Morphy Richards IB73091 User manual

Pets compact upright
Please read and keep these instructions
getting the best from your
new cleaner...
If your cleaner isn’t picking up as well as it should,
please check
• Hepa filter
It is important to clean it everytime you empty the pod, otherwise
the performance of the cleaner will be impaired. The pod filters and
pod are fully washable but must be fully dry before re-fitting (see
page 5).
• Blockages
Check the nozzle, tube and hose for blockages. The panel on the
bottom of the floor nozzle may be removed for access to the floor
nozzle air-path.
• Rotating brush
If the rotating brush is stalled, the brush motor stops automatically.
Switch off and unplug the cleaner before removing any article
trapped in the brush. The brush motor protection will only reset after
the power has been disconnected.
www.morphyrichards.com
73091 Rev 3 15/6/05 9:18 AM Page 1

2
Important safety
instructions
The use of any electrical appliance requires
the following of common sense safety rules.
Primarily there is danger of personal injury
and secondly danger of damage to the
appliance and property. These are indicated in
the text by the following two conventions:
WARNING: Danger of personal injury
IMPORTANT: Damage to the appliance
In addition we offer the following essential
safety advice.
Location
•Do not use or keep this product outside
when it is raining.
•Do not store the appliance near hot ovens
or heating appliances.
Mains lead
•Do not allow the mains lead to become
strained or run this appliance over it.
•If the electrical cable becomes damaged
the complete cable assembly must be
replaced. Do not attempt this task yourself,
contact Morphy Richards using the
helpline number.
Children
•Children do not understand the dangers
associated with operating electrical
appliances. Never allow children to use this
appliance.
Other safety considerations
•Never use the appliance without the filters
installed.
•Never use the appliance to vacuum hot
ashes, broken glass, sharp objects or
liquids.
•Never use in the presence of explosive
liquids or vapours.
•Never pick up inflammable or poisonous
liquids such as petrol, copier toner, or
other volatile substances. Never pick up
acids, asbestos or asbestos dust.
•Always disconnect the appliance from the
mains supply after use or prior to cleaning
or emptying.
•The appliance should never be left running
unsupervised.
•Never modify the cleaner in any way.
•Repairs to electrical appliances are only to
be undertaken by trained personnel.
Unprofessional repairs can be dangerous
for users.
•Use only genuine Morphy Richards spare
parts and accessories
Electrical
requirements
Check that the voltage on the rating plate
of your appliance corresponds with your
house electricity supply which must be A.C.
(Alternating Current).
If the socket outlets in your home are not
suitable for the plug supplied with this
appliance, the plug should be removed and
the appropriate one fitted.
WARNING: The plug removed from the
mains lead, if severed, must be
destroyed as a plug with bared flexible
cord is hazardous if engaged into a live
socket outlet.
Should the fuse in the 13 amp plug require
replacement, a BS1362 13 amp fuse must be
fitted.
Description
Your Pod vacuum cleaner is a versatile
machine that can be used as an upright
cleaner or as a handheld.
73091 Rev 3 15/6/05 9:18 AM Page 2

3
⁄
¤
Ì
Ó
‡
›
‚
fi
·
fl
Features
⁄Telescopic handle release button
¤On/off switch
‹Telescopic tube extension button
›Telescopic handle
fiHandle locking release pin (not shown)
flCarrying handle
‡Pod release button
·Dust collection pod
‚Wheels
„Mesh filter (inside)
‰Dust filter (inside)
ÂBrush storage location
ÊFlexible hose
ÁHose end location
ËHose end
ÈExhaust filter cover
ÍCable storage hanger
ÎCable storage quick release lever
ÏFloor nozzle release button
ÌBody
Accessories you should have:
ÓTelescopic handle tube
ÔMotorised floor head
Plastic extension tube
ÒCrevice tool (stored inside )
ÚBrush attachment

Â
ÒÚ
Í
Î
Á
Ê
‹
A
Ô
‰
È
Ï
„

Ë
B
C
73091 Rev 3 15/6/05 9:18 AM Page 3

4
Assembly
To use as an upright A
1Rotate the cable storage quick release lever
Îand slide the cable from storage.
2Fit the floor nozzle by pressing in the locking
pin and insert the nozzle into the hole at the
base of the body D. Push down fully.
3Locate the telescopic handle into the body
by pushing in the locking pin and lowering
the handle in until the locking pin locates in
the locking hole E.
4Adjust the telescopic handle by sliding the
button ‹down and pulling out or pushing
in the lower half F.
Using
Plug into a mains socket and switch on. G
Using on hardfloors (no brush action)
1On hardfloors where no brush action is
required turn the switch to position I. The
suction motor will operate but not the brush
motor.
Using on carpets (with brush action)
1For use on carpets turn the switch to
position II. This will turn on the suction
motor and allow the brush motor to operate
Note: the brush will only revolve when
the main body is angled into the use
position. When the main body is
upright the brush motor is
automatically switched off.
E
‹
DF
G
73091 Rev 3 15/6/05 9:18 AM Page 4

To use as a handheld B
1Remove the telescopic handle. To remove,
press in the release button ⁄and lift the
handle out.
2Remove the floor nozzle by pressing in the
release button Ï and pulling the floor
nozzle away from the body H.
3Slide the hose end Ëfrom the hose end
location Á. I
4Fit the extension tube to the hose end
Ë.
5Fit the crevice tool Ò to the extension tube.
6If required fit the brush Ú to the end of the
crevice tool
7Press the switch to position I.
Attachments
Uses for the brush attachment include
stairs, upholstery, mattresses, curtains and hard
surfaces like door mouldings and skirting
boards. The crevice tool is particularly useful for
cobwebs and in narrow gaps in the car around
the handbrake and seat.
Dust disposal
Ensure the Pod is switched off and
disconnected from the mains supply.
1Slide the pod release button up and pull the
dust pod away from the cleaner. J
Note: When the floor nozzle is fitted the
cleaner must be tilted slightly backwards to
remove the dust pod.
2Raise up the folded filter handle in the top of
the filter assembly.
3Use the handle to rotate the filter for a few
turns. This agitates the filter loosening the
dust. K
5
J
H
K
I
73091 Rev 3 15/6/05 9:18 AM Page 5

6
4Using the handle, pull the filter assembly
from the top of the dust pod. L
5Empty the dust pod and put safely to one
side.
6Remove outer filter, using lever action as
opposed to straight pull, empty out any
dust. M
7Refit outer filter by pushing gently onto three
lugs.
8Re-fit filter assembly into dust pod. Locate
rear of the filter assembly first.
Note: All parts of the dust pod and dust pod
filter assembly are washable. Use warm water.
Do not use detergent.
IMPORTANT: All parts must be fully dry
before re-fitting.
Replacing dust
container
1Insert the hook at the bottom rear of the
dust pod into the tray on the body. O.
2Push the dust pod towards the cleaner body
until it clicks into place.
Exhaust filter
After approximately 5 emptyings of the dust
container the exhaust filter should be cleaned.
1Unclip the exhaust filter cover Èby lifting
the bottom tab. P
2Remove foam filter.
3Shake the filter vigorously to remove any
build up of dust.
4Refit exhaust filter cover by inserting top two
pegs then clip in the bottom tab.
Depending on usage, the exhaust filter
should be replaced approximately every 6
months.
P
O
M
N
L
73091 Rev 3 15/6/05 9:18 AM Page 6

Cleaning the
machine
Use the brush attachment on the hose and
use the Pod to vacuum itself. To keep the
underside of the cleaning head clean, vacuum it
at regular intervals using the crevice tool.
Or, disconnect the Pod from the mains
supply and remove dust by using a soft damp
cloth and wipe dry. Do not use scourers or
abrasive cleaners.
Floor nozzle access
If a blockage occurs in the floor nozzle air-
path, the panel on the bottom of the floor
nozzle may be removed.
1First disconnect the cleaner from the mains
supply and remove the floor nozzle. Turn the
floor nozzle upside down.
2Using a coin or similar turn the lock screw to
the unlock position.
3Remove the panel and clear the blockage.
Ensure the panel is re-fitted and locked
before re-use.
Brush motor
protection
If the rotating brush is stalled, the brush
motor stops automatically. Switch off and
unplug the cleaner before removing any article
trapped in the brush. The brush motor
protection will only reset after the power has
been disconnected.
Purchasing
replacement filters
The lifetime of the dust filter is dependant
largely upon usage of the cleaner. Should the
dust filter become damaged or if there is a
noticeable drop in performance even after
washing, it should be changed immediately. Use
only Morphy Richards replacement filters which
can be purchased from specialist retailers or by
calling the number on the front page of this
leaflet.
Helpline
If you have any difficulty with your
appliance, do not hesitate to call us. We’re
more likely able to help than the store from
where you bought it.
Please have the following information ready
to enable our staff to deal with your query
quickly:
•Name of the product;
•Model number as shown on the underside
of the appliance;
•Serial number.
7
Q
73091 Rev 3 15/6/05 9:18 AM Page 7

VC73091M UK Rev3 0605
Your two-year
guarantee
•It is important to retain the retailers
receipt as proof of purchase. Staple your
receipt to this back cover for future
reference.
Please quote the following information if the
product develops a fault. These numbers can
be found on the base of the product.
Model no. Serial no.
All Morphy Richards products are
individually tested before leaving the factory. In
the unlikely event of any appliance proving to
be faulty within 28 days of purchase it should
be returned to the place of purchase for it to be
replaced.
If the fault develops after 28 days and within
24 months of original purchase, you should
contact the helpline quoting model number and
serial number. Repair or replacement of the
product is subject to the exclusions set out
below (1-6).
If you suspect a fault, follow the simple
checks detailed below before returning the
appliance or calling the helpline.
•Check the filters for blockages.
•Check the hose and tubes for blockages.
•Check the plug is firmly in the socket and
the supply is switched on.
•Make sure the socket is working by trying
another appliance.
If for any reason this item is replaced during
the two-year guarantee period, the guarantee
on the new item will be calculated from original
purchase date. Therefore it is vital to retain your
original receipt or invoice to indicate the date of
initial purchase.
To qualify for the two-year guarantee the
appliance must have been used according to
the manufacturers instructions.
Morphy Richards shall not be liable to replace
or repair the goods under the terms of the
Guarantee where:
1The fault has been caused or is attributable to
accidental use, mis-use, negligent use or used
contrary to the manufacturers
recommendations or where the fault has been
caused by power surges or damage caused in
transit.
2The appliance has been used on a voltage
supply other than that stamped on the
products.
3Repairs have been attempted by persons other
than our service staff (or authorised dealer).
4Where the appliance has been used for hire
purposes or non-domestic use.
5The guarantee excludes consumables such as
the filters.
6Morphy Richards are not liable to carry out any
type of servicing work, under the guarantee.
This guarantee does not confer any rights
other than those expressly set out above and
does not cover any claims for consequential
loss or damage. This guarantee is offered as an
additional benefit and does not affect your
statutory rights as a consumer.
•This guarantee is valid in the UK and Ireland
only.
The After Sales Division,
Registered address,
Morphy Richards Ltd, Mexborough,
South Yorkshire, England, S64 8AJ
Helpline (office hours)
UK 0870 060 2604
Republic of Ireland 1800 409119
Morphy Richards products are intended
for household use only
Morphy Richards has a policy of
continuous improvement in product
quality and design. The Company,
therefore, reserves the right to change
the specification of its models at any
time.
For additional information on Morphy Richards products www.morphyrichards.com
73091 Rev 3 15/6/05 9:18 AM Page 8
