Morrell SW-UNM-8GE User manual

SW-UNM-8GE
8 Ports Giga Ethernet Switch
User Manual
V
ersion 1.0 | 2017

-1 -
Chapter 1 Product Introduction
Congratulations on your purchase of this 10/100/1000MbpsEthernet Switch. Before you
install and use this product, please read this manual carefully for fully exploiting the
functions of this product.
1.1 Product Overview
TheSwitch is a 8 Ports Giga Ethernet Switch.It prov ides 8 Ports Giga Ethernet
Auto-Negotiation RJ45 ports, all ports support Auto MDI/MDIX function, it with a low-cost,
easy-to-use, high performance, seamless and standard upgrade to improve your old
network to a 1000Mbps network, be the same with small office and home, It will boost your
network performance up to full duplex data transfer. It's LED integration, so that can save
a space, andcan dynamic display on-off of the power and network.
1.2 Features
Complies with IEEE 802.3, IEEE 802.3u, IEEE802.3x, IEEE802.3az, IEEE802.3ab
standards
8 Ports Giga Ethernet Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX
Supports IEEE802.3x flowcontrol for Full-duplex Mode and back-pressure for
Half-duplex Mode
Store and forward mode operates
Supports MAC address auto-learning and auto-aging
LED indicators for monitoring power, link/activity
Supports BPDU Frame EAPOL
Metal case
External power adapter supply
1.3 Package Contents
Check the contents of your package for following parts:
Gigabit Ethernet Switch x 1
User Manual x 1
DC Power Adapter (5V,1A) x 1
If any of these are missing or damaged, please contact your dealer immediately, if
possible, retain the carton including the original packing material, and use them against to
repack the product in case there is a need to return it to us for repair.

- 2 -
Chapter 2 External Component Description
2.1 Front Panel
The front panel of the Switch consists of a series of LED indicators shown as below.
Figure 1 - Front Panel
The LED Indicators will allow you to monitor, diagnose and troubleshoot any potential
problem with the Switch, connection or attached devices. The following chart shows the
LED indicators of the Switch along with explanation of each indicator.
LED COLOR STATUS STATUS DESCRIPTION
PWR Green
On Power On
Off Power Off
LINK/ACT
Amber
10/100M
On A device is connected to the port
Off A device is disconnected to the port
Green
1000M Flashing Sending or receiving data
2.2 Rear Panel
The rear panel of the Switch consists of 8 x 10/100/1000Mbps RJ-45 ports and one DC
power Jack shown as below.
Figure 2 - Rear Panel

-3 -
8 Giga Ethernet RJ-45 ports (1~8):
Designed to connect to the device with a bandwidth of 10Mbps,100Mbps or 1000Mbps.
Each has a corresponding 8 Giga Ethernet LED.
Power Connecto r :
Power is supplied through an external DC power adapter. Check the technical
specification section for information about the DC power input voltage.

-4 -
Chapter 3 Installing and Connecting the Switch
This part describes how to install your Gigabit Ethernet Switch and make connections to it.
Please read the following topics and perform the procedures in the order being presented.
3.1 Desktop Installation
To locate the Switch on a desktop, please followthese steps:
a. Place the Switch on a flat desk.
b. Inspect the Power Adapter carefully and make sure that it is properly connected to
a power source.
c. Ensure adequate ventilation space around the Switch fordissipating heat and air.
Note:
Please avoid any heavy thing placed on the Switch.
To ensure the stable cable connection, please keep the Switch horizontal on the desktop,
with white cover facing up.
3.2 Connecting the Switch
Error! Reference source not found.The Switch can be connected to Error! Reference
source not found.a computer or other devices via a two-pair Category 3, 4, 5 UTP
Straight-Through or Crossover cable. A Category 5, 5e UTP cable must be used for
100Mbps operation. And a Category 5e, 6 cable must used for Giga operation. The
connection can be accomplished from any port on the Switch to the RJ-45
Giga Ethernet ports on a computeror other devices.
After connecting the Switch, you can power on the switch and it will automatically initialize
and its LED indicators will solid light.
Note:
If the LED indicators don’t solid light, please check the power supply and its connection.

-5 -
Chapter 4 Technical Specifications
Standards IEEE802.3 10Base-T, IEEE802.3u 100Base-TX,
IEEE802.3az, IEEE802.3ab
Network Media (Cable)
10BASE-T: UTP category 3,4,5 cable (maximum 100m)
100BASE-Tx: UTP category 5, 5e cable (maximum 100m)
1000BASE-T: UTP category 5e,6 cable (maximum 100m)
Number of Ports 8 Ports Giga Ethernet Auto-Negotiation ports
LED
indicators
Link/Act 10M/100M: Green
1000M: Amber
Power Green
Transfer Method Store-and-Forward
Switching Capacity 16Gbps
MAC capacity 8K
Frame Filtering and
Forward Rate
10Mbps: 14880pps
100Mbps: 148800pps
1000Mbps: 1488000pps
Dimensions (L × W × H) 140*78*28 mm (L x W x H)
Environment Operating Humidity: 10%~90% non-condensing
Storage humidity:5%~90% non-condensing
Power
Supply/Consumption
Input: DC 5V /1A(adapter)
Consumption: 2.75W

- 6 -
