User’s Guide
Wi-Fi®Video Baby Monitor
Models: MBP843CONNECT, MBP843CONNECT-2, MBP843CONNECT-3,
MBP843CONNECT-4
The features described in this User’s Guide are subject to modifications without prior notice.

Welcome...
to your new Motorola Wi-Fi
®
Video Baby Monitor!
Thank you for purchasing the Wi-Fi®Video Baby Monitor. Now you can view
and hear your baby sleeping in another room or you can monitor your older
children in their play room.
Please retain your original dated sales receipt for your records. For
warranty service of your Motorola product, you will need to provide a copy
of your dated sales receipt to confirm warranty status. Registration is not
required for warranty coverage.
For product-related questions, please call:
This User's Guide provides you with all the information you need to get the
most from your product.
Before you use the Wi-Fi®Video Baby Monitor, we recommend that you
insert and fully charge the battery in the Parent Unit, so that it continues to
work if you disconnect it from the electrical outlet to carry it to another
location. Please read the Safety Instructions on pages 6 - 8 before you
install the units.
Got everything?
• 1 x Parent Unit
• 1 x Baby Unit (Camera)
• 1 x Rechargeable Ni-MH battery pack for the Parent Unit
• 1 x Power adapter for the Parent Unit
• 1 x Power adapter for the Baby Unit
In packs with multi Baby Units, you will find one or more additional Baby
Units with power adapters.
US and Canada 1-888-331-3383
Email: [e-mail]
On the Web: www.motorolamonitors.com

Overview of the Parent Unit
1. LCD display
2. Up Key +
Normal Mode: Tilt Up
Menu Mode: Up
3. Down Key -
Normal Mode: Tilt Down
Menu Mode: Down
4. Left Key <
Normal Mode: Pan Left
Menu Mode: Left
5. Right Key >
Normal Mode: Pan Right
Menu Mode: Right
6. Menu Key M
Press to open the Menu options.
7. OK Key O
8. Video ON/OFF Key V
Press to turn OFF the LCD display.
Press again to turn ON the LCD display.
9. Talk Ke y T
Press and hold to speak to your baby.
10. Power Adapter / Battery LED
BLUE when the adapter is powered on.
RED when battery low.
11. Unit ON/OFF LED (Green)
12. Audio Level LED (Green, Orange, Red,
Red)
13. Microphone
14. Power Key P
Press and Hold to switch the unit ON/
OFF.
15. Antenna
Lift up the antenna for optimal reception.
16. Battery cover
17. Stand
18. Speaker
19. USB power adapter socket
110 11 12 14
6
7
8
9
16
17
15
19
18
2
3
4
5
13
Parent unit menu icons
Signal Level (4 Levels)
Night Vision Mode (Screen changes to Black/White)
TTalk Mode
Battery Level Control (4 Levels)
Pan Left
Pan Right
Til t Up
Til t Dow n
Volume Level Control (8 Levels + OFF)
Zoom Level Control (1X, 2X)

Parent unit menu icons (cont’d)
Overview of the Camera Unit
&Brightness Level Control (8 Levels)
mLullaby Control (5 Song Selections)
Alarm Setting (6h, 4h, 2h, Off)
Temperature scale selection (ºC / ºF).
Readings display in BLUE, but turn RED if >29 ºC / 84 ºF or
<14 ºC / 57 ºF.
Displays HH ºC / ºF if >36 ºC / 97 ºF.
Displays LL ºC / ºF if <1 ºC / 34 ºF.
Cam Control (scan, view, add, delete)
View multiple cameras on screen (Picture in Picture). Available when
you have more than 1 Baby Unit (Camera).
VSet Video On Timer (5min, 30min, 60min)
1
9
11
10
8
2
3
6
5
4
7
1. Light Sensor (for night mode
detection)
2. Camera Lens
3. Infrared LEDs (for night vision)
4. Power / Status indicator
5. Microphone
6. PAIR Button
7. Speaker
8. Antenna
9. Micro USB socket
10. ON/OFF Switch
11. Te m p e r at u re S e n s o r
Important guidelines for installing your Wi-Fi
®
Video Baby Monitor
• To use your Baby Unit and Parent Unit together, you must be able to establish a radio link
between them, and the range will be affected by environmental conditions.
• Any large metal object, like a refrigerator, a mirror, a filing cabinet, a metallic door or
reinforced concrete, between the Baby Unit and Parent Unit may block the radio signal.
• The signal strength may also be reduced by other solid structures, like walls, or by radio
or electrical equipment, such as TVs, computers, cordless or mobile phones,
fluorescent lights or dimmer switches.
• Other 2.4GHz products, such as wireless networks (Wi-Fi
®
routers), Bluetooth™
systems, microwave ovens or other Baby Monitors, may cause interference with this
product, so keep the Baby Monitor at least 5ft (1.5m) away from these types of product,
or turn them off if they appear to be causing interference.
• If the signal is weak, try moving the Parent and/or the Baby Unit to different positions in
the rooms.
• Always ensure that you have a good Wi-Fi
®
connection available.

Table of contents 5
ENGLISH
Table of contents
1. Safety Instructions ..................................................................................... 6
2. Getting Started.......................................................................................... 9
2.1 Camera Unit Power Supply.........................................................................9
2.2 Parent Unit Battery Installation ....................................................................9
2.3 Parent Unit Power Supply .........................................................................10
2.4 Registration (Pairing).................................................................................11
3. Using the Wi-Fi®Video Baby Monitor .................................................... 12
3.1 Setting up...................................................................................................12
3.2 Pan and Tilt ................................................................................................12
3.3 Night Vision Mode.....................................................................................12
3.4 Talk Mode .................................................................................................. 12
3.5 Video ON/OFF..........................................................................................12
3.6 Temperature Display (HH °C / °F or LL °C / °F)......................................12
4. Parent Unit Menu Options....................................................................... 13
4.1 Volume.......................................................................................................13
4.2 Brightness ..................................................................................................13
4.3 Lullaby........................................................................................................13
4.4 Zoom..........................................................................................................13
4.5 Alarm..........................................................................................................13
4.6 Camera Control ........................................................................................14
4.7 Temperature..............................................................................................15
4.8 Power Saving Mode ..................................................................................15
5. System Requirements ............................................................................. 16
6. Getting started - Connecting Devices....................................................17
6.1 Setup..........................................................................................................17
6.2 User Account and Camera Setup on Android™ Devices .......................18
6.3 User Account and Camera Setup on iPhone®/iPad®.............................22
6.4 Camera Functions:....................................................................................28
6.5 Working with PC/Notebook.....................................................................31
6.6 Procedure for Resetting the Camera .......................................................31
7. Disposal of the Device (environment)....................................................32
8. Cleaning .................................................................................................. 33
9. Troubleshooting ...................................................................................... 34
10. General Information ................................................................................ 42
11. Technical Specifications ......................................................................... 48

6Safety Instructions
1. Safety Instructions
WARNING:
Strangulation Hazard. Children
have STRANGLED in cords.
Keep this cord out of the reach
of children (more than 3ft (1m)
away). Never use extension
cords with AC Adapters. Only
use the AC Adapters provided.

Safety Instructions 7
ENGLISH
WARNING
This Wi-Fi®Video Baby Monitor is compliant with all relevant standards
regarding electromagnetic fields and is, when handled as described in the
User's Guide, safe to use. Therefore, always read the instructions in this User's
Guide carefully before using the device.
• Adult assembly is required. Keep small parts away from children when
assembling.
• This product is not a toy. Do not allow children to play with it.
• This Wi-Fi®Video Baby Monitor is not a substitute for responsible adult
supervision.
• Keep this user's guide for future reference.
• Keep the cords out of reach of children.
• Do not cover the Wi-Fi®Video Baby Monitor with a towel or blanket.
• Test this monitor and all its functions so that you are familiar with it prior to
actual use.
• Do not use the Wi-Fi®Video Baby Monitor in damp areas or close to water.
• Do not install the Wi-Fi®Video Baby Monitor in extreme cold or heat, direct
sunlight, or close to a heat source.
• Only use the chargers and power adapters provided. Do not use other
chargers or power adapters as this may damage the device and battery
pack.
• Only insert a battery pack of the same type.
• Do not touch the plug contacts with sharp or metal objects.
• Connect the power adapters to easily accessible electrical outlets.
Wi-Fi®CAMERA UNIT SET UP & USE:
• Choose a location for the Wi-Fi®Camera Unit that will provide the best
view of your baby in his/her crib.
• Place the Wi-Fi®Camera Unit on a flat surface, such as a dresser,
bureau or shelf, or mount the Unit on a wall securely using the keyhole
slots under the stand.
• NEVER place the Wi-Fi®Camera Unit or cords within the crib.
• Do not place the Wi-Fi®Camera Unit or cords in the crib or within reach
of the baby (the unit and cords should be more than 3 feet away).

8Safety Instructions
CAUTION
There is a risk of explosion if the battery is replaced by an incorrect type.
Only use a Ni-MH rechargeable battery pack with rating: 3.6V, 900mAh.
Dispose of used batteries according to the instructions.

Getting Started 9
ENGLISH
2. Getting Started
2.1 Camera Unit Power Supply
1. Insert the Power Adapter plug into the micro USB socket at the back of the
Camera Unit.
2. Connect the other end of the Power Adapter into a suitable electrical
outlet.
3. Switch the ON/OFF button to the ON position.
The colored LED will now start flashing slowly.
2.2 Parent Unit Battery Installation
1. Insert the wire tabs of the rechargeable battery pack into the contact slots
as shown above and fit the battery pack into the compartment.
2. Place the battery compartment cover over the battery, making sure that
the battery wires are carefully pushed down and the cover fits properly.
Power adapter plug
Switch to turn ON the camera
Red Black

10 Getting Started
3. Gently tighten the screw in a clockwise direction using a small cross head
or flat end screwdriver.
2.3 Parent Unit Power Supply
IMPORTANT
Installing the rechargeable battery pack and charging it fully before use is
recommended. This will allow the unit to operate on battery in the event of a
power failure.
1. Connect the small plug of the power adapter to the Parent Unit and the
other end to the electrical outlet. Only use the supplied power adapter (5V
DC / 600mA) with the Micro USB plug.
2. Press and hold the PPOWER ON/OFF button for 1 second to switch
ON the Parent Unit.
3. Once the Camera and Parent Units are switched on, the display on the
Parent Unit will show the video captured by the Camera Unit.
4. If there is no connection or you are out of range, the video display will be
replaced by a symbol and the unit will beep every 5 seconds. Move the
Parent Unit closer to the Camera Unit until the link is re-established.
Small cross head or flat
end screwdriver
Micro USB Plug
Micro USB Socket

Getting Started 11
ENGLISH
5. To turn off the Parent Unit, press and hold the PPOWER ON/OFF
button until the progress bar finishes scrolling.
NOTE
The battery icon turns RED and the unit emits a beep every 16 seconds to
indicate that the battery is low and needs to be recharged. The battery pack
takes about 16 hours to charge fully.
When charging
1. During charging, the battery icon at the top right of the screen indicates that it is
charging. If the Parent Unit is powered off while charging, a power plug icon is
displayed for 5 seconds, followed by a battery icon for 45 seconds. The Blue LED
at the top left corner lights up to indicate that the power adapter is plugged in.
2.4 Registration (Pairing)
The Camera Unit is pre-registered to your Parent Unit. You do not need to
register it again unless the Camera Unit loses its link with the Parent Unit.
To re-register your Camera Unit, or register a new Camera Unit, follow the
procedure below:
1. Press the Mbutton of the Parent Unit and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until is highlighted.
The
menu will pop up.
3. Press the +UP button or -DOWN button to select , and press the
Obutton to confirm.
will pop up.
4. Press the +UP button or -DOWN button to select the desired Camera
and press the Obutton to start searching for a camera unit. The green
audio level LED will flash rapidly while searching.
5. Press the Obutton to confirm.
6. Press and hold the PAIR button underneath the Camera Unit until the
Parent Unit finds the camera, beeps and the video from the camera
appears.
NOTE
If a particular Camera Unit was registered previously, registering this current
Camera Unit again will overwrite the old registration.
0

12 Using the Wi-Fi® Video Baby Monitor
3. Using the Wi-Fi®Video Baby Monitor
3.1 Setting up
• Place the Camera Unit in a convenient location (e.g. on a table) and point the
camera lens towards the area you want to monitor.
• Adjust the Camera Unit's camera angle by rotating the camera up, down, left
and right until you are satisfied with the image in the Parent Unit.
NOTE
Do not place the Camera Unit within baby's reach! If there is interference with
the picture or sound, try moving the units to different locations, and ensure that
they are not close to other electrical equipment.
3.2 Pan and Tilt
The camera can be remotely controlled from the Parent Unit.
1. Press the +UP button or -DOWN button to tilt upward or downward.
2. Press the <LEFT button or >RIGHT button to pan left or right.
3.3 Night Vision Mode
The Camera Unit has 8 high-intensity infrared LEDs for picking up clear images
in the dark. When the built-in photo sensor detects a low level of ambient light,
the LEDs will automatically activate and the screen on the Parent Unit will display
in black and white. The icon will be displayed at the top of the LCD screen.
3.4 Talk Mode
Press and hold the TTALK button on the Parent Unit to talk to your baby through
the Camera Unit's loudspeaker. The Ticon will be displayed at the top of the
LCD screen.
3.5 Video ON/OFF
Press the VVIDEO ON/OFF button to turn the LCD display on or off. The
audio monitor will remain On.
3.6 Temperature Display (HH °C / °F or LL °C / °F)
The temperature reading from the temperature sensor at the back of the
Camera Unit will be displayed at the top of the LCD screen. The readings will
turn RED if the temperature goes above 29ºC / 84ºF or below 14ºC / 57ºF.
The reading will change to HH °C / °F if the temperature goes above 36ºC
/ 97ºF. The reading will change to LL °C / °F and icon flashes in red if the
temperature goes below 1ºC / 34ºF.

Parent Unit Menu Options 13
ENGLISH
4. Parent Unit Menu Options
4.1 Volume
1. Press the Mbutton.
The menu bar will pop up and is highlighted.
2. Press the +UP button or -DOWN button to select the desired volume
level from Level
0 ~ 8 . (The default Volume level setting is Level 4.)
4.2 Brightness
1. Press the Mbutton and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until &is highlighted.
3. Press the +UP button or -DOWN button to select the desired brightness
level from Level
1 ~ 8 .(The default brightness level setting is Level 5.)
4.3 Lullaby
1. Press the Mbutton and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until mis highlighted.
3. Press the +UP button or -DOWN button to select the desired song from
the 5 lullabies available, or the cycle option to play all 5 songs in turn. If an
individual song is selected it will only play once. (The default setting is
OFF.)
4. Press Oon the selected lullaby, and then press the +UP button or -
DOWN button to select the desired volume level.
4.4 Zoom
1. Press the Mbutton and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until is highlighted.
3. Press the +UP button or -DOWN button to select 1X or 2X zoom. (The
default setting is 1X.)
4.5 Alarm
1. Press the Mbutton and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until is highlighted.
3. Press the +UP button or -DOWN button to select the alarm time (6h, 4h,
2h). (The default setting is OFF.)
If an alarm time is selected, the Parent Unit will beep for about 45 seconds
after every 6, 4 or 2 hour period.

14 Parent Unit Menu Options
4.6 Camera Control
4.6.1 Add (pair) a camera
1. Press the Mbutton and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until is highlighted.
The
menu will pop up.
3. Press the +UP button or -DOWN button to select , and press the O
button to confirm. will pop up.
4. Press the +UP button or -DOWN button to select the desired Camera,
and press the Obutton to start searching for a camera unit. The green
audio level LED will flash rapidly while searching.
5. Press and hold the PAIR button underneath the Camera Unit until the
Parent Unit finds the camera, beeps and the picture from the camera
appears.
NOTE
A camera can only be registered to one Parent Unit at any one time.
4.6.2 View a camera
1. Press the Mbutton and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until is highlighted.
The menu will pop up.
3. Press the +UP button or -DOWN button to select , and press the O
button to confirm. will pop up.
4. Press the +UP button or -DOWN button to select desired Camera, and
press the Obutton to view the picture from that camera.
TIP
Quick Method to View Cameras.
Directly press O repeatedly to select
instead of entering the menu bar .
4.6.3 Delete a camera
1. Press the Mbutton and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until is highlighted.
The
menu will pop up.
3. Press the +UP button or -DOWN button to select , and press the
Obutton to confirm. will pop up.
4. Press the +UP button or -DOWN button to select the desired Camera,
and press the Obutton to delete that registration.

Parent Unit Menu Options 15
ENGLISH
4.6.4 Scan camera
This function is only available when you have more than 1 Camera Unit (Camera).
1. Press the Mbutton and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until is highlighted.
The
menu will pop up.
3. Press the +UP button or -DOWN button to select , and press the
Obutton to confirm.
4. The screen will then display images from the different registered cameras
in a loop of , changing about every 12 seconds.
TIP
Quick Method to View Cameras.
Directly press O repeatedly to select
instead of entering the menu bar .
4.6.5 View multiple cameras on screen (Picture in Picture)
This function is only available when you have more than 1 Camera Unit. When the
Picture in Picture function is On , you can view multiple cameras on the screen.
1. Press the Mbutton and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until is highlighted.
3. Press the +UP button or -DOWN button to select Picture in Picture On/
Off.
4. When the Picture in Picture function is On, you can press the <LEFT
button/>RIGHT button/+UP button /-DOWN button to switch
between cameras.
4.7 Temperature
1. Press the Mbutton and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until is highlighted.
3. Press the +UP button or -DOWN button to select ºC or ºF.
4.8 Power Saving Mode
1. Press the Mbutton and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until Vis highlighted.
3. Press the +UP button or -DOWN button to select auto video off after 5,
30 or 60 mins if it is not charging.

16 System Requirements
5. System Requirements
Web Portal
• Windows®7
• Mac OS®10.7
• Chrome™ 24
• Internet Explorer®9
• Safari®6
• Java™ 7
• Firefox®18.0
• Adobe®Flash®Player 15.0
Android™System
• Version 4.2 or above
iPhone®/iPad®iOS
• Version 7.0 or above
High Speed (Wi-Fi®) Internet
• At least 0.6 Mbps upload bandwidth per Camera (you can test your internet
speed on this site: http://www.speedtest.net)

Getting started - Connecting Devices 17
ENGLISH
6. Getting started - Connecting Devices
How does it work?
When a user tries to access the Camera, our secure server authenticates the
user’s identity and permits access to the Camera.
6.1 Setup
Connect the Camera to the Power Adapter, then plug into an electrical outlet
and make sure the ON/OFF Switch is in the ON position. The Camera must be
within range of the Wi-Fi®router with which you want to connect. Make sure the
password of the router is available for entering during the in-app setup process.
Status of LED Indication:
Note: You can only setup via a compatible smartphone or tablet and not via a PC.
• Pairing and setting up Flashes slowly in red and blue
• Unconnected Flashes slowly in red
• Connected Lights up in blue
• Ready for connection Flashes slowly in blue
View your Camera from any
compatible device remotely
MBP843
CONNECT
Wi-Fi®Router
Hubble
Service

18 Getting started - Connecting Devices
6.2 User Account and Camera Setup on Android™ Devices
What you need
• MBP843CONNECT Camera
• Power adapter for the Camera
• Device with AndroidTM system version 4.2 and above
6.2.1 Power ON and Connect the Camera
• Connect the power adapter to an electrical outlet and insert the plug into the
micro USB socket on the back of the Camera Unit.
• Make sure that the ON/OFF switch is in the ON position.
• The Camera’s Red LED flashes after the Camera has finished booting. When
you hear one beep, this means that the Camera is ready for setup.
6.2.2 Download Hubble for Motorola Monitors App
• Go to Google Play™ Store to search for "Hubble for Motorola Monitors".
• Download "Hubble for Motorola Monitors" App from Google Play™ Store
and install it on your Android™ device
6.2.3 Run Hubble for Motorola Monitors App on Android™ device
• Ensure that your Android™ device is connected to your Wi-Fi®router.
• Run "Hubble for Motorola Monitors" App, enter your account information,
read through the Terms of Service, then select "I agree to the Terms of Use"
before you tap
Create . (Picture A1)
Note
If you already have a Hubble App account, please select Already have an
Account? to go to the next step.
A1

Getting started - Connecting Devices 19
ENGLISH
Android™
6.2.4 Add the Camera to your account
• Tap on the top right corner of the screen to add camera. (Picture A2)
• The following setup instructions will appear on the screen. (Picture A3)
• Plug in and switch on the camera, and wait for a couple of minutes for it to
warm up.
• Tap
Continue when the Camera LED starts to blink.
A2
A3

20 Getting started - Connecting Devices
• The following setup instructions will appear on the screen. (Picture A4)
• Press and hold the
PAIR button on the bottom left edge of the Camera Unit
for 3 seconds. You will then hear a beep tone, followed by a voice prompt
indicating that the Camera is ready for pairing.
• Tap
Continue .
• The App will automatically search for and connect to your Camera as shown
in the pictures below. (Pictures A5, A6)
• The blue/red color LED on the Camera Unit will flash.
A4
A5 A6
