Monster ROCKIN ROLLER PRO User manual

1
Rockin Roller PRO
PRO
User Manual
FOR QUESTIONS OR TECHNICAL SUPPORT
Please call:
1.800.976.0677
Please do not return this product to the store.

2
TABLE OF CONTENTS
Warning & FCC Statement
Safety Instructions
Contents
Speaker Component
Getting Started
Charging Battery
Bluetooth Connection
NFC Connection
Wireless Microphone
6.3MM Guitar / Mic Input
AUX Input
FM Radio
USB Charging
Equalizer Presets
Auto Standby
TWS Connection
Troubleshooting
Specifications
Limited Warranty
3
4
5
5
5
6
6
6
7
7
7
8
8
8
8
9
9
10
11

A lightning flash and arrowhead within an equilateral triangle denotes the
presence of insulated “dangerous voltage” within the product’s enclosure.
The voltage may be of sufficient magnitude to constitute a risk of electric
shock to persons who come into contact with it.
An exclamation point within an equilateral triangle denotes the presence of
important operation & maintenance/service instructions.
FCC WARNING STATEMENT
WARNING
ponsible for compliance could void the user’s
authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential instal-
lation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different form that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation ExposureStatement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order
to avoid the possibility of exceeding the FCC radio frequency exposure limits, Human proximity to the antenna
shall not be less than 20cm (8 inches) during normal operation.
PREVENT FIRE AND SHOCK HAZARDS. DO NOT USE EXTENSION CORDS
OR OUTLETS THAT EXPOSE PLUG BLADES. DO NOT EXPOSE CABLES
AND PLUGS TO RAIN OR MOISTURE.
DO NOT ATTEMPT TO PERFORM ANY SERVICING THAT IS NOT INCLUDED
IN THE OPERATING INSTRUCTIONS. DO NOT ATTEMPT TO REPLACE THE
BATTERY, AS INCORRECT INSTALLATION CAN CAUSE FIRE OR
EXPLOSION. FOR SERVICE, CONTACT QUALIFIED SERVICE PERSONNEL.
DO NOT REMOVE COVER OR BACK OF PRODUCT. THERE ARE NO
USER-SERVICEABLE PARTS INSIDE. ATTEMPTING TO MODIFY CONTROLS
OR PERFORMANCE BEYOND MANUFACTURER SPECIFICATIONS MAY
RESULT IN HAZARDOUS EXPOSURE TO RADIATION.
3

4
IMPORTANT SAFETYINSTRUCTIONS
1. Read all instructions and save them for personal reference in the future.
2. Follow all directions for operating the product.
3. Heed all warnings on the product and in the operation instructions.
4. Clean with a dry cloth only. Always unplug the product from any power source before cleaning.
5. Do not use third-party attachments or non-recommended accessories with this product.
6. Do not place product on an unstable surface, such as a cart, stand, tripod, table,
etc. Unstable surfaces may cause the product to fall and cause serious injury to
people and serious damage to the product. Follow all manufacturer instructions for
mounting and accessories.
7. Do not block or cover ventilation slots. Openings in the product cabin ensure reliable operation
and prevent overheating. Avoid placing on beds, sofas, and rugs, or mounting on racks or
bookcases, unless proper ventilation is provided.
8. Do not use plug incorrectly. The product may come with a polarized, alternating-current line
plug (one blade is wider/larger than the other). This is a safety feature: the plug will only go into
outlet receptacles one way. Do not force the plug. If the plug does not fit, contact your electrician
to replace the outlet.
9. Prevent power cord hazards. Route cords to avoid walking on them or pinching them, especially
at plug ends and connection points to the product and power outlets.
10. Unplug power cord when not in use. The product should not be plugged into a power source
when not in use for long periods of time.
11. Do not use this product near bodies of water. The product is not waterproof and cannot be fully
submerged in water. Power cords and electric currents should never be exposed to water.
12. Do not set up near heat sources. Avoid radiators, stoves, heat registers, amplifiers, and other
devices that produce heat. Avoid long exposure to sunlight and high temperatures.
13. Refer all service to qualified personnel. If the product becomes damaged during use or
encounters a malfunction, contact qualified service personnel. Do not attempt to service yourself.

( )
Rating Current:7A
ONLYWORK
WITH WALL POWER
840W(COMBINED)
FCC ID:2AAINBL-1100BT
5
CONTENTS
This box includes the following items:
• Monster Rockin’ Roller PRO speaker
• AC Power Cable
• AUX Cable
• Microphone (Wireless)
• User Manual (incl. Warranty Statement)
• Quick Start Guide
• Microphone Mount
If any items are missing, contact our customer service team at 1.800.976.0677.
SPEAKER COMPONENTS
1. Carry handle
2. Ruggedized housing
3. Telescoping handle
4. Battery life indicator
5. Power On/Off switch
6. AC power input
7. AC pass-through outlet
8. In-line rolling wheels
9. USB port (x2)
10. LED interface
11. LED lights
12. AUX input
13. Source selector
14. Bluetooth pairing
15. Radio presets
16. Volume knob
17. Line Out
18. Mic / Guitar Input
19. Mic / Guitar Gain & Echo Controll
GETTING STARTED
Wall Outlet
• Press Battery Level button on side panel
to check current battery charge
• Turn the Power switch to ON.
• The LED battery indicator will turn on.
• The unit will enter Bluetooth pairing mode
(LED will flash blue).
• If 3.5mm AUX cable is plugged in, unit will
automatically enter AUX mode.

( )
Rating Current:7A
ONLYWORK
WITH WALL POWER
840W(COMBINED)
FCC ID:2AAINBL-1100BT
Manual Bluetooth pairing
• Place speaker and Bluetooth device within 3
feet of each other.
• Make sure Bluetooth function is enabled on your
device.
• Press and hold Bluetooth button for 2 seconds
to enter pairing mode. BLUE LED will flash.
• Search for Bluetooth connections on
your device. Select “MONSTER RRPRO”
BLUETOOTH CONNECTION
SOURCE
USB
SOURCE
EZ-PLY
MIC
Guitar
GAIN ECHO
USB
BASS
TREBLE
1 2 3
4 5 6
EZ-PLY
AUX
IN
AM
FM
• Speaker will confirm connection with
audible sound.
• Once paired, BLUE LED will stop flashing
and remain steady.
BLUE LED Indicator
(Flashing to Steady)
NFC CONNECTION
• Turn the speaker on to Bluetooth pairing mode by pressing
and holding to enter into Bluetooth pairing mode.
• Activate Bluetooth on your NFC Compatible
mobile device
• Tap your mobile device onto the NFC logo
of the speaker
• Bluetooth Blue LED Indicator turns solid upon pairing
CHARGING BATTERY
• Connect speaker to AC outlet via AC power input
to charge battery.
▪ Full charge in 7 hours while powered OFF.
▪ Full charge in 15 hours while powered ON.
• 3 GREEN LED indicates full battery charge.
• Flashing RED LED indicates that the battery
level is low.
• NOTE: Before first use, charge unit for ~6 hours.
6

7
AUX INPUT
WIRELESS MICROPHONE
• Make sure batteries are properly installed into the microphone.
• Switch microphone button to ON. LED light will flash RED once.
• BLUE LED on the side of the speaker
(next to battery life LED) will light up when connected.
• Turn red-tipped GAIN and ECHO dials to tune wireless microphone.
• Plug in the 6.3 mm audio jack plug in the MIC input for Microphone, GUITAR input for guitar,
the unit will enter into that mode (MIC / GUITAR), make sure the the Microphone, Guitar, or
other device is on.
• You can connect any audio device that has 6.3 mm audio
output jack, and can playback and audio from this
connected device.
• Playback functions (Play, Pause, Next, Previous) can
be controlled from the connected Audio device.
• Plug in the 3.5 mm Stereo Audio wire into the AUX-IN
input, and the unit will enter into AUX mode and t
BT Blue LED indicator will turn off..
• You can connect any audio device that has 3.5mm
audio output jack, and can playback any audio from
this connected device.
6.3 MM GUITAR / MIC INPUT

FM RADIO
8
AUTO STANDBY
When entering standby, the RED LED Power signal will turn on, and all other LED lights will turn off.
• Bluetooth: Standby mode enables when there is no BT connection, when it has been
disconnected for 15 minutes, or if there is a connection failure.
• AUX: Standby mode enables when the speaker is in AUX mode and does not detect
an AUX cable.
• Work: Standby mode enables in work mode by pressing and holding volume knob
for 3 seconds.
“Wake up” from standby mode:
If the main unitisin Standbymode,press and hold the volume knob for 1 second. The main unitwill turn on and
return tothe latest source mode. The Power Red LED Signal will turn off and the LED Screen will display the
latest source once the main unit is in work mode.
SOURCE
USB
Listening to FM radio
• Press the “Source” button to select.
FM source, the radio station frequency will be
displayed on the screen
• Press and hold ( or ) to search a station.
with the strongest reception.
Store your favorite six radio stations manually
• Tune to the desired radio station.
• Press and hold a number key (1-6) to enter programming mode; The corresponding number blinks
on the screen; enter the stations to save on the selected preset.
• Repeat above step 1-2 to store additional stations.
Store a favorite radio station
• Press the “Source” button to select FM source.
• Press the number 1-6 keys to select one of your favorite radio stations to listen.
USB CHARGING
• With the built in USB power back, connect your USB
cable to one of the two USB power ports. You can
connect an iPhone, iPad, or any Android device.
(USB cable not included)
EQUALIZER (EQ) PRESETS
Customize your
listening experience
with 6 EQ settings when
in Bluetooth or AUX mode.
1
2
3
4
5
6
SOURCE
1 2 3
4 5 6

9
• Make sure AC power cord is fully inserted into the unit and the electrical outlet,
• Make sure Power switch is turned to the ON position.
• If battery is flat, plug AC power cord into electrical outlet to charge.
TROUBLESHOOTING
General
No power
• Bluetooth cottnnection may be poor, move Bluetooth device closer to the unit.
Bluetooth Operations
Poor Audio Quality
• Make sure the unit is not paired to another Bluetooth device.
• Make sure the unit’s Bluetooth is switched to ON.
• Make sure the unit is in pairing mode (BLUE LED flashing).
• Turn Power switch to OFF, then back to ON. Press and hold BT button for 2 seconds to
enter pairing mode.
Cannot Pair to Device
• Turn Power switch to OFF, then back to ON to reset the unit.
• Unplug the AC power cord and plug it back in.
No Button/Key Resonce
• Make sure AUX/Bluetooth-connected device volume is turned up.
• Make sure Bluetooth-connected device is playing audio through BT.
No Music Playing
TWS
TWS CONNECTION
• Make sure the speaker is in Bluetooth mode and
connect to a device.
• Press the TWS button to activate the speaker’s
True Wireless Stereo
(RED LED indicator will flash in TWS mode)
• On a second speaker (NOT connected to a
Bluetooth device), press the TWS button.
• When speakers connect, the RED LED indicator will stop flashing and remain on.
• To disconnect a speaker, press the TWS button.

SPECIFICATIONS
Input Source Bluetooth / FM / AUX
Control Buttons Power, Source, Bluetooth, Volume, Previous / Next, LED lighting, 6 FM
preset keys, Battery level LED indicator, TWS, Bass / Treble
Power Input AC IN 120V/60H z/AC IN 220V/50HZ
Auto Standby When the unit is not being used for over 15 minutes it will automatically
enter standby mode (BT and AUX mode only)
Auto Power Off Yes
Speaker Driver Size 80W x 1
Full Range 8” (woofer) + 3” (full range)
Max SPL 99dB
THD + Noise <10%
S/N >75dB
Cabinet Material Plastic
Dimensions (W x H x D) 16.7” x 20.6” 9.05”
Weight (Kg) 21 lbs
Operating Temperature Range 32F° - 104F°
Operating Humidity Range 40~90% RH
Storage Temperature Range -13F° to 158F°
Bluetooth Version 4.2 + EDR
A2DP, AVRCP
Bluetooth Frequency Brand 2.4GHz ~ 2.48GHz
Bluetooth Range 10m (33ft.)
Power On / Off Key Power On: Switch “Power” key to “I”
Power Off: Switch “Power” ket to “O”
Source Key Press source key to change source between “BT”, “AUX IN”. or “FM”
Volume Knob 1. Rotate VOLUME knob to increase / devrease volume.
2. Press and hold the VOLUME knob for 3s and enter standby status.
Bluetooth Paring
1. Press and hold the PAIRING key for 2s to enter pairing mode.
2. Press and hold the PAIRING key for 8s to clear any previous Bluetooth
paring.
Previous / Next Key Auto search radio stations when in FM mode press and hold “Previous /
Next” key in FM source
Preset 1,2,3,4,5,6 1. Short press - play preset station
1. Long press - store current station to preset
Battery Level Press button to activate LED display
3.5mm AUX In x 1
USB Port x 2 (5v Parallel 2.A)
AC In x 1
AC Out Yes x 2 (Passthrough)
6.3 mm Line in x 1 10
General
Key
Connections Bluetooth
Operating Temperature

11
Limited Warranty
Model: Rockin’ Roller PRO
This Monster-branded product, marketed as new, in the original carton tothe original purchaser (“Product”), is warranted by Russell Distribution
Company, LLC against manufacturing defects in materials and workmanship for a limited warranty period of Ninety (90) Days for Labor and One (1)
year for Parts. This Limited Warranty is conditioned upon proper use of Product by you, the Purchaser.
This Limited Warranty does not apply tostore display products and product sold as a ‘marked down” special, in as is condition, ‘close outs”, “liquida-
tion and clearance sales”, “open box”, products missing accessories, or no fault found.
Proof of purchase in the form of aBill of Sale, Receipt or Receipted Invoice is evidence the Product is within the limited warranty period. The Bill of
Sale, Receipt or Receipted Invoice must be presented as a pre-condition to obtaining the limited warranty service.
This limited warranty begins on the original date of purchase and is valid only on Products purchased through authorized dealers and used Inthe
and service procedures. The original dated bill of sale, receipt or receipted invoice must be presented upon request as proof of purchase.
We will repair your product or if repairs cannot be made, we will replace it at no charge with the same or similar product. If the Product is defective as
eriod, we may use new or remanufactured parts to repair the Product. All replaced parts
and products become our property and must be returned to us. Replacement parts and products assume the remaining original limited warranty, or
ninety (90) days, whichever is longer.
Product freight must be prepaid by you, the original Purchaser and shipped in either its original packaging or packaging affording an equal degree of
protection. We will not be responsible for or obligated to replace damaged Products.
If the Product is received damaged, it is your responsibility a
for 30 days and reserve the right, in our sole discretion, to dispose of the damaged Product or ship it back to you at your expense after 30 days.
This limited warranty covers manufacturing defects in materials and workmanship encountered in normal, and except tothe extent otherwise
expressly provided for in this statement noncommercial use of this Product, and shall not apply tothe following, including, but not limited to: Damage
which occurs in shipment; delivery and installation; applications and uses for which this Product was not intended; altered Product or serial numbers;
re, water, lightning or other acts of nature; use of products, equipment, systems,
utilities, services, hardware, supplies, accessories, applications, installations, repairs, external wiring or connectors not supplied or authorized by
adjustments and failure tofollow operating instructions, cleaning, maintenance and environmental instructions that are covered and prescribed in the
instruction book; reception problems and distortion related to noise, echo, interference or other signal transmission and delivery problems; burned-in
images. Uninterrupted or error-free operation of the Product is not warranted.
THERE ARE NO EXPRESS ORIMPLIED WARRANTIES OTHER THAN THOSE LISTED AND DESCRIBED ABOVE, AND NO WARRANTIES
WHETHER EXPRESS ORIMPLIED, INCLUDING, BUT NOT LIMITEDTO, ANY IMPLIED WARRANTIES OF MERCHANTABILITYORFITNESS
FORA PARTICULAR PURPOSE, SHALL APPLYAFTER THE EXPRESS WARRANTY PERIODS STATED ABOVE, AND NO OTHER EXPRESS
WARRANTY ORGUARANTY GIVENBY ANY PERSON, FIRM OR CORPORATIONWITHRESPECT TO THIS PRODUCTSHALL BE BIND-
ING ON US. REPAIROR REPLACEMENT AS PROVIDED UNDER THIS LIMITED WARRANTY IS YOUR EXCLUSIVE REMEDY ASTHE
CONSUMER. WE SHALL NOT BE LIABLE FOR ANY INCIDENTAL, OR CONSEQUENTIAL DAMAGES FORBREACH OF ANY EXPRESS OR
IMPLIED WARRANTY ON THIS PRODUCT; EXCEPT TO THE EXTENT PROHIBITEDBY APPLICABLE LAW, ANY IMPLIED WARRANTY OF
MERCHANTIBILITYORFITNESS FORA PARTICULAR PURPOSE ON THIS PRODUCTIS LIMITEDFOR THE DURATIONOF THIS LIMITED
WARRANTY THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASEROF THIS PROD-
UCT, IS NONTRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential damages, so
which vary from state tostate. Any provision contained herein which is found contrary tostate or local laws shall be deemed null and void and the
remaining provisions shall continue in full force and effect.
To obtain warranty service:
Telephone: [phone]
Ver. 130828-i

12
Monster and the M Monster logo are registered trademarks of Monster, Inc. and its subsidiaries in the U.S.
and other countries, used under license.
The N-Mark is a trademark or registered trademark of NFC Forum, Inc. in the United States
and in other countries.”
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. Other trade
marks and trade names are those of their respective owners.
NWS, NOAA, and the NOAA Radio logo are registered trademarks of the National Weather Service in the
United States and used with kind permission.
Printed in ChinaVersion: 1.0
