MOTOROLA ATRIX™ 2
User’s Guide
Phone People Email Browser
CameraPlay StoreCalendar Text Messag
CameraPlay StoreCalendar Text Messag
11:35
AT&T

1Welcome
Welcome
MOTOROLA ATRIX™ 2
Powerful just got a lot more fun.
•Android 4.0 (Ice Cream Sandwich):
Android 4.0 is the latest version of the
Android platform for phones, tablets,
and more. It builds on the things people
love most about Android, and adds
powerful new ways of communicating
and sharing.
•Browse in the fast lane: 4G and the
1GHz dual-core processor deliver up to
2x faster processing power than
single-core smartphones.
•ZumoCast™: Our free ZumoCast app
gives you secure, unlimited access to
music, pictures and videos straight
from your computer (see “File Access”
on page 55).
•Capture the moment: Capture every
detail with the 8MP camera and 1080p
HD video recorder (see “Photos &
Videos” on page 36).
•Music to your ears: Play Music,
Motorola’s music player, connects you
to your favorite artists, lyrics, music
news, and more (see “Music” on page
39).
•The Big Time: Connect to an optional
Motorola HD Station to browse or play
high-res video on the big screen (see
“Screen Connections” on page 47).
This product meets the applicable
limit for exposure to radio waves
(known as SAR) of 1.6 W/kg (FCC &
Caution: Before assembling, charging,
or using your phone for the first time,
please read the important safety,
regulatory and legal information
provided with your phone.

2Welcome
IC). The limits and guidelines include a
substantial safety margin designed to
assure the safety of all persons,
regardless of age and health. The highest
SAR values measured for this device are
listed in the regulatory information
packaged with your product.
Note: When using the product while worn
on your body, maintain a distance of
2.5 cm (1 inch) from the body to ensure
compliance with SAR requirements. Note
that the product may be transmitting
even if you are not making a phone call.

3
Contents
Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Find More Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
New for Android™ 4.0 (Ice Cream Sandwich) . . . . . . 5
Let’s Go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Touchscreen & Keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Home Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
People . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Social networking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Text Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Photos & Videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Music. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
AT&T Features & Services . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Screen Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Bluetooth™ & Wi-Fi Connections . . . . . . . . . . . . . . . . . 49
File Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Alarm Clock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Date & Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Security & Screen Lock. . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Tips & Tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . . . . . . 68

4 Your Phone
Your Phone
the important keys & connecto rs
Calendar Text Messag Camera
Phone People Email Browser
11:35
AT&T
JAN
See all your apps.
Touch the Launcher icon.
1 0f 7
Microphone
Micro
USB
Micro
HDMI
Volume
Power /
Sleep
Hold=
power
Press=
sleep
Webcam
Message
Light
Search
Back
Menu
3.5mm
Headset
Home
Calendar
Text Messag
Calendar
Calendar
Calendar
Calendar
ext Messag
Text Messag
Text Messag
Text Messag
Ph
o
n
e
Peo
p
l
e
Em
a
i
l
Bro
w
ser
WWW.
J
A
N
a
pps.
au
n
c
h
e
r i
co
n
.
Camera
Camera
Camera
Camera
Camera
1
1:
3
5
AT
&
T
S
ee all you
r
Touc
h
t
h
e
L
1
0
f 7
Touch a text box (like in a message or
search) to enter text:
•Choose a keyboard: Touch and hold a
blank spot in a text box, then choose
Input Method.
•Close the keyboard: To uch Ba ck .
•Find out more: See “Text Entry” on
page 34.
Yahoo!
m.yahoo.com/?.tsrc=attcf&.intl=US&.lang=en
qwe r t yu i op
asd fghjkl
zx cvbnm
AT&T 8:47
Delete
Search
Symbols
Press=symbols
Hold=settings
Shift Voice

5Find More Information
Find More Information
•On your phone—Touch Apps
>Help Center.
•On any phone—Call AT&T Customer
Care at 1-800-331-0500 or dial 611
from any AT&T mobile phone for
assistance with your service or device.
•On the web—You can also get support
online:
Interactive web tutorials are available
at att.com/Tutorials. Select
Manufacturer: Motorola and Model:
ATRIX 2 from the drop-down menus.
For detailed support information
including device specifications, the
user manual, troubleshooting, user
forums and knowledgebase articles, go
to att.com/DeviceSupport
For information about your wireless
account, service plan or network, go to
att.com/Wireless
•Accessories—You can find accessories
for your phone at
att.com/WirelessAccessories or visit
your local AT&T store.

6 New for Android™ 4.0 (Ice Cream Sandwich)
New for Android™ 4.0 (Ice
Cream Sandwich)
Android 4.0 is the latest version of the
Android platform for phones, tablets, and
more. It builds on the things people love
most about Android, and adds powerful
new ways of communicating and sharing.
To check for your phone version and
updates, touch Apps > Settings
>About phone. If your Android version
isn’t 4.0, touch System updates to check
for updates.
Here are some Android 4.0 highlights:
•New Look: Android 4.0 has a new look
for the home screen and apps, but the
important icons and prompts are still
easy to find.
•Unlock Screen: On the unlock screen,
drag right to just unlock, up for
Phone, left for Camera, or down
for Text Messaging.
•App and widget list: Touch Apps to
open your app and widgets. Flick right
to see more apps (if you have a lot).
Touch Widgets to see what you can
add to your home screen.
•Shortcuts and folders: To drag an app
or widget onto your home screen, just
touch, drag, and drop it where you want
it. On your home screen, you can
combine app shortcuts into folders.
•Camera: The camera is easy to use,
and it has a panorama mode. You can
use zoom and special effects for
recording videos—or, touch the shutter
icon while recording to snap a photo.
For photos, touch a spot to set the
focus point—try new options when you
view and edit photos, too.
•Movies: Now you can rent movies by
touching Apps > Play Movies.

7Let’s Go
•Music: When you're playing songs in
Play Music, a music player appears
on the unlock screen.
•People: The new People app makes
it easier to group your friends and
associates. Your contact information is
stored in a new Me profile.
•Browser: In Browser, you can touch
Menu to select Request desktop
site or choose from expanded
Settings.
•Voice commands: Voice commands
are easy to use—find out more in
“Accessibility” on page 61.
•Settings: Settings are regrouped, and
you can quickly see how much data you
are using: touch Apps > Settings >
Data usage.
Let’s Go
let’s get you up an d running
Assemble & Charge
Caution: Please read “Battery Use &
Safety” on page 68.
1Cover off.
HD1080p
2
HD1080p
SIM in.
HD1080p
3Battery in. 4Cover on.
HD1080p
5Charge up.
3H
6Power up.

8Touchscreen&Keys
To save battery life, see “Battery Tips” on
page 60.
Note: This phone supports apps and
services that use a lot of data, so make
sure your data plan meets your needs.
Contact your service provider for details.
After you power up, create or log into
your Google™ account so you can
download apps from Google Play Store™,
back up your Contacts, and more. You
can also add your email or social
networking accounts. Later, you can add
or remove accounts by touching Apps
> Accounts.
Note: If you want to use a Wi-Fi network
for even faster Internet access,
touch Apps > Settings. Touch Wi-Fi
to search for and connect to wireless
networks. There’s more in “Wi-Fi
Networks” on page 52.
Touchscreen & Keys
a few essentials
Quick Start: Touchscreen
It’s all in the touch:
•Touch: Choose an icon or option.
•Touch & hold: Move items on the home
screen, or open options for items in
lists.
Calendar
Te
Te
xt
xt
M
M
es
es
sa
sa
g
g
Pl
Pl
ay
ay
S
S
t
to
re
Calendar Text Messag Play Store Camera
Phone People Email Browser
11:35
AT&T
WWW
.
JAN
See all your apps.
Touch the Launcher icon.
1 0f 7
Touch to open. Touch &
hold to move or delete.
Drag or flick to scroll
pages(or long lists).

9Touchscreen & Keys
•Drag or flick: Scroll slowly (drag) or
quickly (flick).
•Pinch or double-tap: Zoom in and out
on websites, photos, and maps.
Tips & tricks
•Flick & stop: When you flick a long list,
like Contacts, a scroll bar appears at
the right. Drag the scroll bar to move
quickly, or touch the screen to stop it
where you want.
•Maps: Twist a map with two fingers to
rotate it, and pull two fingers down to
tilt it.
•Sleep: To make the screen sleep or
wake up, press Power .
Note: Your
touchscreen might
stay dark if the
sensor just above it is covered. Don't
use covers or screen protectors (even
clear ones) that cover this sensor.
•Security: To make the screen lock
when you’re not using it, touch
Apps > Settings > Security &
Screen Lock > Screen lock.
•Rotate: In many apps, the touchscreen
switches from portrait to landscape
when you rotate your phone. To turn
this on or off, touch Menu > System
settings > Display > Auto-rotate
screen.

10 Touchscreen & Keys
Power & Sleep Key
Press and hold Power to
open a menu where you can
choose Power off,Sleep (no
Wi-Fi connections), Airplane
mode (no network or other
connections), vibrate , or silent .
To save your battery, prevent accidental
touches, or when you want to wipe
smudges off your touchscreen, put the
touchscreen to sleep by
pressing Power . To wake up the
touchscreen, just press Power again.
To change how long your phone waits
before the screen goes to sleep
automatically, touch Apps >
Settings > Display > Sleep.
Tip: To make the screen lock when it goes
to sleep, see “Security & Screen Lock” on
page 58.
Volume Keys
Press the volume keys on the side of the
phone to change the ring volume (in the
home screen), or the earpiece volume
(during a call).
Menu, Home, Search, & Back
Keys
Touch Menu to open menu options in
your home screen, lists, and other places.
Touch Home to close any menu or app
and return to the home screen. Touch
and hold Home to show the last few
apps you used, then touch an app to
open it. In the home screen,
touch Home to open or close the app
menu.
Touch Back to go to the previous
screen.
Touch Search to start a search.
There’s more in “Search” on page 12.

11Home Screen
Home Screen
quick acces s to the thingsyou need most
Quick Start: Home Screen
Use your home screen for quick access
to apps, notifications, and more.
You’ll see the home screen when you turn
on the phone or touch Home from a
menu:
Calendar
Te
Te
xt
xt
M
M
es
es
sa
g
g
Pl
Pl
ay
ay
S
S
t
to
re
Camera
Calendar Text Messag Play Store Camera
Phone People Email Browser
11:35
AT&T
WWW
.
JAN
See all your apps.
Touch the Launcher icon.
1 0f 7
Notifications
Flick down for details.
Status Indicators
Shortcuts
Favorites Tray
Touch to see all
your apps & widgets.
Widgets
Touch to open. Touch &
hold to move or delete.
Drag or flick to scroll
through pages.
•App menu: See all your apps (if you
have a lot, flick left and right to see
them all).
•Shortcuts: Icons open your favorite
apps, web bookmarks, contacts, mail
labels, or music playlists.
•Widgets: Little windows show you
news, weather, messages, and other
updates.
•Favorites Tray: Shortcuts at the
bottom of the home screen that
appear in all pages. Touch and hold a
shortcut, then drag it to or from the
favorites tray.
Tips & tricks
•Pages: To show other pages of
shortcuts, flick the home screen left or
right.
•Customize widgets: When you open a
widget, touch Menu to show any
options or settings (you can choose

12 Home Screen
accounts for Messages, Social
Networking, or Calendar widgets).
There’s more about social networking
widgets in “Quick Start, Social
Networking” on page 27.
•Add: To add a widget, touch Apps ,
touch Widgets, then touch and hold a
widget. To change your wallpaper,
touch and hold an empty spot on the
home screen.
You can add a folder to organize your
shortcuts.
•Move or delete: To move or de le te
something, touch and hold it until you
feel a vibration, then drag it to another
spot, another page, or to the X at the
top of the screen.
•Options: To show options for list items
(like People), touch and hold them.
To show options for your current
display, touch Menu (not all screens
have options).
Search
To search, use a Search widget on your
home screen or touch Search .
Touch here to enter
text.
Touch to search
by voice.

13Personalize
Phone Status & Notifications
Phone status & notifications
At the top of the screen, icons on the left
notify you about new messages or events
(flick the bar down for details). Icons on
the right tell you about phone status:
Bluetooth™ Wi-Fi
GPS active Airplane mode
Silent ring Vibrate ring
Mic mute Speakerphone
Alarm set Network
(strong)
Charging Charged
Connected to HSPA+
Personalize
addyour personaltouch
Quick Start: Personalize
Customize your phone’s sounds and
appearance to make it unique to you!
Silence all sounds except media & alarms
Vibrate
Volumes
Silent mode
AT&T Firey
Phone ringtone
Kinetic Bell
Vibrate and ring
Dial pad touch tones
Touch sounds
Screen lock sound
SYSTEM
Default noticiation
RINGTONE & NOTIFICATIONS
Sound
Silence all sounds except media & alarms
Brightness
Wallpaper
After 5 minutes of inactivity
Font size
Shrink to t screen
Adjusts the display size and area to t
screen
HDMI Connection
Enable to detect HDMI cable
Normal
Sleep
Auto-rotate screen
Display
HDMI SETTINGS
Set volumes.
Call & Message
Notifications
Set screen brightness.

14 Personalize
Find it: Apps > Settings > Sound or
Display.
Tips & tricks
•Volume: To change your ringtone
volume from the home screen, just
press the volume keys.
•Message alert: To change your new
message notification, touch Apps >
Text Messaging > Menu >
Messaging settings > Notification
Settings.
Sounds
•Change your ringtone and
notifications: touch Apps >
Settings > Sound.
•Toggle on or off new message
notification: touch Apps > Text
Messaging > Menu > Messaging
settings > Notification Settings.
•Set a ringtone for a contact: touch
People, touch the contact, then
touch Menu > Set ringtone.
•Set volume for media: Menu >
System settings > Sound > Volumes.
Display Settings
•Set brightness: Apps > Settings >
Display > Brightness.
•Set orientation: Apps > Settings >
Display > Auto-rotate screen.
Language & Region
Set your menu language:
Find it: Apps > Settings > Language
& input > Locale

15Apps
Apps
get the app you want
Quick Start: Apps
Download games, tools, apps, and more!
Find it: Apps > Play Store.
•New apps: To read about or download
an app in Play Store, touch it.
R’S
CE
Google Play
New and Classic
Movie Favorites
orite
mes
Games
KILLER COMPS
FROM $3.99
NOW And Other
Great Collections
THE DISNEYTHE DISNEY
COLLECTIONCOLLECTION
Musics
Books
Movies
see more
see more
see more
see more
Apps
My Apps
Accounts
Settings
Help
$
NOW
Touch an app to open
its details or install it.
Touch to show your
downloaded apps,
settings, or help.
Search for apps.
Note: When installing an app, make
sure you read the alerts that tell you
what information the app will access. If
you don’t want the app to have access
to this information, cancel the
installation.
•Downloaded apps: To show apps you
downloaded from Play Store, touch
Menu > My apps.
Tips & tricks
•Quick access: For quick access to Play
Store, just touch Apps , then touch
in the top right.
•Trusted apps: Choose your apps and
updates carefully, from trusted sites
like Play Store, as some may impact
your phone’s performance—see
“Choose Carefully” on page 16.
•Recent apps: To show the last few apps
you’ve used, touch and hold Home .

16 Apps
•Update: To make your apps update
automatically, touch Apps > Play
Store > Menu > My apps, touch an
app to open details, then touch the
Allow automatic updating checkbox.
•Uninstall: To uninstall or manage apps,
from the home screen touch Menu >
Manage apps, then touch an app.
Manage & Restore Apps
Find it: Menu > Manage apps
Touch an app in the list, then choose
Uninstall (for apps you downloaded),
Clear cache, Move to SD card (for
downloaded apps), or other options.
Google Play Store™ is also available on
your computer—go to play.google.com.
Sign in to browse and manage apps for all
your Android™ devices.
If you have trouble removing an app, turn
off your phone, then turn it back
on—when you see the “Motorola” logo
during power-up, press and hold both
volume keys until you see the home
screen. Your screen will show Safe Mode
in the lower left corner, and you can
remove the app.
To reinstall apps from Google Play
Store™, touch Apps > (in the top
right) > Menu > My apps. The apps you
downloaded are listed and available for
download.
Choose Carefully
Apps are great. There's something for
everyone. Play, communicate, work, or
have fun. But remember, choose your
apps carefully. Here are a few tips:
•To help prevent spyware, phishing, or
viruses from affecting your phone or
privacy, use apps from trusted sites,
like Play Store.
•In Play Store, check the apps’ ratings
and comments before installing.

17Apps
•If you doubt the safety of an app, don't
install it.
•Like all apps, downloaded apps will use
up memory, data, battery, and
processing power—some more than
others. For example, a simple battery
level widget will use less than a
streaming music player app. After
installing an app, if you're not happy
with how much memory, data, battery
or processing power it's using, uninstall
it. You can always install it again later.
•Just like web browsing, you may want to
monitor childrens’ access to apps to
help prevent exposure to inappropriate
content.
•Certain apps may not provide
completely accurate information. Take
care, especially when it comes to
personal health.
Update Your Phone
You can use your phone or computer to
check, download, and install phone
software updates:
•Using your phone:
If your phone notifies you about an
update, follow the instructions to
download and install it.
To manually check for updates,
touch Apps > Settings > About
phone > System updates.
Your phone downloads any updates
over your mobile network. Remember,
these updates can be quite large
(25MB or more) and may not be
available in all countries. If you don’t
have an unlimited data plan, or mobile
network updates are not available in
your country, you can update using a
computer.

18 Calls
•Using your computer:
On your computer, go to
www.motorola.com/support and
check the “Software” links. If an update
is available, just follow the installation
instructions.
Calls
it’s good totalk
Quick Start: Calls
Dial numbers, see recent calls, and more.
Find it: Apps > Phone
Most recent
DIALER PHONEBOOKRECENT
1 2ABC 3DEF
4GHI 5JKL 6MNO
7PQRS 8TUV 9WXYZ
0
Victor Harp
April 26, 2012
Mobile [phone]
Recent Calls
Touch an entry to
call.
Select phone
numbers from your
People app.
Delete digits you
entered.
Add Number to
Contacts
Most Recent Call
Voice Dial
Call
Enter a phone
number & touch
here to call it.
