Motorola BMC9012 User manual

User Guide
BMC9012
Broadband
Media Center

Copyright © 2004 Motorola, Inc.
All rights reserved. No part of this publication may be reproduced in any form or by any means or used to make any derivative work (such
as translation, transformation or adaptation) without written permission from Motorola, Inc.
Motorola reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of
Motorola to provide notification of such revision or change. Motorola provides this guide without warranty of any kind, implied or expressed,
including but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Motorola may make
improvements or changes in the product(s) described in this manual at any time.
MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. Digeo, the Digeo logo, the Moxi logo and
combinations thereof are trademarks of Digeo, Inc. in the USA and other countries. All other product, service or brand names are the
property of their respective owners.
Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories.
This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this
copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited consumer uses
only, unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

BMC9012 User Guide
i
Graphical symbols and supplemental warning markings on bottom of terminal
WARNING
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION
TO PREVENT ELECTRICAL SHOCK, DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE, OR OTHER
OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point, within an equilateral triangle, is intended to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying the appliance.
INSTALLATION
This installation should be made by a qualified service person and should conform to all local codes.
This equipment operates over the marked Voltage and Frequency range without requiring manual setting of any selector
switches. Different types of line cord sets may be used for connections to the mains supply circuit and should comply with the
electrical code requirements of the country of use.
Coaxial Connections – To reduce the risk of fire, use only No. 26 AWG or larger coaxial cable or equivalent.
REPAIRS
If you find the unit in need of repair, contact your cable system operator for repair or replacement.
NOTE TO CATV SYSTEM INSTALLER
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper
grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close as
possible to the point of cable entry as practical.
EXAMPLE OF ANTENNA GROUNDING
EXAMPLE OF ANTENNA GROUNDING
Antenna lead
in wire
Ground
clamp
Antenna
discharge unit
(NEC Section 810-20)
Grounding conductors
(NEC Section 810-21)
Grounding
clamps
Power service grounding
electrode system
(NEC Article 250, Part H)
Electric service
equipment
NEC=NATIONAL ELECTRICAL CODE

Safety & Regulatory
ii
Important Safeguards
1 Read instructions
All the safety and operating instructions should be read before the appliance is operated.
2 Retain instructions
The safety and operating instructions should be retained for future reference.
3 Heed warnings
All warnings on the appliance and in the operating instructions should be adhered to.
4 Follow instructions
All operating and use instructions should be followed.
5 Cleaning
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
6 Attachments
Do not use attachments not recommended by the product manufacturer as they may cause hazards.
7 Water and moisture
Do not use this equipment near water; for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or
near a swimming pool, and the like.
8 Accessories
Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall causing serious injury and serious
damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the
equipment. Any mounting of the appliance should follow the manufacturer’s instructions, and should use a mounting accessory
recommended by the manufacturer.
9 Ventilation
Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the equipment and to protect it from
overheating. The openings should never be blocked by placing the product on a bed, sofa, rug, or similar surface. Equipment should
never be placed near or over a radiator or heat register, or in a built-in installation such as a bookcase or rack unless proper
ventilation is provided. See “BMC9000 Ventilation” in Chapter 2 for more information.
10 Power sources
This product should be operated only from the type of power sources indicated on the marking label. If you are not sure of the type of
power supplied to your home, consult your local power company. For equipment intended to operate from battery power, or other
sources, refer to the operating instructions.
11 Ground or polarization
This equipment may be equipped with a polarized alternating-current line plug (a plug having one blade wider than the other). This
plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try
reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
12 Power cord protection
Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.
13 Outdoor Antenna Grounding
If an outside antenna or cable system is connected to the equipment, be sure the antenna or cable system is grounded as to provide
some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70,
provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and
requirements for grounding electrode.
14 Lightning
For added protection for this equipment during a lightning storm, or when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the video product due to
lightning and power line surges.
15 Power lines
An outside antenna system should not be located in the vicinity of overhead power lines or where it can fall into such power lines or
circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits,
as contact with them may be fatal.
16 Overloading
Do not overload wall outlets and extension cords as this can result in a risk of fire or electrical shock.
17 Object and liquid entry
Never push objects of any kind into this equipment through openings as they may touch dangerous voltage points or short-out parts
that could result in a fire or electrical shock. Never spill liquid of any kind on the product.
18 Servicing
Do not attempt to service this equipment yourself as opening or removing covers may expose you to dangerous voltage or other
hazards, refer all servicing to qualified service personnel.

BMC9012 User Guide
iii
19 Damage requiring service
Unplug this equipment from the wall outlet and refer servicing to qualified service personnel under the following conditions:
! When the power supply cord or plug is damaged.
! If the equipment has been exposed to rain or water.
! If liquid has been spilled, or objects have fallen into the equipment.
! If the equipment does not operate normally by following the operating instructions. Adjust only those controls that are covered by
the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work
by a qualified technician to restore the equipment to its normal operation.
! If the equipment has been dropped or cabinet has been damaged.
! When the equipment exhibits a distinct change in performance, indicating a need for service.
20 Replacement parts
When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or
have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.
21 Safety check
Upon completion of any service or repairs to this video product, ask the service technician to perform safety checks to determine that
the product is in proper operational condition.
22 Heat
The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including
amplifiers) that produce heat.
23 Battery usage
Notwithstanding any information provided by Motorola in this manual regarding the use of batteries, the end user assumes all
responsibility and liability to use and dispose of batteries in accordance with all applicable laws, rules and regulations. Motorola will
not be liable to anyone for the end user's failure to use and/or dispose of batteries in the proper manner and in accordance with such
laws, rules and regulations, or for any defect contained in batteries that may cause injury damage to persons or property.
Usage Warnings
Avoid Damaging Your Television or Other AV Equipment
Do not use with certain televisions or equipment. Some televisions can be damaged if certain interactive television services or functions are
used, such as tickers and online video games that can remain static on your screen. Static images presented during the use of interactive
television services may "burn" into the screen, causing a permanent shadow of the static image to appear, even when such service or
feature is not used. Consult your television owner's manual to determine if such features and functions can be used safely on your set. If
you are unable to find this information in the owner's manual, contact your television dealer or the manufacturer to determine if such static
images will cause damage to your television. Before connecting or disconnecting any audio-visual (AV) device, make sure that the power to
the set- top box and to the AV device is turned off. This will reduce the risk of electrical damage to your equipment. To avoid damage to AV
equipment or to the set-top box, do not touch AV cord terminals or the set-top box's AV ports with your fingers or allow metal parts to touch
them.
Warning About Photosensitive Seizures
Exposure to certain visual images, including flashing lights or patterns that may appear in the use of online video games, each user
interface, the video phone (if available), and other functions/applications which may be included as part of your interactive television
service, can cause a very small percentage of people to experience a seizure. Even people without a history of seizures or epilepsy may
have an undiagnosed condition that can cause photosensitive epileptic seizures while watching or using video games. These seizures may
have a variety of symptoms, which may include eye or face twitching, lightheadedness, altered vision, shaking or jerking of arms or legs,
confusion or disorientation, or momentary loss of awareness. Seizures may also cause a loss of consciousness or convulsions that can
lead to injury from falling down or striking nearby objects. Immediately stop using the service and consult a doctor if you experience any of
these symptoms. Parents should watch for and ask their children about the above symptoms because children and teenagers are more
likely than adults to experience these seizures.
Taking the following precautions may reduce the risk of photosensitive epileptic seizures:
! Avoid using any such iTV features/services on large television screens
! View your television in a well-lit room
! Sit farther from the television screen
! Do not use any such iTV features/services when drowsy or tired
If you or any of your relatives have a history of seizures or epilepsy, consult a doctor before using the interactive television services.

Safety & Regulatory
iv
Regulatory Information
Federal Communications Commission Radio and Television Interface Statement for a Class ‘B’ Device
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in the residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If the equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one of the following measures:
! Re-orient or relocate the receiving antenna.
! Increase the separation between the equipment and receiver.
! Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
! Consult the dealer or an experienced radio/TV technician for help.
Changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.
Declaration of Conformity
According to 47 CFR, Parts 2 and 15 for Class B Personal Computers and Peripherals; and/or CPU Boards and Power Supplies used with
Class B Personal Computers, Motorola, Inc., 101 Tournament Drive, Horsham, PA 19044, declares under sole responsibility that the
product identifies with 47 CFR Part 2 and 15 of the FCC Rules as a Class B digital device. Each product marketed is identical to the
representative unit tested and founded to be compliant with the standards. Records maintained continue to reflect the equipment being
produced can be expected to be within the variation accepted, due to quantity production and testing on a statistical basis as required by 47
CFR 2.909. Operation is subject to the following condition: This device must accept any interference received, including interference that
may cause undesired operation. The above named party is responsible for ensuring that the equipment complies with the standards of 47
CFR, Paragraphs 15.107 to 15.109.
Canadian Compliance
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B est conforme ảla norme NMB-003 du Canada.

BMC9012 User Guide
1
Table of Contents
Introduction.........................................................................................................2
BMC9012 Features ..................................................................................................................... 2
BMC9012 Diagrams.................................................................................................................... 3
BMC9012 Front View ..............................................................................................................3
BMC9012 Back View .............................................................................................................. 3
Installation...........................................................................................................4
Ventilation Requirements ............................................................................................................ 4
Equipment Required ................................................................................................................... 5
BMC9012 Connection Procedure ............................................................................................... 5
Digital video/digital audio ........................................................................................................ 6
Digital video/composite audio ................................................................................................. 6
Component video/digital audio................................................................................................ 7
Component video/composite audio......................................................................................... 7
S-video/composite audio.........................................................................................................8
Composite video/audio ...........................................................................................................8
Basic coaxial (RF) video/audio ............................................................................................... 9
Hardware Installation Wrap-Up ...................................................................................................9
Audio Configuration................................................................................................................... 10
Video Configuration................................................................................................................... 10
Remote Control .................................................................................................12
Programming Procedure ...........................................................................................................12
Television Codes................................................................................................................... 13
Audio/Video Receiver Codes ................................................................................................ 16

Introduction
2
Chapter 1
Introduction
The Motorola Broadband Media Center (BMC) family of products delivers digital video and audio,
and a whole new experience in interactive cable television to your home. Finding what you want
to watch and watching it when you want has never been easier. The BMC9012 is simple to set up
and easy to operate.
This guide introduces you to the features and set up of your BMC. Please refer to your Viewer's
Guide to learn more about operating the BMC and some of the advanced features this model
provides.
BMC9012 Features
The following list contains features standard on the BMC9012.
Standard Features
! Dual analog/digital cable video tuners
! DOCSIS cable modem
! Integrated HDTV decoder
! Integrated Digital Video Recorder (DVR)
! High quality interactive graphics
! Standard RF and A/V outputs
! S-Video
! Component video (Y-Pr-Pb)
! Digital Video Interface (DVI)
! Digital audio (S/PDIF coaxial and optical)
! Two USB 1.1 and two USB 2.0 interfaces
! 10/100 Ethernet port
! Clock and channel display
! Front panel control buttons
Specifications
! Power supply: line input voltage 95V - 125V AC; frequency 57Hz - 63Hz
! USB power: two connectors front, 5V, 500mA max combined current
! USB power: two connectors rear, 5V, 500mA max combined current
! DVI power 5V, 100mA max current
! Operating temperature: 15°C - 40°C
! Dimensions (W x H x D): 17" x 3.3" x 12"
! Weight: approximately fifteen pounds

BMC9012 User Guide
3
BMC9012 Diagrams
The following illustrations show the BMC9012 front and back views. Slight variations may exist for
presentation purposes.
BMC9012 Front View
BMC9012 Back View

Installation
4
Chapter 2
Installation
This chapter contains information necessary to help you successfully disconnect, move, and
reconnect the cable connections between the BMC9012 and the TV. It also describes how to
confirm proper installation of the unit.
You won’t need any special tools to disconnect the BMC9012, although you may need a wrench
to loosen any tight connections. Make sure all coaxial connections are finger-tight secure, but not
so tight they cannot be undone with your fingers.
Warnings
!
Do not connect the BMC9012 unit to any switched power source.
! Use only the specified BMC9012 power cord labeled "For use with BMC9012 Only."
! Use the BMC9012 polarized power cord for the BMC9012 only.
! Keep the BMC9012 on, unless moving or servicing the unit. If power is removed, or a power
outage occurs, it will take several minutes after power is restored for the unit to resume
normal operations.
Ventilation Requirements
Allow adequate ventilation and airflow around the BMC9000 to prevent overheating.
Warnings
!
Cabinet installations must have open airflow or no doors.
! Vents must be unobstructed and open to ambient air.
! Ensure top, side, and back clearance of at least two inches.
! Keep away from other heat-generating devices.
Figure 1: BMC9000 Ventilation

BMC9012 User Guide
5
Equipment Required
! Three RCA male/male cables (two if the TV uses a DVI-D, component, or S-Video
connection)
! One RF coaxial cable
! DVI-D, component, or S-video cable (use best connection supported by TV)
! One S/PDIF audio cable, optical or coaxial (if available on TV or receiver)
See the wiring diagrams starting on page 6 for reference.
BMC9012 Connection Procedure
This section describes the possible installation scenarios for the BMC9012. Use the information in
this section and the accompanying wiring diagrams that follow to install the BMC9012.
The BMC9012 allows multiple types of audio and video connections. It is recommended that you
utilize the best connection that your TV and audio system supports. Refer to your TV’s and/or
audio device’s documentation for specific information on what they will support.
1. To begin, make sure the TV and the BMC9012 are off and all connections are unplugged.
2. Position the BMC9012 in a well-ventilated open area near the TV and/or audio receiver.
3. Connect the incoming cable supply to the BMC9012. Attach one end of the coaxial cable to
the wall port and the other end to the Cable In port of the BMC9012.
4. To connect audio and video cables, refer to the diagram and instructions applicable to your
installation. Choose from the following configurations:
For this configuration Go to
DVI-D + digital audio Figure 2, pg 6
DVI-D + composite audio Figure 3, pg 6
Component video + digital audio Figure 4, pg 7
Component video + composite audio Figure 5, pg 7
S-Video + composite audio Figure 6, pg 8
Composite video + composite audio Figure 7, pg 8
RF coaxial Figure 8, pg 9
Note To integrate additional devices into your configuration, such as a DVD player or VCR,
refer to the manufacturer’s documentation for each device.
Use the diagrams that follow to assist you in installing the appropriate audio and video
connections for the BMC9012.

Installation
6
Digital video/digital audio
1. Connect one end of the DVI-D cable to the DVI-D port of the BMC9012 and the other end to
the DVI-D In port of the TV or receiver.
2. Attach one end of the S/PDIF audio cable to the appropriate optical or coaxial S/PDIF port of
the BMC9012 and attach the other end to the S/PDIF in port of the TV or receiver.
3. Follow the instructions under Hardware Installation Wrap-up, starting on page 9.
Figure 2: DVI-D digital video with S/PDIF digital audio
Digital video/composite audio
1. Connect one end of the DVI-D cable to the DVI-D port of the BMC9012 and the other end to
the DVI-D In port of the TV or receiver.
2. Attach one end of the composite audio cables to the Left (L) and Right (R) audio outputs of
the BMC9012 and the other end to the respective Land Rinputs of the TV or receiver.
3. Follow the instructions under Hardware Installation Wrap-up, starting on page 9.
Figure 3: DVI-D digital video with composite audio

BMC9012 User Guide
7
Component video/digital audio
1. Connect component video cables from the Y, PB, and PRoutputs on the BMC9012 to the Y,
PB, and PRinputs on the TV or receiver.
2. Attach one end of the S/PDIF audio cable to the appropriate optical or coaxial S/PDIF port of
the BMC9012 and attach the other end to the S/PDIF in port of the TV or receiver.
3. Follow the instructions under Hardware Installation Wrap-up, starting on page 9.
Figure 4: Component video with S/PDIF digital audio
Component video/composite audio
1. Connect component video cables from the Y, PB, and PRoutputs on the BMC9012 to the Y,
PB, and PRinputs on the TV or receiver.
2. Attach one end of the composite audio cables to the Left (L) and Right (R) audio outputs of
the BMC9012 and the other end to the respective Land Rinputs of the TV or receiver.
3. Follow the instructions under Hardware Installation Wrap-up, starting on page 9.
Figure 5: Component video with composite audio

Installation
8
S-video/composite audio
1. Connect one end of the S-Video cable to the S-Video port of the BMC9012 and the other end
to the S-Video In port of the TV or receiver.
2. Attach one end of the composite audio cables to the Left (L) and Right (R) audio outputs of
the BMC9012 and the other end to the respective Land Raudio inputs of the TV or receiver.
3. Follow the instructions under Hardware Installation Wrap-up, starting on page 9.
Figure 6: S-video with composite audio
Composite video/audio
1. Attach one end of a composite cable to the video (V) output of the BMC9012 and the other
end to the Video In port of the TV or receiver.
2. Attach one end of the composite audio cables to the Left (L) and Right (R) audio outputs of
the BMC9012 and the other end to the respective Land Rinputs of the TV or receiver.
3. Follow the instructions under Hardware Installation Wrap-up, starting on page 9.
Figure 7: Composite video/audio

BMC9012 User Guide
9
Basic coaxial (RF) video/audio
1. Attach one end of the coaxial cable to the To TV port on the BMC9012 and the other end to
the Cable/Antenna In port of the TV. This connection provides both audio and video signals.
2. Follow the instructions under Hardware Installation Wrap-up, starting on page 9.
Figure 8: Basic RF coaxial connection
Hardware Installation Wrap-Up
The following procedures walk you through a final inspection and power-up of the system, and
then show you how to configure the system software. Also, depending on the type of TV and
connection used, you may need to tune the TV to the proper channel or set the video input
source. Refer to your TV user manual for details.
To complete the hardware installation
1. Verify that all cable connections are tight and secure, all coaxial connections are finger-tight
and properly seated, and that all RCA-style plugs are fully seated.
2. Ensure that nothing blocks the vents of the BMC9012 and other equipment.
3. Plug the TV power cord into the wall outlet.
4. Attach one end of the power cable to the BMC9012 Power port and plug the other end into
the wall outlet. Then turn on the BMC9012 by pressing and releasing the Reset switch
located on the right-hand side of the front panel.
Note Once the BMC9012 is turned on, you never need to turn it off. Unless you are
moving it or having it serviced, you should leave it powered on at all times to
ensure that scheduled recordings are not interrupted.
While the BMC9012 starts up, a sequence of numbers may appear on the front panel display
(where the time is normally shown). This display is designed to help troubleshoot the system. If
the BMC9012 is unable to complete the startup process, please note the number shown on the
display and refer to this number when speaking with your cable provider's customer support line.
The Moxi splash screen indicates a successful installation. Allow the unit approximately three
minutes to fully start, and then configure the audio and video software settings using the
information in the next two sections.

Installation
10
Audio Configuration
When your cable company installs your system, they configure your audio setting for you.
However, if you upgrade or change your sound system, you’ll need to reconfigure the Media
Center’s audio output also.
To configure the Media Center’s audio settings
1. Press the MOXI button on the remote to bring up the Moxi Menu.
2. Go to Settings and choose Digital Audio.
3. Bring the desired setting into center focus and press OK to select it.
4. Choose one of the following:
! Choose Dolby Digital for digital audio support if your system uses an S/PDIF connection
! Choose Stereo for a typical Red/White dual composite cable connection
! Choose TV if your system uses a direct RF coaxial cable to connect directly to your TV
The following table represents the audio format supported by each type of physical connection
available on the BMC9012.
Audio connections: supported formats
Audio connection Supported audio
Stereo Dolby Digital
S/PDIF audio ##
Composite audio (L/R) #
RF coaxial cable #
Video Configuration
To configure the Media Center’s video settings
1. Press the MOXI button on the remote to bring up the Moxi Menu.
2. Go to Settings and choose Video Output.
3. Bring one of the following settings into center focus and press OK to select it.
! 1080i: If you have a high-definition (HD) compatible TV connected by a DVI-D or
Component (Y, Pb, Pr) cable, then select the 1080i setting.
! 480p/720p: If your TV does not support 1080i, but supports other high-resolution
settings, then you can select 480p or 720p. Keep in mind that you must use a DVI-D or
Component cable connection to support settings above 480i (see table on the following
page).
! S-Video/RCA (default setting): If your TV does not support high-definition settings, and it
is connected by an S-video cable, composite video cable (the yellow-tipped RCA cable),
or a basic coaxial (RF) cable, then select the S-Video/RCA option. This option supports
resolutions up to 480i.
! See your TV’s user manual for the setting that is right for your TV.

BMC9012 User Guide
11
4. When you select a video output setting, Moxi tries that setting for you.
a. If you are switching between RF/composite/S-video and component/DVI-D input
connections, you may need to switch your TV's input to match the new setting. Once you
see the new setting display correctly, you'll need to switch back to the original connection
in order to confirm the new setting in the Moxi Menu. Once confirmed, you can return to
the new connection and TV input setting for normal viewing.
b. If you are not switching between RF/composite/S-video and component/DVI-D
connections, you may be able to confirm the new setting without changing TV inputs.
5. If you select a setting that is not supported, your screen may appear unreadable. Moxi reverts
to your previous video output setting after 20 seconds if you don't confirm the new one.
The following table lists the video resolutions supported by each type of physical connection
available on the BMC9012:
Video connections: supported resolutions
Connection Supported resolution
480i 480p 720p 1080i
DVI-D digital video ###
Component video ###
S-video #
Composite video #
RF coaxial cable #
TIP The “p” and “i” designations in the resolution settings above stand for “progressive” and
“interlaced.” The 480p and 480i formats are called the SD (standard definition) formats,
and 480i is roughly equivalent to a normal analog TV picture. When analog TV shows are
broadcast on digital TV stations, they are broadcast in 480p or 480i. The 720p, 1080i and
1080p formats are HD (high definition) formats. When you hear about “HDTV,” this is
what they are talking about.

Remote Control
12
Chapter 3
Remote Control
The Moxi remote control allows you to access, control, and enjoy the
many features of your BMC9012. You can also use this remote control
as the primary remote control for many brands of TVs and audio
devices. Instructions in this chapter show you how. Refer to the
accompanying Viewer Guide for explanations of the buttons.1, 2
Figure 9: Moxi remote Control
Programming Procedure
The Moxi remote control will operate the BMC9012, and once
programmed, will simultaneously control the power, volume, and mute
functions of your TV or audio receiver. Use the following instructions to
program the remote control.
From the tables on the following pages, find the code(s) for your brand
of TV or audio receiver and use this information with the “Programming
by Code” procedure below. However, if your brand is not listed, or the
given codes do not work, then go to “Programming by Search”
procedure on page 13.
Programming by Code
1. Turn on the TV or receiver that you want to control.
2. On the remote control, press and hold the MOXI and OK buttons
simultaneously until the LED light on the top blinks twice.
3. Enter one of the device codes from the reference tables and press OK. The LED will blink
twice. (If the LED blinks once, the code was invalid—try again.)
4. Press the Power button on the remote to test device control. If the device does not respond
try a different code, by starting again from step 3. Repeat until successful, or go to the next
procedure.
Note To factory reset the remote, type code 9 9 9 9 and press OK in step 3 above.
1Your cable operator may provide a different remote control. If yours doesn't look like the one pictured here, please refer
to the manual provided with your remote control.
2Use only high quality, non-corrosive batteries designed for use in electronic equipment.

BMC9012 User Guide
13
Programming by Search
1. Turn on the device you wish to program the remote for and ensure that the volume is audible.
2. On the Moxi remote, press and hold the MOXI and OK buttons simultaneously, until the LED
light blinks twice.
3. Press and release 9 9 1 0 for TV, or 9 9 1 1 for audio receiver. The LED light blinks twice.
4. Press and release the Mute button. If this mutes the device, then go to step 6.
5. If pressing Mute in the previous step did not work, press the Up arrow to advance to the next
code, and then press Mute again. Repeat until the device responds.
6. Press OK to set the current code and exit the process.
Note Some older devices may not be supported. If the device still fails to respond, use the
device’s original remote to control it. Contact Customer Care for additional assistance.
Television Codes
(Audio/Video Receiver codes star on page 16)
TV Brand Manufacturer Code TV Brand Manufacturer Code
3M 0737 A-Mark 0003
AOC 0030, 0003, 0052, 0137, 0185 Abex 0032
Admiral 0093, 0463 Advent 0761
Adventura 0046 Aiko 0092
Aiwa 0701 Akai 0030, 0098, 0591
Alaron 0179, 0183, 0216 Ambassador 0177
America Action 0180 Ampro 0751
Anam 0180, 0004, 0009, 0068 Anam National 0055, 0161
Apex Digital 0748, 0765, 0767 Archer 0003
Audinac 0391 Audiovox 0451, 0180, 0003, 0092, 0623, 0713
Baysonic 0180 Broksonic 0236, 0463, 0003, 0426, 0642
Bush 0355 CCE 0037, 0217, 0329
CXC 0180 Candle 0030, 0056, 0046, 0186
Carnivale 0030 Carver 0054, 0170
Casio 0611 Bell & Howell 0154, 0016
Bradford 0180 Celebrity 0000
Changhong 0765 Cineral 0451, 0092
Citizen 0060, 0030, 0056, 0039, 0046, 0092,
0186, 0280, 0561
Clairtone 0185
Compaq 0749 Concerto 0056
Contec 0180, 0157, 0158, 0185 Craig 0180, 0161
Crosley 0054 Crown 0180, 0039, 0672
Curtis Mathes 0047, 0054, 0154, 0451, 0093, 0060,
0030, 0145, 0056, 0016, 0039, 0166,
0415, 0466, 0702, 0747, 1147, 1347
Daewoo 0451, 0039, 0066, 0067, 0091, 0092,
0623
Denon 0145, 0511 Dumont 0017
Dwin 0720, 0774 Dynatech 0049
Ectec 0391 Eiki 0735
Electroband 0000, 0185 Electrohome 0381, 0389, 0409
Emerson 0154, 0236, 0463, 0180, 0282, 0178,
0179, 0039, 0038, 0158, 0177, 0181,
0182, 0183, 0185, 0270, 0280, 0623
Envision 0030
Fisher 0154, 0159 FlexVision 0713
Fujitsu 0179, 0683 Funai 0180, 0179, 0171

Remote Control
14
TV Brand Manufacturer Code TV Brand Manufacturer Code
Futuretech 0180 GE 0047, 0051, 0451, 0282, 0178, 0021,
0055, 0027, 0029, 0135, 0279, 0747,
1147, 1347
Gibralter 0017, 0030 GoldStar
0030, 0178, 0001, 0002, 0032, 0106,
0409
Goodmans 0360 Gradiente 0053, 0056, 0170, 0392
Grundig 0037 Grunpy 0180, 0179
Haier 0768 Hallmark 0178
Harley Davidson 0179, 0043 Harman/Kardon 0054, 0078
Harvard 0180, 0068 Hauppauge 0693
Havermy 0093 Hitachi 0145, 0056, 0016, 0032, 0038, 0095,
0097, 0151, 0173, 0227, 0279, 0409,
0413, 0576, 0577, 0583, 0723, 0770,
1145
InFocus 0736, 0738, 0741, 0752 Infinity 0054
Innova 0037 Inteq 0017
JBL 0054 JCB 0000
JVC 0053, 0036, 0069, 0160, 0169, 0182 Janeil 0046
Jensen 0050 KEC 0180
KMC 0106 KTV
0180, 0030, 0039, 0183, 0185, 0217,
0280
Kamp 0216 Kawasho 0158, 0216, 0308
Kaypani 0052 Kenwood 0030
Kloss 0024, 0046, 0078 Konka 0628, 0632, 0638, 0703, 0707
LG 0056, 0442 LXI
0047, 0054, 0154, 0156, 0178, 0148,
0747
Loewe 0136, 0633, 0693, 0694 Logik 0016
Luxman 0056 MEI 0185
MGA 0150, 0030, 0178, 0155 MTC 0060, 0030, 0056, 0049, 0091, 0185,
0216
Magnavox 0054, 0030, 0179, 0020, 0024, 0028,
0036, 0096, 0186, 0187, 0230, 0386,
1254, 1454
Majestic 0016, 0015
Marantz 0054, 0030, 0037, 0444, 1554 Matsushita 0250, 0650
Megatron 0178, 0145, 0003 Memorex 0154, 0250, 0463, 0150, 0178, 0179,
0016, 0106, 1037
Mercury 0001 Midland
0047, 0017, 0051, 0039, 0032, 0135,
0747
Minutz 0021 Mitsubishi
0093, 0150, 0178, 0014, 0098, 0155,
0331, 0358, 0592
Motorola 0093, 0055 Multitech 0180, 0049, 0217
NAD 0156, 0178, 0166 NEC 0030, 0056, 0036, 0170, 0434, 0455,
0704
NTC 0092 Nesa 0763
Netsat 0037 Nikko 0030, 0178, 0092, 0317
Nisato 0391 Noblex 0430
Noshi 0018 On Command 0531
Onwa 0180 Optimus 0154, 0250, 0166, 0650
Optiview 0756 Optonica 0093, 0165
Orion 0236, 0463, 0179 Ovation 0734
Panasonic 0250, 0051, 0055, 0162, 0226, 0650 Penney 0047, 0156, 0051, 0060, 0030, 0178,
0021, 0018, 0039, 0002, 0003, 0027,
0032, 0110, 0135, 0149, 0309, 0747,
1347
Philco 0054, 0463, 0030, 0145, 0020, 0028,
0096, 0302
Philips 0054, 0037, 1354, 1454
Pilot 0030, 0039 Pioneer 0038, 0166, 0172, 0679
Portland 0039, 0092 Princeton 0685, 0700, 0717
