Morphy Richards IB75400 User manual

Therapeutic heat pad
Please read and keep these instructions
getting the best from your
new heat pad...
Safety
•For your safety, the in-built system in this product will
automatically shut off the power if it reaches a
temperature that is higher than considered comfortable.
It will also shut off automatically if any unsafe situation
should arise.
Temperature controlled
•The heat pad will automatically reduce the temperature
to less than 50˚C after 90 minutes and will switch off
completely after 3 hours.
www.morphyrichards.com
9
0870 060 2616
1800 409089
Switch 9 Rev 1 30/9/04 2:46 PM Page 1

2
Important safety
instructions
The use of any electrical appliance
requires the following of basic common
sense safety rules.
Primarily there is danger of injury or death
and secondly the danger of damage to the
appliance. These are indicated in the text by
the following two conventions:
WARNING: Danger to the person!
IMPORTANT: Damage to the appliance!
In addition we offer the following
essential safety advice.
Care instructions
•Do not leave switched on when not in
use.
•Do not dry clean.
•Examine the appliance frequently,
including the flexible cord, for signs of
wear or damage (eg.abrasions, holes,
tears or blisters). In case of damage or
misuse, please return immediately
following instructions under servicing.
•The cover may be detached for washing,
but do not wash the pad itself. Make sure
the cover is dry before use.
•The welded plastic cover of the pad can
be cleaned with a damp cloth, after the
pad has been disconnected from the
power supply.
•When not in use store flat.
NOTE: This pad should not be used in
direct contact with upholstery containing
acrylic or modacrylic pile fibre fabrics.
Personal safety
•The pad may be safely curved around the
limbs but it SHOULD NOT be used folded
or rucked.
•The pad should not be slept on or used
inside a bed.
•Do not fall asleep when the pad is
switched on.
•Do not use the pad in the bathroom.
•Do not leave the pad in contact with the
skin for excessive periods of time.
•Overlong application at a high setting can
result in skin burns.
•Should the pad feel hot, switch down to
the next lowest heat setting or switch off.
•Never place additional objects such as
hot water bottles or pillows on the heated
area.
•Do not use if wet.
•Do not use if oitment or lotions have been
applied to the affected area.
•Do not use with a helpless person, an
infant or a person insensitive to heat.
•The cord between the control and the
heat pad does get warm in normal
operation. This is quite normal.
All Morphy Richards heat pads have been manufactured to the highest European
standards. This product has been comprehensively tested for all known safety situations, so
you can relax in the knowledge that it will provide warmth, comfort and peace of mind.
IMPORTANT INSTRUCTIONS
PLEASE READ CAREFULLY
AND RETAIN FOR
FUTURE USE
Switch 9 Rev 1 30/9/04 2:46 PM Page 2

3
Product safety
•Avoid pressing sharp creases onto the
pad.
•Do not jerk, or exert pressure on the
flexible mains cord, or use it as a handle.
•Do not switch on to dry the pad or cover
after washing.
•Do not leave unattended.
•Not intended for medical use in
hospitals.
•The pad has a plastic cover to protect
against dampness. This cover should not
be removed.
Electrical requirements
Check that the voltage on the rating
label of your appliance corresponds with
your house electricity supply which must be
A.C. (Alternating Current).
If the socket outlets in your home are not
suitable for the plug supplied with this
appliance, the plug should be removed and
the appropriate one fitted.
WARNING: The plug removed from
the mains lead, if severed, must be
destroyed as a plug with bared flexible
cord is hazardous if engaged into a live
socket outlet.
Should the fuse in the 13 amp plug
require changing, a 3 amp BS1362 fuse
must be fitted.
This appliance does not need to be
earthed. It is a double insulated product.
Before use
Before using this appliance ensure that
the voltage indicated on the product
corresponds with the mains voltage in your
home. If you are in any doubt about your
supply, ask your electrical dealer or local
electricity company.
Safeguard overheat
protection system
Activation
The system will remain dormant
indefinitely as long as the heat pad is
operating in the normal temperature range.
If for any reason the heat pad is operated in
an abnormal situation or condition which
would otherwise have induced a rapid
temperature rise high enough to constitute a
hazard, the OVERHEAT SYSTEM should
intervene by cutting off the supply current
before the temperature reaches the point at
which damage may occur.
It is normal for the lead from the heat
pad to the switch to become warm as this
is part of the heated protection circuit
extended to the switch.
Action in case of activation
In the event of the OVERHEAT SYSTEM
operating, the heat pad will cease to
function and must be returned to the
service department address given in this
leaflet. A charge will be made for this
service.
WARNING: No attempt should be
made to repair the heat pad or have it
repaired locally and the switch
supplied must never be replaced other
than by the manufacturers since the
specialised components are not
generally available.
The fact that this heat pad incorporates
the overheat system does not absolve the
user from observing these instructions.
Switch 9 Rev 1 30/9/04 2:46 PM Page 3

4
Switch control
How to use
1Apply the pad on the area to be treated.
2Select the heat setting as required.
Heat levels 1 and 2
Will provide continuous steady warmth
and can be used for longer periods of time
up to a maximum of 3 hours.
Heat levels 3 and 4
Will provide a higher level of heat and
should be used for a shorter period of time.
To avoid excessive heat exposure the
heat pad will automatically reduce the
temperature to less than 50˚C after 90
minutes and will switch off completely after 3
hours.
WARNING: This safety device
prevents over exposure to excessive
temperatures which can result in skin
damage.
Braille markings
•Braille markings are located on the back
of the switch to help identify the direction
of the heat level in the dark, or if visually
impaired.
•The highest heat level
high level is identified by 3 raised
nodules
mid level by 2 raised nodules
low level by 1 raised nodule.
Features
⁄Illuminated heat setting light
(To identify heat levels in the dark)
¤Heat levels 3 & 4
‹Heat level 1 & 2
›Braille markings
(located on the back of the switch)
fiOff position
¤
›
⁄
‹fi
Switch 9 Rev 1 30/9/04 2:46 PM Page 4

5
Washing instructions
1Remove fleece cover and wash on a
wool programme at 40˚C.
2Re-shape while damp and line dry.
3Ensure cover is completely dry before
using.
WARNING: The pad must never be
washed but can be wiped carefully
with a damp cloth.
Servicing
•The pad should be serviced every 2
years. Pack and send carriage paid to
the Service department (see address
below).
•Astandard service charge (inclusive of
packing and return carriage) is made for
routine inspection where no repair is
found to be necessary.
•If the pad fails to operate, check the
following before retuning:
1Ensure that the plug and socket have not
become disconnected.
2Check that the supply plug is correctly
connected to the flex.
3Check the supply fuse and the 3 amp
plug fuse if applicable.
Service department
Waterside Mill
Langham Street
Rosegrove
Burnley
BB12 6AL
Republic of Ireland c/o
Dimpco Ltd
Airport Road
Cloghran
Co. Dublin
Helpline
Should you need any advice on using
the product, please contact our helpline,
8:30 - 5:00 Mon - Thurs
8:30 - 4:00 Fri
Tel: [phone]
0870 060 2616
1800 409089
Switch 9 Rev 1 30/9/04 2:46 PM Page 5

HP75400M UK Rev 1 0704
Service and aftersales department,
Waterside Mill, Langham street,
Rosegrove, Burnley, BB12 6AL
Helpline (office hours)
UK 0870 060 2616
Republic of Ireland 1800 409089
Morphy Richards products are intended for
household use only
Morphy Richards has a policy of continuous
improvement in product quality and design.
The Company, therefore, reserves the right
to change the specification of its models at
any time.
Your one year guarantee
It is important to retain the retailers
receipt as proof of purchase. Staple your
receipt to this back cover for future
reference.
Please quote the following information if
the product develops a fault. These numbers
can be found on the rating label attached to
the heat pad and on the back of the switch.
Model no. Serial no.
All Morphy Richards products are
individually tested before leaving the factory.
In the unlikely event of any appliance proving
to be faulty within 28 days of purchase it
should be returned to the place of purchase
for it to be replaced.
If the fault develops after 28 days and
within 12 months of original purchase, you
should contact the Helpline number quoting
Model number and Serial number on the
product, or write to Morphy Richards at the
address shown.
You will be asked to return the product (in
secure, adequate packaging) to the address
below along with a copy of proof of
purchase.
Subject to the exclusions set out below
(see Exclusions) the faulty appliance will then
be repaired or replaced and dispatched
usually within 28 working days of receipt.
If for any reason this item is replaced
during the 1 year guarantee period, the
guarantee on the new item will be calculated
from original purchase date. Therefore it is
vital to retain your original till receipt or
invoice to indicate the date of initial
purchase.
To qualify for the 1 year guarantee the
appliance must have been used according to
the manufacturers instructions.
EXCLUSIONS
Morphy Richards shall not be liable to
replace or repair the goods under the terms
of the guarantee where:
1The fault has been caused or is
attributable to accidental use, misuse,
negligent use or used contrary to the
manufacturers recommendations or where
the fault has been caused by power
surges or damage caused in transit.
2The appliance has been used on a voltage
supply other than that stamped on the
products.
3Repairs have been attempted by persons
other than our service staff (or authorised
dealer).
4Where the appliance has been used for
hire purposes or non domestic use.
5Morphy Richards are not liable to carry
out any type of servicing work, under the
guarantee.
This guarantee does not confer any rights
other than those expressly set out above and
does not cover any claims for consequential
loss or damage. This guarantee is offered as
an additional benefit and does not affect your
statutory rights as a consumer.
•This guarantee is valid in the UK and
Ireland only.
Switch 9 Rev 1 30/9/04 2:46 PM Page 6
