems, follow the
heating equipment manufacturer’s guidelines and
safety standards such as those published by NFPA
and ASHRAE.
* Actual length of straight duct plus duct tting equivalent. Equivalent
length of duct pieces are based on actual tests conducted by GE
Evaluation Engineering and reect requirements for good venting
performance with any ventilation hood.
This Hood Must
Use 8" Round Duct.
It Can Transition to
3-1/4" x 12" Duct.

7
Installation Instructions
STEP 1 CONSTRUCT CEILING SUPPORT
Plan the location
Determine the exact location of the vent hood.
• Use a plumb bob to check location to be sure countertop/cook-
top location below the hood will align exactly.
• The hood should project forward 1-1/2" beyond the front edge of
the cooking appliance. See illustration.
• Observe the recommended space (30") between the cooking
surface and bottom of hood.
Ceiling
Hood
Ducting
Centerline
Side View
Approx. 1-1/2"
Beyond Cooking
Surface
Cooktop
Countertop
31-1/2"
Hood
Front 15-3/4"
Ceiling support structure
• At the hood location, install 2 x 4 cross-framing
between ceiling joists as shown. (2x4s are required to
support the weight of the hood.)
• Arrange cross-framing in the ceiling to suit the exist-
ing structure.
• Your ceiling joists will be like one of the following
examples.
11-1/4" Install Cross-Framing
Symmetrically About
Duct/Cooktop Centerline
7-1/4"
16" Joist
Spacing
2x4 Cross-
Framing
8" Duct
Align Duct to Cen-
ter of Cooktop Cooktop
Outline
Top View—Ceiling Joists Parallel to Front of Hood
Front
of Hood
EXAMPLE A

8
Installation Instructions
STEP 1 CONSTRUCT CEILING SUPPORT (cont.)
Align Duct to
Center of Cooktop
Cooktop
Outline
Top View—Ceiling Joists Run Perpendicular to Front of Hood
Front
of Hood
EXAMPLE B
11-1/4" Install Cross-Framing
Symmetrically About
Duct/Cooktop Centerline
16" Joist
Spacing
2x4 Cross-
Framing
7-1/4" 8" Duct
EXAMPLE C
7-1/4"
2x4 Cross-
Framing
11-1/4" Install
Cross-Framing
Symmetrically About
Duct/Cooktop Centerline
8" Duct
16" Joist
Spacing
Align Duct to
Center of Cooktop Cooktop
Outline
Top View—Ceiling Joists at Angle with Front of Hood
Front
of Hood

9
Installation Instructions
STEP 1 CONTINUED
• Arrange cross-framing in the ceiling to suit the existing
structure. See examples.
– Secure each 2 x 4 block with at least four (4) #10 wood
screws, 3" long (not supplied). Use 8 wood screws total
for the two supports.
• The cross-framing must be accurately aligned to
ensure correct positioning of the hood.
• The cross-framing must be level in all directions.
Check with a spirit level and adjust if necessary.
IMPORTANT: The ceiling structure must be capable of sup-
porting the weight of the hood (approximately 300 pounds)
and any inadvertent user contact loads. The hood support
frame will be supported by the 2 x 4 min. cross-framing.
Ductwork
• Use the shortest and straightest duct route possible. For
satisfactory performance, duct run should not exceed
100-feet equivalent length for any duct conguration.
• Refer to “Duct Fittings” chart to compute the maximum
permissible length for duct runs to the outdoors.
• This vent hood must use 8" round duct. The 8" round
duct can transition to 3-1/4" x 12".
• Install the house ductwork to run horizontally between
ceiling joists or straight up through the roof.
Finish the Ceiling
• Finish the ceiling surface. Be sure to mark location of
the ceiling joists and cross-framing. Check to be sure
the ceiling is level; use shims, if necessary.
*Depending on available space.

10
Installation Instructions
STEP 2 REMOVE THE PACKAGING
The vent hood is packed separately from the decorative
duct cover or accessory covers ZX1059SFSS or
ZX10510SFSS.
• Remove the frame, cover, parts box and packaging.
• Remove junction box cover.
• Install strain relief onto junction box cover.
STEP 3 CHECK INSTALLATION HARDWARE AND ACCESSORIES
Locate the hardware accessory pack shipped with the
hood and check contents.
11-1/4”
TO CENTER LINE
OF HOLES
7-1/4” TO
CENTER LINE
OF HOLES
WIRE
HOLE
ACCESS
WIRE
HOLE
ACCESS
Mounting Screw Holes
2 Phillips-Head
Decorative Screws
4 Filters
4 Lock Washers
Template
Installation/Service
Stop Screw
4 Machine Screws
Support Frames
with 8 Screws
and 8 Washers
4 Hex-Head
Lag Screws
Decorative Duct Covers

11
STEP 4 MOUNT TEMPLATE
• Align the template with the marks on the ceiling and tape
in place.
– Be sure the template is oriented correctly, with the front
of the hood.
• Use a plumb bob to be sure the mounting holes will pro-
vide parallel alignment with the countertop below.
• Center-punch all hole locations.
• Drill pilot holes in the 4 screw locations. Use a 5/32" bit
and drill approximately 1-1/2" deep.
• Cut the 8-1/4" duct opening and approximately 1" wire
access hole.
Installation Instructions
STEP 5 INSTALL SUPPORT FRAME
Install upper support frame
• Secure the upper support frame to the ceiling joists
and cross-framing with the 4 lag screws provided. For
maximum rigidity and strength, the screws must be
driven into the center of the joists and/or cross- framing.
Check to be sure the support frame is level, vertically
and horizontally.
Install lower support frame
• Insert lower support frame (or accessory support frame,
ZX1059SFSS or ZX10510SFSS) into the upper support
frame and loosely secure with 8 screws and washers (4
on the front and 4 on the back sides).
• Adjust the lower support frame up or down to the
desired height above the countertop. Tighten screws.
IMPORTANT: Again, check to be sure the support is level in
both directions. There is no way to level the hood after the
hood is secured to the frame.
30" Recommended
10"
40"
Countertop
Hood
Mounting
Flange
Lower Support
76"
Wire Access Holes

12
Installation Instructions
STEP 6 SECURE WIRING
• Route house wiring through the ceiling hole and pull a
length to reach the hood junction box, approximately 6"
below the support.
STEP 7 SIZE AND INSTALL
DUCTWORK
• Tape the wire to the left side of the frame support to
prevent damage during installation and service.
• Measure from house duct ange to bottom of support
frame (Dim. A).
– Add at least 1" for duct overlap at the top.
– Subtract 1-3/4" for hood insertion into the bottom of
the frame to determine required duct length.
• Cut the 8" duct length required.
NOTE: The bottom of the duct must be external (female)
connection to the top of the hood. The bottom end should
be ared slightly, to facilitate installation of the hood.
• Install duct up through support frames and attach to
house ducting with sheet metal screws.
• Seal the connection with duct tape.
Ceiling
Support
Frames
Tape
House
Wiring
Left Side
View

13
Installation Instructions
STEP 8 INSTALL DECORATIVE DUCT COVERS
• Pretap or drive decorative screw into the screw holes
on the support frame. This will make screw installation
easier.
• Separate the two decorative duct covers.
• Select the inside cover (top), which has two screw holes
in the top.
• Slide the decorative duct cover over the support frame
and push to the ceiling.
• Attach to the hood support at the top with 2 supplied
decorative screws.
• Locate the third decorative screw in the hardware
package. Set aside.
• Slide the lower decorative duct over the installed upper
duct and push to the top.
• Install the decorative stop screw in the center hole of the
upper (inner) duct cover. The decorative screw will act as
a stop screw and prevent the lower decorative duct cover
from sliding down.
CAUTION: The stop screw must be installed.
Failure to do so could result in personal injury or damage
to the duct cover.
PRUDENCE : La vis supérieure doit être
en place, an d’éviter les blessures ou d’endommager le
capot antipoussière.
STEP 9 INSTALL HOOD
NOTE: AT LEAST THREE PEOPLE ARE REQUIRED TO
COMPLETE THIS INSTALLATION!
• Lift the hood up to the support frame. Carefully align the
hood mounting holes to the support frame holes and, at
the same time, the hood duct connector into the duct.
• Install screws through the hood and hood support.
• Check hood level in both directions.
• Check to be sure that the duct is positioned over the
hood connector.
• Seal the duct connection with duct tape.
NOTE: Do not drive screws through this duct connection.
Doing so will prevent proper damper operation.
Stop Screw
Apply Duct Tape
to Seal Duct
Connection
Install
4 Lock Washers
and 4 Machine Bolts
Bottom
Duct
Cover
Right
Side
Front Front
Front

14
Installation Instructions
STEP 10 CONNECT ELECTRICAL
Verify that power is turned o at the source.
WARNING: If house wiring is not 2-wire
with a ground wire, a ground must be provided by the
installer. When house wiring is aluminum, be sure to use
UL-approved antioxidant compound and aluminum-to-
copper connectors.
AVERTISSEMENT : Si le câblage de
la maison n’est pas du type à deux ls avec un l de terre,
l’installateur doit fournir un circuit de terre. Quand les ls
de la maison sont en aluminium, il prendre soin d’utiliser
de la pâte antioxidation approuvée par UL et des con-
necteurs pour l’aluminium-cuivre.
• Install strain relief onto the knockout of the junction box
cover.
• Insert house wiring through strain relief and tighten.
• Connect white leads to branch circuit white lead.
• Connect black leads to branch circuit black lead.
• Connect green/yellow leads to branch circuit green or
bare ground lead.
• Secure all connections with wire nuts on each electrical
connector.
• Push wires into junction box and replace cover. Be sure
wires are not pinched.
STEP 11 SLIDE DUCT COVER DOWN
• Hold the decorative duct cover and remove the
decorative stop screw from the support frame. Dress
all wire harnesses out of the path of the duct cover
seating.
• Slide the lower duct cover down onto the hood.

15
Installation Instructions
STEP 12 INSTALL FILTERS, FINALIZE INSTALLATION
• Tip the lter into the lower slots at the rear of the
opening. Lift the lter and pull the knob forward until the
lter rests on the slots.
• Make sure you have engaged the "Clean Filter Reminder
Switch" with the right side grease lter by checking to
see if the red light is glowing in the display. If the red
light is glowing, please adjust the lter until the red
indicator light turns o.
• Clean the hood with an approved stainless steel cleaner.
• Check hood operation. If the hood does not operate,
check that house wires have been connected securely
and that no wires have been damaged during
installation. Check the breaker or house fuse is turned
on.
Filter Slots

16
Note: While performing installations described in this
book, safety glasses or goggles should be worn.
For Monogram® local service in your area, call
1.800.444.1845.
Note: Product improvement is a continuing endeavor at
General Electric. Therefore, materials, appearance and
specications are subject to change without notice.
Pub. No. 31-14899
11-10 GE
Printed in Italy
