Motorola SURFboard SVG2501 User manual

SURFboard®SVG2501
Wireless Voice Gateway
IP telephony, high-speed data with router and firewall,
integrated field-replaceable Lithium-ion battery backup, and
a wireless access point converge in one convenient package.

Seamless Mobility in a Stylish Package
Seamless Mobility in a Stylish Package
Show your premium customers that you appreciate their business
and you are serious about yours. Designed for seamless mobility,
Motorola’s SURFboard SVG2501 Wireless Voice Gateway is a
fully integrated telecommunications solution that combines the
functionality of a cable modem, embedded Multimedia Terminal
Adapter (eMTA), four-port router with advanced firewall, an
802.11b/g wireless access point, and an integrated field-replaceable
Lithium-ion backup battery—all in one convenient, sleek, stylish
package for the sophisticated consumer.
The SVG2501 is an advanced, integrated, and robust residential
and commercial telecommunications solution, ideal for seamless
mobility and PacketCable™ Multimedia (PCMM) architectures.
The SVG2501 combines all the IP functionality today’s consumers
demand, in a single compact and stylish unit.
High-Speed Internet Access
High-Speed Internet Access
Four 10/100 Ethernet RJ-45 ports, an integrated DOCSIS 2.0 cable
modem, and an integrated 802.11b/g wireless access point on the
full-featured home network router provide both high-speed Internet
access and a single platform for home networking, eliminating the
need for stand-alone routers, hubs, and access points.
Digital Voice Telephone Service
Digital Voice Telephone Service
The SVG2501 delivers up to two lines of primary-line digital voice
telephone service (terminating in RJ-11 connectors) over cable’s
broadband connection to the home. Voice traffic is prioritized
over Internet traffic, giving the user high-quality voice calls, even
while surfing the Web. The SVG2501 also supports a variety of rich
CLASS features, such as caller ID, call waiting, three-way calling,
and call forwarding.
Wireless Gateway
Wireless Gateway
An 802.11b/g/e/i wireless gateway allows consumers to
network computers, gaming consoles, and other peripherals
anywhere in the home.
With Motorola’s SURFboard integrated home networking
CPE solutions, cable operators can now offer a complete
provisioning, configuration, management, and support
system for their customers—from the gateway to the
desktop and beyond.
SURFboard SVG2501 Wireless Voice Gateway
Motorola’s SVG2501 SURFboard Wireless Voice Gateway provides cable
operators with an intelligent way to offer their customers high-speed data,
landline, and mobile telephone services and an enhanced home network
experience using a single broadband communication solution.

User-friendly Installation
Motorola’s integrated SVG2501 includes stateful firewall protection
and WEP (Wired Equivalency Privacy). The SVG2501 is also equipped
with a built-in, easy-to-use Motorola Wi-Fi installation wizard -- a ‘zero-
touch’ auto Wi-Fi provisioning tool -- which seamlessly configures
a secure Wi-Fi connection on a user’s machine. When the Wi-Fi
wizard is finished, a secure WPA (Wi-Fi Protected Access) encrypted
wireless connection is established to the gateway, protecting the
user’s machine from hacker attacks. Motorola’s embedded software
enables Wi-Fi deployments with high levels of quality, reliability, and
customer satisfaction, with low operational and support costs for
the MSO.
Service Assurance
Supporting the Wi-Fi home network is a new challenge for the cable
industry. As the leading worldwide provider of DOCSIS®products,
Motorola is helping ease cable operators into Wi-Fi delivery. By
combining the highest-performing and lowest cost of ownership
modems in the industry, with easy-to-use Wi-Fi installation and
pairing tools as well as advanced remote management features,
the SVG2501 is offering an all-in-one approach to broadband home
networking. In addition, Motorola’s field-proven NBBS device
management software platform provides the MSO with intelligent
management, auto-provisioning, and remote management features
to improve accuracy, efficiency, and customer satisfaction. These
value-adding features enable remote device administration for
improved accuracy and reduced support costs. The SVG2501 is
compatible with Motorola’s NBBS scalable, carrier-grade software
platform that enables cable operators to remotely access, configure,
monitor, and troubleshoot their full portfolio of consumer devices,
home networks, and services.With Motorola’s integrated SURFboard
home networking CPE solutions and our advanced Remote Device
Management Software Platform, cable operators can now offer
their high-ARPU subscribers a complete customer care solution —
provisioning, configuration, management, and support — from the
gateway to the desktop and beyond.
SURFboard SVG2501 Wireless Voice Gateway
Highlights1
Ease of use
Plug and play installation
Front-panel LEDs for power, data activity, and voice
Intuitive, Web-based diagnostics for quick and easy
troubleshooting
Versatile and convenient
Four 10/100 Ethernet (RJ-45) ports enable flexible,
high-speed connectivity
Integrated 802.11b/g wireless access point and up
to two lines (RJ-11) of full-featured telephone service
provide maximum convenience in a small footprint
Advanced router and firewall
Reliable
Power management enhancements optimize
Wi-Fi handset battery performance
Integrated field-replaceable Lithium-ion backup
battery
Expandable
Features up to 16 Service Identifiers (SIDs) for future
expansion of enhanced features
Remote configuration and monitoring
Help to reduce support costs and aid troubleshooting
DOCSIS / Euro-DOCSIS 2.0 and PacketCable /
Euro-PacketCable 1.0 certified; interoperable with
DOCSIS / Euro-DOCSIS 1.0 and 1.1 and compatible
with PacketCable / Euro-PacketCable 1.5; SIP;
CableHome™ 1.1 optional
Signaling
Support for Network Call Signaling (NCS) and
Session Initiation Protocol (SIP)
Telephony
Support for G.711 as well as multiple low-rate
vocoders
Automatic fax modem processing, including support
for T.38 protocol
Telco interfaces configurable to meet multiple market
standards

SURFboard SVG2501 Wireless Voice Gateway
Enhanced Power Management
The SVG2501 offers a number of power management features,
including 802.11e U-APSD (WMM Power Save), which enable
users to optimize the battery life of their Wi-Fi handset.
A highlight of the 802.11e power management standard is
the synchronization between the SVG2501 and the Wi-Fi
handset. The Wi-Fi handset receives data from the SVG2501 at
infrequent intervals, allowing it to enter sleep mode when the
phone is not in use, thereby minimizing the phone’s “on-time”
and improving its battery utilization.
Built-In Security
The SVG2501 is equipped with a number of security features,
including:
802.11i security (WEP-64/128, WPA-PSK, WPA, WPA2, TKIP,•
AES, 802.1x)
802.11i (pre-authentication)•
IPSEC/PPTP/L2TP NAT pass-through for VPN tunneling•
Wi-Fi–Protected Setup• ™ (WPS)
User-friendly, secure mobile pairing•
Wi-Fi Wizard removes end-user complexity for secure○
PC client setup
Push button configuration for WPS compliant clients○
Provider Benefits
Single-infrastructure delivery of multiple
services
One infrastructure for communication
services, providing the ability to offer
customers both residential and cellular
phone service, simultaneous use of phone
lines and high-speed data services, and a
single bill for their voice and data services.
Better coverage for more satisfied
customers
Increased customer satisfaction from
improved in-home coverage, a key user
network quality metric.
Value-added service packages
Improved customer retention through
unique value-added services and the
packaging of mobile and landline phone
services.
Flexible pricing options
Greater pricing flexibility resulting from
multi-service packaging and migration
of customers to higher-revenue/-margin
wireless offerings.
All-in-one solution for secure voice and
data services
A single product solution with support for
a variety of CLASS features provided today
by the phone company (e.g., caller ID, call
waiting, and call forwarding), advanced
routing features, and an integrated firewall
to help provide Internet security.
Consumer Benefits
Lower-cost cellular calls
Reduced cellular bill resulting from off-
loading the cellular air-interface when calls
are made from the Wi-Fi handset in the
home through the SVG2501.
Better Wi-Fi and cellular coverage
Improved in-home coverage and reliability,
which is often limited with cellular service.
Higher-quality cellular
Wireline audio quality when passed over
the SVG2501’s Wi-Fi connection.
One-number convenience
Convenience of a single mobile number
and voicemail service, whether inside or
outside the home.
M
t

M
otorola b
el
el
ie
ie
ve
ve
s
s
in
n
“going green”
—
we have a global
co
mm
m
it
it
m
me
nt
t
t
o su
st
ai
ai
ni
ni
ng
ng
t
h
e env
i
ronment.
Mo
Mo
to
o
ro
ro
la
la
h
h
as
as
b
b
b
ee
ee
n
n
working
f
or years to continually improve our
e
nvironmental
p
ro
f
ile. We are in ste
p
with our customers and
th
e
i
r
i
ncreas
i
n
g
i
nterest
i
n
p
artner
i
n
g
w
i
t
h
a com
p
an
y
t
h
at w
ill
help them reduce their carbon footprint, while offering compelling
p
roducts that will hel
p
them
g
row their eco-conscious customer
b
ase.
M
otorola desi
g
ned the SVG2501 to minimize its
i
mpact on the environment
.
M
otorola’s
g
atewa
y
s com
p
l
y
with international environmental
and energy e
ff
icient standards, including
E
NER
G
Y
S
TARquali
f
ied
po
o
we
w
r su
pp
p
lies, California Efficienc
y
Com
p
liance for the
p
ower
su
su
pp
pp
ly
ly
,
,
Eu
E
ro
o
pe
pe
an
an
C
C
od
e
e
of
f
C
C
on
o
du
ct
t
com
pl
p
ia
nc
c
e
fo
o
r
bo
th
t
t
he
p
ow
w
er
e
su
su
pp
pp
lyly
a
a
ndnd
mm
odod
emem
,
,
anan
dd
lele
adad
-f-f
rere
ee
ci
ci
rcrc
uiui
t
t
bobo
ar
ar
dsds
,
,
as
as
cc
er
er
ti
ti
fifi
eded
b
b
yy
Ro
HS
H
c
c
om
p
l
ia
ia
nce
.
P
acka
g
in
g
T
he SVG2501 uses Motorola’s new, environmentall
y
friendl
y
p
ac
k
a
g
e
d
es
ig
n; our
g
atewa
y
ss
hip
i
n s
i
n
gl
e
p
ac
k
b
oxes.
By
b
ot
h
eli
m
i
nat
i
ng t
h
e suspens
i
on p
l
ast
i
c an
d
re
d
uc
i
ng t
h
e
b
ox s
i
ze,
M
otorola is he
lp
in
g
to reduce the environmental im
pa
ct o
f
the
S
V
G
2501. As an even more i
mp
actful ste
p,
o
pe
rators m
ay
choose
t
o rece
i
ve t
h
e pro
d
ucts
i
na
b
u
lk
pac
k
age, t
h
us re
d
uc
i
ng t
h
eextra
wa
w
st
e
e
an
an
d
d
tr
an
n
sp
sp
ort wei
g
ht associated with sin
g
le
p
ack
ag
g
es
s
..
Mo
Mo
to
to
ro
ro
la
la
’s
’s
ss
in
in
glgl
ee
anan
d
d
bu
bu
lk
lk
p
p
ac
ac
ka
ka
gi
gi
ng
ng
s
s
ol
ol
ut
ut
io
io
ns
ns
e
e
li
li
mi
mi
na
na
te
te
e
e
xc
c
es
es
s
s
U
SB
ca
c
bles.
Ad
d
di
d
tionally, customers have the
o
pt
pt
io
io
n
n
to
to
r
r
ed
ed
uc
uc
e the
number o
f
cables shi
pp
ed with each
u
ni
t.
t
T
T
he
he
p
p
ac
ac
k
ka
gi
ng
is 100%
re
cy
clable.
O
ur
pa
ck
ag
in
g
is now labeled with standard rec
yc
li
ng
c
o
d
es
(
suc
h
as
)
to make it easier
f
or our customers to identi
f
y
rec
y
clin
g
g
op
op
po
po
rt
rt
un
un
it
it
ie
ie
s
s.
SURFboard SVG2501 Wireless Voice Gateway

STARLINE MBN100 1 GHz Optical Node
Specifications
SURFboard SVG2501 Wireless Voice Gateway
GENERAL
Standards DOCSIS 2.0 and PacketCable
1.0 certified; interoperable with
DOCSIS 1.0 and 1.1 and
compatible with Packet
Cable 1.5; SIP; CableHome 1.1
optional
Cable Interface F-Connector, female, 75 Ω
Network Interface Four 10/100 Ethernet
ports
Wireless Interface 802.11b/g Wi-Fi
Dimensions 9.2 in H x 1.5 in W x 6.1 in D
(23.4 cm x 3.81 cm x 15.6 cm)
Regulatory RoHS compliant, FCC, UL
listed (U.S. and Canada),
Industry Canada, ENERGY
STAR qualified, CoC compliant
INPUT POWER
North America 105 to 125 VAC, 60 Hz
Outside North America 100 to 240 VAC, 50 to 60 Hz
ENVIRONMENTAL
Operating Temperature 32 °F to 104 °F (0 °C to 40 °C)
Storage Temperature
Without Battery –22 °F to 158 °F (–30 °C to
70 °C)
With Battery –14 °F to 140 °F (–10 °C to
60 °C)
Store replacement batteries at 25 °C for optimal
storage life
Operating Humidity 5 to 95% R.H.
(non-condensing)
DOWNSTREAM
Modulation 64 or 256 QAM
Maximum Data Rate* 38 Mbps (256 QAM at
5.361 Msym/s)
Bandwidth 6 MHz
Symbol Rates 64 QAM @ 5.069 Msym/s,
256 QAM 5.361 Msym/s
Operating Level Range –15 to +15 dBmV
Frequency Range 88 to 860 MHz
Input Impedance 75 Ω(nominal)
UPSTREAM
Modulation 8***, 16, 32***, 64***,
128*** QAM or QPSK
Maximum Channel Rate 30 Mbps**
Bandwidth 200 kHz, 400 kHz, 800 kHz,
1.6 MHz, 3.2 MHz, 6.4 MHz***
Symbol Rates 160, 320, 640, 1280, 2560, and
5120*** ksym/s
Operating Level Range
A-TDMA 8 to 54 dBmV (32 QAM, 64
QAM)
8 to 55 dBmV (8 QAM, 16
QAM)
8 to 58 dBmV (QPSK)
S-CDMA 8 to 53 dBmV (all modulations)
Output Impedance 75 Ω(nominal)
Frequency Range 5 to 42 MHz (edge to edge)
TELEPHONY
Line Type 2-wire
Hook State Signaling Loop start
Maximum Line Length
(one-way) 500 ft (AWG 26/0.4 mm @ 65
°C)
DTMF Level Sensitivity Range 0 and –20 dBm
Speech Coding 64 kbps PCM, μ-law or A-law
companding; support for G.711,
G.726, G.728, G.729, G.723.1,
iLBC, and BV16/32 codecs
Line Termination Configurable based on market
needs
Loss Plan
Receive (D/A) 4 dB
Transmit (A/D) 2 dB (configurable based
on market needs)
Loss Plan Tolerance ±1 dB; 60/50 Hz loss >20 dB
(one-way; referenced to off-
hook loss at 1,004 Hz)
Ringing Wave Form Quasi-trapezoidal
Ringing Crest Factor 1.2 <CF <1.6
NETWORK
Gateway DHCP, NAT, VPN tunneling;
static routing and dynamic IP
routing (RIPv1, RIPv2); SPI
firewall with DoS protection
and intrusion prevention; port,
packet, and URL keyword
filtering; full suite of ALGs;
UPnP IGD 1.0
Wireless LAN 802.11b/g Wi-Fi, WDS bridging,
802.11e WMM admission
control, QoS
Power Management 802.11e WMM power save/U-
APSD (Unscheduled-Automatic
Power Save Delivery)
802.11i Security WEP-64/128, WPA-PSK, WPA,
WPA2, TKIP, AES, 802.1x,
802.11i (pre-authentication)
Mobile Pairing User-friendly Wi-Fi–protected
setup (WPS) for secure mobile
pairing with compatible dual-
mode handset
Regulatory Domains To include US, Canada, ETSI,
World
Transmit Power Output
IEEE 802.11b 19 dBm +1/–1.5 dB at all rates
in all channels
IEEE 802.11g 16 dBm +1/–1 dB at 54 Mbps
in all channels
Receiver Sensitivity > –90 dBm at 11 Mbps;
> –74 dBm at 54 Mbps
Product features may vary by model type.
All features, functionality, and other product specifications are
subject to change without notice or obligation.

SURFboard SVG2501 Wireless Voice Gateway
Plug-and-play
Simple to set up and easy to use—just plug it in and go.
1Certain features may not be activated by your service provider, and/or their network settings may limit the feature’s functionality. Additionally, certain features may
require a subscription. Contact your service provider for details. All features, functionality, and other product specifications are subject to change without notice or
obligation. Your service provider, not Motorola, is responsible for the provision of Voice-over-IP (VoIP) telephony services through this equipment. Motorola shall not
be liable for, and expressly disclaims, any direct or indirect liabilities, damages, losses, claims, demands, actions, causes of action, risks, or harms arising from or
related to the services provided through this equipment. Important: Be aware that you will not be able to make any calls using this VoIP device if your broadband
connection is not functioning properly. Battery backup times may vary based on many factors, including the battery age, charging state, storage conditions, and
operating temperature, as well as by factors such as data activity and length of active telephone calls.

www.motorola.com/broadband
MOTOROLA and the Stylized M Logo are registered and the EcoMoto name and logo are trademarked in the U.S. Patent and Trademark Office. SURFboard is a registered
trademark of General Instrument Corporation, a wholly-owned subsidiary of Motorola, Inc. Wi-Fi and the Wi-Fi Alliance logo are registered marks and Wi-Fi Protected Setup is a
trademark of the Wi-Fi Alliance. DOCSIS and CableLabs are registered trademarks and PacketCable and CableHome are trademarks of Cable Television Laboratories, Inc. ENERGY
STAR is a registered mark owned by the U.S. government. Windows is a registered trademark and Vista is a trademark of Microsoft Corporation in the U.S. and/or other countries.
Linux® is a registered trademark of Linus Torvalds in the U.S. and other countries. UNIX is a registered trademark of the Open Group in the United States and other countries.
Macintosh is a registered trademark of Apple Computer, Inc. All other product or service names are the property of their respective owners.
© Motorola, Inc. 2009. All rights reserved.
569779-001-a 06/09
COMPLIANT
