MOTOROLA ATRIX™

1Welcome
Welcome
MOTOROLA AT R I X
It’s not part-computer, it’s leave-your-computer-behind.
• A computer that doubles as a phone: Built with
PC-like dual-core technology, the MOTOROLA
ATRIX also comes packing 1GB of RAM. You’ll see
everything in crisp, rich 24-bit colour with the
world’s first qHD smartphone display. With the
support of up to 48GB memory, you’ll be able to
store thousands of songs, photos and files.
• A phone that acts like a computer: With the
revolutionary webtop, you now have the freedom to
access and manage your files, photos, emails and
web on a larger screen virtually anywhere you go.
Just connect your ATRIX using the optional Lapdock
or HD multimedia dock (page 37).
Note: Certain apps and features may not be available
in all countries.
Caution: Before assembling, charging or using your
phone for the first time, please read the important
legal and safety information packaged with your
product.
More
•Answers:Touch > Help centre.
You can also flick your home screen left or right to
show the Getting started and Tips & tricks widgets.
•Updates:Get phone updates, PC software, online
help and more at www.motorola.com/myatrix.
•MOTOBLUR: After you create a MOTOBLUR account,
open it at www.motorola.com/mymotoblur .
• Accessories: Find accessories for your phone at
www.motorola.com/products.

2Your phone
Your phone
the important keys & connectors
Browser Market
H
is attending the World Music
Festival!
1 hour ago
Hey, I'm just back
from my trip, want
to grab a coffee?
Natanya Ray Dylan Foster
1 more day before
I hit those slopes!
9 minutes ago
GPS NavTV & radio
TRANSCANADA
Br
o
w
se
r
Ma
rk
et
H
th
e Wor
ld
Music
t
g
t
n
i
s atten
d
i
n
F
estiva
l!
1
hour a
go
to
grab
a
coffe
Hey, I'm just
b
f
rom my trip,
to gra
ba
co
ffe
N
atanya
Ra
e
b
e
a
e
b
e
a
e
b
e
a
9 minutes a
go
e
e?
b
e
a
b
ack
want
e
e?
a
yDy
l
an Foste
r
1
more day before
I
hit those slopes
!
G
P
S
N
a
vTV
&
r
ad
i
o
T
RAN
S
C
ANADA
Microphone
Micro USB
Volume
3.5mm
headset
WebcamMessage
light
Search
Back
Menu
Hold=
power
Press=
sleep
HDMI
Home
Power /
Sleep
Note: Your phone might look a little different.
.
:-)
DEL
DEL
Done
Enter message here
:
H
Delete
Press=smiley
Hold=icon menu
Press=symbols
Hold=settings
Shift Voice
Symbols Emoticons

3Let’s go
Contents
Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Touchscreen & keys . . . . . . . . . . . . . . . . . . . . . . . . . 5
Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Personalise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Apps & updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Social networking . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Entertainment centre . . . . . . . . . . . . . . . . . . . . . . . 36
Webtop application . . . . . . . . . . . . . . . . . . . . . . . . . 37
Wireless . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Memory card & file transfer . . . . . . . . . . . . . . . . . . 41
Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Safety, regulatory & legal . . . . . . . . . . . . . . . . . . . . 51
Let’s go
let's get you up and running
Assemble & charge
Caution: Please read “Battery use & safety” on
page 51.
To save battery life, see “Battery tips” on page 25.
1Cover off 2SIM in
3Battery in 4Cover on
5Charge up 6Power up, log in
3
H

4Let’s go
Set up & go
Create or log into a MOTOBLUR account
to get your contacts, email, messages and
status information, for all your accounts,
all in one place. Registration is secure and
should only take a few minutes.
Note: This phone supports apps and services that use
a lot of data, so make sure your data plan meets your
needs. For details, contact your service provider.
1Tu r n o n .
2Select a language.
3Register or log in.
To create a MOTOBLUR account,
enter your name, your current email address (where
MOTOBLUR can send account information) and a
new MOTOBLUR password.
If you choose Skip setup for now, go to step 5.
4Add your accounts to MOTOBLUR.
To add an account, touch it. Then, enter the
username or email and password that you set up on
that account.
Tip: For more, or to add accounts anytime, go
to “Add accounts” on page 11.
5When your phone shows your home screen, import
your SIM contacts: Touch Contacts, then
touch Menu > More > Import/export > Import
contacts from: SIM card. Touch OK to confirm.
Your MOTOBLUR account
Only MOTOBLUR syncs contacts, posts, feeds,
messages, emails, photos and much more—from
sources like Facebook™, Twitter, MySpace, your work
email, Picasa™ and Photobucket™—and serves them
up just the way you want them.
To add or edit the email, social networking and other
accounts in your MOTOBLUR, touch >
Accounts. To set up email accounts, see “Set up
messaging” on page 21.
You can log into MOTOBLUR from a computer to
upload contacts, reset your password, get help or even
locate your phone: www.motorola.com/mymotoblur
Turn it on & off
To turn on your phone, press and
hold Power on top of your phone.
To turn off your phone, press and
hold Power , then touch Power off
in the menu that opens.

5Touchscreen & keys
Wi-Fi™ connect
If you want to use a Wi-Fi network for even faster
Internet access, touch Menu > Settings >
Wireless & networks > Wi-Fi settings. Touch Wi-Fi to
search for and connect to wireless networks. There’s
more in “Wi-Fi™ networks” on page 39.
Cool content & more
Browse and download thousands of the coolest apps
on the planet from Android Market™. On top of that,
you get a full HTML browser, so you can surf in style.
Download new apps with “Apps & updates” on
page 10.
Security
Your contacts are backed-up on MOTOBLUR, so don’t
worry. Even if you lose your phone, MOTOBLUR can
help you find it or wipe it. And when you get your next
MOTOBLUR product, your stored info makes it a snap
to set up with just your username and password.
Of course, it doesn't stop there. There are plenty of
ways to protect your phone and your information,
in “Security” on page 47.
Touchscreen & keys
a few essentials
Touchscreen
To use your touchscreen:
•Touchitems to select them. Try it: On the home
screen, touch Contacts.
• Touch & hold items to open options. Try it: On the
home screen, touch Contacts, then touch
and hold a contact to open options.
•Draga list or
the home
screen, to see
more. Try it: On
the home
screen, touch
Contacts
then drag your
list up or down.
When you drag
or flick a list, a scroll button appears on the right.
Drag the scroll button to move faster.
• Flick (drag quickly and release) a list to move quickly.
When you flick a long list, touch the screen to stop it
from scrolling.
Contacts: A-Z
Arthur Baudo
Barry Smyth
Jim Somers
Contacts: All contacts

6Touchscreen & keys
If your screen goes to sleep, press Power .
In many apps, the touchscreen can switch from
portrait to landscape when you rotate your phone:
Touch Menu > Settings > Display > Auto-rotate
screen.
Note: Your touchscreen might
stay dark if the sensor just
above it is covered. Don't use
covers or screen protectors (even clear ones) that
cover this sensor. To find Motorola accessories for
your phone, visit www.motorola.com/products.
Menu, home & back keys
Touch Menu to open menu options in your home
screen, lists and other places.
Touch Home to close any menu or app and return
to the home screen. Touch and hold Home to
show the last few apps you used, then touch an app to
open it. On the home screen, touch Home to open
or close the app menu.
Touch Back to go to the previous screen.
Power & sleep key
Press and hold Power to open a
menu where you can turn off sound
(Silent mode), network and wireless
connections (Flight mode) or the phone
(Power off).
To save your battery, prevent accidental touches or
when you want to wipe smudges off your
touchscreen, put the touchscreen to sleep by pressing
Power . To wake up the touchscreen, just
press Power again.
To change how long your phone waits before the
screen goes to sleep automatically, touch Menu >
Settings > Display > Screen timeout.
Tip: To make the screen lock when it goes to sleep,
use “Screen lock” on page 48.
Volume keys
Press the volume keys on the side of
your phone to change the ring volume
(on the home screen) or the earpiece
volume (during a call).

7Home screen
Home screen
quick access to the things you need most
Quick start: Home screen
The home screen gives you all your latest information
in one place. It’s what you see when you turn on the
phone or touch Home from a menu.
Browser Market
11:35
H
is attending the World Music
Festival!
10:14 AM
AM
10
:1
4
A
AM
10
:1
4
A
AM
10:14
A
1 hour ago
Natanya Ray
Hey, I'm just back
from my trip,
want to grab a
yj
fti
N
atanya
R
ay
H
e
y
, I'm
j
ust
ba
M
M
M
M
a
M
M
M
M
M
Dylan Foster
1 more day before
I hit those slopes!
9 minutes ago
y
Ihi h l !
c
k
D
y
l
an Foster
1 more da
y
be
f
or
e
GPS NavTV & radio
TRANSCANADA
Phone status
Widgets
Touch to open.
Touch & hold to move
items (or show options
in lists).
Drag or flick to open
panels (or scroll in
lists).
Open the app menu.
Flick this bar down to
see notifications.
Use the widgets, shortcuts and panels to see what's
important to you—whether it's home, work or play.
Use & change your home screen
On your home screen, shortcuts are icons that open
your favourite apps, web bookmarks, contacts, mail
labels or music playlists. Widgets show you news,
weather, messages and other updates.
Flick the home screen left or right to open other panels
of shortcuts and widgets.
•To open something, touch it. Touch Home to
return to the home screen.
Tip: When you open a widget, touch Menu to
show any options or settings (you can choose
accounts for Messages, Social networking, or
Calendar widgets).
There’s more about social networking widgets in
“View account updates & features” on page 12 and
“Update your status” on page 12.
•To resize Motorola
widgets, touch and hold
one until you feel a
vibration, then release.
Drag a corner to resize.
THURSDAY
08
JULY
1:30 pm to 2:30 pm
3:00 pm to 4:00 pm +2 more
+2 more
1:30 pm to 2:30 pm
5th and Broadway
2:00 pm to 3:00 pm
3:00 pm to 4:00 pm
Team meeting: Design review
Lunch with Ray Smith
Business plan discussion with team
Team meeting: Design review
Lunch with Ray Smith
TH
U
R
S
DAY
0
8
JULY
1:30
30
1
pm to
pm to
2:30
2:30
pm
pm
3:0
00
p
m to 4:00
pm
+2 m
o
r
e
+2 m
o
r
e
1:3
30
p
m to 2:30
pm
5th
th a
nd Broadwa
y
2:0
00
pm to 3:00
pm
3:0
00
pm to 4:
00
p
m
T
Te
eam
meeting: Design review
L
Lu
unch
with Ray Smith
Bu
usin
ess plan discussion with team
T
Te
eam
meetin
g
: Desi
g
n review
nch
nch
with
with
Ray
Ray
Smith
Smith
team
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
1:3
1:3
1
Lu
Lu
Lu
u
u
u
un
u
Lu
un
L

8Home screen
•To add something or change your wallpaper, touch
and hold an empty spot until you open the Add to
Home screen menu.
You can add a folder to organise your shortcuts.
•To move or delete something, touch and hold it
until you feel a vibration, then drag it to another
spot, another panel or the bin at the bottom of the
screen.
Search
Phone status & notifications
At the top of the screen, icons on the left notify you
about new messages or events (flick the bar down for
details). Icons on the right tell you about the phone's
status:
Bluetooth™ active Wi-Fi™ active
GPS active flight mode
silent ring vibrate ring
microphone mute speakerphone on
alarm set network (full)
Type, then touch.
Touch, then speak.
Choose what you search.
Text search
Voice search
Tip: To show today’s date, touch and hold the status
icons.
HSPA ready HSPA transferring
3G ready 3G transferring
battery (charging) battery (full charge)
