Motorline professional MPXR92MSWBE Instruction Manual

V1.0
REV. 02/2022
MPXR92MSWBEMPXR92MWSBE
EN
USER/INSTALLER MANUAL

A B
1B
4A
4A
4B
4A
5
6A
6A
6B
8B
8A
7A
7B
ENEN
PRODUCT DESCRIPTION
WALL MOUNT
TECHNICAL CHARACTERISTICS
BASIC CONTENT
DIMENSIONS AND DIAGRAM OF PRODUCT CONNECTORS
OPERATING SCHEME
. SAFETY INSTRUCTIONS
. THE PRODUCT
. INSTALLATION
01. SAFETY INSTRUCTIONS00. CONTENT
INDEX
ThisproductiscertifiedinaccordancewithEuropeanCommunity
(EC) safety standards.
This product complies with Directive 2011/65/EU of the European
Parliament and of the Council, of 8 June 2011, on the restriction
of the use of certain hazardous substances in electrical and
electronicequipmentandwith DelegatedDirective(EU)2015/863
from Commission.
(Aplicável em países com sistemas de reciclagem).
Esta marcação indica que o produto e acessórios eletrónicos
(ex. carregador, cabo USB, material eletrónico, comandos, etc.)
não devem ser descartados como outros resíduos domésticos,
no final da sua vida útil. Para evitar possíveis danos ao ambiente
ou à saúde humana, decorrentes da eliminação descontrolada
de resíduos, separe estes itens de outros tipos de resíduos e
recicle-os de forma responsável, para promover a reutilização
sustentável dos recursos materiais. Os utilizadores domésticos
devem entrar em contacto com o revendedor onde adquiriram
este produto ou com a Agência do Ambiente Nacional, para
obter detalhes sobre onde e como podem levar esses itens
para reciclagem ambientalmente segura. Os utilizadores
empresariais devem contactar o seu fornecedor e verificar os
termos e condições do contrato de compra. Este produto e os
seus acessórios eletrónicos não devem ser misturados com
outros resíduos comerciais para lixo.
Thismarkingindicatesthattheproductandelectronicaccessories
(eg. charger, USB cable, electronic material, controls, etc.) are
susceptible to electric shock by direct or indirect contact with
electricity. Be cautious when handling the product and observe
all safety procedures in this manual.
ATTENTION:
CABLE DESCRIPTION
DIP SWITCH CONFIGURATION
INSTRUCTIONS FOR CONSUMERS / SPECIALIZED TECHNICIANS
DEVICE TEST
CONNECTION TO MRAC CONTROL BOARD
EXTERNAL POWER CONNECTION
. DIP SWITCH
. TROUBLESHOOTING
. COMPONENT TESTING
. CONNECTION SCHEME

A B
ENEN
GENERAL WARNINGS
•This manual contains very important safety and usage information.
very important. Read all instructions carefully before beginning the
installation/usage procedures and keep this manual in a safe place
that it can be consulted whenever necessary.
•This product is intended for use only as described in this manual. Any
other enforcement or operation that is not mentioned is expressly
prohibited, as it may damage the product and put people at risk
causing serious injuries.
•Thismanualis intendedfirstly for specialized technicians, and does not
invalidate the user’s responsibility to read the “User Norms” section in
order to ensure the correct functioning of the product.
•The installation and repair of this product may be done by qualified
and specialized technicians, to assure every procedure are carried
out in accordance with applicable rules and norms. Nonprofessional
and inexperienced users are expressly prohibited of taking any action,
unless explicitly requested by specialized technicians to do so.
•Installations must be frequently inspected for unbalance and the
wear signals of the cables, springs, hinges, wheels, supports and other
mechanical assembly parts.
•Do not use the product if it is necessary repair or adjustment is
required.
•When performing maintenance, cleaning and replacement of parts,
the product must be disconnected from power supply. Also including
any operation that requires opening the product cover.
•The use, cleaning and maintenance of this product may be carried
out by any persons aged eight years old and over and persons whose
physical,sensorialormentalcapacitiesarelower,orbypersonswithout
any knowledge of the product, provided that these are supervision
and instructions given by persons with experienced in terms of usage
of the product in a safe manner and who understands the risks and
dangers involved.
•Children shouldn’t play with the product or opening devices to avoid
the motorized door or gate from being triggered involuntarily.
01. SAFETY INSTRUCTIONS
WARNINGS FOR TECHNICIANS
•Before beginning the installation procedures, make sure that you have
all the devices and materials necessary to complete the installation
of the product.
•You should note your Protection Index (IP) and operating temperature
to ensure that is suitable for the installation site.
•Provide the manual of the product to the user and let them know how
to handle it in an emergency.
•If the automatism is installed on a gate with a pedestrian door, a door
locking mechanism must be installed while the gate is in motion.
•Do not install the product “upside down” or supported by elements do
not support its weight. If necessary, add brackets at strategic points
to ensure the safety of the automatism.
•Do not install the product in explosive site.
•Safety devices must protect the possible crushing, cutting, transport
and danger areas of the motorized door or gate.
•Verify that the elements to be automated (gates, door, windows,
blinds, etc.) are in perfect function, aligned and level. Also verify if the
necessary mechanical stops are in the appropriate places.
•The centralmust be installed on asafe place of any fluid (rain, moisture,
etc.), dust and pests.
•You must route the various electrical cables through protective tubes,
to protect them against mechanical exertions, essentially on the
power supply cable. Please note that all the cables must enter the
central from the bottom.
•If the automatism is to be installed at a height of more than 2,5m from
the ground or other level of access, the minimum safety and health
requirements for the use of work equipment workers at the work of
Directive 2009/104/CE of European Parliament and of the Council of 16
September 2009.
•Attach the permanent label for the manual release as close as possible
to the release mechanism.
•Disconnect means, such as a switch or circuit breaker on the electrical

A B
ENEN
01. SAFETY INSTRUCTIONS
panel, must be provided on the product’s fixed power supply leads in
accordance with the installation rules.
•If the product to be installed requires power supply of 230Vac or
110Vac, ensure that connection is to an electrical panel with ground
connection.
•The product is only powered by low voltage satefy with central (only
at 24V motors)
WARNINGS FOR USERS
•Keep this manual in a safe place to be consulted whenever necessary.
•If the product has contact with fluids without being prepared, it must
immediately disconnect from the power supply to avoid short circuits,
and consult a specialized technician.
•Ensure that technician has provided you the product manual and
informed you how to handle the product in an emergency.
•If the system requires any repair or modification, unlock the
automatism, turn off the power and do not use it until all safety
conditions have been met.
•In the event of tripping of circuits breakers of fuse failure, locate
the malfunction and solve it before resetting the circuit breaker or
replacing the fuse. If the malfunction is not repairable by consult this
manual, contact a technician.
•Keep the operation area of the motorized gate free while the gate in
in motion, and do not create strength to the gate movement.
•Do not perform any operation on mechanical elements or hinges if
the product is in motion.
RESPONSABILITY
•Supplier disclaims any liability if:
•Product failure or deformation result from improper installation
use or maintenance!
•Safety norms are not followed in the installation, use and
maintenance of the product.
•Instructions in this manual are not followed.
•Damaged is caused by unauthorized modifications
•In these cases, the warranty is voided.
MOTORLINE ELECTROCELOS SA.
Travessa do Sobreiro, nº29
4755-474 Rio Côvo (Santa Eugénia)
Barcelos, Portugal
SYMBOLS LEGEND:
• Important safety
notices
• Useful information
• Programming
information
• Potentiometer
information
• Connectors
information
• Buttons
information

A B
01
02
04
03
06 05
ENEN
. THE PRODUCT . THE PRODUCT
• Power Supply 12V DC 1A
• Current 300mA (max)
• Insulation IP65
• Communication RS485
• Technologies Bluetooth, NFC, Mifare Card
• Card Reading Format Mifare (13.56 MHz)
• Reading Reach 3-5 cm
• ID Setup DIP Switch
• Operating temperature -25°C to 55°C
• Operating Humidity 20% ~ 80%
• Dimension 77x120x22mm (WxHxD)
Backlit reader for external use which is part of the control and management of access to a
given location.
TECHNICAL CHARACTERISTICS
PRODUCT DESCRIPTION
BASIC CONTENT
01 • 01 MPXR92MWBE
02 • 01 Metallic Rear Plate
03 • 02 Screw for Wall fixing
04 • 01 Screw for mounting plate
05 • 01 Hex Key
06 • 01 Cable
OPERATING SCHEME
CLOSED DOOR
VERIFY USER
APP ACTIVATION
MRAC
CONTROL BOARD MOBILE
BLUETOOTH NFC MIFARE CARD
IDENTIFICATION MODE
CREATE USER
STORED
BY SECURITY CODE
DISTANCE CONTACT WITH
READER
REGISTER
ACCESS CODE
DATA BASE
MANAGEMENT
SOFTWARE
VERIFICATION FAILED
Please try again!
OPEN DOOR
SUCCESSFULLY
VERIFIED
Thanks


ON
1 2 3 4 5 6
77mm 22mm
26mm
114mm
120mm
EN
. THE PRODUCT
DIMENSIONS AND DIAGRAM OF PRODUCT CONNECTORS
LED
indicator
14 pin connectors:
• RS485
• energy input
ID configurator
Violation alarm button
(On the back of the
mounting plate)
MIFARE
Card Area
Star-shaped screw hole to
secure the reader to the
back plate
BACK PLATE FRONT
BOTTOM
SIDE BEHIND

A B
1
7
ENEN
01
01
02
02
03
. DIP SWITCH. INSTALAÇÃO
DIP SWITCH CONFIGURATION
• RS OUTPUT AND POWER INPUT
WALL MOUNT
 A (blue)
V (red)
GND (black)
 B (yellow)
Mount the MPXR92MWSBE
terminal on the back plate.
Attach the
MPXR92MWSBE and
the back plate using
a star-shaped screw.
BOTTOM VIEW
Fix the back plate to the wall using the wall
mount screws. (Use proper bushings for this
purpose)
1
2
3
CABLE DESCRIPTION
For the control board to be able to identify the task of each of the readers interconnected in an
access control system, it is necessary that each of these devices has a unique identification ID.
This ID is crucial to identify the task that each device performs and which port/access where
it is installed.
The definition is made through the dip switch board on the back of each reader, according to
the following table:
• If you connect two or more devices with the same ID to a control board, it will create a
communication conflict and none will work properly.
ID Dip switch Door Function
No ID
ON
1 2 3 4 5 6
- -

ON
1 2 3 4 5 6
Door 
Entry

ON
1 2 3 4 5 6
Exit

ON
1 2 3 4 5 6
Door 
Entry

ON
1 2 3 4 5 6
Exit
5
ON
1 2 3 4 5 6
Door 
Entry
6
ON
1 2 3 4 5 6
Exit
7
ON
1 2 3 4 5 6
Door 
Entry
8
ON
1 2 3 4 5 6
Exit

A B
GND GND GND PWR
GND DATA1
CLK1
ERR1BZ1
DATA2
CLK2
PWR
DATA3
CLK3
DATA4
CLK4
485+ TXD1
485- RXD1
TXD3
RXD3 OK2 OK1
ERR2BZ2
ENEN
12Vdc (Red)
12Vdc (Red)
RS485 RXD (Blue)
RS485 TXD
(Yellow)
GND (Black)
GND (Black)
Recommended power supply
• Vdc , at least mA;
• Comply with the IEC/EN - standard;
• To share power with other devices, use a power supply with higher current
ratings.
Nº PIN DESCRIPTION WIRE
1 Vdc Red
 GND Black
FA3
MPXR92MWSBE
MPXR92MWSBE
. CONNECTION SCHEME
CONNECTION TO MRAC CONTROL BOARD
. CONNECTION SCHEME
EXTERNAL POWER CONNECTION
RS485 RXD
(Blue)
RS485 TXD
(Yellow)
MRAC
MRAC
CONTROL
BOARD

A B
ENEN
PROBLEM SOLUTION
The reader's backlight does not turn on. Check if the power supply and RS
connection are connected correctly.
I don't hear the beep when reading the
card. Please contact our technical support department.
. TROUBLESHOOTING. TESTE DE COMPONENTES
INSTRUCTIONS FOR CONSUMERS / SPECIALIZED TECHNICIANSDEVICE TEST
To avoid touch sensor self-detection interference, please do not touch the sensor when
turning on the device's power.
1. When the power is on, the player will flash the green LED and you will hear the beep
sound simultaneously.
2. Place the supplied card near the reader. The reader should beep simultaneously.
