Motorola MBP43-B User manual

User’s Guide
Digital Video Baby Monitor
Models: MBP43-B
The features described in this User’s Guide are subject to modifications without prior notice.

Welcome...
to your new Motorola Digital Video
Baby Monitor!
Thank you for purchasing your new Digital Video Baby Monitor. Ifyou
have always wondered what your Baby is up to when you are away,
wonder no more. You can now monitor your pet’s activities from another
room.
Please retain your original dated sales receipt for your records. For
warranty service of your Motorola product, you will need to provide a copy
of your dated sales receipt to confirm warranty status. Registration is not
required for warranty coverage.
For product related questions, please call:
US and Canada 1-888-331-3383
Email: [e-mail]
This User’s Guide provides you with all the information you need to get the
most from your product.
Before you can use the Baby monitor, we recommend you insert and fully
charge the battery in the owner unit, so that it continues to work if you
disconnect it from the power supply to carry it to another location. Please
read the Safety Instructions on page 6 before you install the units.
Got everything?
• 1 x Owner unit
• 1x Baby unit(s)
• 1 x Rechargeable Ni-MH battery pack
• 1 x Power adapter for the Owner unit
•1 x Power adapter(s) for the Baby unit
In multi-camera packs, you will find one or more additional camera units
with power adapter units.

1. Display (LCD screen)
2. Up Key +
Normal Mode: Tilt Up
Menu Mode: Scroll Up
3. Down Key -
Normal Mode: Tilt Down
Menu Mode: Scroll Down
4. Left Key <
Normal Mode: Pan Left
Menu Mode: Left
5. Right Key >
Normal Mode: Pan Right
Menu Mode: Right
6. Menu Key M
Press to open the Menu options
7. OK Key O
8. Quick Scan key >>
Press to double the video pan and
tilt speed.
Press again to return to normal speed.
9. Talk Key T
Press and hold to speak to your Baby
10. Power Indicator LED turns BLUE
when the unit is on and the power
adapter is plugged in.
RED when battery low.
11. Unit ON/OFF LED (Green)
12. Audio Level LED (Green, Orange,
Red, Red)
13. Microphone
14. Power / Video ON-OFF key VP
Press and Hold to turn the unit
ON/OFF
Press once to turn ON and OFF the
LCD display
15. Antenna
Lift the antenna for optimal
reception
16. Battery cover
17. Stand
18. Speaker
19. Power Adapter Socket
Overview of the Owner Unit
18
15
16
17
1
11
13
6
7
8
9
2
3
4
5
10 12 14
19
POWER
Owner unit menu icons
1Signal Level (5 Levels)
No RF Signal
Night Vision Mode (Screen changes to Black/White)
TTalk Mod e
Battery Level Control (4 Levels)
Pan Left
Pan Right
Tilt Up
Tilt Down
Pan/Tilt at normal speed
Pan/Tilt at double speed
B

1. Photo Sensor (Night Vision Mode)
2. Camera Lens
3. Infrared LEDs
4. Power LED
5. Microphone
6. Speaker
7. ON/OFF Switch
8. Power Adapter Socket
9. Antenna
10. Pair Key
11. Temperature Sensor
Important guidelines for installing your Baby Monitor
•To use your Video Monitor Baby and Owner Unit together,you must be
able to establish a radio link between them, and the range will be affected
by environmental conditions.
• Any large metal object, like a refrigerator, a mirror, a filing cabinet, metallic
doors or reinforced concrete between the Baby and Owner Unit may
block the radio signal.
• The signal strength may also be reduced by other solid structures, like walls, or
by radio or electrical equipment, such as TVs, computers, cordless or mobile
phones, fluorescent lights or dimmer switches.
• Use of other 2.4 GHz products, such as wireless networks (Wi-Fi®routers),
Bluetooth®systems, or microwave ovens, may cause interference with this
product, so keep the Baby monitor away at least 5ft (1.5m) from these types
of products, or turnthem off if theyappear to be causing interference.
• If the signal is weak, try moving the Owner and/or the Baby Unit to
different positions in the rooms.
Owner unit menu icons (cont’d)
Overview of Your Baby Unit
*Volume Level Control (8 Levels)
Brightness Level Control (8 Levels)
Soothing Baby Music Control (5 Song Selections)
ZZoom Level Control (1X, 2X)
Alarm Setting (6h, 4h, 2h, Off)
Cam Control (Scan, View, Add, Delete)
Temperature Reading (HH °C / °F or LL °C / °F)
Icon & reading turn RED >29°C / 84°F, and reading
displays >HH °C /°F (if >36°C / 97°F)
Icon & reading turn RED <14°C / 57°F, and reading
displays <LL °C /°F (if <1°C / 34°F)
6
10
5
4
3
2
1
11
9
7
8

Table of contents 5
ENGLISH
Table of contents
1. Safety Instructions..................................................................................... 6
2. Getting Started.......................................................................................... 8
2.1 Baby Unit Power Supply.............................................................................8
2.2 Owner Unit Battery Installation ...................................................................8
2.3 Owner Unit Power Supply...........................................................................9
2.4 Registration (Pairing).................................................................................10
3. Using the Baby Monitor........................................................................... 11
3.1 Setting up...................................................................................................11
3.2 Pan and Tilt ................................................................................................11
3.3 Night Vision Mode.....................................................................................11
3.4 Talk Mode ..................................................................................................11
3.5 Video ON/OFF..........................................................................................11
3.6 Temperature (HH °C / °F or LL °C / °F)...................................................12
4. Owner Unit Menu Options...................................................................... 13
4.1 Volume.......................................................................................................13
4.2 Brightness ..................................................................................................13
4.3 Soothing Baby Music................................................................................13
4.4 Zoom..........................................................................................................13
4.5 Alarm..........................................................................................................14
4.6 Camera Control ........................................................................................14
4.6.1 Add (pair) a camera ..................................................................14
4.6.2 View a camera ...........................................................................14
4.6.3 Delete a camera ........................................................................15
4.6.4 Scan the cameras ......................................................................15
4.7 Temperature..............................................................................................15
5. Disposal of The Device (environment) ................................................... 16
6. Cleaning .................................................................................................. 17
7. Help.......................................................................................................... 18
8. General Information ................................................................................ 20

6SafetyInstructions
