Motionics BlueDial-LT User manual

Bluetooth Digital Indicator Lite
BlueDial-LT User Guide
Important Notes
Description
NOT
Do NOT open the device. Opening causes permanent damage and voids the
warranty.
BlueDial-LT transmitter & digital indicator should be both on before pairing.
BlueDial-LT operates on two separate batteries:
1) Rechargeable built-in Li-Po battery for the Bluetooth transmitter
2) Coin SR44 or LR44 battery for the digital dial
Origin Button – press to zero dial reading; this can also be done in the App
Unit Button – select reading in inch/mm
Dial Battery – insert coin battery SR44 or LR44 for digital dial
Status LED
– Bluetooth transmitter is on
– BlueDial-LT is in charge
– BlueDial-LT is fully charged
Micro USB Port – connect to USB cable to charge BlueDial-LT
1
2
3
4
1 5
5
6
7
!
12
3
6
7
5
4

BlueDial-LT 1X
USB Charging Cable 1X
USB Power Adapter 1X
User Guide 1X
Included in the box
Compatible Software
Quick Start
Plug in USB Bluetooth dongle if using Windows PC.
Run the software, tap Scan/+ button to enter pairing page.
BlueDialLTXXX
to connect.
Connection may take a few seconds, once paired, BlueDial-LT reading shows
in the software.
Motionics, LLC www.motionics.com [email protected]
8500 Shoal Creek Blvd Building 4 Suite 209, Austin, TX, 78757
© 2020 Motionics, LLC. All rights reserved. Made in the U.S.A
Turn on BOTH
Dial indicator Bluetooth transmitter
!
1 5
iOS: MultiGage Reader
Android: MultiGage Reader
Windows: MultiGage Reader (BLE Dongle Required)
iOS app can be directly downloaded from the App Store for FREE.
Android app can be directly downloaded from the Google Play Store for FREE.
Windows software is available at Motionics.com/download.
