Motorola Pulse S505 Manual

en
read me rst

en Your headphones 1
Your headphones
Microphone
(on front)
/
_
+
R
L
Play/Pause
Music & Calls
Light
Volume &
Track Control
Power

2Step 1: Charge up & power on en
Step 1: Charge up & power on
Note: Before use, charge until the light turns green.
Power on.
Charge up.
Power
(Wall charger
not included.)

en Step 2: Get the right fit 3
Step 2: Get the right fit
Right-side
controls
Swivel
Adjustable
slider

4Step 3: Pair your headphones en
Step 3: Pair your headphones
Pair with Motorola Connect
Note: You can use this app on most devices with
Android 4.3 or later. If your device is not compatible
with Motorola Connect, follow the steps in “Pair with
Bluetooth™” on page 5.
1Download the free Motorola Connect app from
Google Play™ Store.
2Turn on your headphones.
3Open Motorola Connect, touch +, and select your
headphones from the list of devices.
Tip: You can also use Motorola Connect to check
your battery, see the last known location where you
connected, or get more help.

en Step 3: Pair your headphones 5
Pair with Bluetooth™
Pair without the Motorola Connect app.
1
Turn on Bluetooth on your device.
2
Turn on your headphones.
3
On your device, go to the Bluetooth
menu to pair & connect. Enter 0000
if prompted.
4
When the device and headphones
connect, you’ll hear a tone.
Headphones
light is solid
blue.
Headphones
light blinks
blue.

6Music en
Music
Note: Playing the next or previous track depends on
your phone’s music controls.
Volume down
+
Or press & hold to
play the next track.
Or press & hold to
play the last track.
Play/pause
music
Volume up

en Calls 7
Calls
Incoming call:
In a call:
Answer call.
Press & hold
either volume
button to
ignore a call.
End call.
Press + and - together
to mute or unmute.

8Voice Control en
Voice Control
This feature uses your phone’s voice control app.
Note: voice control may not work on some devices or
in all languages
Note: Using a mobile device or accessory while
driving may cause distraction and may be illegal.
Always obey the laws and drive safely.
Press & hold to
start voice control.

en Advanced 9
Advanced
Status Lights
On/Off fading blue
Pairing mode blinking blue
Connected solid blue
Low battery blinking red
Full charge solid green
Charging solid red

10 Advanced en
Charge level:
•Red: Low, 0-19%
•Yellow: Medium,
20-70%
•Green: High, 71-100%
Note: Your battery is designed to last the life of the
product. It should only be removed by a recycling
facility. Any attempt to remove or replace your
battery may damage the product and void your
warranty.
Press + and - together to
check the charge level
(while not in a call).

en Advanced 11
Reset
Turn off Bluetooth for all connected devices. Turn on
the headphones, then press and hold all three buttons
until the status light shows alternating red and blue.
You’ll hear a tone.
Press & hold
these three
buttons to reset.

12 Advanced en
Second device
Do you use a phone and a tablet? Connect with both
of them at the same time.
1Pair to your first device using the steps in “Pair
with Bluetooth™” on page 5.
2Turn off Bluetooth on your first device (your phone,
tablet, or computer).
3Turn off the headphones. Then turn them back on.
4Pair to your second device using the steps in “Pair
with Bluetooth™” on page 5.
5On your first device, turn Bluetooth back on to
connect to it simultaneously. You’ll hear a tone
when the first device connects.
Tip: To switch and play audio from the second
connected device, pause the current music device
and then press play on the second device.

en Help 13
Help
•Gethelp:Visit www.motorola.com/support.
• Find regulatory markings: carefully remove the
right earphone cover to expose the FCC and
other regulatory markings for your device.
MOTOROLA and the Stylized M Logo are trademarks or registered trademarks
of Motorola Trademark Holdings, LLC. All other product or service names are
the property of their respective owners.
© 2015 Motorola Mobility LLC. All rights reserved.
Caution: Motorola does not take responsibility for changes/modification to
the transceiver.
Bluetooth ID: D025976
Product ID: Model S505
Manual Number: 68017952002-A
