Monster MSB3785 User manual

Please read this instruction manual carefully and keep it for future reference
MODEL: MSB3785
HOME THEATER BLUETOOTH SOUNDBAR

CAUTION: TO REDUCE THE ELECTRIC SHOCK, DO NOT REMOVE THE
COVER (OR BACK). NO USER SERVICEABLE PART INSIDE, REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DANGEROUS VOLTAGE:The lighting flash with arrowhead symbol within
an equilateral triangle is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of electric shock to persons.
ATTENTION:The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
2
WARNING:TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE.
WARNING: USE UNDER SUPERVISION OF AN ADULT DUE TO LONG
CORD This unit has a long cord that can be easily tripped on or pulled on,
causing injury. Please make sure it is arranged so that it will not drape over a
tabletop, etc. Where it can be pulled on by children or tripped over accidentally.
CALIFORNIA PROP 65 WARNING:”WARNING” This product contains chemicals
known to the State of California to cause birth defects or other reproductive harm.
For more information on these regulations and a list of chemicals, log on the
following website: http://www.oehha.ca.gov/prop65.html
This product meets and complies with all Federal regulations.
FCC STATEMENT:
This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.

Before using the unit, be sure to read all operating instruction carefully, please
note that these are general precautions and may not pertain to your unit. For
example, this unit may not have the capability to be connected to an outdoor
antenna.
1. Read these instructions
All the safety and operating instructions should be read before the appliance is
operated.
2. Keep these instructions
The safety and operating instructions should be kept for future reference.
3. Heed all warnings
All warnings on the appliance and in the operating instructions should be
adhered to.
4. Follow all instructions
All operation and use instructions should be followed.
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules.These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator and your body.
5. Do not use this apparatus near water
The appliance should not be used near water; for example, near a bath tub,
3

washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming
pool.
6. Clean only with dry cloth
The appliance should be cleaned only as recommended by the manufacturer.
7. Do not block any ventilation openings.Install in accordance with the
manufacturer’s instructions.
Slots and openings in the cabinet and in the back or bottom are provided for
ventilation, to ensure reliable operation of the product and to protect it from
overheating. These openings must not be blocked or covered. The openings
should never be blocked by placing the product on a bed, sofa, rug, or similar
surface. This product should never be placed near or over a radiator or heat
source. This product should not be placed in a built-in installation, such as a
bookcase or rack unless proper ventilation is provided or the manufacturer’s
instructions have been adhered to.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The
wide or the third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit from the
apparatus.
11. Only use attachments / accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury
from tip-over.
An appliance and cart combination should be moved with care. Quick stop,
excessive fore and uneven surfaces may cause the appliance and cart
combination to overturn.
13. Unplug this apparatus during lightning storms or when unused for
long periods of time.
To protect your product from a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall outlet and disconnect
the antenna or cable system. This will prevent damage to the product due to
lightning and power-line surges.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or
4

moisture, does not operate normally, or has been dropped.
15. Power source
This product should be operated only from the type of power source indicated
on the marking label. If you are not sure of the type of power supply to your
home, consult your appliance dealer or local power company. For products
intended to operate from battery power, or other source, refer to the operation
instructions.
16. Power lines
An outside antenna system should not be located in the vicinity of overhead
power lines or other electric light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside antenna system, extreme
care should be taken to keep from touching such power lines or circuits as
contact with them might be fatal.
17. Overloading
Do not overload wall outlets and extension cords as this can result in a risk of
fire or electric shock.
18. Object and liquid entry
Never push objects of any kind into the product through openings as they may
touch dangerous voltage points or short out parts that could result in fire or
electric shock. Never spill or spray any type of liquid on the product.
19. Outdoor antenna grounding
If an outside antenna is connected to the product, be sure the antenna system
is grounded so as to provide some protection against voltage surges and built
up static charges. Section 810 of the National Electric Code ANSI/ NFPA 70
provides information with respect to proper grounding of the mast and
supporting structure, grounding of the lead- in wire to an antenna discharge
product, size of grounding conductors, location of antenna- discharge product,
connection to grounding electrodes and requirements for the grounding
electrodes.
5

20. Service
Do not attempt to service this product yourself as opening or removing covers
may expose you to dangerous voltage or other hazards. Refer all servicing to
qualified service personnel.
b)If liquid has been spilled or objects have fallen into the product.
c)If the product has been exposed to rain or water.
d)If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions, as an adjustment of other controls may result in damage and will
require extensive work by a qualified technician to restore the product to its
normal operation.
e)If the product has been dropped or the cabinet has been damaged.
f)When the product exhibits a distinct change in performance- this indicates a
need for service.
25. Note to CATV system installer
This reminder is provided to call the CATV system installer' s attention to
Article 820- 40 of the NEC that provides guidelines for proper grounding and,
in particular, specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of cable entry as
practical.
NOTE: Refer all servicing to qualified service personnel. Servicing is
required when the unit has been damaged in any way such as the
following: the power-supply cord or plug has been damaged, liquid has
been spilled into unit, the unit has been exposed to rain or moisture, the
unit has been dropped or the unit does not operate normally.
21. Replacement parts
When replacement parts are required, be sure the service technician uses
replacement parts specified by the manufacturer or those that have the same
characteristics as the original parts. Unauthorized substitutions may result in
fire or electric shock or other hazards.
22. Safety check
Upon completion of any service or repairs to this product, ask the service
technician to perform safety checks to determine that the product is in proper
operating condition.
23. Wall or ceiling mounting
Theproduct should be mounted to a wall or ceiling only as recommended by
the manufacturer.
24. Damage requiring service
Unplug this product from the wall outlet and refer service to qualified service
personnel under the following conditions.
a)When the power- supply cord or plug is damaged.
6

PRODUCT OVERVIEW
7
1
2
CONTROL PANEL
FRONT VIEW
BOTTOM VIEW 3
4
REAR PANEL
911 12 13 14
1. Remote Sensor
2. Mode Indicator
3. LED Light Effect
4. Mode Switch Button
5. Volume Up Button
6. Power On/Off Button
7. Volume Down Button
8. LED Light Effect Button
9. HDMI IN arc Port
11. OPTICAL IN Jack
13. LINE IN Jacks
12. AUX IN Jack
14. DC IN Jack
AUX IN
LINE IN
OPTICAL IN
HDMI IN
BT/USB
10
10. USB Port
AUX IN
LINE IN
OPTICAL IN
HDMI IN
BT/USB
HDMI IN arc
OPTICAL IN
AUX IN
DC IN
DC 16V, 3.0A
LINE IN
L R
USB
5
6
7
8

8
REMOTE CONTROL
Fig.1
Fig.2 Fig.3
Remove and discard the insulation film as Fig.1.
1
2
3
4
5
6
7
8
9
10
13
1. (Power On/Off) Button
2. AUX Button
3. LINE IN Button
4. (Previous) Button
7. (Mute) Button
12. (Next) Button
13. (Play/Pause) Button
14. (Volume Up/Down) Button
10. USB/REC. Button
OPEN
OPE N
3V CR2025
3V CR2025
with the polarity markings facing upward as Fig.3.
Fig.4
AUX
OPTICAL
LINE
IN
Sound Mode
VOL
STANDARD
14
8. BT (Bluetooth) Button
9. OPTICAL Button
5. Sound Mode (POP, ROCK
CLASSIC, STANDARD) Button
BATTERY REPLACING:
USING AT FIRST TIME:
Pull out the battery holder as Fig.2.
Replace the old button cell with a new CR2025 button cell
Push back the battery holder as Fig.4.
BATTERY INSTALLATION OF REMOTE CONTROL
ROCK
CLASSIC
POP
HDMI
IN 11
12
11. HDMI IN Button
6. (Light Effect) Button
BT
USB
REC.

9
9
BATTERY PRECAUTIONS
Follow these precautions when using a battery in this device:
1. Use only the size and type of battery specified.
2. Be sure to follow the correct polarity when installing the battery as indicated in the battery
compartment, a reserved battery may cause damage to the device.
3. Do not mix different types of batteries together ( e.g: Alkaline and Carbon-zinc )
or old batteries with fresh ones.
4. If the batteries in the device are consumed or the device is not to be used for a long period of time,
remove the batteries to prevent damage or injury from possible leakage.
5. Do not try to recharge the battery as it is not intended to be recharged; it can overheat and rupture.
(Follow the battery manufacturer’s instructions.)
6. The batteries shall not be exposed to excessive heat such as sunshine or fire.
7. Clean the battery contacts and also those of the device prior to battery installation.
8. The remote control is supplied with a coin/button
cell battery. If the coin button cell battery is
swallowed, it can cause severe internal burns in
just 2 hours and can lead to death. Keep new
and used battery away from children. If the
Battery compartment does not close securely,
stop using the product and keep it away from
children. If you think batteries might have been
swallowed or placed any part of the body, seek
immediate medical attention.
CR2025
Remote control operation range
●
●When direct sunlight, an incandescent lamp, fluorescent lamp or any other strong light
shines on the REMOTE SENSOR of the unit, the operation of the remote may be unstable.
CAUTION
●Danger of explosion if the battery is incorrectly replaced.
●Replace only with the same or equivalent type.
16.4 Feet (5M)
When there is an obstacle between the remote and the receiver, the unit may not operate.

PLACEMENT AND MOUNTING
1. Placing the device on a table - Ventilation
When placing the Sound Bar on an entertainment center, bookshelf, or any type of
enclosed space, be sure to allow at least 2-3 inches of space around the Sound Bar for
ventilation. If the Sound Bar is enclosed in a tight space, without ventilation, heat
generated from the Sound Bar could produce a potential heat hazard.
2. The Installation Distance
2-3inches
2-3inches
10
914.2mm (35.99 inches)

2.1 Mountingto a wooden wall
A. Mark the position of the mounting screws on the wall using a pencil.
C. Put the sound bar onto the mounting screws. Make sure they are firm and stable.
2.2 Mountingto a brick wall
35.99 inches
B. Drill the screws directly into the marks that you have made on the wall and leave
approx. 0.3 inches length to hook the sound bar.
(screws not included)
(screws and plastic fixing plugs are not included)
E. Put the sound bar onto the mounting screws. Make sure they are firm and stable.
A. Mark the position of the mounting screws on the wall using a pencil.
B. Drill 2 holes on wall with a powerful electric drill.
C. Insert the fixing plug and hammer into the holes.
D. Secure the screws into the fixing plug and leave approx. 0.3 inches length to hook
the sound bar.
35.99 inches
11

GENERAL OPERATION
1. Connect the AC/DC adapter to the unit and wall outlet.
12
4. During Playback:
2. Press the button on the unit or remote control to power on the unit.
The LED light effect will light up.
different LED light effects.
~ Press and hold the button on the unit or on remote control to turn on or turn
off the LED light effect.
5. Press and hold the button on the unit or press the button on remote control
to power off the unit.
~ Press the button on the unit or on remote control repeatedly to change to
Mode 10: The LED light flashes in disco mode.
Mode 8: The LED light will go from left to right without music playing.
The RGB LED light with combined color dance to the music rhythm
and volume from left to right.
Mode 11: The Blue, Violet, Red, Yellow, Green and Light Blue Light effect will
go from left to right slowly and repeatedly.
Mode 1: The LED light will be solid Blue.
Mode 2: The LED light will be solid Green.
Mode 3: The LED light will be solid Red.
Mode 9: The RGB LED light with combined color will flash repeatedly and
alternatively.
Mode 4: The LED light will be Yellow.
Mode 5: The LED light will be Light Blue.
Mode 6: The LED light will be Violet.
Mode 7: The LED light will be White.
3. Press the button on the unit repeatedly, or press the AUX, OPTICAL, BT,
LINE IN, HDMI IN or USB button on remote control to switch to the desired
mode directly. The corresponding mode indicator on front right of the unit will
light up.
~ Press the + or - button on the unit repeatedly to adjust volume.
~ Press the VOL+ or VOL- button on remote control repeatedly to adjust volume.
~ Press the button on remote control to turn on or turn off sound.
~ Press the Sound Mode button (POP, ROCK, CLASSIC, STANDARD) on remote
control to set to desired EQ mode.

BLUETOOTH OPERATION
10
5. After successful paired, the Bluetooth indicator will be solid blue.
6. During playback:
~ Press the or button on remote control to skip tracks.
~ Press the button on remote control to pause, press it again to resume.
1. Power on the unit as previously explained.
3. Power on the external Bluetooth enable device and enter Bluetooth mode and try
searching the unit.
NOTE: The unit will be automatically connected with the last connected Bluetooth
device if their Bluetooth function are activated and they are in working range.
13
4. When MONSTER SB2 appears, select it and make connection.
2. Press the button on the unit repeatedly, or press the BT button directly on
remote control to switch to the Bluetooth mode, the BT/USB indicator on front
right of the unit will turn blue and blink.
7. Press and hold the button to disconnect current connection and go into a
pairing mode, you can pair to new devices with this sound bar.

AUX IN OPERATION
Rear View
Mobile Phone
Connect to the Phones; AUX Out;
Line Out Jack of the external devices
(Such like MP3 Player; cell phones;
iPod/iPad ... etc)
MP3 Player
1. Plug one end of the AUX IN cable into the AUX IN jack on the unit.
2. Plug the other end of the AUX IN cable into the headphone jack or Aux Out jack
on the external audio player.
14
3. Power on the unit as previously explained.
4. Press the button on the unit repeatedly, or press the AUX button on remote
control directly to switch to the AUX IN mode, the AUX IN indicator on front
right of the unit will light.
5. Power on the connected external player and start playback as usual.
An external Audio player (such as mobile phone, MP3 player etc.) can be
connected to this unit and listen through the unit's speakers.
HDMI IN arc
OPTICAL IN
AUX IN
DC IN
DC 16V, 3.0A
LINE IN
L R
USB

LINE IN OPERATION
An external Audio/Video player (such as TV, DVD player etc.) can be connected
to this unit and listen through the unit's speakers.
1. Plug one end of the Line in cable into the LINE IN jacks (L&R) on the unit.
2. Plug the other end of the Line in cable into the Line Out jacks (L&R) on TV or
DVD player etc.
Rear View
Line out jacks of
TV/DVD player etc.
L R Video
15
white red
5. Power on the connected external player and start playback as usual.
3. Power on the unit as previously explained.
4. Press the button on the unit repeatedly, or press the LINE IN button on
remote control directly to switch to the LINE IN mode, the LINE IN indicator on
front right of the unit will light.
HDMI IN arc
OPTICAL IN
AUX IN
DC IN
DC 16V, 3.0A
LINE IN
L R
USB

OPTICAL-IN OPERATION
4. Power on the connected external player and start playback as usual. Turn on the
digital audio output and set it to PCM (Pulse Code Modulation) type similar to
the below figure:
Bass
Treble
Balance
Select Move MENU Exit
Sound Mode Standard
Surround Off
AVL Off
Audio Language English
Picture Time Setup Lock Off
AudioAudio
Digital Output PCMDigital Output PCM
1. Connect the Optical out jack from the external audio player (such as TV, DVD
player etc.) to the OPTICAL IN jack on the rear side of unit with the optical
connection cable as illustated below: (For PCM format only)
OPTICAL OUT
Optical Connection Cable
(not included)
Rear View
TV or DVD player etc.
16
2. Power on the unit as previously explained.
3. Press the button on the unit repeatedly, or press the OPTICAL button on
remote control directly to switch to the OPTICAL mode, the OPTICAL IN
indicator on front right of the unit will light.
HDMI IN arc
OPTICAL IN
AUX IN
DC IN
DC 16V, 3.0A
LINE IN
L R
USB
Example for reference only

17
1. Plug one end of the HDMI cable into the HDMI IN arc port on the unit.
2. Plug the other end of the HDMI cable into the HDMI arc port on TV.
LR Video
5. Power on the connected TV and start playback as usual.
3. Power on the unit as previously explained.
Rear View
HDMI arc
Explanation:
ARC (Audio Return Channel)
NOTE: The HDMI input channel only works for TV with HDMI ARC feature and it
needs turn on this feature from your TV.
HDMI IN OPERATION
TV with HDMI IN arc port can be connected to this unit, and play audio through the
speakers.
HDMI IN arc port
of the TV
4. Press the button on the unit repeatedly, or press the HDMI IN button on
remote control directly to switch to the HDMI IN mode, the HDMI IN indicator
on front right of the unit will light.
HDMI Cable (not included)
HDMI IN arc
OPTICAL IN
AUX IN
DC IN
DC 16V, 3.0A
LINE IN
L R
USB

10
18
RECORDING OPERATION
This unit has Recording function, please insert a USB device first when using this function.
1.
2.
3. When in playback, press and hold the button on Main Unit or USB/REC. button on
remote control, a prompt tone will be heard to indicate you the recording is begin.
4. Press and hold the button on Main Unit or USB/REC. button on remote control again to
stop recording, two beep tones will be heard.
•
NOTE:
The recorded tracks will be stored in USB device automatically and will be played in priority
in USB mode.
•When in USB playback, press and hold the button on Main Unit or USB/REC. button on
remote control to access the recording file list directly.
•The recording function only works in BT, AUX and Line in mode.
USB OPERATION
1. Insert the USB device to the USB port on the unit.
Note: Whether in any mode, it will automatically switch to USB mode when the USB device
is inserted.
2.
3.
4. During playing:
~ Press the or button on remote control to skip tracks.
~ Press the button on remote control to pause, press it again to resume.
USB
Power on the unit as previously explained.
Power on the unit as previously explained.
Press the button on the unit repeatedly, or press the desired button on remote control to
switch the mode directly. The corresponding mode indicator on front right of the unit will light up.
Press the button on the unit repeatedly, or press the USB/REC. button on remote control
directly to switch to USB mode, the BT/USB indicator on front right of the unit will turn to
White.
HDMI IN arc
OPTICAL IN
AUX IN
DC IN
DC 16V, 3.0A
LINE IN
L R
USB
Rear View

Play music/movie in the paired/
connected device as usual and make
sure the volume level of it is in high
level.
Sound distortion/rattle
Reduce the volume level of the paired/
connected device.
Bluetooth
reception failure
Put the external BT device close to the
unit.
Input source incorrect
The unit is in power off mode
The paired/connected device
is not in playback mode
The external device is
too far from the unit
Remote Control
not functioning Out of range
The battery in the remote
control is drained
Point the remote control to the remote
sensor on the unit within 16 feet, +/-30
degress
Replace with new battery.
No sound or
sound weak
Volume level in minimum position
SYMPTOM
TROUBLESHOOTING
POSSIBLE CAUSE POSSIBLE SOLUTION
No power The adapter is not connected Connect the adapter to the unit and wall
outlet
Press the button on the unit or on
remote control to power on the unit
Raise the volume level by pressing the
+ button on the unit
Or press VOL+ button on remote control
Reduce the volume level by pressing
the - button on the unit
Or press VOL- button on remote control
19
Press the button on the unit
repeatedly or use the corresponding
button on remote control to switch to
desired mode.
HDMI IN(ARC)
not working
Not paired Pair the unit with the BT Device as the
procedures stated in this manual.
Not insert to HDMI ARC channel
The ARC control is off
Please read which channel is the ARC
channel for your TV, and insert this HDMI
cable to HDMI ARC channel. it only
works in HDMI ARC channel.
Please go to the TV setup menu, turn
on the CEC control and turn on the ARC
from the setup menu.
Volume level too high

SPECIFICATIONS
SPECIFICATIONS AND ACCESSORIES ARE SUBJECT TO CHANGE
WITHOUT NOTICE
20
Power input ............................................................................AC100~240V, 50/60Hz
Power output ........................................................................DC16V 3.0A
Audio output .....................................................................................2x12.5W + 25W
Bluetooth effective working range in open area......................................up to 32 feet
Remote effective working range..............................................................up to 16 feet
PACKAGES
1 x Main Unit
1 x Power Adapter
1 x Remote Control
1 x AUX IN Cable
1 x LINE IN Cable
1 x User Manual
For service assistance and product information, please call: 1-800-968-9853.
Curtis International Ltd.
7045 BECKETT DRIVE, UNIT 15, MISSISSAUGA, ON, L5S 2A3
www.curtisint.com
Table of contents
Languages:
Other Monster Speakers System manuals
