Motorola MBP481 User manual

UK EN
QUICK START GUIDE
For a full explanation of all features and instructions, please refer to the User’s Guide
(available for download from www.motorolahome.com).
1. Setting up your Digital Video Baby Monitor
MODELS:
MBP481,
MBP481-2,
MBP481-3,
MBP481-4
WARNING:
Strangulation Hazard: Children have STRANGLED in cords. Keep
this cord out of the reach of children (more than 1 metre away).
Never use extension cords with AC Adapters. Only use the AC
Adapters provided.
• Insert the DC plug of the power adapter with the
smaller DC plug into the DC jack in the side of the
Baby Unit.
• Connect the other end of the power adapter to a
suitable mains power socket.
NOTE
Only use the power adapter provided.
A. Connecting Baby Unit to power

UK EN
• A rechargeable battery pack is supplied and
should be fitted, so that the Parent Unit can
be moved without losing the link and picture
from the Baby Unit(s). Charge the Parent
Unit before you use it for the first time or
when the Parent Unit indicates that the
battery is low.
• Slide off the battery compartment cover
• Insert the plug of the battery pack into the
jack inside the battery compartment, and fit
the battery pack into the compartment.
• Replace the battery compartment cover,
and pull out the stand (refer to section C).
B. Installing battery and connecting Parent Unit to power
RED
BLACK
Battery Pack

UK EN
C. Desktop Mount of Parent Unit
• Flip the stand from Parent rear to open
position for desktop mount.
• Insert the DC plug of the power adapter
with the bigger DC plug into the DC jack in
the side of the Parent Unit.
• Connect the other end of the power adapter
to a suitable mains power socket.
NOTE
Only use the power adapter and battery pack provided. The Parent Unit can
work with the power adapter connected but without a battery pack installed.

UK EN
2. Basic operation of the keys
Parent Unit
0Power button Press and hold to switch the Parent Unit ON/OFF.
MENU button Press to open menu options.
OOK button Press to confirm a selection.
UP/
VOL+ button
Press to increase the speaker volume.
While in the menu, press to scroll up.
While viewing a zoomed image, press and hold to move the
image upward.
DOWN/
VOL- button
Press to decrease the speaker volume.
While in the menu, press to scroll down.
While viewing a zoomed image, press and hold to move the
image downward.
<LEFT button While viewing a zoomed image, press and hold to move the
image leftward.
RIGHT/ZOOM
button
While in a menu, press to choose the option on the right side.
While viewing a zoomed image, press to zoom out; or press
and hold to move the image rightward.
Baby Unit
ON/OFF switch Slide the power switch down to switch on the Unit.
Slide the power switch up to switch off the Unit.
PAIR PAIR button Press and hold to pair to the Parent Unit.

UK EN
3. General Information
If your product is not working properly, read this Quick Start Guide or the User’s Guide.
Contact Customer Service:
[phone] (UK only - Calls cost 7p per minute plus your telephone company's access charge.)
[phone] (ROI)
Email: [e-mail]
On the Web: www.motorolahome.com/support
Consumer Products and Accessories Limited Warranty ("Warranty")
Thank you for purchasing this Motorola branded product manufactured under license by Binatone
Electronics International LTD ("BINATONE").
What Does this Warranty Cover?
Subject to the exclusions contained below, BINATONE warrants that this Motorola branded product
("Product") or certified accessory ("Accessory") sold for use with this product that it manufactured to
be free from defects in materials and workmanship under normal consumer usage for the period
outlined below. This Warranty is your exclusive warranty and is not transferable.
Who is covered?
This Warranty extends only to the first consumer purchaser, and is not transferable.
What will BINATONE do?
BINATONE or its authorised distributor at its option and within a commercially reasonable time, will
at no charge repair or replace any Products or Accessories that do not conform to this Warranty. We
may use functionally equivalent reconditioned/ refurbished/ pre-owned or new Products,
Accessories or parts.
What Other Limitations Are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE

UK EN
DURATION OF THIS LIMITED WARRANTY, OTHERWISE THE REPAIR OR REPLACEMENT
PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE
CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN
NO EVENT SHALL MOTOROLA OR BINATONE BE LIABLE, WHETHER IN CONTRACT OR TORT
(INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE
PRODUCT OR ACCESSORY, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF
BUSINESS, LOSS OF INFORMATION OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN
CONNECTION WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS OR ACCESSORIES
TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.
Some jurisdictions do not allow the limitation or exclusion of incidental or consequential damages, or
limitation on the length of an implied warranty, so the above limitations or exclusions may not apply
to you. This Warranty gives you specific legal rights, and you may also have other rights that vary
from one jurisdiction to another.
Exclusions
Normal Wear and Tear. Periodic maintenance, repair and replacement of parts due to normal wear
and tear are excluded from coverage.
Batteries. Only batteries whose fully charged capacity falls below 80% of their rated capacity and
batteries that leak are covered by this Warranty.
Products Covered Length of Coverage
Consumer Products One (1) year from the date of the products original purchase by
the first consumer purchaser of the product.
Consumer Accessories Ninety (90) days from the date of the accessories original
purchase by the first consumer purchaser of the product.
Consumer Products and
Accessories that are Repaired or
Replaced
The balance of the original warranty or for Ninety (90) days
from the date returned to the consumer, whichever is longer.

UK EN
Abuse & Misuse. Defects or damage that result from: (a) improper operation, storage, misuse or
abuse, accident or neglect, such as physical damage (cracks, scratches, etc.) to the surface of the
product resulting from misuse; (b) contact with liquid, water, rain, extreme humidity or heavy
perspiration, sand, dirt or the like, extreme heat, or food; (c) use of the Products or Accessories for
commercial purposes or subjecting the Product or Accessory to abnormal usage or conditions;
or (d) other acts which are not the fault of MOTOROLA or BINATONE, are excluded from coverage.
Use of Non-Motorola branded Products and Accessories. Defects or damage that result from the
use of Non-Motorola branded or certified Products or Accessories or other peripheral equipment are
excluded from coverage.
Unauthorised Service or Modification. Defects or damages resulting from service, testing,
adjustment, installation, maintenance, alteration, or modification in any way by someone other than
MOTOROLA, BINATONE or its authorised service centers, are excluded from coverage.
Altered Products. Products or Accessories with (a) serial numbers or date tags that have been
removed, altered or obliterated; (b) broken seals or that show evidence of tampering;
(c) mismatched board serial numbers; or (d) nonconforming or non-Motorola branded housings,
or parts, are excluded from coverage.
Communication Services. Defects, damages, or the failure of Products or Accessories due to any
communication service or signal you may subscribe to or use with the Products or Accessories is
excluded from coverage.
How to Obtain Warranty Service or Other Information?
To obtain service or information, please call:
[phone] (UK only - Calls cost 7p per minute plus your telephone company's access charge.)
[phone] (ROI)
Email: [e-mail]
On the Web: www.motorolahome.com/support
You will receive instructions on how to ship the Products or Accessories at your expense and risk,
to a BINATONE Authorised Repair Centre. To obtain service, you must include: (a) the Product or
Accessory; (b) the original proof of purchase (receipt) which includes the date, place and seller of

UK EN
Manufactured, distributed or sold by Binatone Electronics
International LTD., official licensee for this product. MOTOROLA
and the Stylized M Logo, are trademarks or registered trademarks of
Motorola Trademark Holdings, LLC. and are used under license. All
other trademarks are the property of their respective owners.
© 2016 Motorola Mobility LLC. All rights reserved.
the Product;(c) if a warranty card was included in your box, a completed warranty card showing the
serial number of the Product; (d) a written description of the problem; and, most importantly;
(e) your address and telephone number.
These terms and conditions constitute the complete warranty agreement between you and
BINATONE regarding the Products or Accessories purchased by you, and supersede any prior
agreement or representations, including representations made in any literature publications or
promotional materials issued by BINATONE or representations made by any agent, employee or
staff of BINATONE, that may have been made in connection with the said purchase.
CE DECLARATION
This product is in compliance with the essential requirements and other relevant provisions of the
R&TTE directive 1999/5/EC.
Download User Guide from website: www.motorolahome.com
Printed in China
EN_UK Version 2.0
