Morphy Richards MREBQN4 User manual

INSTRUCTION MANUAL
Models: MREBQN4 & MREBKG5
Read these instructions carefully before
using this appliance for the rst time.
STORE THESE INSTRUCTIONS CAREFULLY
Electric Under Blanket
For product hints and tips plus more join us at
facebook.com/MorphyRichardsAUS instagram.com/morphyrichardsau
www.morphyrichards.com.au
替换控制器外形
单控款

2
Model: MREBQN4 MREBKG5
Size: Queen King
Dimensions: 203 x 152cm 203 x 182cm
Colour: White
Rated Voltage: 220-240V~ 50-60Hz
Rated Power: 2 x 100W
Heat Settings: 6
Safety Auto Off: 8 hours
Overheat Protection: Yes
Cord Length: 2.4m
Detachable Controls: Yes
Machine Washable: Yes
Blanket Material: Non-woven polyester
Skirt Size: 40cm
SPECIFICATIONS
• For greater precision, always refer to the rating label placed on the product.

3
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY
CAUSE INJURY AND/OR DAMAGE AND MAY INVALIDATE YOUR
WARRANTY.
The use of any electrical appliance requires the following common
sense safety rules.
• Before connecting and switching on the blanket, ensure that
the voltage indicated on the rating label corresponds to the
mains voltage in your home.
• Do not plug into a powerboard, double adaptor or the like.
The power plug must be inserted directly into the wall power
socket.
• Read the instructions carefully, in conjunction with the
illustrations, before using for the first time.
• If the cord of this blanket is damaged, unplug and discontinue
use of the product then contact the manufacturer.
• If the supply cord or controller is damaged, it must be
completely replaced by a special cord assembly available from
the manufacturer or its service agent.
• Check that your blanket is not damaged before switching it on.
• Always unfold or unroll before switching on.
• Failure to observe these instructions will result in overheating.
This will activate the overheat safeguard system, thus leaving
the heated throw inoperative.
• Use as an under-blanket only.
• These blankets are not recommended for futons.
IMPORTANT!!
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY
AND RETAINED FOR FUTURE REFERENCE.
Also note the information presented on the appliance

4
• When storing the blanket, allow it to cool down before folding.
Fold neatly but not tightly (or rolled) without sharp bends in
the heating elements and store where no other heavy objects
will be placed upon it.
• The blanket should not be used on an adjustable bed or chair.
However, if the blanket is used on an adjustable bed or chair,
check that the blanket and cord do not become trapped or
rucked (creased or bunched up), for example, in hinges.
• The blanket is not to be used by very young children (0-3
years). Children under the age of three are not to use this
appliance due to their inability to react to overheating.
• The blanket is not to be used by young children over the age
of three unless the controls have been preset by a parent or
guardian, or unless the child has been adequately instructed
on how to operate the controls safely.
• This blanket is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
• This blanket must not be used by persons insensitive to heat
and other very vulnerable persons who are unable to react to
overheating.
• Make sure that the heating area (on any side of the bed) does
not fall over the edge of the mattress, that the attachments
are adequate and suited to the mattress, and that the
instructions are read before using the blanket.
• This blanket is not intended for use by young children or
infirm persons without adequate supervision.
• Electric blankets are intended for human use only. Not for
animals and pets. Do not allow pets or animals to lie or chew
on this product or on the electrical cords etc.
• Prolonged application at the highest heat setting can result in
skin burns.
IMPORTANT SAFETY INSTRUCTIONS

5
• Do not tuck the edges of the blanket in or use when rucked
(creased) or folded.
• Keep the controller away from an open window.
• Keep the controller away from external heat sources. ie. a
heater, fire places etc.
• Do not use pins as these may damage the electric wiring.
• The flexible supply cord and switch must, as far as
practicable, be kept outside of the blanket. DO NOT COVER
THE CONTROLLER.
• Do not switch the power on if the blanket is wet or in a folded
or creased state.
• Switch off at the power outlet and remove the plug from the
mains when the blanket is not in use.
• Bed clothes should not be folded back when the blanket is
switched on.
• Do not leave heavy objects on the heated throw, e.g. folded
blankets, suitcases etc. when the heated throw is switched on
as this will trigger the overheat temperature device and render
the heaed throw PERMANENTLY inoperable. This may also
invalidate the warranty.
• Do not dry clean this blanket. Cleaning liquid may have a
damaging effect on the insulation covering of the heating
element. Follow washing directions located on the blanket
rating label. (Foot end of the blanket) and in this Instruction
Manual.
• Arrange the blanket so that the elements are not under the
pillows and/or bolsters.
• For additional protection, it is strongly recommend that the
use of a residual current device (RCD) with a tripping current
not exceeding 30mA be used on the circuit supplying this
product. If you are unsure if your home has this device, please
contact your nearest Electrical Contractor.
• WARNING: This appliance is NOT to be used with extension
leads and/or power boards.
IMPORTANT SAFETY INSTRUCTIONS

6
• Always treat electrical appliances with the upmost care. Do
not use this product in any other fashion or for any other
purpose other than stated in these instructions.
• If any abnormality or defect in operation is observed,
discontinue its use immediately and consult the distributor
regarding its examination and/or repair.
• The blanket should be examined frequently for signs of wear
or damage, either of the blanket, controller or flexible cord.
If wear is visible or if any abnormality or defect in operation
in the blanket is observed, discontinue use immediately and
consult a qualified and registered person for service.
• It is recommended that your blanket is inspected by a
qualified and registered person after 3 years of use.
• This blanket is for domestic use only. It is not intended for use
in hospitals or the like.
• Only use the controllers supplied with this blanket.
• Persons suffering from bed-wetting should not use this
blanket.
• The blanket must not be used over or under a water bed.
IMPORTANT SAFETY INSTRUCTIONS
DO NOT use when folded or creased
DO NOT pierce with needles
Not to be used by very young children (0-3 years)

7
BEFORE FIRST USE
Turn off the power and remove the plug from the power source
• To fit the controller simply hold the socket on the blanket
with one hand and push the controller plug all the way until it
clicks in. There are grooves to use as a guide.
• To remove the controller, hold the corner of the blanket and
pull the controller plug directly out. Do not pull the controller
cable.
• Do not fold, roll or kink the cable. Allow the cable to hang
freely.
• Ensure the cable is not pulled so tight that it bends hard at the
blanket connector end.
• NOTE: Ensure that the electric blanket is sized to suit your
mattress i.e. queen sized electric blanket must be used on a
queen sized mattress.
• Do not use a single bed blanket on a Double, Queen or King
size mattress.
• The blanket top must not hang over the edges of the
mattress.
• Remove all packaging parts before initial operation.
• When the blanket is used for the first time, it can smell of
plastic, but this disappears after a short time.
• Use the appliance as an under blanket only.
• Note: Your electric blanket must be placed directly onto the
mattress. If using a mattress protector, this goes over the
electric blanket.
CONNECTING THE CONTROLLER

USING THE CONTROLLER
IMPORTANT: Only use the blanket with detachable controller/s
model BLV-C24.
Do not use any other controller for this blanket.
Heat Settings:
• 1-2 = Low heat 35-40°C (suitable for continuous use)
• 3-4 = Medium heat 45-50°C
• 5-6 = High heat 55-60°C (recommended for preheating only)
• Press the Power button to turn the blanket on.
• To increase the required heat setting, simple press the “+”
until you see the desired heat setting on the LED display.
• To decrease the required heat setting, simple press the “-”
until you see the desired heat setting on the LED display.
• Press the Power button on the controller to turn off the
blanket.
• TURN OFF AND UNPLUG THE BLANKET WHEN NOT IN USE.
• Keep the controller away from external heat sources. i.e.
heater, fireplace etc.
When using the heated throw, some people may be susceptible to
a tingling sensation when alone or when touching someone else
using the blanket.
This ‘tingling’ feeling is known as an ‘electric field effect’ and is
occasionally known to happen across all makes and brands of
blankets. It is caused by the current flowing through the element
creating an Electromagnetic Field (EMF). Some people are more
susceptible to feeling this EMF tingling sensation than others. This
is no cause for concern and is in no way an electric shock.
ELECTRICAL FIELD EFFECT

9
Note: Your electric blanket must be placed directly onto the
mattress. If using a mattress protector, this goes over the electric
blanket.
IMPORTANT: Place the blanket onto the mattress with the
controller connection/s at the HEAD END of the bed.
Note: Electric blankets MUST NOT be used on top of the user (as
with a normal blanket), instead they must be firmly secured to the
mattress.
• Fit the side skirts around the edges of the mattress then use the
elastic skirt to ensure that the blanket fits snuggly around the
sides and underneath the mattress.
• Spread the skirt around the mattress edge ensuring even
tension and making sure the blanket is placed evenly over the
mattress then ensure that the blanket is flat and crease free.
FAILURE TO FOLLOW THESE FITTING INSTRUCTIONS MAY
TRIGGER THE OVERHEAT PROTECTION SYSTEM AND RENDER
THE BLANKET PERMANENTLY INOPERATIVE. THIS MAY
INVALIDATE THE WARRANTY.
Note: Care should also be taken if you are using a continental
quilt because heat will build up more quickly than with other bed
coverings. A short period may only be needed to reach maximum
temperature depending on the insulation density of your quilt. This
also applies if using additional bed blankets.
• The electric blanket should not be tucked in at the sides.
• Make your bed in the usual manner.
• After the blanket is secure and fitted correctly, plug the
controller(s) into the wall power socket and turn on.
• NOTE: Do not plug into a powerboard, double adaptor or the
like. The power plug must be inserted directly into the wall
power socket.
IMPORTANT: DO NOT COVER THE CONTROLLERS AT ANY TIME.
• Keep the controller away from external heat sources. i.e.
heaters, fireplaces etc.
ELECTRIC BLANKET PLACEMENT

10
Auto Off
• This controller is fitted with a 8 hour count down auto OFF
timer, which starts to countdown from when your heat setting
has been selected, and will switch off after 8 hours.
• Note: Once a heat setting has been selected and the
controller is powered ON, the countdown timer will not be
affected by adjusting the heat level.
• The timer will only be reset to 8 hours by pressing the Power
button OFF and then turning back ON.
• When the controller has timed out, the element will turn off.
Press the Power button back on to reset.
Preheat
• At normal ambient temperature you should allow at least 15
minutes on heat setting “5-6” to preheat.
• You may get into bed sooner while the bed is still warming up,
however DO NOT leave the blanket on setting “5-6” while you
are in the bed.
• Note: A cold room or bed that has not been used for some
time may require a greater length of time to preheat.
Overheat Protection
• The blanket is fitted with numerous overheat safeguard
systems. This offers protection against overheating or damage
to the elements by disengaging the power to the elements
before overheating hazards occur.
• Should there ever be a problem with the heating element in
the blanket, it will automatically close down the operation and
the heated throw will turn off.
• The controller must not be covered. The controller has built in
protection, so that if the controller overheats, or the heating
element is damaged, it will automatically close down the
operation permanently.
OPERATION

11
• If overheating occurs, the heated throw is permanently
damaged and cannot be used again. A replacement will be
needed.
• NOTE: Keep the controller away from external heat sources.
i.e. heater, fireplace etc.
OPERATION
CLEANING & CARE
• This electric blanket must be washed on the hand wash cycle
only (MAX 40°C). Never use hot water as the blanket may
shrink and will void the warranty.
• Before washing, first disconnect the plug connection and
remove the plug from the heated throw. We recommend that
the heated throw is washed separately. Ensure the controllers
do not get wet at any time.
• Use a mild detergent with dosage according to the
manufacturer’s instructions.
• Please note that excessive washing will wear out the electric
blanket. For this reason, it should only be washed a maximum
of 5 times throughout its entire life.
• Only use the heated throw when it is completely dry.
IMPORTANT: NEVER SWITCH ON THE BLANKET TO DRY IT!

12
Treatment For Localised Soiling
• The area affected should be sponged gently using a natural
wool detergent or mild soap flakes dissolved in lukewarm
water (40°C Max), followed by two consecutive spongings
using clean, soap-free lukewarm water.
• Lightly compress the treated area between two towels to
absorb excess water.
• Do not wring or spin dry the heated throw.
• Refer to the section “Drying” for drying instructions.
• The connections to the blanket must be kept free of moisture.
Hand Washing (Recommended)
• Place the blanket in lukewarm (40°C Max) water (bathtub or
large laundry tub is ideal) mixed with either a natural wool
detergent or with mild soap flakes.
• Soak the blanket for approximately five minutes, and then
gently squeeze the soapy water through.
• Rinse the blanket thoroughly with clean lukewarm water until
no more suds are visible and allow water to drain off.
• Refer to the section “Drying” for drying instructions.
• With normal use it is recommended that you hand wash your
blanket once a year.
• Do not wring or spin dry the blanket.
Machine Washing
• Place the blanket in the washing machine with either a natural
wool detergent or with mild soap flakes.
• Set your machine to the Hand Wash/Delicate/Gentle cycle
(without Spin dry) and set the water temperature to warm
(40°C Max). Do NOT wash with HOT water.
• When the cycle has finished, allow water to drain off. Refer to
the section “Drying” for drying instructions.
CLEANING & CARE

13
• Do not wring the blanket. Do not spin dry.
Drying
• Spread the blanket out on a clean surface (e.g. a large table)
to dry in a shady area.
• Your blanket can also be dried on a clothes line provided the
blanket is not creased or folded.
• Ensure pegs are not used on the element areas of the blanket
if hanging on the line.
Note: The blanket must be thoroughly dried including controller
sockets before being re-fitted to your bed.
• Do not wring the blanket. Do not spin dry.
Storage
• When not in use, store the blanket by allowing it to cool down
before folding. Fold neatly (or rolled) but not tightly without
sharp bends in the heating elements and store where no other
heavy objects will be placed upon it.
• Store in a dry place where it cannot be damaged.
CLEANING & CARE

14
WARRANTY
Please refer to the warranty card in the box for warranty information.
For any troubleshooting advice, please contact the relative Customer
Care Centre below.
Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd
8 Lakeview Drive, 38 Harris Road, East Tamaki,
Scoresby 3179, Victoria Auckland 2013
Australia New Zealand
Ph: 1300 556 816 Ph: 0800 666 2824
MAINTENANCE
If the unit fails to operate efficiently, is broken or other problems
arise, unplug and do not operate.
Ask for advice by calling your local after sales service agent or
the Customer Care Centre on 1300 556 816 (AU) / 0800 666 2824
(NZ).

15
NOTES

Glen Dimplex Australia Pty Ltd
8 Lakeview Drive
Scoresby VIC 3179
Phone: [phone]
Email: [email protected]
Web: www.morphyrichards.com.au
Recycling: Do not dispose of electrical appliances
as unsorted municipal waste. Use separate
collection facilities. Contact your local government
for information regarding the collection systems
available. If electrical appliances are disposed
of in landfills or dumps, hazardous substances
can leak into the ground water, polluting the food
chain and damaging health and wellbeing.
© Glen Dimplex Australia. All rights reserved. Material contained in this publication may not be reproduced in
whole or in part, without prior permission in writing of Glen Dimplex Australia.
MREB_IM_v1
