Motive DELPHI ATDC Ex 2GD Installation and operating instructions

manual addendum
brake motors
DELPHI ATDC Ex 2GD

Manual Addendum DELPHI ATDC Ex 2GD pag 2/20 REV.03
II 2G Ex eb IIC T4 *(T3) Gb
II 2D Ex tb IIIC T135°C IP65 Db
Tamb=-20 +40 *(+50) °C
II 2G Ex db IIC T4 Gb
II 2D Ex tb IIIC T135°C IP66 Db
Tamb=-20 +55°C
* Option only for IE3 motors
Reference list:
Norm (last issue) Title
Dir. 2014/34/EU Equi ment and Protective systems intended for use in Potentially Ex losive Atmos heres. Safety
requirements
IEC 60034-5:2000/A1:2006
Rotat ng electr cal mach nes – Part 5: Degrees of protect on prov ded by the ntegral des gn of rotat ng electr cal
mach nes (IP code) – Class f cat on Internal methods Tests not related to standards, developed by laboratory or
under cl ent’s spec f cat on
EN IEC 60079-0:2018 Explos ve atmospheres – Part 0: Equ pment – General requ rements
IEC 60079-7:2015+AMD1:2017 Explos ve atmospheres – Part 7: Equ pment protect on by ncreased safety “e”
IEC 60079-31:2014 Explos ve atmospheres – Part 31: Equ pment dust gn t on protect on by enclosure “t”
IEC 60204-1:2005 Safety of mach nery – Electr cal equ pment of mach nes – Part 1: General requ rements
Field of a lication
The person author zed to do the work s respons ble for the zones shar ng. He must follow the norms EN 60079-31,
EN60079-14, EN 60079-17 and EN 60079-19 (whenever the r appl cat on s poss ble) when choos ng the su table
motor. The eventual dust depos ts mustn’t have a th ckness > 5mm.
Conformity declaration
The conform ty declarat on reported n th s addendum, s the document that test f es the product conform ty to the
D rect ve 2014/34/EU.
The val d ty of such cert f cate s related to the respect of the nstruct ons spec f ed n the use and ma ntenance
manual, together w th the follow ng add t onal nstruct ons.
Additional instructions
The persons author zed to do the work n an amb ent exposed to explos on r sk must be nstructed about the r ght
procedure for the use of the motor, respect ng all norms related to safety, nstallat on and use.
Motors must be protected aga nst over-heat ng by su table control means that must be chosen, cons der ng the
work ng cond t ons, accord ng to the norm EN60079-15, EN60079-0 and EN60079-31.
All Mot ve Delph -Ex motors are standard equ pped w th temperature probes (up to s ze 132,
ncluded, 3 PTO 130°C probes; from s ze 160, ncluded, 3 PTC 130°C therm stors), to be
connected to a su table release dev ce as reported n EN 50495 standard.
It is forbidden to o en the terminal box to connect electric wires or make any
intervention in resence of ex losive atmos here. Before any of such o erations,
disconnect the motor from the electric ower su ly and avoid the ossibility of any
accidental switching on of the motor.

Manual Addendum DELPHI ATDC Ex 2GD pag 3/20 REV.03
These ATDC motors with brakes can be used in otential ex losive atmos heres in the zone 21
(II 2 D T135°C) and/or zone 1 (II 2 G T4) only if used as a arking brake.
This addendum is su lied with the "installation and maintenance standards" manual of the electromagnetic
brake on board. The end user is required to read it and check the requirements.
For correct motor vent lat on, t’s recommended to ma nta n a m n mum d stance from walls or obstruct ons equal to
50mm for motors from s ze 56 to 160 and 100mm from s ze 180 to 355.
Motors s ze 56÷160
Motors s ze 180÷355

Manual Addendum DELPHI ATDC Ex 2GD pag 4/20 REV.03
Ground connect on must be done (w th galvan zed screw and spr ng washer suppl ed) ns de the term nal box (f g.1)
and by us ng the screw on the frame (f g.2).
The sect on of the ground w re connected to the motor frame must have a m n mum sect on of 4 mmq.
f
g.1
f
g.2
For correct t ghten ng of the ground ng screws, please refer to the table below.
M4 M5 M6 M8 M10 M12 M16
Nm 2 3,2 5 10 20 35 65
Use with converters
When Delph -Ex motors are used w th converters, n add t on to the general select on cr ter a
(l m t values: rated voltage <830V, peak voltage <2,2kV, voltage grad ents <2,2kV/1µs), cons derat on should be
g ven the follow ng po nts:
• Motors powered by nverter have a voltage (or current) wh ch s not purely s nuso dal.
Th s leads to an ncrease n losses, v brat on, no se, and a d fferent temperature r se.
• Poss b l ty of sp kes s l nked to the value of the converter power supply voltage and the length of the motor power
cable.
To l m t the phenomenon, t’s adv sable to use spec f c f lters connected between the converter and the motor
(mandatory for motor power cables over 50 mt).
All Delph -Ex motors are equ pped as standard w th a re nforc ng Nomex f lm between phases to protect aga nst the
voltage peaks.
• The correct ground ng of the motor and the dr ven mach ne s very mportant to avo d voltage and stray currents n
the bear ngs.
To prevent the current c rculat on n the bear ng f the motor t s not equ pped w th an nsulated bear ng, use a
proper f lter to reduce the h gh frequency harmon c voltage above 50kHz.
• Motors w th power from 110kW and up must be equ pped w th nsulated bear ng and the coupl ng must be
nsulated.

Manual Addendum DELPHI ATDC Ex 2GD pag 5/20 REV.03
• It’s mandatory connect thermal probes to the converter to safeguard the motor from the overheat ng wh ch could be
generate by a m suse.
These probes have two term nals for connect on marked w th a label and located ns de the ma n term nal box.
• For nverter power supply the sw tch ng frequency must be h gher than 4kHz (PWM type), output frequency range
0÷150Hz.
• Atex forced vent lat on assembly s mandatory f the motor s used at frequenc es lower than 50Hz at constant
torque load.
If the motor s used at frequenc es lower than 50Hz at quadrat c torque load, please refer to the follow ng graph for
the max mum percentage of torque load adm tted.
For motor Speed/Torque curves, refer to follow ng l nk: https://www.mot ve. t/en/rapport .php

Manual Addendum DELPHI ATDC Ex 2GD pag 6/20 REV.03
When Delph -ATDC-Ex 2GD brake motors are used w th var able speed dr ves, n add t on to the general select on
standards and requ rements conta ned n th s addendum, the end user must cons der the max mum speed l m ts
appl cable at the nput of the brake, as nd cated n the follow ng tablechart.
Frame IEC Maximum s eed a licable [r m]
63 3600 Duty S1
4320 Duty S3 40%
71 3600 Duty S1
4320 Duty S3 40%
80 3600 Duty S1
4320 Duty S3 40%
90 3600 Duty S1
4320 Duty S3 40%
100 3600 Duty S1
4000 Duty S3 40%
112 3600 Duty S1
4000 Duty S3 40%
132 3600 Duty S1
4000 Duty S3 40%
160 3600 Duty S1
2900 Duty S3 40%
180 2500 Duty S1
2800 Duty S3 40%
200 2500 Duty S1
2800 Duty S3 40%
225 2500 Duty S1
2800 Duty S3 40%
250 1800 Duty S1
2200 Duty S3 40%
280 1800 Duty S1
2200 Duty S3 40%

Manual Addendum DELPHI ATDC Ex 2GD pag 7/20 REV.03
Installation recautions
For the nstallat on of the motor please cons der the follow ng:
• make sure that no damages have occurred dur ng transport.
• remove carefully the components of the plant from the wrapp ng mater al and any other protect ve dev ces.
• make sure that the value of the voltage on the motor plate s the same as the voltage of ma ns.
• surfaces n contact w th the electr c bond ng and the rat ng plate must not be varn shed.
• set the motor on a flat surface.
• make sure that the bear ngs or the flange are well f xed and, n case of d rect coupl ng, the motor s perfectly
al gned.
• rotate the rotor manually n order to ver fy the absence of any dragg ng.
• ver fy the rotat on sense remov ng the coupl ng.
• spl ce (extract) the output components ( .e. coupl ng, belt pulley, etc.) only us ng correct dev ces (shr nk ng-on).
Avo d not allowed tens on on the pulley.
• n the models n wh ch the shaft s w th the end downwards, use the protect ve cover. If the end of the shaft s
upwards, use a cover prevent ng any penetrat on of external parts nto the fan.
• do not h nder the vent lat on. The d scharged a r, together w th the a r com ng from other groups, must not be
mmed ately re-asp rated.
• ver fy the correct ground ng of the motor.
Maintenance warnings: clean the motor only with a wet or antistatic cloth.

Manual Addendum DELPHI ATDC Ex 2GD pag 8/20 REV.03
Electrical and thermal rotections
Protect ons must be chosen based on the spec f c runn ng cond t ons, accord ng to standards EN60079-14 and
EN61241-14.
External rotections:
• Protect on aga nst overcurrent and short-c rcu ts; th s protect on can be made w th the magnetotherm c c rcu t
breaker or w th fuses; these must be cal brated on the motor current.
• Protect on aga nst overload by thermal relay that controls a power l ne contactor upstream the motor.
• If the appl cat on requ res, protect on aga nst excess ve speed of the electr c motor, for example f the mechan cal
load may dr ve the electr c motor tself and thereby create a hazardous s tuat on.
• If spec al cond t ons or synchron sed operat on w th other mach nes or parts of mach nes requ re t, protect on
aga nst power fa lures or d ps by means of a m n mum voltage relay that controls an automat c power kn fe sw tch.
Internal rotections:
The electr cal protect ons on the motor power supply may not be suff c ent to protect aga nst overloads.
Connect ng bu lt- n protect ons on the w nd ngs solves th s problem:
• PTO b metall c probe (normally-closed electromechan cal dev ce that becomes open when the threshold
temperature s reached).
The reset of th s cut-out must be performed manually only, and not automat cally. The user, n compl ance w th the
norms, must use a tr pp ng relay out n compl ance w th IEC 61508 standard (Fa l Safe type).
Mot ve Delph -Ex motors, up to s ze 132 ncluded, are equ pped as standard w th 3 PTO 130°C b metall c probes.
• PTC therm stor (dev ce that suddenly changes pos t vely ts res stance when the threshold temperature s reached).
Mot ve Delph -Ex motors, from s ze 160 ncluded, are equ pped as standard w th 3 PTC 130°C therm stors.

Manual Addendum DELPHI ATDC Ex 2GD pag 9/20 REV.03
Bearings lubrication
Motors w th sh elded self-lubr cat ng bear ngs “ZZ” (as standard up to motor s ze 280 ncluded) do not requ re any
per od c lubr cat on.
Bear ngs l fe ranges from 3 up to 5 years accord ng to the ax al and rad al loads that are charged on the shaft and to
env ronmental cond t ons the motor s used n.
Motors from s ze 180 prov ded w th the bear ngs lubr cat on un t must be lubr cated wh le runn ng accord ng to the
lubr cat ng ntervals and the grease quant ty as reported n table 1.
For not standard roller "NU" bear ngs and angular contact ball bear ngs "7.." , the lubr cat on ntervals t m ng,
reported n table 1, s the half.
Lubr cat on ntervals t m ng s also the half for motors suppl ed by converter, because the grease vetr f cat on caused
by the currents arc between stator and rotor.
For th s reason, nsulated bear ngs (spec al execut on) are recommended on such motors, espec ally when the rated
power s ≥110kW.
Use l th um o polyurea grease w th m neral o l bas s su table for a max mum work ng temperature of at least 190°C.
Table 1
Motor Size
Grease quantity
[g]
Lubrication intervals in o eration hours
2 Poles
4
-
6
-
8 Poles
2 Poles
4 Poles
6
Poles
8 Poles
315
36
45
800
2300
4100
5100
355
45
60
700
2000
4000
4500

Manual Addendum DELPHI ATDC Ex 2GD pag 10/20 REV.03
Maximum radial and axial loads

Manual Addendum DELPHI ATDC Ex 2GD pag 11/20 REV.03
PECULIAR FEATURES OF DELPHI ATDC Ex 2GD MOTORS
User manual + addendum
• L m ted surface temperature
• Low magnes um percentage
• Internal temperature <135°C
checked by 3PTO/3PTC probe
mounted as standard
• Exclus on of dust and water IP65
•
Earth connect on ns de the term nal
box or on the hous ng
• Term nals protected aga nst
corros on, unscrew ng and
rotat on
• Shock absorb ng rubber IP65
•
Cert f ed ant
-
pull ng cable
gland and plug II 2GD
• Fa
n cover IP20 on entry a r s de
and IP10 on ex t
• Conduct ve mater al fan
Manufacturer’s mark
Motor type
Protect on aga nst explos on
YYMM product on date
Ser al number
IP protect on ndex
•
Re nforced t
-
box for h gh coll s on res stance
•
Explos on-proof and flame-retardant
2GD brake equ pped w th PTO probe
Motor eff c ency class
(IE2 – IE3)
Not f ed body number
ATEX cert f cate number

Manual Addendum DELPHI ATDC Ex 2GD pag 12/20 REV.03
DELPHI ATDC Ex 2GD CLASSIFICATION
MOTOR
For GAS G
II 2 G Ex eb IIC T4 Gb
         

CE mark ng

ATEX code for prevent on of explos on

Surface ndustr es

An area where explos ve atmospheres may be present dur ng normal operat ons (Zone 1)

Protect on aga nst gas combust on

Explos on protect on: Internat onal

Increased safety

For nstance, for Hydrogen. Equ pment marked as su table for Group IIC s also su table for IIB and IIA

T4 for max mum surface temperature of 135°C

Extended level of protect on n hazardous zones w th explos ve gas m xtures
For DUST D
II 2 D Ex tb IIIC T135°C Db
         

CE mark ng

ATEX code for prevent on of explos on

Surface ndustr es

An area where explos ve atmospheres may be present, n the form of a flammable cloud of dust n the a r, dur ng
normal operat ons (Zone 21)

Protect on aga nst dust combust on

Explos on protect on: Internat onal

Enclosure protect on

For conduct ve dust. Equ pment marked as su table for Group IIIC s also su table for IIIB and IIIA

Max mum surface temperature of 135°C

Extended level of protect on n flammable dust atmospheres

Manual Addendum DELPHI ATDC Ex 2GD pag 13/20 REV.03
Mark ng appl cable only on DELPHI Ex IE3 motors (w th Tamb=-20 +50 °C)
For GAS G
II 2 G Ex eb IIC T3 Gb
         

CE mark ng

ATEX code for prevent on of explos on

Surface ndustr es

An area where explos ve atmospheres may be present dur ng normal operat ons (Zone 1)

Protect on aga nst gas combust on

Explos on protect on: Internat onal

Increased safety

For nstance, for Hydrogen. Equ pment marked as su table for Group IIC s also su table for IIB and IIA

T3 for max mum surface temperature of 200°C

Extended level of protect on n hazardous zones w th explos ve gas m xtures
For DUST D
II 2 D Ex tb IIIC T135°C Db
         

CE mark ng

ATEX code for prevent on of explos on

Surface ndustr es

An area where explos ve atmospheres may be present, n the form of a flammable cloud of dust n the a r, dur ng
normal operat ons (Zone 21)

Protect on aga nst dust combust on

Explos on protect on: Internat onal

Enclosure protect on

For conduct ve dust. Equ pment marked as su table for Group IIIC s also su table for IIIB and IIIA

Max mum surface temperature of 135°C

Extended level of protect on n flammable dust atmospheres

Manual Addendum DELPHI ATDC Ex 2GD pag 14/20 REV.03
BRAKE
For GAS G
II 2 G Ex db IIC T4 Gb
         

CE mark ng

ATEX code for prevent on of explos on

Surface ndustr es

An area where explos ve atmospheres may be present dur ng normal operat ons (Zone 1)

Protect on aga nst gas combust on

Explos on protect on: Internat onal

Explos on-proof hous ng w th barr er-type connector cable outlet

Equ pment marked for Group IIC

T4 for max mum surface temperature of 135°C

Extended level of protect on n hazardous zones w th explos ve gas m xtures
For DUST D
II 2 D Ex tb IIIC T135
°C
IP66 Db
         

CE mark ng

ATEX code for prevent on of explos on

Surface ndustr es

An area where explos ve atmospheres may be present, n the form of a flammable cloud of dust n the a r, dur ng
normal operat ons (Zone 21)

Protect on aga nst dust combust on

Explos on protect on: Internat onal

Enclosure protect on

For conduct ve dust

Max mum surface temperature of 135°C

Extended level of protect on n flammable dust atmospheres

Manual Addendum DELPHI ATDC Ex 2GD pag 15/20 REV.03

Manual Addendum DELPHI ATDC Ex 2GD pag 16/20 REV.03

Manual Addendum DELPHI ATDC Ex 2GD pag 17/20 REV.03

Manual Addendum DELPHI ATDC Ex 2GD pag 18/20 REV.03

Manual Addendum DELPHI ATDC Ex 2GD pag 19/20 REV.03

Manual Addendum DELPHI ATDC Ex 2GD pag 20/20 REV.03
