Motorola RAZR V3xx User manual

MOTOMANUAL
MOTORAZR
™
V3xx
www.motorola.com

1
HELLOMOTO
Introducing your new MOTO RAZR™ V3xx 3G wireless phone. Here’s a quick anatomy lesson.
Navigation Key
Navigate menus.
Center Select Key
Open menus, select menu items.
Clear/Back Key
CameraKey
Microphone
Power/End Key
Turn on/off, hang up, exit menus.
Right Soft KeyLeft Soft Key
Volume Keys
Internal CameraLens
Smart Key
Send Key
Make & answer calls.
Open text messages.
Go online.

2
To change your home screen shortcuts and your main menu appearance, see page 52.
Accessory Connector Port
Insert battery charger
& phone accessories.
Volume Keys
Open ring style menu or adjust camera
zoomwhen flip is closed.
Active Video Call Indicator
Battery ChargingIndicator
Smart Key
Choose a ring style when flip is closed.
Hold the smart key to lock or unlock all
side keys.
CameraKey
Take camera photo when flip is closed.
External CameraLens
Bluetooth™ Connection Indicator
External Display
See incoming call information, use as
camera viewfinder when flip is closed.

3
Home Screen Main Menu
Press the Navigation Key
up, down, left, or right
(
S ) to highlight a menu
feature.
3
Press the Center Key s
to select it.
4
Messages Camera Select Back
WebAccess
Press and hold the
Power Key O for a few
seconds or until the
display lights up to turn
on your phone.
1
Press the Center Key s
to open the
Main Menu .
2
Service Provider
12:00

4
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States for hearing impaired)
1-800-461-4575 (Canada)
Certain mobile phone features are dependent on the capabilities
and settings of your service provider’s network. Additionally,
certain features may not be activated by your service provider,
and/or the provider's network settings may limit the feature’s
functionality. Always contact your service provider about feature
availability and functionality. All features, functionality, and other
product specifications, as well as the information contained in this
user's guide are based upon the latest available information and
are believed to be accurate at the time of printing. Motorola
reserves the right to change or modify any information or
specifications without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US
Patent & Trademark Office. All other product or service names are
the property of their respective owners. The Bluetooth trademarks
are owned by their proprietor and used by Motorola, Inc. under
license. Java and all other Java-based marks are trademarks or
registered trademarks of Sun Microsystems, Inc. in the U.S. and
other countries. Microsoft, Windows and Windows Me are
registered trademarks of Microsoft Corporation; and Windows XP
is a trademark of Microsoft Corporation.
© Motorola, Inc., 2007.
Caution: Changes or modifications made in the radio phone, not
expressly approved by Motorola, will void the user’s authority to
operate the equipment.
Manual Number: 6809511A08-O

contents
5
contents
menu map. . . . . . . . . . . . 5
Use and Care . . . . . . . . . 7
essentials . . . . . . . . . . . . 8
about this guide . . . . . . 8
SIM card. . . . . . . . . . . . 9
battery . . . . . . . . . . . . . 9
turn it on & off . . . . . . . 11
make a call . . . . . . . . . 12
answer a call. . . . . . . . 12
store a phone number 12
call a stored phone
number. . . . . . . . . . . . 13
your phone number . . 13
main attractions . . . . . . 14
Bluetooth® wireless . 14
audio player . . . . . . . . 20
photos . . . . . . . . . . . . 22
videos . . . . . . . . . . . . . 25
video calls. . . . . . . . . . 27
text messages . . . . . . 28
memory card . . . . . . . 30
cable connections. . . . 33
phone updates . . . . . . 34
basics. . . . . . . . . . . . . . . 35
display . . . . . . . . . . . . 35
text entry . . . . . . . . . . 38
volume . . . . . . . . . . . . 42
navigation key. . . . . . . 43
smart key . . . . . . . . . . 43
external display. . . . . . 43
handsfree speaker . . . 44
codes & passwords . . 44
lock & unlock phone . . 45
customize . . . . . . . . . . . 46
ring style. . . . . . . . . . . 46
time & date. . . . . . . . . 47
wallpaper . . . . . . . . . . 48
screen saver . . . . . . . . 48
themes . . . . . . . . . . . . 49
display appearance . . . 49
shortcuts and main menu
. . . . . . . . . . . . . . . . . . 50
answer options. . . . . . 51
calls . . . . . . . . . . . . . . . . 52
turn off a call alert . . . . 52
recent calls . . . . . . . . . 52
redial. . . . . . . . . . . . . . 54
return a call. . . . . . . . . 54
caller ID . . . . . . . . . . . 54
emergency calls . . . . . 55

6
contents
voicemail . . . . . . . . . . . 55
other features . . . . . . . . 57
advanced calling . . . . . 57
phonebook. . . . . . . . . . 62
messages . . . . . . . . . . 66
instant messaging . . . . 69
personalizing . . . . . . . . 71
call times & costs . . . . 72
handsfree . . . . . . . . . . 73
data calls . . . . . . . . . . . 74
network . . . . . . . . . . . . 76
personal organizer . . . . 76
security . . . . . . . . . . . . 79
fun & games . . . . . . . . 79
service and repairs . . . . 82
SAR Data . . . . . . . . . . . . 83
EU Conformance . . . . . . 85
Safety Information . . . . 88
Industry Canada Notice 94
FCC Notice . . . . . . . . . . . 95
Warranty. . . . . . . . . . . . . 96
Hearing Aids . . . . . . . . 100
WHO Information . . . . 101
Registration . . . . . . . . . 101
Export Law. . . . . . . . . . 102
Recycling . . . . . . . . . . . 102
Perchlorate Label. . . . . 103
Driving Safety . . . . . . . 104
index. . . . . . . . . . . . . . . 106

menu map
7
menu map
main menu
9 Video Camera
É Tools
•USIM*
•Calculator
• Datebook
•AlarmClock
• Dialing Services
• Fixed Dial *
• Service Dial *
•QuickDial
• Activation List
• Messenger *
• Voice Message
• World Clock
I Camera
h Multimedia
• Media Finder
•Music
• Pictures
• Videos
• Voice Records
• Ring Tones
• Wallpapers
• Themes
•Camera
• Video Camera
• Voice Record
á Web Access
•Browser
• Bookmarks
•History
• Go To Page
•BrowserSetup
• Web Sessions *
Q Games & Apps
e Messages
• Create Message
•Voicemail
• Message Inbox
•EmailMsgs
• Browser Messages
• Info Services *
• Outbox
•Drafts
• Templates
s Recent Calls
• (press the * or # to scroll
through the call lists)
n Phonebook
w Settings
• (see next page)
L Connection
• Bluetooth® Link
• USB Settings
•MOTOSYNC™*
% Airplane Mode
• Airplane Mode
• Prompt at Startup
* optional features
This is the standard main menu layout.
Your phone’s menu may be a little
different.
To change your home screen shortcuts
and your main menu appearance, see
page 52.

8
menu map
settings menu
l Personalize
• Home Screen
• Main Menu
•VoiceDialSetup
•Skin
• Greeting
• Wallpaper
• Screen Saver
t Ring Styles
•Style
•(style) Detail
L Connection
• Bluetooth® Link
• USB Settings
•MOTOSYNC™*
H Call Forward *
• Voice Calls
• Video Calls
•CancelAll
• Forward Status
• Push to Call Fwd No.
U In-Call Setup
• Date and Time *
• In-Call Timer
• Call Cost Setup *
• My Caller ID
• Answer Options
• Call Waiting
•MSGAlert
Z Initial Setup
• Time and Date
• Speed Dial
•AutoRedial
• Display Timeout
• Backlight
• Charging Lights
• TTY Setup *
•Scroll
• Text Marquee
• Language
•BatterySave
• Brightness
•DTMF
• Master Reset
•MasterClear
m Phone Status
•MyTel.Numbers
• Credit Info/Available *
• Active Line *
•BatteryMeter
• Download Location
• Storage Devices
• Voice Dial Languages
• Software Update *
• Other Information
S Headset
• Auto Answer
• Ringer Options
•VoiceDial
J Car Settings
• Auto Answer
• Auto Handsfree
•Power-OffDelay
• Charger Time
j Network
•NewNetwork
•NetworkSetup
• Available Networks
• My Network List *
• Service Tone
• Call Drop Tone
u Security
• Phone Lock
• External Key Lock
• Lock Application
• Show Private Entries
• Fixed Dial *
• Restrict Calls *
• Call Barring *
•SIMPIN
• New Passwords
• Certificate Mgmt *
c Java™ Settings
• Java System
• Delete All Apps
• App Vibration
• App Volume
• App Priority *
• App Backlight
• Set Standby App *
•DNSIP*
% Airplane Mode
• Airplane Mode
• Prompt at Startup
* optional features

Use and Care
9
Use and Care
Use and Care
To care for your Motorola phone, please keep it away from:
liquids of any kind dust and dirt
Don’t expose your phone to water, rain,
extreme humidity, sweat, or other moisture.
Don’t expose your phone to dust, dirt, sand,
food, or other inappropriate materials.
extreme heat or cold cleaning solutions
Avoid temperatures below -10°C/14°F or
above 45°C/113°F.
To clean your phone, use only a dry soft cloth.
Don’t use alcohol or other cleaning solutions.
microwaves the ground
Don’t try to dry your phone in a microwave
oven.
Don’t drop your phone.

10
essentials
essentials
about this guide
This guide shows how to open a menu
feature as follows:
Find it: s > eMessages > Create Message
This means that, from the home screen:
1 Press the center key s to open the
menu.
2 Press the navigation key S to scroll to
eMessages , and press the center key s
to select it.
3 Press the navigation key S to scroll to
Create Message , and press the center key s
to select it.
CAUTION: Before using the
phone for the first time, read the
Important Safety and Legal
Information
included in the gray-
edged pages at the back of this
guide.
symbols
This means a feature is network,
SIM card, or subscription
dependent and may not be available
in all areas. Contact your service
provider for more information.

11
essentials
SIM card
Caution: Don’t bend or scratch your SIM card.
Keep it away from static electricity, water, and
dirt.
Yo u r Subscriber Identity Module (SIM) card
contains personal information like your phone
number and phonebook entries. It can also
contain your voicemail, text message, and
Internet access settings. If you put your SIM
card in another phone, that phone uses your
phone number.
To insert and use a
memory card , see
page 32.
Turn off your phone and remove your
battery before you install or remove a SIM
card.
battery
battery installation
This means a feature requires an
optional accessory.
symbols
12
12

12
essentials
battery charging
New batteries
are not fully
charged. Plug
the battery
charger into your
phone and an
electrical outlet.
Your phone
might take
several seconds to start charging the battery.
When finished, your display shows
Charge Complete .
Tip: Relax, you can’t overcharge your battery.
It will perform best after you fully charge and
discharge it a few times.
The battery charger shipped with this device
is designed for Motorola 3G mobile phones.
Other chargers might take longer to charge
your battery, or cause your calls to fail during
charging.
battery tips
Battery life depends on the network, signal
strength, temperature, features, and
accessories you use.
• Always use Motorola
Original batteries and
chargers. The warranty does
not cover damage caused by
non-Motorola batteries and/or chargers.
34
Battery ChargingIndicator

13
essentials
• New batteries or batteries stored for a
long time may take more time to
charge.
• When charging your battery, keep it
near room temperature.
When storing your battery, keep it
uncharged in a cool, dark, dry place.
• Never expose batteries to
temperatures below -10°C (14°F) or
above 45°C (113°F). Always take your
phone with you when you leave your
vehicle.
• It is normal for batteries to gradually
wear down and require longer charging
times. If you notice a change in your
battery life, it is probably time to
purchase a new battery.
Contact your local recycling center for
proper battery disposal.
Warning: Never dispose of batteries in a fire
because they may explode.
Before using your phone, read the battery
safety information in the “Safety and General
Information” section included in this guide.
turn it on & off
Caution: Some phones ask for your SIM card
PIN code when you turn them on. If you enter
an incorrect PIN code three times before the
correct code, your SIM card is disabled, and
your display shows
SIM Blocked . Contact your
service provider.
To turn on your phone ,
press and hold
O for a few
seconds or until the keypad
or display lights up.
032375o

14
essentials
If prompted, enter your eight-digit SIM card
PIN code and/or four-digit unlock code (for
more about codes, see page 46).
To turn off your phone , press and hold O
for a few seconds.
make a call
To make a call , enter a phone number and
press
N . To “hang up,” close the flip or
press
O .
To make video calls, see page 29.
answer a call
To answer a call when your phone rings
and/or vibrates, just open the flip or press
N .
To “hang up,” close the flip or press O .
store a phone number
You can store a phone number in your
Phonebook :
1 Enter a phone number in the home
screen.
2 Press Store .
Select
Create New Contact , if necessary.
3 Enter a name and other details for the
phone number. To select a highlighted
item, press the center key
s .
4 Press Done to store the number.
To
edit or delete a Phonebook entry, see
page 65.
To s t o re an
email address from the home
screen, press
s > nPhonebook > New Entry .
Enter the new contact’s name and
Email
information.

15
essentials
call a stored phone
number
Find it: s > nPhonebook
1 Scroll to the phonebook entry.
Shortcut: In the phonebook, press
keypad keys to enter the first letters of an
entry you want.
2 Press N to call the entry.
Note: You can show contacts stored in your
phone’s memory or on your SIM card. To
choose which contacts you see, press
s > nPhonebook , then press Options > View .
You can select
Phone & SIM Card , SIM Card , or
Phone Contacts . Contacts on the SIM card only
include a
Name and Number . To choose where
you store contacts, go back to the home
screen and press
s > nPhonebook , then
press
Options > Setup > Default Storage
>
Phone or SIM Card .
your phone number
From the home screen, press
the clear key
D then # to see your
number.
Tip: Want to see your phone number while
you’re on a call? Press
Options > My Tel. Number .
You can edit the name and phone
number stored on your SIM card. From
the home screen, press
D# , select an
entry, press
View , press Options , and select Edit .
If you don’t know your phone number, contact
your service provider.

16
main attractions
main attractions
You can do much more with your phone than
make and receive calls!
Bluetooth® wireless
Your phone supports Bluetooth wireless
connections. You can connect your phone
with a Bluetooth headset or car kit to make
handsfree calls. You can also connect your
phone with a phone or computer that
supports Bluetooth connections to exchange
files.
You can also use Bluetooth® A2DP stereo
headphones to listen to music files you store
on your phone.
Note: The use of wireless phones while
driving may cause distraction. Discontinue a
call if you can’t concentrate on driving.
Additionally, the use of wireless devices and
their accessories may be prohibited or
restricted in certain areas. Always obey the
laws and regulations on the use of these
products.
For maximum Bluetooth security , you
should always connect Bluetooth devices in a
safe, private environment.
use a headset or handsfree car
kit
Before you try to connect your phone with
a handsfree device
, make sure the device is
on and ready in pairing or bonding mode
(see the user’s guide for the device).

17
main attractions
Find it: s > wSettings > Connection
>
Bluetooth Link > [Add Audio Device]
Your phone lists the devices it finds within
range.
1 Scroll to a device in the list and press the
center key
s .
2 Press Yes or OK to connect to the device.
3 If necessary, enter the device passkey
(such as
0000 ) and press OK .
When your phone is connected, the
Bluetooth indicator
O appears in the home
screen.
You cannot play some copyrighted files over a
Bluetooth connection.
Shortcut: When your phone’s
Bluetooth power is on, your phone can
automatically connect to a handsfree device
you have used before. Just turn on the device,
or move it near the phone. If the device
doesn’t connect, turn it off and back on.
During a call or while playing a sound file, you
can press
Options > Use Bluetooth to connect to a
headset or handsfree device you have used
before.
Tip: Want to know more about your headset
or car kit? For specific information about a
device, refer to the instructions that came
with it. For more Bluetooth support, see:
www.motorola.com/Bluetoothsupport
copy files to another device
You can use a Bluetooth connection to
copy a media file, phonebook entry,
datebook event, or Web shortcut from your
phone to a computer or other device.
Note: You can’t copy some copyrighted
objects.

18
main attractions
1 On your phone, scroll to the object that
you want to copy to the other device.
2 Press Options , then select:
• Manage > Copy for media files.
• Send Contact for phonebook entries.
• Send for datebook events.
3 Select a recognized device name, or
[Look For Devices] to search for the device
where you want to copy the file.
If your phone could not copy the file to the
other device
, make sure the device is on and
ready in discoverable mode (see the user’s
guide for the device). Also, make sure the
device is not busy with another similar
Bluetooth connection.
Note: Once you connect your phone to a
Bluetooth device, that device can start similar
Bluetooth connections with your phone. Your
display shows the Bluetooth indicator
O at
the top when there is a Bluetooth connection.
To change a device’s
Access setting, see
page 21.
receive files from another
device
If you do not see the
Bluetooth indicator
O at the top of your
phone display, turn on your phone’s
Bluetooth feature by pressing
s > wSettings
>
Connection > Bluetooth Link > Setup > Power > On .
1 Place your phone near the device, and
send the file from the device.
If your phone and the sending device
don’t recognize each other, place your
phone in discoverable mode so the
sending device can locate it: press
s > wSettings > Connection > Bluetooth Link
>
Find Me .
