Installation Instructions: Yamaha 10-302
EPCO Products, Inc.
Fort Wayne, IN USA
1-844-MotorM8 (668-6768)
epcomarineproducts.com
R
R
It is necessary to confirm the spacing of the contact points on
the outboard motor are the same as A.
The motor yoke spacing Ais the Center to Center distance between the
motor contact points securing the MotorMate to the motor drive
shaft housing. See Reference Image A below.
The transom mount spacing Bis measured between the outside edges
of the stern brackets. See Reference Image B below.
Confirm Measurements Prior to Installation
The cover around the contact points could be damaged and/or cracked if instructions are not followed.
MotorMate is not responsible for any damage to the MotorMate unit or any part of the motor due to improper installation or use.
RV:3062015
MADE IN THE USA Call 1-844-MotorM8 (668-6768) for assistance with installation
(6.00") (8.25")
Example of the recessed areas containing the
motor contact points where the MotorMate End
Caps secure the motor and where the outboard
motor center to center measurements are made.
Two Brackets (L/R)
Two Washers
Package Contents: 1 2
5
43
Remove nut from bolt Place bracket and than washer over bolt
Secure nut tightly
Reference Images:
(8.25")
Measure between
the outside edges of
the stern brackets.
Yamaha Installation Video:
epcomarineproducts.com/yamaha/
(6.00")
Measure between
center to center
distance between the
contact points.
A B
Clip Locking Pins into holes on the brackets.
Straighten motor. Lower motor very slowly and
stop one inch away to make sure MotorMate End
Caps are aligned with the contact points on the
motor. Continue lowering the motor while aligning
the MotororMate End Caps with the motor contact
points until the motor is securely held in place.
MotorMate Locking Pin

LIMITED WARRANTY
EPCO Products, Inc., warrants the MotorMate
Outboard Motor Locking System to be free from
defects in materials or workmanship for the lifetime
of the MotorMate. This warranty is granted to the
original purchaser of the MotorMate unit. This warranty
does not cover any MotorMate unit that has been
modied in any way or if it is used with a motor for
which it was not originally designed nor specied.
This warranty does not cover damage, loss or failure
which results in whole or in part from improper
installation, misuse, neglect, failure to properly
maintain, or other damage caused by inappropriate
handling or use of, the MotorMate.
This warranty is limited to repair or replacement of
the defective MotorMate in the sole and exclusive
discretion of EPCO Products, Inc. This warranty does
not cover, and no claim shall be made hereunder
for, consequential damages, secondary charges,
incidental damages, labor, installation costs or ex-
penses, or losses or liability to third parties for personal
injury or property damage proximately resulting from de-
fects in the MotorMate. ALL IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE AND ALL OTHER WARRANTIES,
EXPRESSED OR IMPLIED, ARE EXCLUDED AND
DISCLAIMED, EXCEPTING ONLY THE EXPRESSED
WARRANTIES SPECIFICALLY SET FORTH IN THIS
LIMITED WARRANTY.
Breach or failure under the foregoing warranty shall not
be grounds to rescind any agreement under which the
MotorMate has been purchased or to claim set o or other
remedies against EPCO Products, Inc., or any other party
as a result of such breach or defect.
In order to make a claim under this warranty, the owner
of the MotorMate must provide written notice of specic
defects to EPCO Products, Inc., promptly, and in no event
more than thirty (30) days, after discovery of such defect.
The owner may return a defective MotorMate only upon
receipt of written return authorization from EPCO Products, Inc.
EPCO Products, Inc.
3736 Vanguard Drive - P.O. Box 9250
Fort Wayne, IN 46899-9250
1-844-MotorM8 (668-6768)
www.epcomarineproducts.com
RV3032015 Pat.
See Reverse For Installation Instructions
Installation Date:
Staple receipt to warranty for documentation purposes.
Purchased From:
