Motorola KRZR K1M SPRINT User manual

1
HELLOMOTO
Introducing your new MOTO KRZR
TM
K1m wireless phone. Here’s a quick anatomy lesson.
N
Message Contacts
MENU
Thu, Oct 23 12:45pm
P
0
❙❙❙
1X
EV
Smart/
Speakerphone
Key
Make & answer
calls.
Scroll up, down,
left or right.
Turn on & off,
hang up, exit
menus.
Select.
Volume Keys
Left Soft Key Right Soft Key
Clear/Back Key
Camera Key
Voice Key
Microphone
Make sure your fingers
don’t cover the
microphone during calls.
4:56pm
Play/Pause
Skip Back/
Rewind
Skip Forward/
Fast Forward
Music Player Controls:
Camera
Lens
N
P
0
❙❙❙
1X
EV

2
Message ContactsMenu
Tue, May 16 2:11pm
OK
1. New Contact
2. Contact List
3. Groups
4. Speed Dials
CONTACTS
B
PP
NN
0
❙❙❙
0
❙❙❙
1X
EV
1X
EV
1
23
Press the center
key sto open the
Main Menu.
Press and hold the
Power Key P for a
few seconds or until
the display lights up to
turn on your phone.
4
Home Screen Main Menu
Press the center
key sto select.
Press the navigation
key Sleft/right to
highlight a menu option,
then down to highlight
a suboption.

3
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States for hearing
impaired)
1-800-461-4575 (Canada)
Certain mobile phone features are dependent on the
capabilities and settings of your service provider’s
network. Additionally, certain features may not be
activated by your service provider, and/or the provider's
network settings may limit the feature’s functionality.
Always contact your service provider about feature
availability and functionality. All features, functionality,
and other product specifications, as well as the
information contained in this user’s guide are based
upon the latest available information and are believed to
be accurate at the time of printing. Motorola reserves
the right to change or modify any information or
specifications without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in
the US Patent & Trademark Office. The Bluetooth
trademarks are owned by their proprietor and used by
Motorola, Inc. under license. All other product or service
names are the property of their respective owners.
© Motorola, Inc. 2007
Caution: Changes or modifications made in the
radio phone, not expressly approved by Motorola,
will void the user's authority to operate the
equipment.
Manual number: 6809501A99-B

4
contents
contents
menu map . . . . . . . . . . . 6
Use and Care . . . . . . . . . 8
essentials . . . . . . . . . . . . 9
about this guide. . . . . . . 9
battery . . . . . . . . . . . . . 10
turn it on & off . . . . . . . 13
make a call. . . . . . . . . . 13
answer a call . . . . . . . . 13
adjust volume . . . . . . . 14
change sounds
settings . . . . . . . . . . . . 14
store a phone number . 14
call a stored phone
number . . . . . . . . . . . . 15
see your phone
number . . . . . . . . . . . . 15
main attractions . . . . . 16
get & play music . . . . . 16
record & play voice
records . . . . . . . . . . . . 29
record & play video
clips . . . . . . . . . . . . . . . 30
take & send a photo . . 32
send a multimedia
(picture/video) message .
34
receive a multimedia
(picture/video) message .
37
download pictures . . . . 38
download V CAST
videos . . . . . . . . . . . . . 38
manage memory . . . . . 38
Bluetooth
connections . . . . . . . . . 41
cable connections . . . . 44
TTY operation . . . . . . . 44
basics . . . . . . . . . . . . . . 46
home screen . . . . . . . . 46
navigation key . . . . . . . 49
menus . . . . . . . . . . . . . 49
enter text. . . . . . . . . . . 51
external screen . . . . . . 55
handsfree speaker. . . . 55
standalone mode. . . . . 56
change a code, PIN,
or password. . . . . . . . . 57
lock/unlock phone . . . . 58
if you forget a code,
PIN, or password. . . . . 58
customize . . . . . . . . . . 59
sounds settings . . . . . . 59
get ringtones . . . . . . . . 61
talking phone settings . 61
answer options . . . . . . 61
wallpaper . . . . . . . . . . . 62

5
contents
screen saver . . . . . . . . 62
backlight . . . . . . . . . . . 63
brightness. . . . . . . . . . 63
AGPS & your location . 64
AGPS limitations
& tips . . . . . . . . . . . . . 65
calls . . . . . . . . . . . . . . . . 66
redial a number. . . . . . 66
automatic redial . . . . . 66
emergency calls . . . . . 66
use AGPS during
emergency call . . . . . . 67
recent calls . . . . . . . . . 68
return unanswered
calls . . . . . . . . . . . . . . 69
attach a number . . . . . 69
speed dial . . . . . . . . . . 69
voicemail . . . . . . . . . . 70
in-call options . . . . . . . 70
other features . . . . . . . . 71
advanced calling . . . . . 71
messages. . . . . . . . . . 72
contacts . . . . . . . . . . . . 74
personalizing
features . . . . . . . . . . . 77
call times & data
volumes . . . . . . . . . . . 83
handsfree . . . . . . . . . . 84
Bluetooth wireless
connections . . . . . . . . 85
data & fax calls . . . . . . 86
network . . . . . . . . . . . 86
personal organizer . . . 87
security. . . . . . . . . . . . 89
fun & games. . . . . . . . 89
service & repairs . . . . . 91
Specific Absorption
Rate Data
. . . . . . . . . . . 92
Safety and General
Information
. . . . . . . . . 96
Industry Canada
Notice to Users
. . . . . 101
FCC Notice To Users . 102
MotorolaLimited
Warranty for the
United States and
Canada
. . . . . . . . . . . . 103
HearingAid
Compatibility with
Mobile Phones
. . . . . . 107
Information from the
World Health
Organization
. . . . . . . . 108
California Perchlorate
Label
. . . . . . . . . . . . . . 110
Smart Practices
While Driving
. . . . . . . 111
index . . . . . . . . . . . . . . 113

6
menu map
menu map
main menu
B GET IT NOW*
• Music & Tones
• Picture & Video
•Games
•News&Info
• Tools on the Go
•Extras
C MESSAGING
•NewMsg
• Inbox
• Sent
•Drafts
•Voicemail
•E-mail*
• Mobile IM*
•Chat*
E CONTACTS
• New Contact
• Contact List
• Groups
• Speed Dials
A RECENT CALLS
•Missed
• Received
• Dialed
•All
•ViewTimers
D SETTINGS & TOOLS
(see next page)
* optional features
This is the standard main
menu layout. Your phone’s
menu may be a little different.

7
menu map
SETTINGS & TOOLS menu
My Account
Tools
• Voice Commands
• Calendar
•AlarmClock
• World Clock
• Notepad
• Calculator
Sounds Settings
•MasterVolume
• Call Sounds
• Alert Sounds
•KeypadVolume
• Service Alerts
•PowerOn/Off
• Alarm Sounds
• Talking Phone
Display Settings
• Banner
• Backlight
• Brightness
• Wallpaper
• Screensaver
• Display Themes
Phone Settings
• Standalone Mode
• Shortcut Key
• Language
• Location
• Security
• System Select
•NAMSelect
Call Settings
• Answer Options
• Auto Retry
• TTY Mode
• One Touch Dial
• Voice Privacy
• Data Settings
• DTMF Tones
Bluetooth
•AddNewDevice
Memory
• Save Options
• Phone Memory
•CardMemory
Phone Info
•MyNumber
•SWVersion
• Icon Glossary

8
Use and Care
Use and Care
Use and Care
To care for your Motorola phone, please keep it away from:
liquids of any kind dust and dirt
Don’t expose your phone to water,
rain, extreme humidity, sweat, or
other moisture.
Don’t expose your phone to dust, dirt,
sand, food, or other inappropriate
materials.
extreme heat or cold cleaning solutions
Avoid temperatures below
-10°C/14°F or above 45°C/113°F. To clean your phone, use only a dry soft cloth. Don’t use alcohol or other
cleaning solutions.
microwaves the ground
Don’t try to dry your phone in a
microwave oven. Don’t drop your phone.

9
essentials
essentials
about this guide
This guide shows how to locate a menu
feature as follows:
Find it: MENU ( s ) &ARECENT CALLS %Dialed
This means that, from the home screen:
1 Press the center key s to open the
menu.
2 Press the navigation key S left or right to
scroll to
ARECENT CALLS , and press the
center key
s to select it.
3 Press the navigation key S down to
scroll to
Dialed , and press the
center key
s to select it.
CAUTION: Before using the
phone for the first time, read the
Important Safety and Legal
Information
included in the gray-
edged pages at the back of this
guide.
symbols
This means a feature is network/
subscription dependent and may not
be available in all areas. Contact your
service provider for more
information.
This means a feature requires an
optional accessory.

10
essentials
battery
battery tips
Battery life depends on the network, signal
strength, temperature, features, and
accessories you use.
• Always use Motorola
Original batteries and
chargers. The warranty
does not cover damage
caused by non-Motorola batteries and/
or chargers.
• New batteries or batteries stored for a
long time may take more time to
charge.
• When charging your battery, keep it
near room temperature.
• When storing your battery, keep it
uncharged in a cool, dark, dry place.
• Never expose batteries to
temperatures below -10°C (14°F) or
above 45°C (113°F). Always take your
phone with you when you leave your
vehicle.
• It is normal for batteries to gradually
wear down and require longer charging
times. If you notice a change in your
battery life, it is probably time to
purchase a new battery.
Contact your local recycling center for
proper battery disposal.
Warning: Never dispose of batteries in a fire
because they may explode.
Before using your phone, read the battery
safety information in the “Safety and General
Information” section included in this guide.

11
essentials
install the battery
1
2
3
charge the battery
New batteries are shipped partially charged.
Before you can use your phone, you need to
install and charge the battery as described
below. Some batteries perform best after
several full charge/discharge cycles.
Note: When the battery is charging, the
phone automatically changes to the audible
Master Volume setting, regardless of which ring
style you have set. The phone changes back
to your selected ring style when you
disconnect the charger.
To charge usingthe charger:
1
Insert the
charger into the
USB connector
on your phone
as shown.

12
essentials
2 Plug the other end of the charger into the
appropriate electrical outlet.
The battery indicator
N flashes while
your phone is charging.
3 When your phone is turned on with the
charger attached, the charge complete
message will flash on the display for
two seconds and then the battery meter
symbol will stop flashing when your
phone is fully charged. If your phone is
turned off with the charger attached, the
charge complete message will stay on
the display when your phone is fully
charged. Remove the charger.
Tip: You can safely leave the charger
connected to the phone after charging is
complete. This will
not damage the battery.
When you charge the battery, the battery level
indicator in the upper right corner of the
display shows charging progress. At least one
segment of the battery level indicator must be
visible to ensure full phone functionality while
charging.
To charge from your PC, connect a cable
from your phone’s mini-USB port to a high-
power USB port on a computer (not a low-
power one such as the USB port on your
keyboard or bus-powered USB hub). Typically,
USB high-power ports are located directly on
your computer.
Both your phone and the computer must be
turned on, and your computer must have the
correct software drivers installed. Cables and
software drivers are available in Motorola
Original data kits, sold separately.

13
essentials
turn it on & off
1 Open your phone.
2 Press and hold
the power
key
P for
three seconds.
The phone may require several seconds to
power on.
3 If necessary, enter your four-digit unlock
code (the last four digits of your phone
number) and press
OK to unlock the
phone.
To turn off your phone, press and hold
O for
a few seconds.
make a call
Note: You must dial the phone number from
the home screen. See page 46.
1 Dial the number.
Tip: If you make a mistake, press the
clear key
B to delete the last digit. Press
and hold
B to clear all digits.
2 Press N to make the call.
3 Press P to end the call.
Tip: Closing the flip also ends the call unless
you are using the speakerphone feature (see
page 55).
answer a call
When you receive a call, your phone rings or
vibrates and displays an incoming call
message.
1 Press N to answer.
2 Press P to end the call.
Power
Key

14
essentials
Tip: You can set the phone to answer calls
when you open the flip:
Find it: MENU ( s ) &DSETTINGS & TOOLS
%Call Settings %Answer Options %Flip Open
Note: If the phone is locked, you must first
enter your four-digit unlock code to answer
the call.
adjust volume
Press the up or
down volume
keys to:
• increase or
decrease earpiece volume during a call
• increase or decrease ringer volume
setting when the home screen is
visible (phone must not be in a call and
flip must be open)
• silence an incoming call alert
change sounds settings
In the home screen,
press the down
volume key to
switch to lower call
sounds volume,
then switch to
Vibrate Only , then Alarm Only , and,
finally,
All Sounds Off . Press the up volume key to
cycle back from silent to vibrate and then to
the lowest call volume setting.
store a phone number
You can store a phone number in Contacts :
1 Enter a phone number in the home
screen.
2 Press Save .
Select
New Contact , if necessary.
Volume
Keys
Volume
Keys

15
essentials
3 Enter a name and other details for the
phone number. To select a highlighted
item, press the center key
s .
4 Press Done to store the number.
To edit or delete a
Contacts entry, see page 74.
Tip: You can set your phone to display a
picture for each caller or set it to play a
ringtone for a specific caller each time they
call you (see “assign picture to entry” on
page 74 and “assign ringtone to entry” on
page 75).
call a stored phone
number
Find it: MENU ( s ) &nCONTACTS
1 Scroll to the Contacts entry.
2 Press N to call the entry.
see your phone number
To view your phone number from the home
screen, press
B# .
While you are on a call, press
Options . Select
Phone Info , then My Number , and then MDN .

16
main attractions
main attractions
You can do much more with your phone than
make and receive calls!
get & play music
Use the Music & Tones menu to:
• get new music and tones
• play music in your MUSIC LIBRARY
• record new sounds
• set music or tones as your ringtone
Tip: From the home screen (see page 46), get
to
Music & Tones quickly by pressing S left.
download V CAST music
directly to phone
1 Browse or search the catalog to find the
songs you want.
To preview a song, highlight the song and
select
Preview .
2 To buy a song, highlight the song and
select
Buy .
After your press
Buy your phone shows
song details and price.
3 Press BUY ( s ) to confirm your selection.
4 When you see a confirmation that your
purchase was successful and your music
is available for download, press
OK ( s ) to
continue, or choose to download later.

17
main attractions
5 When prompted to select a storage
location, scroll to
Phone Memory or Memory Card
and press the center key
s to begin
downloading.
Note: Your phone must be in an EVDO
coverage area to download music.
Your phone displays a status indicator.
After downloading, you must wait for the
phone to acquire the content license.
6 Press OK ( s ) when the download is
complete.
7 Press Play to play the downloaded song
immediately.
or
Press Library to go to the MUSIC LIBRARY (see
next section).
or
Press OK ( s ) to return to the previously
viewed music catalog.
transfer music from a
computer
You can transfer songs from a computer to
your phone with a USB cable connection. You
can purchase these songs from the V CAST
Music Store or import them from your CD
collection.
computer system requirements
To access the V CAST Music Store from a
computer or to transfer music from a
computer to your phone, you need the
Windows® XP operating system, Windows
Media Player 10, and an active internet
connection.
If you have the Windows XP operating
system and an internet connection, you can
download Windows Media Player 10 from the
V CAST web site:

18
main attractions
1 From your computer’s Web browser, go to
http://getitnow.vzwshop.com/
index.aspx&id=music_vcast_catalog
.
2 In the “Access the V CAST Music Store”
window, click on “DOWNLOAD NOW”.”
buy music from V CAST
Music Store
1 On your computer, launch Windows
Media Player.
2 In the Windows Media Player window,
click on the V CAST Music icon in the
upper right corner.
If you don’t see the V CAST Music icon,
click on the butterfly icon, then select
“V CAST Music” from the list.
3 Click the “Log In” button, then log in by
entering your mobile phone number and
password.
If you have not registered yet, click on the
“Register” button, then follow the
instructions to register and get your
password.
4 Browse or search the store to find the
songs you want.
To preview a song, click on the headset
icon next to the song title.
5 To buy a song, click the “Purchase” button
next to the song title.
6 Repeat steps 4 and 5 to add more songs
to your shopping cart.
7 When you finish shopping, click on “MY
PURCHASES,” then click on the
“DOWNLOAD” button to download your
songs.
When downloading is complete, click on the
“Library” tab in the Windows Media Player
window to see the songs you purchased.
