Motorola BLINK1.1-B User manual

USER’S GUIDE
Models: BLINK1.1-B, BLINK1.1-
BLINK1.1-R, BLINK1.1-S
Wi-Fi®Video Baby Monitor Camera
The features described in this user’s guide are subject to
modications without prior notice.
BLINK1.1_USA_V1_2013_08_16.indd 1
BLK
BLINK1.1-W
16/8/13 2:08 PM

Welcome...
to your new Motorola Baby Monitor Camera!
Thank you for purchasing the Motorola Wi-Fi® Video Ba
Monitor Camera. Now you can see and hear your baby sleep in
its room or you can monitor your older children in their playroom.
You can set up the camera only from your iPhone®/iPad®or
™
and view the camera video
™
Please keep your original dated sales receipt for your records.
For warranty service of your Motorola product, you will need to
provide a copy of your dated sales receipt to conrm warranty
status. Registration is not required for warranty coverage.
For product related questions, please call:
US and Canada 1-888-331-3383
This User’s Guide has all the information you need to get the
most out of your product.
Please read the Safety Instructions on page 5 - 6 before you
install the unit.
Inside the Box
• 1 x Wi-Fi® Camera Unit (in either red, silver, white or black)
• 1 x Power Adapter
Overview of your Camera
Important guidelines for installing your Wi-Fi®Camera Unit
• Use of other 2.4GHz products, such as other wireless
networks, Bluetooth® systems or microwave ovens may
cause interference with this product. Keep the Wi-Fi®
Camera Unit away from these types of products, or turn
them off if they appear to be causing interference.
• Always ensure that you have a good Wi-Fi®connection
available.
1. Photo Sensor
(for night mode detection)
2. Infrared LEDs (for night vision)
3. Camera Lens
4. Power/Status LED
5. Microphone
6. Speaker
7. ON/OFF Switch
8. Antenna
9. Temperature Sensor
10. Power Adapter Connector
11. Reset Button
2
3
4
5
6
8
9
10
7
1
11
BLINK1.1_USA_V1_2013_08_16.indd 2-3
by
notebook or devices for Android
iPhone®/iPad .
®
from your PC or Notebook, as well as devices for Android or
16/8/13 2:08 PM

created by: Pro. Q.C. Systems Design Limited
5
1. Safety Instructions
WARNING
This Wi-Fi®Camera Unit is compliant with all relevant
described in the User’s Guide, safe to use. Therefore, always
read the instructions in this User’s Guide carefully before using
the device.
WARNING:
®
Wi-Fi®CAMERA UNIT SET UP & USE:
•Determine a location for the Wi-Fi®
®
Camera Unit that will
provide the best view of your baby in the crib.
•Place the Wi-Fi
®
Ddresser, bureau, or shelf, or wall-mount it using the
keyhole slot in the base.
•Do not place the Wi-Fi camera or cords in the crib or
within reach of the baby (the unit and cords should be
more than 3 feet away).
•Secure the cord to the wall to keep cord away from the
baby’s reach.
Safety Instructions 5
STRANGULATION HAZARD - Keep the unit and
adapter cord more than 3 feet from the crib and
out of baby’s reach.
NEVER place Wi-Fi camera or cords within the crib.
Secure the cord more than 3 feet away from baby’s reach.
Never use extension cords with AC Adapters. Only use
the AC Adapters provided.
ENGLISH
4
Table of Contents
1. Safety Instructions .......................................................................... 5
2. System Requirements..................................................................... 7
3. Getting started - Connecting Devices ........................................... 8
3.1 Setup .......................................................................................... 8
3.2 User Account and Camera Setup:
Working with devices for Android™......................................... 9
4. Camera ........................................................................................... 19
4.1 Connecting the Camera to Power.......................................... 19
4.2 Camera Functions:
Working with PC/Notebook.................................................... 19
4.3 Viewing another Camera:
Working with PC/Notebook.................................................... 21
4.4 Camera Functions:
Working with devices for Android™....................................... 22
4.5 Adding another Camera:
Working with devices for Android™....................................... 25
4.6 Camera Functions:
Working with iPhone®/iPad®................................................... 28
4.7 Adding another Camera:
Working with iPhone®/iPad®................................................... 31
5. Procedure for resetting the Camera ............................................ 31
6. Help................................................................................................. 32
7. General Information ...................................................................... 42
8. Technical Specications............................................................... 49
Table of Contents
BLINK1.1_USA_V1_2013_08_16.indd 4-5
&DPHUD8QLWRQDIODWVXUIDFHVXFKDV
3.4 User Account and Camera Setup:
Working with iPhone®/iPad®................................................... 13
3.3 User Account and Camera Setup:
Working with 3&RUQRWHERRN
™
. ............................................... 9
16/8/13 2:08 PM

created by: Pro. Q.C. Systems Design Limited
ENGLISH
67
2. System Requirements
Web Portal
• Windows® system XP SP3 or above
• Mac OS® version 10.7 or above
• Internet Explorer® version 8.0 or above
• Firefox® version 11.0 or above
• Chrome™ version 18.0 or above
• Safari® version 5.1 or above
• Java™version 7 or above
Android™System
• Version 2.3.6 or above
iPhone®/iPad®iOS
• Version 4.3 or above
System RequirementsSafety Instructions
• Adult assembly is required. Keep small parts away from
children when assembling.
• This product is not a toy. Do not allow children to play with it.
• This Wi-Fi® Camera Unit is not a substitute for responsible
adult supervision.
• Keep this user’s guide for future reference.
• Do not place the Wi-Fi® Camera Unit or cables in the crib or
within reach of the baby (the unit should be at least 3 feet
away).
• Keep the cords out of reach of children.
• Do not cover the Wi-Fi® Camera Unit with a towel or blanket.
• Test the Wi-Fi® Camera Unit and all its functions so that you
are familiar with it prior to use.
• Do not use the Wi-Fi® Camera Unit near water.
• Do not install the Wi-Fi® Camera Unit near a heat source.
• Only use the power adapter provided. Do not use other
power adapters as this may damage the device.
• Never use extension cords with power adapters.
• Do not touch the plug contacts with sharp or metal objects.
BLINK1.1_USA_V1_2013_08_16.indd 6-7 16/8/13 2:08 PM

created by: Pro. Q.C. Systems Design Limited
89Getting started
8Getting started: Working with devices for Android™9
ENGLISH
3. Getting started - Connecting Devices
How does it work?
• The Monitor Everywhere Server keeps track of the cameras.
• When a user wants to access the camera, the server
authenticates the user and permits the user access to the
camera.
3.1 Setup
Connect the Camera to the power adapter and plug it into
a power socket. Wait until the camera LED changes to fast
blinking, which means that camera is in reset/setup state and
camera is ready for ‘Camera Setup’ registration. The Camera
must be within range of the Wi-Fi® router with which you want it
to link.
Status of LED Indication:
- Reset / Setup state: fast blinking
- Unconnect state: slow blinking
- Connect state: always on
View your camera from
any device remotely
Access your
camera locally
BLINK1.1_USA_V1_2013_08_16.indd 8-9
3.2 User Account and Camera Setup:
Working with PC or notebook
•
•
•
In general, there are three alternative ways to create user
account and camera setup:
With PC or
With devices for Android™ or
With iPhone®/iPad®
16/8/13 2:08 PM
•
•
•
•
•
•
•
•
Attention for “Camera Setup mode via micro-USB
port’:
Turn on your PC.
Connect the one end of USB cable (shipped with package)
to the micro-USB port on camera and the other end to the
USB port on PC.
Plug an adaptor to the camera and the other end of adaptor
to the power outlet.
Switch the power switch on camera from OFF to ON.
Wait for 1 minute until camera emits two short beeps and PC
has detected the camera.
Run your web browser.
Type in the following link into address box.
http://setup.monitoreverywhere.com/ConfServer/
ConfApp/application.html
•
•
•
•
‘BLINK1.1’ Setup page is displayed on the web browser
Select your choice whether is ‘Windows Setup’ or ‘Mac
Setup’.
Then, you will be asked to run <Setup Blink> application.
Click <Run>.
Then, [log in] screen pops up.
•Enter username and password if you have account .
OR

created by: Pro. Q.C. Systems Design Limited
10 11
• Tap NEXT STEP.
Getting started: Working with devices for Android™
10 Getting started: Working with devices for Android™11
ENGLISH
BLINK1.1_USA_V1_2013_08_16.indd 10-11
• Select GET STARTED.
• Follow the on-screen instructions and select the camera and
the Wi-Fi® connection that your camera can use. If necessary
enter a password.
• Tap CONNECT TO Wi-Fi.
16/8/13 2:08 PM
3.3 User Account and Camera Setup:
Working with devices for Android™
• Download and install the application “Monitor Everywhere”
from the Google Play™ Store. Note: If you can’t nd the
application, then use your device browser to go to
www.monitoreverywhere.com for advice on how to install.
• Turn on the Wi-Fi®of your device for Android™ and select
your wireless network.
• Switch on the camera (see 5. Procedure for resetting the
Camera).
• Run the “Monitor Everywhere” application. After initialization,
the Baby Monitor Setup wizard appears.
• Select CREATE ACCOUNT.
•
•
•
•
•
•
•
•
•
•
Follow on-line instruction to complete.
Press ‘Sign up’ to create your new account if you don’t
have.
Enter user name, password, confirm password and
email address.
Select your home Wi-Fi router.
Enter your Wi-Fi password.
Hear a long beep and wait until you will see
**IMPORTANT** message.
Then, follow **IMPORTANT** message to unplug USB
cable from your PC and from your camera first.
Press ‘Continue’.
Wait until “Your camera is ready now’ screen pops up.
Press ‘View camera’ to go to
www.monitoreverywhere.com to view your camera or
use your smartphone to log to your account to view your
camera.
®
®

created by: Pro. Q.C. Systems Design Limited
12 13
• Once your camera is installed, you can rename it.
• Tap DONE.
• Tap START MONITOR to show the camera view.
• Tap VIEW to show the camera view and the controls.
Note:
The Camera SSID is printed on the label on the bottom of the
Camera, for example: ID: Camera-1006fa
On your devices for Android™ you will see: Camera-1006fa.
3.4 User Account and Camera Setup:
Working with iPhone®/iPad®
• Install the application “Monitor Everywhere” from the
Getting started: Working with devices for Android™
12 Getting started: Working with iPhone®/iPad®13
ENGLISH
BLINK1.1_USA_V1_2013_08_16.indd 12-13 16/8/13 2:08 PM
• Agree with the terms of use and select I AGREE.
•
Tap NEXT STEP.
• Follow the on screen checklist to ensure that your camera
is power connected and tap NEXT.
• Select the camera from the list.
If you cannot nd the camera ID on the list, please reset the
camera with the following procedure:
1. Switch the ON/OFF switch to ON.
2. Press and hold the RESET button on the underside of
the camera for 5 seconds, until you hear a beep sound.
3. Release the RESET button and wait for the camera to
complete the internal reset procedure.
select SIGN UP.
4. After about 60 seconds you will hear two short beeps
• Wait for up to ve minutes. If the connection process takes
longer, tap CANCEL and try again.
•
Ensure that you have a good Wi-Fi network connection.
and the green LED starts blinking.
• Select CREATE ACCOUNT.
• Enter a user name, a password, an e-mail address and
App StoreSM. Note: If you can’t nd the application, then use

12 13
S5 S6
Getting started: Working with devices for Android™
12 Getting started: Working with iPhone®/iPad®13
ENGLISH
14 15
Getting started: Working with iPhone®/iPad®
14 Getting started: Working with iPhone®/iPad®15
ENGLISH
S3
• Tap Continue (picture S3).
•Switch on the camera (see 5. Procedure for resetting the
Camera) and follow the on-screen instructions.
S4
•Tap Done, by which you agree to the Terms of Use
BLINK1.1_USA_V1_2013_08_16 .indd 14-15
•Enter a user name, a password and an e-mail address.
(picture S4).
16 /8/13 2:08 PM
your device browser to go to www.monitoreverywhere.com
for advice on how to install.
• Run the “Monitor Everywhere” application and follow the
screen number sequence:
S1 S2
•Tap Continue (picture S6).

created by: Pro. Q.C. Systems Design Limited
16 17
S9 S10 S12 S13
•On your iPhone or iPad , under Settings select Wi-Fi.
Select your preferred Wi-Fi connection from the network list
and wait until it is connected (pictures S12, 13).
Getting started: Working with iPhone®/iPad®
16 Getting started: Working with iPhone®/iPad®17
ENGLISH
BLINK1.1_USA_V1_2013_08_16.indd 16-17
• Run the “Monitor Everywhere’ app again.
Note: The Camera SSID is printed on the label on the bottom
of the Camera, for example: ID: Camera-1006fa. On your
iPhone®/iPad®, you will see: Camera-1006fa.
16/8/13 2:08 PM
•Tap (pictures S9,10).
•Enter ‘Wi-Fi’ password for camera (picture S11), then press
Next
S11
S7 S8
•On your iPhone®or iPad®, under Settings select Wi-Fi, then
select the camera from the network list and wait until it is
connected (pictures S7, 8).

created by: Pro. Q.C. Systems Design Limited
18 19
4. Camera
4.1 Connecting the Camera to Power
• Insert the small end of the Power Adapter into the Power
Adapter Connector and plug the Power Adapter into a
suitable power socket.
• Slide the ON/OFF switch to ON, the green Power LED will
light up. (Note: To switch the device off, slide the ON/OFF
switch to OFF.)
4.2 Camera Functions:
Working with PC/Notebook
• Go to URL: https://www.monitoreverywhere.com.
• Enter the User Name and Password and then tap LOGIN, if
you have already created an account.
• Select the camera and tap VIEW to see the camera view and
control buttons.
• Tap on the icons for different functions:
Getting started: Working with iPhone®/iPad®
18 Camera Functions: Working with PC/Notebook 19
ENGLISH
BLINK1.1_USA_V1_2013_08_16.indd 18-19
•Tap Start monitor (picture S15).
•Tap on the Camera icon to start viewing (picture S16).
S16
16/8/13 2:08 PM
S14 S15
•Press the iPhone®or iPad®HOME button and run the
“Monitor Everywhere” application again.
