Installation and Operating Instructions
7670
For use in North America
Read this entire manual before you install and use your new room heater. If this room
heater is not properly installed, a house fire may result. To reduce the risk of fire, follow
the installation instructions. Failure to follow instructions may result in property damage,
bodily injury, or even death.
Contact local building officials about restrictions and installation/inspection-requirements
in your area.
Save these instructions

2
We congratulate you on your choice of a Morsø stove. Morsø has
been producing some of the world’s best stoves since 1853. If you
follow this installation- and operating instruction carefully, we can
assure you many years of warmth and pleasure.
Optional Accessories
A wide range of accessories (such as handling gloves, fireside tools, glass cleaner and heatproof
paint) are available for use with your Morsø stove. They help with day-to-day running and
maintenance. Contact your Morsø dealer for more information.
The Morsø 7670 meets the U.S. Environmental Protection Agency’s emission limits for wood
heaters sold on or after July 1, 1990.
The Morsø 7670 have been tested by OMNI-Test Laboratories, Inc. The test standards are
ANSI/UL-1482 for the United States and ULC S627 for Canada.
The stove is listed for burning wood only. Do not burn other fuels.
Under specific test conditions this heater has been shown to deliver heat at rates ranging from
10,875 to 21,267 Btu´s.
Cast iron
Cast iron is a live material. There are no two ovens that are identical. This is partly due to the
tolerances of the casting process, partly because the ovens are a work of craftsmanship.

3
2
CONTENTS:
1.0 Installation of your Morsø stove 4
1.1 Checking loose parts in the stove 4
1.2 The chimney / flue system 5
1.3 Flue Connection 6
1.4 Connection to existing chimney 6
1.5 Positioning the stove 8
2.0 Operation 11
2.1 Before you start firing 11
2.2 Lighting and loading intervals 12
3.0 Maintenance 15
3.1 Exterior maintenance 15
3.2 Internal maintenance 15
3.3 Cleaning the stove and the flue 17
3.4 Leaving the stove for extended periods 19
3.5 Parts diagram 20
3.6 Parts list 22

4
1.0 Installation of your Morsø stove
Installation of woodburning stoves must be safe and legal.
Consult with a structural engineer for the installation.
The stove must be installed on a non-combustible wall.
If your Morsø stove is not installed correctly, it may cause a house fire. To reduce the risk
of fire, the installation instructions must be followed carefully. Contact the local building
officials about restrictions and installation inspection in your area.
Before you start installing your stove, make sure that:
- The stove and chimney connection are placed far enough from combustible materials to meet
all clearance requirements.
- The floor protection must be adequate and must be made correctly according to ´the
requirements.
All neccessary approvals are needed from the local building officials.
The data plate, which is located on the back of the stove, provides information regarding safety
testing information, name of certified testing laboratory, and installation requirements.
Installation requirements vary in different districts, and the local building officials have the final
authorization to approve your installation. You should discuss the installation with them before
beginning. Please ask your dealer for further information.
Do not connect to any air distribution duct or system.
Important: If the installation instructions are not followed carefully, it may cause dange-
rous situations like chimney - and house fires. Follow the instructions carefully and do
not deviate from them as it may cause injuries to people or property.
1.1 Checking loose parts in the stove
After unpacking, check that the fire bricks are firmly in position and have not shifted in transit.
Check also that the air control works freely.
Before starting the initial fire, make sure that the baffles is placed correctly.
Standard Accessories
A Morsø glove and ceramic flue connection gasket are standard accessories that usually can
be found in the ashpan or firebox area.

5
4
1.2 The chimney / flue system
Note that the flue system must be independently secured and must not rely on the stove for
support.
The stove must not be connected to a chimney flue serving any other appliance.
(Several flues may run up a single chimney stack; use one flueway per appliance).
Use a residential type masonry or listed type HT factory-built chimney.
High Temperature (H.T.) Chimney Standard UL-103-1985 (2100º F.) or a code-approved
masonry chimney with flue liner for the USA, and High Temperature (650ºC) Standard
ULC S-629 for Canada.
The internal dimensions of the chimney connector and chimney must not be less than 6 inches
diameter (or equivalent cross section), and should not be significantly larger than this. Too
large a section will tend to allow the flue gases to cool excessively, causing sluggishness or
unpredictability in the stove’s performance.
We recommend the length of the chimney system should be at least 16 feet (not required)
above the stove in normal domestic situations, measured from the flue collar to the top of the
chimney.
Local conditions like for example - roof constructions, large trees nearby and high altitude,
may influence the chimney draft and height. Therefore, contact the local professional chimney
sweep or your Morsø dealer.
Typical Factory-Built or Masonry Chimney Installations

6
1.4 Connection to the existing chimney
A chimney connector is the double-wall or single-wall pipe that connects the stove to the chim-
ney. The chimney itself is the masonry or prefabricated structure that encloses the flue. Chim-
ney connectors are used only to connect the stove to the chimney.
Double-wall connectors must be tested and listed for use with solid-fuel burning appliances.
Single-wall connectors should be made of 24 gauge or heavier gauge steel. Do not use
galvanized connector; it cannot withstand the high-temperatures that smoke and exhaust gases
can reach, and may release toxic fumes under high heat. The connector must be 6 inches (150
mm) in diameter.
If possible, do not pass the chimney connector through a combustible wall or ceiling.
If passage through a combustible wall is unavoidable, refer to the sections on Wall Pass-
Throughs. Do not pass the connector through an attic, a closet or similar concealed
space when installing the chimney connectors.
It is important to keep the flue gases moving smoothly in the right direction. Do not vent into a
large void at this location; rather form one continuous section all the way up. Use mild bends
(e.g. 45º vs. 90º) rather than sharp angles where a change of direction is required. All parts of
the venting must be accessible for cleaning purposes.
In horizontal runs of chimney, maintain a distance of 18 inches from the ceiling. Keep it as
short and direct as possible, with no more than two 90 degree turns. Slope horizontal runs of
connector upward 1/4 inch per foot (20 mm per metre) going from the stove toward the chimney.
The recommended maximum length of a horizontal run is 3 feet (1 metre), and the total length
should be no longer than 8 feet (2.5 metres).
Information on assembling and installing connectors is provided by the manufacturer’s
instructions exactly as you assemble the connector and attach it to the stove and chimney.
Be sure the installed stove and chimney connector are correct distances from near by
combustible materials. See the clearance paragraph page 8.
1.3 Flue Connection
The stove is supplied from the factory with a round blanking plate blocking off the top and rear
flue exit (behind the rear shield plate). A flue collar are placed in the firebox area.
Use a 24 MSG black or blue chimney connector or listed double wall chimney connector. Refer
to local codes and the chimney manufacturer’s instructions for precautions required for passing
a chimney through a combustible wall or ceiling. Remember to secure the chimney connector
with a minimum of three screws to the product and to each adjoining section.
The collar can be fitted to the rear outlet. Simply knock out the round panel on the rear heat
shield plate to reveal the cast iron plate. Untwist the blanking plate and the flue collar and swap
their positions. Re-secure by pushing down and tighten the enclosed screws.
Position the stove and connect to the flue system.
Wear gloves and protective eyewear when drilling, cutting or joining sections of
chimney connector
Where passage through a wall or partition of combustible construction is desired, the installation
shall conform to CAN/CSA-B365.

7
6

8
Distance to walls and lintel
When the stove is positioned near combustible materials, observe all current local and national
building regulations with regards to clearances. Whatever regulations apply to your area, do
not in any case install the stove within 8 inches of combustible materials around the sides or
16 inches above the top of the stove (fireplace installations require greater clearances above
the stove - see below in the clearance chart). These distances may need to be increased if the
materials are sensitive to heat. Note also that wall paper and other decorative materials may
become detached with the effects of heat and care should be taken to ensure that they do not
fall towards the stove in such an event.
1.5 Positioning the stove
The stove must be installed on a non-
combustible wall.
The wall-mounting fixture is provided with four
holes for mounting expansion bolts in the wall.
The bolts must be sized to secure that the wall
and the materials it is made from are capable
of supporting the stove. If in doubt, contact an
expert. The weight of the empty stove is 128
kg (282 lbs.). The wall-mounting fixture may be
used as drilling template.
Mount the wall-mounting fixture on the wall. If
the flue exit is wanted to the rear, build a wall
bushing correctly into the wall (see illustration).
Lift the wood stove in place so that it rests on
the bottom part of the wall-mounting fixture, and
secure it again to the fixture by means of the
screws included.
D
D
Min. 11¾" Min. 300 mm
D-D
Revisions
Rev.
Sign.:
Title:
Drawing no.:
1:5
Væghængt
Morsø 7600
KDU
25.03.08
A3
Assembly
130,21 kg
Date of print: 01-03-2010
C:\UDV\tegninger\7600\7600 Assembly.SLDASM
7600-81 a
-
Itemno.:
This drawing is Morsø Jernstøberi A/S' property and must not be sold, lended or copied without any written authorization from the company.
Material:
Weight:
Model no.
Drawingtype:
Location of file:
Scale:
Format:
Released:
Construction:
Date:
Side 2 of 2

9
8
CLEARANCE REQUIREMENTS ALCOVE INSTALLATION
DOUBLEWALL CONNECTOR
USA CANADA
A.
B.
C.
D.
E.
F.
G.
H.
W.
D.
G.
15’’
1’’
N/A
21’’
7’’
N/A
33,5’’
70.5”
N/A
32’’
33,5’’
381 mm.
25 mm.
N/A
533 mm.
178 mm.
N/A
851 mm.
1791 mm.
N/A
813 mm.
851 mm.
SIDEWALL TO UNIT
BACKWALL TO UNIT
CORNERWALL TO UNIT
SIDEWALL TO CONNECTOR
BACKWALL TO CONNECTOR
CORNERWALL TO CONNECTOR
UNIT TO CEILING
FLOOR TO CEILING
MINIMUM ALCOVE WIDTH
MAXIMUM ALCOVE DEPTH
ALCOVE CEILING ABOVE STOVE TOP
CLEARANCE REQUIREMENTS STANDARD RESIDENTIAL INSTALLATION
INTEGRAL REAR AND BOTTOM SHIELDS
TOP OR REAR VENT
SINGLE OR DOUBLEWALL CONNECTOR
USA CANADA
A.
B.
C.
D.
E.
F.
G.
H.
15’’
1’’
2,5’’
21’’
7’’
8,5’’
47’’
84’’
381 mm.
25 mm.
64 mm.
533 mm.
178 mm.
216 mm.
1194 mm.
2134 mm.
SIDEWALL TO UNIT
BACKWALL TO UNIT
CORNERWALL TO UNIT
SIDEWALL TO CONNECTOR
BACKWALL TO CONNECTOR
CORNERWALL TO CONNECTOR
UNIT TO CEILING
FLOOR TO CEILING
FLOOR PROTECTOR MUST BE NON-COMBUSTIBLE
MATERIAL, IT MUST EXTEND BENEATH HEATER AND TO
THE FRONT/SIDES/REAR AS INDICATED.
LE PROTECTEUR DE PLANCHER DOIT ÈNTRE MATÉRIAL
INCOMBUSTIBLE, IL DOIT S'ÉTENDI EN DESSOUS DE
L'APPAREIL ET AU DEVANT, CÔTE ET À L'AARIÈRE DEL
L'APPAREIL COM INDIQUE.

10
Distance to furniture
The recommended minimum distance from stove to furniture is 30 inches. Note that some
furniture is more easily affected by heat and may need to be moved to a greater distance. This
is your responsibility.
In addition other combustible materials, away from the stove. In general, a distance of 30 inches
must be maintained between the stove and moveable combustible item such as drying clothes,
newspapers, firewood etc.
WARNING:
NEVER DRAW COMBUSTION AIR FROM A WALL, FLOOR OR CEILING CAVITY OR FROM
ANY ENCLOSED SPACE SUCH AS AN ATTIC OR GARAGE.
DO NOT INSTALL IN SLEEPING ROOM.
Note:
Acid Protection
If acid-washing the masonry around the stove, protect the stove surface with an acid-proof
cover
Fresh Air Inlet
Unless there is deemed to be sufficient ambient leakage of air into the room via doorways,
windows and the like, a dedicated fresh air inlet will be needed. This inlet should have 2 square
inches (1250 square mm) of free air space. This is particularly important where the room is
well sealed, or where an extractor hood or ventilation system disturbs the natural air pressure.
Such an inlet should not be on a wall that is usually subject to negative pressure from normal
wind pattern. Avoid placing the inlet directly across the room from the stove, thus causing a
cold air draft.
FLOOR PROTECTION REQUIREMENTS NON-COMBUSTIBLE MATERIALS
BENEATH STOVE
USA CANADA
A.
B.
C.
D.
N/A
6’’
6’’
16’’
200 mm.
200 mm.
200 mm.
450 mm.
EXTENDING DISTANCE, BACK
EXTENDING DISTANCE, RIGHT SIDE
EXTENDING DISTANCE, LEFT SIDE
EXTENDING DISTANCE, FRONT

11
10
2.0 Operation
2.1 Before you start firing
For Use with Solid Wood Fuel Only. Do Not Overfire, If Heater or Chimney Connector Glows
You Are Overfiring. Inspect and Clean Chimney Frequently. Under Certain Conditions of
use creosote buildup may occur rapidly. Because of risk of smoke and flame spillage,
operate only with door fully closed.
Caution:
Hot while in operation. Keep children, clothing and furniture away. Contact may cause
skin burns.
Do not use chemicals or fluids to start the fire.
Do not burn garbage or flammable fluids.
Do not use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter or fluid or
similar liquids to start or freshen up a fire in this heater. Keep all such liquids away from
the heater while it is in use.
Caution: Do not place fuel within the installation clearances for the stove or within the
space required for loading fuel and ash removal.
Starting the First Fire
The initial fire should be small, so that the stove paint can cure and the main plates of
the stove can settle into position. Some fumes will be given off by the paint. Ventilate the
room during this phase.
The setting of the air control, lighting techniques and loading intervals will depend on
chimney draft, the fuel used, the heat required and so on. Some basic techniques are
outlined below.
In principle
Your stove should be with Primary and Secondary air and Pilot air inlets.
Primary Air is controlled using the lever situated over the door. Moving the control lever to right
position will open the air inlet and will allow a supply of preheated air to enter the firebox via the
‘airwash’ system situated inside the stove and above the glass.
Choosing your fuel
Cut the wood to a length of max 12 inches (30 cm) and approx. 3 to 3.5 inches (7-8 cm) in
section. If you can weigh your wood, aim for around 2 lbs. For correct combustion and heat
output, wood fuel should contain no more than 20% moisture; this can easily be checked by
using the Morsø Moisture Meter (part # 62929900)
To naturally season wood fuel, stack and store it under cover in an airy location where fresh air
can move through each piece. Some soft woods may take as little as one good summer to season
whereas harder woods such as oak, maple, and elm may require seasoning up to 18 months.
Avoid overly dry wood that is gray in color as under certain conditions it can cause performance
problems, such as back-puffing and sluggishness. Well seasoned wood will be light to hold and
will show signs of cracking from the center-out in the ends. If your wood spits or sizzles when
burnt, and your stove’s door glass persistently mists up, your wood is not properly seasoned.
Never use drift wood (from the sea), whose salt content may cause corrosion, nor construction
wood that may have been impregnated with chemicals.

12
The secondary air is injected into the flue gases above the fire resulting in a cleaner, more
efficient combustion process. The supply of secondary air and Pilot air is fixed open and is not
adjustable. For extra safety, your stove should be with a removable handle.
2.2 Lighting and loading intervals
When first lighting the stove, a large volume of air is needed. When the stove is cold, you should
leave the door open an inch or two for the first few minutes and open the primary air supply
completely. While the door is open, do not leave the stove unattended.
To form a reasonable bed of ash on the floor of the stove, you should use 2-3 pounds of dry
kindling at the initial lighting. If possible, maintain a 1-1.5 inch (2-3 cm) layer of ash on the floor
of the combustion chamber for added insulation.
1. A layer of embers will form rapidly if the stove is lit with 2 -
4 fuel tablets or 7 - 10 rolled up sheets of newspaper un-
derneath 1-2 kg of dry kindling.
2. Open the air supply as much as possible. This is done using
the handle above the door.
3. After the paper/solid alcohol tablets have caught fire, lea-
ve the fire door ajar about 5 - 10 cm, so that the chimney
draws well.
4. When you can see that the chimney is hot enough to draw
(after 5 - 10 minutes), close the door. If all the necessary
conditions are met, a thick layer of embers will have been
formed in the combustion chamber after another 15 - 20
minutes, and there will be a high temperature in the com-
bustion chamber, which is necessary in order to be able
to continue the combustion.

13
12
5. If the condition in step 4 is met, place max. 2 pieces of
wood with a total weight of 1.5-2 kg and a length of 25-
30 cm over the embers in a single layer, with a distance of
approximately 1 cm.
6. Open the air supply to maximum, and close the door.
The fresh wood will be lit within 2-3 minutes.
If it does not light, open the door slightly to allow in enough
air to ignite the wood.
Close the door again once the wood has caught.
7. Reduce the amount of combustion air to the desired posi-
tion, and the optimal combustion will continue. Make sure
that there is always enough air (oxygen) to maintain clear,
lasting flames when, and after, reducing the amount of
combustion air.
During the official test, the stoking interval was 70-80 mi-
nutes.
8. Once the fire has been reduced to a thick layer of embers,
a new portion of wood can be added by repeating steps 5
& 7.

14
Do not for any reason attempt to increase the firing of your heater by altering the air control
adjustment range outlined in these directions.
Warning: Fireplace stoves must never be left unattended with the door open.
If the door is left partly open, gas and flame may be drawn out of the fireplace stove
opening, creating risks from both fire and smoke. We recommend that you fit a smoke
detector in the room where the stove is installed.
DO NOT OVERFIRE THIS HEATER. Overfiring may cause a house fire, or can result in
permanent damage to the stove. If any part of the stove glows, you are overfiring.
The maximum recommended weight of wood fuel per load is 2.0 kg/h/4.0Ibs (approx 3 split logs).
Under normal firing, the average flue temperature in the stove pipe, measured 20 cm above
the stove, is approx. 300° C (550°F). The maximum flue temperature in the stove pipe must not
exceed 450° C (750°F). If the flue temperature exceeds 450°C (750°F), it is considered as over
firing and may cause premature wear and tear of the stove.
To help gauge the correct running temperature of your stove, we recommend you use the Morsø
Flue Gas Thermometer (part # 62901200). The Flue Gas Thermometer magnetically attaches
onto the stove pipe approx 20 cm (8”) above the stove’s top plate and measures the surface
temperature of the stove pipe. Please see your authorized Morsø Dealer for availability.
Draft conditions
If smoke or fumes come out of your stove when lightning up and reloading, or if the fire simply
will not respond, a poor draft is almost certainly to blame. (In a very few cases, there may be
insufficient fresh air getting into the room - see installation advice above). Take advice from your
stove supplier on how best to upgrade your flue system to improve draft.
Rules of woodburning
If you want less heat, put fewer logs on the stove and reduce the amount of air. It is still important
to maintain a good layer of embers.
Less heat - less wood - less air
Greater heat - more wood - more air
Soot deposits will settle on the glass if the stove is run too slowly or if your wood is
not well seasoned.
We would strongly recommend that you do not leave your stove alit at night. It harms the envi-
ronment, and constitutes very poor use of the wood, as the gases in the wood do not ignite at
the low temperature, but settle as soot (unburned gases) in the chimney and stove instead.

15
14
Replace broken glass immediately.
Do not operate your stove if the glass in the door is damaged.
If you need to replace the glass, it should be replaced with the high temperature ceramic class
supplied by Morsø, contact your Morsø dealer.
Installing the glass
Never install the glass when the stove is in function.
Ceramic glass replacement
Ceramic glass cannot be recycled because it has a higher
melting point that ordinary glass. If ceramic glass is mixed
with ordinary glass, the raw material is spoiled, and the re-
claiming process may be halted. Take care that the ovenproof
glass does not end up among ordinary recycled waste. That
will be a great benefit to the environment.
Note: Should be handed in to a recycling station as ceramic
glass.
Reasons for dirty glass
· Fuel too wet
· Logs too large or not split
· Combustion temperatures too low
3.0 MAINTENANCE
When perfoming maintenance on your stove, always protect yourself, using safety
goggles and gloves.
3.1 Exterior Maintenance
The stove surface is painted with heat-resistant Senotherm paint. It is best kept clean by
vacuuming with a soft brush attachment or by wiping with a lint-free cloth.
Over a period of time, the painted surface may become slightly grey. A can of Morsø touch-up
spray paint should be available from your stove supplier. This can be applied - in accordance
with the instructions - in just a few minutes. When first firing after touching up, the stove will give
off a slight smell as the paint cures. Make sure to ventilate the room well during this phase.
3.2 Internal maintenance
Glass
If the stove is generally run at the correct temperatures, there should be little or no dirt on the
glass. If dirt does settle during lighting, most will burn off as temperatures increase.For heavier
deposits that will not burn off, use morsø glass cleaner, applied when the glass is cold, in
accordance with the instructions. Never use abrasive cleaners on the glass surface.
Revisions
Rev.
Sign.:
Title:
Drawing no.:
1:5
Glasmontering 7600 NA
Glass mounting 7600 NA
Morsø 7600
RSV
01.03.2010
A4
Assembly
128,21 kg
Date of print: 01-03-2010
U:\udv\Tegninger\7600\7600 Assembly.SLDASM
7600-119 a
-
Itemno.:
This drawing is Morsø Jernstøberi A/S' property and must not be sold, lended or copied without any written authorization from the company.
Material:
Weight:
Model no.
Drawingtype:
Location of file:
Scale:
Format:
Released:
Construction:
Date:

16
To reduce the risk of breaking the glass, avoid striking the glass or slamming the door.
2. Unscrew the 4 bolts that secure the glass. (In the event that a bolt sheers off when being
unscrewed, remove the remaining body of the bolt by drilling down its centre with 1/8 inch high
speed steel drill bit. Smaller drill bits may be successful, but do not use a lager bit. Make sure
the bit stays away from the edges of the bolt - this may damage the thread in the cast iron).
3. Remove the old ceramic gaskets and clean up the surface underneath with wire wool or
emery paper to remove loose particles.
4. Place the new gasket material in position around the perimeter of the window area, making sure
to pinch them to the length in such a way that they make a continuous seal. Leave no gaps.
5. Place the new glass in position on the strips and screw home the fresh bolts and fitting by
hand.
6. Finally, give each of the bolts an extra half turn or so. The glass should held tight enough by
that cleaning will not dislodge it. Do not over-tighten the bolts as this may put excessive pressure
on the glass, resulting in cracking - important!
1. When you open the door, you will find two hinge pins, one in each hinge. Remove the two
hinge pins, lift the door off the hinges and place it face down on a sheet of cardboard or other
nonabrasive fabric.
NOTE: The flame-path equipment, the ceramic rope and the paint finish are not covered
by guarantee.
All of these service parts can be bought from your morsø dealer, and we recommend that
damaged parts are replaced as soon as possible to avoid collateral damage.
Should the baffle be distorted by an overfire, the stove will still function, although its efficiency
may be compromised. Replace it as soon as possible.
Reasons for fast internal wear and tear
Persistent heavy firing
Soot and ashes left to accumulate
Internal service parts
The flame-path equipment - consisting of the ashpan, grate, firebricks, Cast iron fire plates, glass,
baffle and flue collar - are subject to the extremes of heat produced by the fire. From time to
time, one or other of these parts may need replacing as a matter of routine maintenance.
Gasket
The gasket around the perimeter of the door may harden over a period of time. It should be
replaced if it becomes difficult to close the doors or if air starts to leak in around the perimeter
of the doors, causing the fire to become a little less controllable. A morsø rope gasket kit is
available from your stove supplier.

17
16
Caution:
Never empty a stove in operation.
Never use your household or shop vacuum cleaner to remove ash from the stove;
always remove and dispose of the ash properly.
Creosote - formation and need for removal
When wood is burned slowly, it produces tar and other organic vapors, which combine with
expelled moisture to form creosote. The creosote vapors condense in the relatively cool chimney
flue of a slow-burning fire. As a result, creosote residue accumulates on the flue lining. When
ignited this creosote makes an extremely hot fire. When burning wood, the chimney and chimney
connector should be inspected at least once every two months during the heating season to
determine if a creosote buildup has occurred. If creosote has accumulated, it should be removed
to reduce the risk of a chimney fire.
by burial in soil or otherwise locally disperded, they should be retained in the closed container
until all cinders have thoroughly cooled.
Return the ash pan to its original position in the stove, and close the door.
Clean the flue/chimney - all the way from the stove to the flue terminal point above the house.
A good routine is to clean the flue after each heating season in any case, and inspect prior
to the season to ensure that bird’s nests or other blockages have not occurred during the off
season.
Ash disposal
Empty the ashpan on a daily basis or as needed. Ash allowed to build up towards the underside
of the grate will trap heat and could cause premature failure of the grate.
Empty the ashpan according to this procedure:
Open the front door, and use a shovel or poker to stir excess ash through the ash slots in the
grate down into the ash pan. Take out the ash pan, making sure to keep it level to avoid spilling
ash.
Dispose the ash in a metal container with a tight fitting lid.
The closed container of ashes should be placed on a noncombustible floor or on the ground,
well away from all combustible materials, pending final disposal. If the ashes are disposed of
3.3 Cleaning the Stove and the Flue
Check for soot above the baffle plate and around the flue outlet every month or so to start with.
If the stove suddenly becomes sluggish, check for a soot fall around the flue collar or in the
flue/chimney.
The chimney and chimney connector should be inspected at least once every two months
during the heating season to determine if a creosote buildup has occurred. If creosote
has accumulated, it should be removed to reduce the risk of a chimney fire.

18
Chimney sweeping
Inspect the system regularly during the heating season as part of a regular maintenance schedule.
To inspect the chimney, let the stove cool completely. Then, using a mirror, sight up through the
flue collar into the chimney flue. If you cannot inspect the flue system in this fashion, the stove
must be disconnected to provide better viewing access.
Clean the chimney using a brush the same size and shape as the flue liner. Run the brush up
and down the liner, causing any deposits to fall to the bottom of the chimney where they can
be removed through the clean-out door.
Clean the chimney connector disconnecting the sections, taking them outside, and removing
any deposits with a stiff wire brush. Reinstall the connector sections after cleaning, being sure
to secure the joints between individual sections with sheet metal screws.
If you cannot inspect or clean the chimney yourself, contact your local Morsø Dealer or a
professional chimney sweep.
If you do experience a chimney fire, act promptly and:
Close the air control.
Get everyone out of the house.
Call the Fire Department.
Annual maintenance
Before the heating season, perform a thorough cleaning, inspection and repair:
Thoroughly clean the chimney and chimney connector.
Inspect the chimney for damage and deterioration. Replace weak sections of prefabricated
chimney. Have a mason make repairs to a masonry chimney.
Inspect the chimney connector and replace any damaged sections.
Check gasketing for wear or compression, and replace if necessary.
Check the glass for cracking; replace if needed.
Check door and handle for tightness. Adjust if needed.
How to clean the inside parts of Morsø 7670
When cleaning the inside parts of the stove in connection with the annual visits from your local
chimney sweep we recommend that you remove the inside parts from the fire chamber. Please
be careful as the vermiculite parts are porous. Cleaning of the stove must be done when the
stove is cold.

19
18
3.4 Leaving the stove for extended periods
Important:
If the stove is to be left unused for any period of time, clean it out thoroughly and leave the air
control slightly open to allow airflow. Make sure that the flue does not allow rainwater to come
anywhere near the stove; install a chimney cap, but do not block off the flue completely.
These measures should ensure there is a slight movement of air through the stove, and that the
body of the stove remains dry, right into the corners.
Any ash left within an unfired stove can attract moisture like blotting paper. If moisture is allowed
to settle within the stove, rust will form. Rust expands as it takes a grip. This can lead to undue
pressure on the stove joints, and this in turn may result in damage to the stove.
NOTE: It is best to thoroughly clean the stove after the heating season has concluded. Adding
a dessicant, such as kitter litter, into the ash pan helps absorb moisture during the summer
months. Be sure to remove this prior to the heating season.
We hope you have many years of carefree warmth in its company. Some initial experimentation
with loading and running techniques will decide your normal routine. If you have any problems
after this short learning phase, please refer to your stove dealer. Should they be unable to help
for any reason, please contact us in writing at the address on the front of this publication.

20
3.5 Parts diagram for model Morsø 7670
24
25
30
29 28 23
27
26
2
6
50
51
12
35 34 36 68
10 33
69
70
44 32
7 54 55
4139 43 53
42 38405
37
18
13
52
15
50
71
73
94
1
21
74 72
20 14
17
56
6766
58
4
19
67
75
100
76
11
3
17
28 26
43
32 37
33
32
17
8
3237
33 32 45
33
66
32
48
46
47 46
29
100
9
61 98 49
49
98
99
*
*
101
102
69
68
43
59
Revisions
Rev.
Sign.:
Title:
Drawing no.:
1:7
Res. tegn. 7600 NA
Parts Diagram 7600 NA
Morsø 7600
RSV
17.11.2008
A2
Assembly
Date of print: 16-12-2010
C:\UDV\tegninger\7600\7600 Assembly.SLDASM
7600-500 j
-
Itemno.:
This drawing is Morsø Jernstøberi A/S' property and must not be sold, lended or copied without any written authorization from the company.
Material:
Weight:
Model no.
Drawingtype:
Location of file:
Scale:
Format:
Released:
Construction:
Date:
7600 Cumbustion Chamber
Side 1 of 2
g Ændret skruer pos. 31 til pos. 100. RSV 01.09.2009
f To skruer ændret til én pos. 67, nederst v. stang til håndtag. RSV 28.05.2009 h Tilføjet pinolskrue pos. 101. RSV 11.02.2010 i Tilføjet forrist pos. 115. RSV 05.05.2010 j Ændret pos. forrist fra 115 til 102. RSV 16.12.2010
