Motorola PMLN6757 User manual

ADJUSTABLE D-STYLE
EARPIECE
WITH PUSH-TO-TALK (PTT)
AND MICROPHONE
PMLN6757
en-US
it-IT
de-DE
nl-NL pt-PT ru-RU
es-ES fr-FR
MN000356A01_aa.book Page 1 Monday, December 21, 2020 4:35 PM

1
English
Foreword
Radio-Frequency (RF) Energy Exposure and
Product Safety Guide for Portable Two-Way Radios
Attention!
This Adjustable D-Style Earpiece, when attached to the radio, is
restricted to occupational use only to satisfy the Federal
Communications Commission (FCC)/International Council on
Non-Ionizing Radiation Protection (ICNIRP) RF energy exposure
requirements. Before using this product, read the RF Energy
Exposure and Product Safety Guide that ships with the radio
which contains instructions for safe usage and RF energy
awareness and control for compliance with applicable standards
and regulation.
Acoustic Safety
Exposure to loud noises from any source for extended periods of
time may temporarily or permanently affect your hearing. The
louder the volume, the less time is required before your hearing
could be affected. Hearing damage from loud noise is sometimes
undetectable at first and can have a cumulative effect. To protect
your hearing:
• Use the lowest volume necessary to do your job.
• Turn up the volume only if you are in noisy surroundings.
• Turn down the volume before connecting headset or earpiece.
• Limit the amount of time you use headsets or earpieces at high
volume.
• When using the radio without a headset or earpiece, do not
place the radio speaker directly against your ear.
MN000356A01_aa.book Page 1 Monday, December 21, 2020 4:35 PM

2
English
Description
The PMLN6757 Adjustable D-Style Earpiece with Push-to-Talk
(PTT) and Microphone can be used when the operator would like
to conceal two-way radio usage from others. This earpiece
accessory is used in quiet environments to prevent others from
hearing radio transmission.
Note: The user is responsible to ensure that surveillance features
of the selected accessory are suitable for his/her intended
use.
Operating Instruction
1. Turn the radio off.
2. Attach the Adjustable D-Style Earpiece kit connector to the
radio and secure the connector as shown in Figure 1.
Figure 1: Attaching the Accessory Connector to the Radio
1
2
3
MN000356A01_aa.book Page 2 Monday, December 21, 2020 4:35 PM

3
English
3. Pull the rubber earloop to its largest size as shown in
Figure 2, and slip it over the ear.
Figure 2: Pulling the Rubber Earloop
4. Push in the earloop to adjust to a comfortable position.
5. Turn the radio on and adjust the audio volume to a
comfortable listening level.
Note: When earpiece is connected to the radio side connector,
radio speaker is muted, and audio is only heard from the
earpiece speaker.
6. Press the PTT button to transmit and speak into the earpiece
microphone in a normal manner.
7. Release the PTT button to receive.
8. Turn the radio off before removing the earpiece from the radio
side connector as shown in Figure 3.
MN000356A01_aa.book Page 3 Monday, December 21, 2020 4:35 PM

4
English
Figure 3: Detaching the Accessory Connector from the Radio
1
2
3
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M
logo are trademarks or registered trademarks of Motorola Trademark
Holdings, LLC and are used under license. All other trademarks are the
property of their respective owners.
© 2020 Motorola Solutions, Inc. All rights reserved.
