Motorola MBP21 User manual

User’s Guide
Digital Audio Baby Monitor
The features described in this user’s guide are subject to modifications without prior notice.
Models: MBP21, MBP21-2

Welcome...
to your new Motorola Baby monitor!
Thank you for purchasing the Digital Audio Baby Monitor. Now you
hear your baby sleeping in another room.
Please retain your original dated sales receipt for your records. For
warranty service of your Motorola product, you will need to provide
a copy of your dated sales receipt as proof of warranty status.
Registration is not required for warranty coverage.
For product related questions, please call:
[phone] in Europe
Email: [e-mail]
This User Guide provides you with all the information you need to
get the most from your product. Please read the Safety Instructions
on page 6 before you install the units.
Got everything?
• 1 x Parent Unit
• 1 x Baby Unit
• 1 x Battery door for Parent Unit
• 1 x Power adapter for Parent unit
• 1 x Power adapter for Baby unit
In packs with dual parent units, you will find an additional parent unit
with power adapter.

Overview of the Parent Unit
2
1
5
3
6
7
4
8
1. Power/Link indicator
On when the parent unit is
powered on and linked to
the baby unit.
Flashes when the parent
unit is searching the baby
unit.
2. Microphone
3. LEFT button <
Press to decrease the
speaker volume.
4. RIGHT button >
Press to increase the
speaker volume.
5. Power button
0
Press and hold to power on/
o the parent unit.
6. Battery cover
7. Speaker
8. Power jack

Overview of the Baby Unit
Important guidelines for installing your digital baby monitor
• To use your baby unit and parent unit together, you must be able to
establish a radio link between them. Note - The range may be aected
by environmental conditions.
• Any large metal object, like a refrigerator, a mirror, a filing cabinet,
a metallic door or reinforced concrete, between the baby unit and
parent unit may block the radio signal.
• The signal strength may also be reduced by other solid structures,
like walls, or by radio or electrical equipment, such as TVs, computers,
cordless or mobile phones, fluorescent lights or dimmer switches.
• If the signal is poor, try moving the parent unit and/or the baby unit to
a dierent position in the room.
4
1
2
3
5
6
1. Microphone
2. Power button
0
Press and hold to power on/
o the baby unit.
3. Speaker
4. Power indicator
On when the baby unit is
powered on.
5. Power jack
6. Temperature sensor

5
ENGLISH
Table of contents
1. Safety Instructions..........................................................................6
2. Getting Started................................................................................8
2.1 Baby unit power supply........................................................................ 8
2.2 Parent unit power supply..................................................................... 9
2.3 Parent unit battery installation .........................................................10
3. Using Your Digital Audio Baby Monitor.................................... 11
3.1 Power on or o the Baby Unit ...........................................................11
3.2 Power on or o the Parent Unit.........................................................11
3.3 Speaker volume ......................................................................................11
4. Disposal of the Device (environment) .................................... 12
5. Cleaning........................................................................................... 13
6. Troubleshooting ............................................................................ 14
7. General Information...................................................................... 16
8. Technical Specifications .............................................................. 21
Table of contents

6Safety Instructions
1. Safety Instructions
WARNING:
Strangulaton Hazard. Chldren have
STRANGLED n cords. Keep ths cord out of
the reach of chldren (more than 1metre away).
Never use extenson cords wth AC Adapters.
Only use the AC Adapters provded.

7
ENGLISH
Safety Instructions
BABY MONITOR SET UP & USE:
• Determine a location for the BABY UNIT that will allow you to
hear your baby in his/her cot.
• Place the BABY UNIT on a flat surface, such as a dresser, bureau,
or shelf or mount the Unit to a wall securely using the keyhole
slots under the stand.
• NEVER place the Baby Unit or cords within the cot.
WARNING
This Digital Audio Baby Monitor is compliant with all relevant
standards regarding electromagnetic fields and is, when handled as
described in the User Guide, safe to use. Therefore, always read the
instructions in this User Guide carefully before using the device.
• Adult assembly is required. Keep small parts away from children
when assembling.
• This product is not a toy. Do not allow children to play with it.
• This Digital Audio Baby Monitor is not a substitute for responsible
adult supervision.
• Keep this User Guide for future reference.
• Keep the cords out of reach of children.
• Do not cover the Digital Audio Baby Monitor with a towel or
blanket.
• Test this monitor and all its functions so that you are familiar with it
prior to actual use.
• Do not use the Digital Audio Baby Monitor in damp areas or close
to water.
• Do not install the Digital Audio Baby Monitor in extreme cold or
heat, direct sunlight, or close to a heat source.
• Do not touch the plug contacts with sharp or metal objects.
• Connect the power adapters to easily accessible mains power.
CAUTION
There is a risk of explosion if the battery is replaced by an incorrect
type. Dispose of used batteries according to the instructions.

8Getting Started
2. Getting Started
2.1 Baby unit power supply
• Insert the DC plug of the power adapter into the DC jack on the side
of the baby unit, as shown.
• Connect the other end of the power adapter to a suitable mains
power socket.
• The Power indicator will illuminate.
NOTE
Only use the power adapter provided (DC6/400mA).

9
ENGLISH
Getting Started
2.2 Parent unit power supply
MBP21PU
• Insert the DC plug of the power adapter into the DC jack on the
side of the parent unit.
• Connect the other end of the power adapter to a suitable mains
power socket.
• The parent unit will turn on.
NOTE
Only use the power adapter provided (DC6/400mA).

10 Getting Started
2.3 Parent unit battery installation
As an option, the Parent Unit can be powered by alkaline batteries
(Size AAA x 2, NOT included), so that it continues to work if you
disconnect it from the mains power to carry it to another location.
Please follow the steps below to install alkaline batteries.
• Open and lift the battery door up as shown in the figure. (Fig.b1)
(Fig.b1)
(Fig.b2)
(Fig.b3)
• Insert the alkaline batteries follow the direction into battery
compartment.(Fig.b2)
(Fig.b1)
(Fig.b2)
(Fig.b3)
• Insert the catches at the top of the battery door then close the
door as shown in the picture. (Fig.b3)
(Fig.b1)
(Fig.b2)
(Fig.b3)
