Motion Computing C5 User manual

Familiarize yourself with the following reference materials:
1. Complete the interactive Get Going with Tablet PC tutorial.
(Start > All Programs > Tablet PC > Get Going with Tablet PC)
2. Complete the other useful Tablet PC Tutorials.
(Start > All Programs > Tablet PC > Tablet PC Tutorials)
3. Open and review the Motion Dashboard.
(Start > All Programs > Motion Computing > Motion Dashboard
or see "Using the Tablet PC Buttons" below)
4. Refer to the Motion User Guide if you have any questions.
(Start > All Programs > Motion Computing > Motion User Guide)
Getting started
Using the pen
Using the C5 pen on the screen is similar to using a mouse to make
selections and open les.
The following table explains the similarities between a C5 pen and
a mouse.
Helpful bar code scanner tips
• The bar code button is located on the top right-edge of the C5.
• Hold the C5 by the handle to scan. Ensure the scan beam
covers the entire bar code.
• Press the button once to trigger the scanner. Do not hold the
button down when scanning.
• The C5 beeps when the barcode successfully scans.
• Hold the pen like a regular pen.
• You can rest your hand on the screen.
• Calibrate the digitizer and pen for better pointer alignment
through the Pen & Tablet panel.
• For more information, see the Motion C5 User Guide.
Select Point and click Point and tap the display
Open a le or
application
Double-click Double-tap or double-touch on
the display
Select and drag Click and drag
Display properties
or edit functions
(cut, copy, paste)
Right-click and
hold
Tap or touch and drag on the
display
Using the C5 buttons and LEDs
Programmable A
(to rotate display press
Function and A)
Directional
control
Optimizing battery life
• Use AC power when available. When the C5 is
connected to AC power, the battery will continue to charge
while using the C5.
• In the Display panel of the Motion Dashboard, adjust the
brightness to the dimmest comfortable brightness level.
• In the Motion Dashboard, set the power button to Stand By
or Hibernate to conserve battery power, to quickly power on
and o, or when not using the C5.
• When not in use, turn o wireless adapters in Motion Dashboard.
• For advanced tips about extending the battery life, go to
www.motioncomputing.com/tips.
Motion Computing and Speak Anywhere are registered trademarks and Motion is a trade-
mark of Motion Computing, Inc. in the United States and other countries. All trademarks or
registered trademarks are properties of their respective owners.
Copyright © 2007 Motion Computing, Inc. All rights reserved.
(April 2007) P/N 024-02-XXXX Rev. X00
Helpful tip:
Use the Function button to activate the secondary functions of the
Directional Control, Motion Dashboard, and Rotate buttons. For more
information, see the Motion C5 User Guide on your Tablet PC desktop.
MotionTM C5 Mobile Clinical Assistant
Quick Reference Guide for Windows XP
Function button (right-click function)
Eraser
Pen tip
®
Hold the pen on the display until
the mouse icon appears, and
then remove the pen tip from the
display
1. Press the power button.
2. When prompted, press the Windows Security button.
3. Using the pen and the on-screen keyboard, tap in
your password.
Logging on
After turning on your C5, perform the
following steps:
This Quick Reference Guide provides information for using the
C5 Mobile Clinical Assistant.
NOTE: For additional reference information, see the Quick
Setup included with your C5.
Function Mouse action Pen action
Programmable B
Wi-Fi LED
Battery LED
Bluetooth LED
Helpful pen tips
Windows
Security
button
Power
button
Function Motion Dashboard

Open the Motion
Dashboard by
pressing this
button on the
front of the C5.
You can use the Fingerprint Reader for user authentication, password
replacement, and four-way directional scrolling.
To set up the Fingerprint Reader, see "Using Motion OmniPassTM and
Fingerprint Reader" in the Motion C5 User Guide.
Setting up the Fingerprint Reader
Using the MotionTM Dashboard
to adjust C5 settings
1. For information about conguring speech recognition,see “Using
Speech Recognition” in the Motion C5 User Guide.
2. Complete the Using Speech Recognition tutorial.
(Start > All Programs > Tablet PC > Tablet PC Tutorials > Speech)
Using speech recognition
IMPORTANT: The Motion C5 User Guide,located on your C5 desktop, contains information about the following topics.
Setting wireless devices
Using the ports and card slots
For information about the locations and uses for the ports
and card slots, see "Features" in the Motion C5 User Guide.
Note: The C5 must be powered by AC power to use USB ports.
• To set up and use your Bluetooth wireless devices, see
"Using Bluetooth" in the Motion C5 User Guide.
• To set up the built-in Wi-Fi adapter, see "Using Wi-Fi (802.11
a/b/g)" in the Motion C5 User Guide.
Using the digital camera
Camera button
Adjust brightness
Select the default
display scheme for the
external monitor
Control audio playback
Congure microphones and
Speak Anywhere®
Category
View
Classic View
Click here to change views
Access information
for using the Motion
Dashboard
Set display to O
Click here to change views
Set to Stand By Mode
Congure power button for o, Hibernate,
or Stand By mode
Congure security settings
Calibrate and customize the pen
and buttons
Set 802.11 on or o
Set Bluetooth®on or o
Adjust power settings
Entering text and data
1. To open the Input Panel, tap inside a text eld, and then tap the
oating Input Panel icon. Or, tap the Input Panel icon to the
right of the Start button to open the Input Panel.
2. Select one of the three Input Panel input modes to enter data.
Mode 3: Keyboard input
Tap the on-screen keyboard.
Mode 2: Character input
Enter characters one at a time.
Mode 1: Handwriting input
Enter handwriting (use cursive
or block letters).
Tap
Tap
Tap
• Hold the camera steady when pointing the lens at the
object you want to photograph.
• Press the Camera button once to activate the
viewnder.
• Press the button again to take the picture.
• The C5 will prompt you to enter a name and location to
save the image.
The C5 includes a 2.0 megapixel digital camera. The
camera lens is located on the back of the C5, at the top
near the handle.
The gure below shows the location of the camera button.
