Motorola L6I User manual

motorola.com
L6i
GSM
English

1
HELLOMOTO
HELLOMOTO
Introducing your new Motorola L6i GSM wireless phone.
Here’s a quick anatomy lesson.
For Push to Talk (PTT) details, see page 59.
Left Soft Key
Navigate menus.
Select menu
items.
PTT/Smart Key
Right Soft Key
Turn on & off,
hang up, exit
menus.
Make & answer
calls.
Open menus.
Camera Key
Camera
Mini-USB Port
Charge up and
connect phone
accessories

2
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
Certain mobile phone features are dependent on the capabilities and
settings of your service provider’s network. Additionally, certain features
may not be activated by your service provider, and/or the provider’s
network settings may limit the feature’s functionality. Always contact your
service provider about feature availability and functionality. All features,
functionality, and other product specifications, as well as the information
contained in this user’s guide are based upon the latest available
information and are believed to be accurate at the time of printing.
Motorola reserves the right to change or modify any information or
specifications without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US Patent &
Trademark Office. The Bluetooth trademarks are owned by their proprietor
and used by Motorola, Inc. under license. Java and all other Java-based
marks are trademarks or registered trademarks of Sun Microsystems, Inc.
in the U.S. and other countries. All other product or service names are the
property of their respective owners.
© Motorola, Inc., 2006.
Caution: Changes or modifications made in the radio phone, not expressly
approved by Motorola, will void the user’s authority to operate the
equipment.

3
Software Copyright Notice
The Motorola products described in this manual may include copyrighted
Motorola and third-party software stored in semiconductor memories or
other media. Laws in the United States and other countries preserve for
Motorola and third-party software providers certain exclusive rights for
copyrighted software, such as the exclusive rights to distribute or
reproduce the copyrighted software. Accordingly, any copyrighted software
contained in the Motorola products may not be modified,
reverse-engineered, distributed, or reproduced in any manner to the extent
allowed by law. Furthermore, the purchase of the Motorola products shall
not be deemed to grant either directly or by implication, estoppel,
or otherwise, any license under the copyrights, patents, or patent
applications of Motorola or any third-party software provider, except for
the normal, non-exclusive, royalty-free license to use that arises by
operation of law in the sale of a product.

4
contents
contents
menu map . . . . . . . . . . . 6
Safety Information . . . . 8
EU Conformance. . . . . 15
Recycling Information 16
essentials. . . . . . . . . . . 17
about this guide. . . . . 17
SIM card . . . . . . . . . . 17
battery . . . . . . . . . . . . 18
turn it on & off. . . . . . 21
make a call . . . . . . . . 21
answer a call . . . . . . . 22
your phone number. . 22
main attractions . . . . . 23
take & send a photo . 23
record video . . . . . . . 25
FM radio . . . . . . . . . . 27
create & share media 29
cable connections . . . 31
Bluetooth™
wireless. . . . . . . . . . . 31
basics . . . . . . . . . . . . . . 36
display . . . . . . . . . . . . 36
menus . . . . . . . . . . . . 39
create SMS . . . . . . . . 41
volume . . . . . . . . . . . 46
navigation key . . . . . . 47
handsfree speaker . . 47
codes & passwords . 47
lock & unlock phone . 48
lock & unlock keypad 48
customize . . . . . . . . . . 49
ring style . . . . . . . . . . 49
time & date . . . . . . . . 50
wallpaper. . . . . . . . . . 50
screen saver . . . . . . . 51
display appearance . . 51
answer options . . . . . 52
calls . . . . . . . . . . . . . . . 53
turn off a call alert . . . 53
recent calls . . . . . . . . 53
redial . . . . . . . . . . . . . 54
return a call . . . . . . . . 55
notepad. . . . . . . . . . . 55
hold or mute a call. . . 55
call waiting . . . . . . . . 56
caller ID . . . . . . . . . . . 56
emergency calls . . . . 57
international calls . . . 57
1-touch dial . . . . . . . . 57
voicemail . . . . . . . . . . 58
push to talk (PTT) . . . 59

5
contents
other features . . . . . . . . 64
advanced calling . . . . . 64
phonebook . . . . . . . . . 66
messages . . . . . . . . . . 70
personalizing . . . . . . . . 72
call times & costs . . . . 74
handsfree . . . . . . . . . . 75
data & fax calls . . . . . . 76
network. . . . . . . . . . . . 77
personal organizer. . . . 78
security . . . . . . . . . . . . 79
fun & games . . . . . . . . 80
SAR Data . . . . . . . . . . . . 82
WHO Information . . . . . 84
index . . . . . . . . . . . . . . . 85

6
menu map
menu map
main menu
n Phonebook
s Recent Calls
• Received Calls
• Dialed Calls
• Notepad
•CallTimes*
• Call Cost
•DataTimes*
•DataVolumes*
e Messages
• Create Message
• Message Inbox
• Outbox
•Drafts
•MMSTemplates
•QuickNotes
• Browser Msgs
• Info Services
•Voicemail
É Tools
• SIM Tool Kit Apps*
• Calculator
• Datebook
• Shortcuts
•AlarmClock
• Dialing Services
• Fixed Dial
• Service Dial*
•QuickDial
• Voice Dial
Q Games & Apps
á Web Access
•Browser
• Web Shortcuts
• Stored Pages
•History
•GoToURL
•BrowserSetup
• Web Sessions*
h Multimedia
•Pictures
• Sounds
•Camera
• Videos
• Video Camera
•FMRadio
E Bluetooth Link
• Handsfree
• Device History
• Setup
w Settings
• (see next page)
* optional features
This is the standard main menu
layout. Your phone’s menu may be
a little different.

7
menu map
settings menu
l Personalize
• Home Screen
• Main Menu
•ColorStyle
• Greeting
• Wallpaper
• Screen Saver
t Ring Styles
•Style
• Style Detail
L Connection
• Bluetooth Link
•Sync
H Call Forward *
•VoiceCalls
• Fax Calls
• Data Calls
• Cancel All
• Forward Status
U In-Call Setup
•In-CallTimer
• Call Cost Setup
•MyCallerID
• Talk and Fax
• Answer Options
• Call Waiting
Z Initial Setup
• Time and Date
• 1-Touch Dial
• Display Timeout
• Backlight
• TTY Setup *
•Scroll
• Language
• Contrast
• Brightness
•DTMF
• Master Reset
•MasterClear
m Phone Status
• My Tel. Numbers
• Active Line *
• Battery Meter
• Software Update *
• Other Information
S Headset
• Auto Answer
•VoiceDial
J Car Settings
• Auto Answer
• Auto Handsfree
• Power-Off Delay
• Charger Time
j Network
• New Network
•NetworkSetup
• Available Networks
• My Network List *
• Service Tone
• Network Jingle *
• Call Drop Tone
u Security
• Phone Lock
• Lock Keypad *
• Lock Application
•FixedDial
• Restrict Calls
•CallBarring*
• SIM PIN
• New Passwords
• Certificate Mgmt *
6 PTT Settings
• PTT Service
c Java Settings
• Java System
• Delete All Apps
•AppVibration
•AppVolume
• App Backlight
* optional features

8
Safety Information
Safety and General Information
Safety Information
This section contains important information on the safe and
efficient operation of your mobile device. Read this information
before using your mobile device.
*
Exposure To Radio Frequency (RF) Energy
Your mobile device contains a transmitter and receiver. When it is ON,
it receives and transmits RF energy. When you communicate with your
mobile device, the system handling your call controls the power level at
which your mobile device transmits.
Your Motorola mobile device is designed to comply with local regulatory
requirements in your country concerning exposure of human beings to
RF energy.
Operational Precautions
For optimal mobile device performance and to be sure that human exposure
to RF energy does not exceed the guidelines set forth in the relevant
standards, always follow these instructions and precautions.
External Antenna Care
If your mobile device has an external antenna, use only a
Motorola-supplied or approved replacement antenna. Use of unauthorized
antennas, modifications, or attachments could damage the mobile device
and/or may result in your device not complying with local regulatory
requirements in your country.
* The information provided in this document supersedes the general safety
information in user’s guides published prior to May 1, 2006.

9
Safety Information
DO NOT hold the external antenna when the mobile device is IN USE.
Holding the external antenna affects call quality and may cause the mobile
device to operate at a higher power level than needed.
Product Operation
When placing or receiving a phone call, hold your mobile device just like
you would a landline phone.
If you wear the mobile device on your body, always place the mobile device
in a Motorola-supplied or approved clip, holder, holster, case, or body
harness. If you do not use a body-worn accessory supplied or approved by
Motorola, keep the mobile device and its antenna at least 2.5 centimeters
(1 inch) from your body when transmitting.
When using any data feature of the mobile device, with or without an
accessory cable, position the mobile device and its antenna at least
2.5 centimeters (1 inch) from your body.
Using accessories not supplied or approved by Motorola may cause your
mobile device to exceed RF energy exposure guidelines. For a list of
Motorola-supplied or approved accessories, visit our website at
www.motorola.com .
RF Energy Interference/Compatibility
Nearly every electronic device is subject to RF energy interference from
external sources if inadequately shielded, designed, or otherwise
configured for RF energy compatibility. In some circumstances your mobile
device may cause interference with other devices.
Follow Instructions to Avoid Interference Problems
Turn off your mobile device in any location where posted notices instruct
you to do so. These locations include hospitals or health care facilities that
may be using equipment that is sensitive to external RF energy.

10
Safety Information
In an aircraft, turn off your mobile device whenever instructed to do so by
airline staff. If your mobile device offers an airplane mode or similar
feature, consult airline staff about using it in flight.
Pacemakers
If you have a pacemaker, consult your physician before using this device.
Persons with pacemakers should observe the following precautions:
• ALWAYS keep the mobile device more than 20 centimeters
(8 inches) from your pacemaker when the mobile device is
turned ON.
• DO NOT carry the mobile device in the breast pocket.
• Use the ear opposite the pacemaker to minimize the potential
for interference.
• Turn OFF the mobile device immediately if you have any reason to
suspect that interference is taking place.
Hearing Aids
Some digital mobile devices may interfere with some hearing aids. In the
event of such interference, you may want to consult your hearing aid
manufacturer or physician to discuss alternatives.
Other Medical Devices
If you use any other personal medical device, consult your physician or the
manufacturer of your device to determine if it is adequately shielded from
RF energy.
Driving Precautions
Check the laws and regulations on the use of mobile devices in the area
where you drive. Always obey them.
When using your mobile device while driving, please:

11
Safety Information
• Give full attention to driving and to the road. Using a mobile device
may be distracting. Discontinue a call if you can’t concentrate
on driving.
• Use handsfree operation, if available.
• Pull off the road and park before making or answering a call if
driving conditions so require.
Responsible driving practices can be found in the “Smart Practices While
Driving” section at the end of this guide and/or at the Motorola website:
www.motorola.com/callsmart .
Operational Warnings
Obey all posted signs when using mobile devices in public areas, such as
health care facilities or blasting areas.
Automobile Air Bags
Do not place a mobile device in the air bag deployment area.
Potentially Explosive Atmospheres
Areas with potentially explosive atmospheres are often but not always
posted, and can include fueling areas such as below decks on boats, fuel or
chemical transfer or storage facilities, or areas where the air contains
chemicals or particles, such as grain, dust, or metal powders.
When you are in such an area, turn off your mobile device, and do not
remove, install, or charge batteries. In such areas, sparks can occur and
cause an explosion or fire.
Damaged Products
If your mobile device or battery has been submerged in water, punctured,
or subjected to a severe fall, do not use it until you take it to a Motorola
Authorized Service Center. Do not attempt to dry it with an external heat
source, such as a microwave oven.

12
Safety Information
Batteries and Chargers
If jewelry, keys, beaded chains, or other conductive materials touch
exposed battery terminals, this could complete an electrical circuit (short
circuit), become very hot, and could cause damage or injury. Be careful
when handling a charged battery, particularly when placing it inside a
pocket, purse, or other container with metal objects.
Use only
Motorola Original™ batteries and chargers.
Caution:
To avoid risk of personal injury, do not dispose of your battery in
a fire.
Your battery, charger, or mobile device may contain symbols, defined as
follows:
Symbol Definition
Important safety information
follows.
Do not dispose of your battery or
mobile device in a fire.
Your battery or mobile device may
require recycling in accordance
with local laws. Contact your local
regulatory authorities for more
information.
Do not throw your battery or
mobile device in the trash.
Your mobile device contains an
internal lithium ion battery.
Do not let your battery, charger,
or mobile device get wet.
Listening at full volume to music
or voice through a headset may
damage your hearing.
032374o
032376o
032375o
032378o
Li Ion BATT

13
Safety Information
Choking Hazards
Your mobile device or its accessories may include detachable parts,
which may present a choking hazard to small children. Keep your mobile
device and its accessories away from small children.
Glass Parts
Some parts of your mobile device may be made of glass. This glass could
break if the product is dropped on a hard surface or receives a substantial
impact. If glass breaks, do not touch or attempt to remove. Stop using your
mobile device until the glass is replaced by a qualified service center.
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts when
exposed to flashing lights, such as when playing video games. These may
occur even if a person has never had a previous seizure or blackout.
If you have experienced seizures or blackouts, or if you have a family
history of such occurrences, please consult with your physician before
playing video games or enabling a flashing-lights feature (if available) on
your mobile device.
Discontinue use and consult a physician if any of the following symptoms
occur: convulsion, eye or muscle twitching, loss of awareness, involuntary
movements, or disorientation. It is always a good idea to hold the screen
away from your eyes, leave the lights on in the room, take a 15-minute
break every hour, and stop use if you are very tired.
Caution About High Volume Usage
Listening at full volume to music or voice through a headset may
damage your hearing.

14
Safety Information
Repetitive Motion
When you repetitively perform actions such as pressing keys or entering
finger-written characters, you may experience occasional discomfort in
your hands, arms, shoulders, neck, or other parts of your body. If you
continue to have discomfort during or after such use, stop use and see
a physician.

15
EU Conformance
European Union Directives
Conformance Statement
EU Conformance
Hereby, Motorola declares that this product is in compliance
with:
• The essential requirements and other relevant provisions of
Directive 1999/5/EC
• All other relevant EU Directives
The above gives an example of a typical Product Approval Number.
You can view your product’s Declaration of Conformity (DoC) to Directive
1999/5/EC (to R&TTE Directive) at
www.motorola.com/rtte .
To find your DoC, enter the product Approval Number from your product’s
label in the “Search” bar on the Web site.
IMEI: 350034/40/394721/9
0168
Type: MC2-41H14
Product
Approval
Number

16
Recycling Information
Recycling In formation
Caring for the Environment by
Recycling
When you see this symbol on a Motorola product, do not dispose
the product with household waste.
Recycling Mobile Phones and
Accessories
Do not dispose of mobile phones or electrical accessories, such as chargers
or headsets, with your household waste. In some countries or regions,
collection systems are set up to handle electrical and electronic waste
items. Contact your regional authorities for more details. If collection
systems aren’t available, return unwanted mobile phones or electrical
accessories to any Motorola Approved Service Centre in your region.

17
essentials
essentials
about this guide
This guide shows how to locate a menu feature as follows:
Find it: Press - > Recent Calls > Dialed Calls
This example shows that, from the home screen, you press
- to open the menu, scroll to and select sRecent Calls ,
then scroll to and select
Dialed Calls .
Press the navigation key
S to scroll to a menu feature.
Press the center key
s to select the highlighted menu
feature.
SIM card
You r Subscriber Identity Module (SIM) card contains personal
information like your phone number and phonebook entries.
Caution: Don’t bend or scratch your SIM card. Keep it away
from static electricity, water, and dirt.
symbols
This means a feature is network, SIM card,
or subscription dependent and may not be available
in all areas. Contact your service provider for
more information.
This means a feature requires an optional accessory.

18
essentials
battery
battery tips
Battery life depends on the network, signal strength,
temperature, features, and accessories you use.
• Always use Motorola Original batteries and
chargers. The warranty does not cover
damage caused by non-Motorola batteries
and/or chargers.
12
34
5
