Motorola
SM56 Modem
Quick Start User's Guide
Contents
1Overview
2Introduction
3Personal Computer Requirements
4Preparing the Computer for SM56 Installation
5Installing Hardware
6Installing SM56 Software
6-1 Installing SM56 Software on Windows 95/98
6-2 Installing SM56 Software on Windows NT4.0
7Verifying Correct SM56 Installation
8Changing the Operating System
9Using the SM56 Modem
10 Un-installing and Upgrading the SM56 Modem
11 Troubleshooting
12 Reporting Problems and Contacting the Modem Supplier
13 Understanding SM56 Windows Logo Certification
14 An Overview of the V.90 Standard Protocol
Appendix A SM56 Features
Appendix B Software License Agreement
Appendix c Supported AT Commands
1Overview
This document helps the OEM, system integrator, VAR, and end user with host system selection
and proper modem hardware and software installation. It lists qualified host personal computer
systems, and explains proper modem use. This document helps you select CPUs, and it explains
the tradeoffs associated with different processors. It explains the use of the SM56 Data/Fax/Voice
modem with various sound card configurations. It also aids you in troubleshooting and testing the
SM56 equipped system.
2Introduction
Motorola's SM56 Modem is a feature-rich modem at an attractive price. It provides high-speed
communications between your personal computer and a remote location, such as an Internet
Service Provider (ISP), so you can:

•Receive data at up to 56 Kbps in V.90 or K56flex modes
•Get automatic fallback to V.34 (33.6 Kbps) rates in bad line conditions and on non-
V.90/K56flex headends
•Use your computer as a telephone answering machine (TAM)
•Send and receive faxes on your personal computer at rates up to 14.4 Kbps
•Use your computer as a video phone to place and receive video phone calls
(Data/Fax/TAM/Speakerphone modem with video equipment)
•Use your computer to conduct hands-off speakerphone voice calls
(Data/Fax/TAM/Speakerphone modem)
Important
The SM56 ISA modem runs on Windows 95, Windows 98, and it can be used by applications that
run in an MS-DOS box (under Windows 95/98). Windows 95 and Windows 98 use the same
SM56 software builds.
The SM56 PCI modem also runs on Windows 95 and Windows 98. It does not directly support
Windows 95/98 DOS box applications. Refer to the Troubleshooting section for information on a
third party COM port virtualizing/trapping application that allows the SM56 PCI modem to be
used with DOS box applications.
Personal-computer OEMs that incorporate the SM56 can benefit from sizable cost reductions,
hardware reduction, and lower power consumption. End users benefit from quick, easy and
affordable software upgrades, which help them keep current with the latest communications
technology.
Please check with your direct modem supplier for the latest software updates and other product
information.
3Personal Computer Requirements
Motorola performs rigorous, exhaustive testing on its modems. It developed a list of recommended
personal computer features that perform well with the SM56. The information includes qualified
CPUs, Level 2 cache requirements, operating systems, RAM requirements, and third-party sound
card compatibility. However, in today's dynamic technology markets, it is not possible to test all
components and combinations on all systems.
This section outlines minimum system requirements for SM56 operation. On these systems, CPU
loading was found to be acceptable and the modem demonstrated good performance over the entire
network model.
Important: SM56 operation is not limited to the personal computer systems listed here.
Recommended CPUs
The SM56 modem has been qualified (tested for processor loading and TSB network model
coverage) on the following processors:

•Intel Pentium, 150MHz with MMX, 256K Level 2 (L2) cache
•Intel Pentium, 200MHz, 256K L2 cache
•Intel Pentium II
•Intel Pentium Pro
•Intel Celeron (Pentium II, 266MHz, no L2 cache)
The SM56 functions satisfactorily on the following systems. However, it has not been fully
qualified (it was not tested for processor loading or TSB performance):
•AMD K6, 233 MHz, 256K L2 cache
•AMD K6-2, 256K L2 cache
•Cyrix 6x86MX, 266MHz, 256K L2 cache
The SM56 does not function on the following CPUs, whose floating-point performance is
insufficient:
•Cyrix MediaGX
•Cyrix MediaGXM
•Cyrix 6x86
Level 2 Cache Benefits
Level 2 (L2) cache is an instruction memory (SRAM) bank that resides outside the CPU core. It
holds many instructions close to the CPU, to reduce the need for the processor to use slow access
cycles fetching instructions from main memory (DRAM). Eliminating most CPU accesses to main
memory considerably improves overall system performance.
The SM56 Software Modem works best when a minimum of 256K L2 Cache is installed on the
computer system motherboard to minimize processor loading. Intel's Celeron (266MHz PII)
systems do not have L2 cache. Although the SM56 operates on those systems, host processor
loading increases in the absence of L2 cache.
Compatible Operating Systems
The SM56 modem will run on the following operating systems:
•Windows 95 (OEM Service Release 2.0 or later)
•Windows 98
•DOS Box under Windows 95/98. Note that the SM56 PCI modem does not include direct DOS
box support. Refer to the Troubleshooting section for information on working around this
limitation.
System RAM Requirements
The SM56 Modem operates on systems that have the minimum RAM required by the installed
operating system. As with L2 cache, the more main memory, the better. The recommended RAM is
twice the required minimum. This reduces slow hard-disk swapping and improves overall system

performance... especially when executing numerous concurrent processes. The minimum RAM
requirements are:
Windows 95/98 16 MB
4Preparing the Computer for SM56 Installation
To ensure problem-free installation of the SM56 modem, ensure that an IRQ is available, as
follows.
1. In Win95/98, open the Control Panel.
2. Double click the System icon.
3. Select the Device Manager tab.
4. Highlight the Computer icon.
5. Select the Properties radio button.
6. Ensure that the Interrupt Request (IRQ) radio button is selected.
This displays the IRQ lines that are in use on the computer. Available lines are not shown in the
list. To install the SM56 ISA modem hardware, interrupt line 3, 4, 5, 6, 7, or 9 must be available.
The PCI SM56 software modem can use an IRQ in the range 3 through 15.
If there is no IRQ line available for the SM56 disable one of the COM ports in the BIOS.
Note: If you are using a Windows 95/98 DOS box application, the modem requires two IRQs.
Refer to the Troubleshooting section in this document, or to the on-line User's Guide for more
information on DOS application support. You can access the User's Guide through the modem
Control Panel.
Important: The SM56 PCI modem does not directly support DOS box applications. Please refer to
the Troubleshooting section for information on how to get around this limitation.
To ensure that COM Port 2, 3, or 4 is available, you can use the following steps:
1. Open the Control Panel.
2. Double click the System icon.
3. Choose the Device Manager tab.
4. Highlight the Ports (COM and LPT) branch.

5. Expand the branch to see which ports are installed on the computer.
To install the SM56 ISA modem so that it is accessible through older application software and
DOS programs, COM port 2, 3, or 4 should be available. If none of these ports are available, you
must disable one of the COM ports in the BIOS.
5Installing Modem Hardware
Hardware Installation:
Install the modem card as follows.
1. Power down the personal computer.
2. Locate a vacant bus connector (ISA or PCI, depending on your hardware) and insert the modem
card.
3. If using the SM56 Data/Fax/TAM/Speakerphone modem, connect the sound subsystem
interface cable(s) to the modem card (via the internal TAPI connector or using the audio jacks
-- refer to the information above on sound card compatibility.)
4. Connect the modem Line input to an analog phone jack using an RJ-11 phone cable. Optionally,
connect a telephone handset to the Phone input on the line interface card. The external
telephone cable connections are as follows.
5. Replace the personal computer cover and power the personal computer on.

6Installing SM56 Software
6-1 Installing SM56 Software on Windows 95/98
IPCI Slots
The SM56 for PCI is PCI Plug and Play compliant. It requires one IRQ ( IRQ 3, 4,...15) and one
memory mapped base address.
Windows 95/98 assigns the modem a COM port number. The SM56 installation software attempts
to negotiate a COM port number in the range of 1-4 in order to support older software and DOS
games. Note that the SM56 PCI modem does not include direct DOS box support. Please refer to
the Troubleshooting section for information on how to get around this limitation.
Installing on Windows 95/98
(Note: The Install Wizard may vary slightly with different versions of Windows 95 and Windows
98.)
On starting Windows 95/98 for the first time after installing the SM56 (ISA or PCI) line interface
card, the Windows 95/98 Configuration Manager detects the new hardware, assigns resources to it,
and then displays a window requesting the modem software drivers. This indicates that the
Configuration Manager is looking for the information (INF) file, which contains information about
the modem, including device type (Modem), device driver information (the name of the driver that
will control the modem) and the AT command/response sets that it supports.
In response to the request window, insert the distribution CD-ROM that contains the SM56
installation software. Select Driver from Disk Provided by Hardware Manufacturer. Windows
should find the information on the disk and identify the device as the SM56 Modem Line Interface
Card. It copies the files from the install disk to the computer.
Note: The SM56 install program may display a message box that reports Cannot locate file
_inst32.ex_... If this occurs, browse and re-point the path to the SM56 installation CD ROM
again. Then click OK.
On boards that have voice capabilities (SM56 Data/Fax/Voice models), another device is found
after the modem has been installed. Windows notifies you that it has found a Serial Wave Device
for the modem and prompts for a Wave Device driver. Re-point Install Shield to the SM56
distribution disk, and click OK.
When these two devices are installed, the SM56 Modem Setup program runs.
SM56 Modem Setup for PCI
The modem setup program for PCI does not prompt for user input during installation. It defaults to
USA country code and Domestic English as the language for the Help files. If you wish to change
either of these settings you may do so via the SM56 PCI Control Panel application (see Verifying
Correct SM56 Installation section) after setup is complete. Also, for SM56
Data/Fax/TAM/Speakerphone modems the microphone and speaker gain selections are done via

the Control Panel application (under the Advanced tab). The SM56 PCI Data/Fax/TAM only
modem does not have a Microphone/Speaker Gain selections.
Determining Microphone Gain Setting
If you connect the modem to the sound card through the internal TAPI connector, use the following
procedure to determine the appropriate microphone gain.
Determine whether the sound card has applied any gain to the microphone signal that is presented
at its TAPI
connector.
Note: The SM56 PCI modem (Data/Fax/TAM/Speakerphone only) Control Panel application
provides slider bars so users can fine tune speaker and microphone gains more easily.
6-2 Installing SM56 Software on Windows NT 4.0
Important -- The SM56 software for Windows NT is Data/Fax only, there is no speakerphone
or TAM supported.
Windows NT 4.0 does not fully support plug and play (PnP). Therefore, after installing the modem
board in the computer and booting, the operating system will not automatically recognize that new
hardware is present. You must manually install the modem as follows:
Step 1 -- Install a COM port for the modem
You must install a COM port for the SM56 modem as follows:
1. Open the Windows NT Control Panel.
2. Double click the Ports icon. The Ports window opens.
3. Select Add.
4. Select a COM port number (in the range 1-4 preferably) that is not already installed, and
allocate to it the standard resources as follows:
COM Port IO Address IRQ
13F8 4
22F8 3
33E8 4
42E8 3
5. When your selections are complete click OK.
6. You will be prompted to restart the computer, do not do so yet. Select Don't Restart Now.
7. Close the Ports window.
Step 2 -- Install the SM56 modem software

1. Open the Windows NT Control Panel.
2. Double click the Modems icon....the Install New Modem dialog appears.
3. Click the "Don't detect my modem; I will select it from a list" check box. Then click Next.
4. Click the Have Disk button.
5. Browse to the Windows NT SM56 modem install software. Click misgmodm.inf to highlight it.
Then click Open, then click OK.
6. Select the Motorola SM56 Modem (note that the product name listed will vary depending on
which modem you have -- Data/Fax/, Data/Fax/TAM, etc.) from the list. Click Next.
7. Click the port number selected in Step 1 above to highlight it as the COM port for the modem.
Then click Next. The wizard will now copy all the necessary files and install the SM56 modem on
your PC.
8. When complete, restart the PC to activate and start the COM port and SM56 modem devices.
You are now ready to use the modem.
7Verifying Correct SM56 Installation
Verify that the SM56 software and hardware installation was completed correctly as follows.
Verifying SM56 Software Installation
1. Verify correct COM port selection.
You can check COM port installation through the Modems icon in the Control Panel or through
the SM56 Control Panel application (see below). Normally, the SM56 will install on COM2,
COM3, or COM4. Sometimes, however, depending on your computer system setup or Windows
setup, the SM56 may install on COM5 (or higher).
Although the modem functions correctly on COM5, many Internet Service Provider (ISP) software
applications (such as AOL) do not work if the modem is on a COM port number higher than
COM4. If the SM56 installs on COM5 (or higher), refer to the Troubleshooting section for
assistance.
2. Run simple diagnostic from the SM56 Control Panel.
The SM56 software modem provides an informative Control Panel that reports:
•Modem status: in use/not in use; dialing; negotiating a connection; actual connect rate (updated
in real time during a connection)
•A button to access the on-line User's Guide
The SM56 Control Panel program also provides access to two Windows components:
•COM port and IRQ information
•A diagnostic utility that sends the modem ATI commands and displays the results: software
build, modem type (DF or DFV), and more.

To access the diagnostics option from the Control Panel, click Properties; select the Diagnostics
tab; select the SM56 Modem from the list; and then click More Info. If the driver is properly
installed, a dialog box appears, with responses to the ATI commands as shown in the example
below. Refer to the AT Commands section in the on-line User's Guide for an explanation of ATI
commands.
Verifying SM56 Hardware Operation
To verify correct SM56 modem card hardware operation (up to the isolation transformer), you can
use the following loop back test procedure.
1. Important: Remove the telephone line connector from the modem card.
2. Select Start.
3. Select Programs-->Accessories-->HyperTerminal.
4. Double click the Hypertrm.exe icon.
5. Optionally, select a connection name and icon.
6. In the Connect Using window, select Motorola SM56 modem.
7. Enter a number in the Phone Number box.
8. Select Dial.
9. Select Cancel.
10. Enter AT <cr>.
The response OK should appear.
11. Enter ATS46 = 23 <cr>.
12. Enter AT&T1 <cr> . Wait a few seconds.
13. Type some letters at the keyboard. If the hardware is functioning correctly, the letters you type
appear on the HyperTerminal display.
8Changing the Operating System
Windows 98 Upgrade Error Message
If the SM56 modem is installed on a Windows 95 PC, and then the system is upgraded to Windows
98, the following error message appears when Windows 98 starts:

Duplicated device: vcd
To remove the error, edit the SYSTEM.INI file and locate the line that reads:
Device = *vcd
Delete this line. Save the modified SYSTEM.INI file and restart Windows 98. You will no longer
get the error message.
9Using the SM56 Modem
32-Bit Windows 95/98 Applications
Because 32-bit Windows 95/98 applications use TAPI for communicating with modems, using the
SM56 is as easy as selecting the SM56 modem by name from the list of available modems.
16-Bit Windows 95/98 Applications
Because 16-bit applications cannot use the TAPI interface, there is a bit more setup needed.
1. Select Motorola SM56 modem from the list of supported modems (if the SM56 modem is
not shown, select Hayes Compatible modem).
2. Configure the application's COM port selection. Use the COM port assigned to the SM56
modem.
3. If the application requires it, enter specific AT commands for the SM56 modem. (For a
full list of AT commands, refer to the SM56 on-line User's Guide). Some typical AT
commands are listed below.
DOS-Based Applications and Games
Important: The SM56 PCI modem does not include direct DOS box support. Please refer to the
Troubleshooting sections for information on a way to get around this limitation.
The SM56 ISA modem can be used in DOS only through a Windows 95/98 DOS box.
DOS support is achieved by virtualizing the standard I/O and IRQ assigned to a COM port. This
means that the SM56 drivers capture and redirect all I/O to/from the standard I/O address for the
COM port to which it assigned. In simpler terms, you tell the application the COM port of the
SM56, and then use all the standard I/O and IRQ settings. Standard I/O addresses and IRQs for
COM Ports 1-4 are as follows:
COM Port IO Address IRQ
13F8 4

22F8 3
33E8 4
42E8 3
To determine the SM56 COM port number, open the SM56 Control Panel and select the
Diagnostics tab. The COM port number to which the SM56 modem is assigned is listed here.
Configure your application to use this COM port. For example, if the SM56 modem has been
assigned COM 3, configure your application to communicate through COM 3.
Enter the AT commands for the SM56 modem as required by the application. Some typical AT
commands are as follows.
AT Commands Commonly Needed by Applications
Applications generally prompt for the following commands.
Initialization* AT&F
Hangup ATH0
Dialing string ATDT
Answer string ATA
*Some games require that the modem refrain from performing error correction and data
compression. In these cases, use the initialization string AT&F\N0.
For a full list of AT commands, refer to the on-line User's Guide.
10 Un-installing and Upgrading the SM56 Modem
SM56 Un-Install Procedure
1. Open the Control Panel.
2. Select Add\Remove Programs.
3. In the dialog box, select Motorola SM56 Modem Uninstall.
4. Select Add/Remove.
5. When asked to close the Control Panel window do so to allow the SM56 Control Panel applet to
be removed.
6. Shut down the computer.
7. Remove the SM56 hardware from the computer. (Note: If you do not remove the SM56 line
interface card, the SM56 will be automatically re-installed when Windows 95/98 restarts.)

The SM56 modem software remains on the PC hard disk for later installs without needing a
complete software install again. Simply install the modem card back in the PC and the software
will automatically self-install.
SM56 Software Upgrade Procedure (Windows 95/98)
Upgrade the SM56 modem to a newer version as follows.
1. Obtain the latest software version from your direct modem supplier.
2. Run setup.exe and follow the Upgrade Wizard prompts. The upgrade utility retains a backup of
your previous modem version in a folder called Program Files\Motbak95.
Recovering From an Unsuccessful Upgrade (Windows 95/98)
If , after an SM56 upgrade, you have problems with the new driver, you can restore your previous
SM56 software installation as follows. Perform all of the following steps.
1. Open the Control Panel. Select Add/Remove programs.
2. If SM56 Modem is in the list of installed programs, click on SM56 Modem, then Click
Add/Remove to run the un-install program.
3. Open the windows\inf\other folder. Delete all Motorola INF files that are listed there.
4. Edit the Registry and remove the following key if present:
HKLM-->System-->CurrentControlSet-->Services-->SM34DFV
5. Open the Control Panel and determine if the SM56 Modem Control Panel is there. If so, close
the Control Panel; open the windows\system folder; and delete the mca.cpl file.
6. Open the windows\system.ini file. Search for device = motvcd.vxd. If it is present, change it
to device = *vcd.
7. Restart the computer.
8. Upon restart, the New Hardware Found window appears. Browse to: Program
Files\Motbak95.
9. Perform the SM56 software installation procedure (refer to Section 6 or 7). This will reinstall
your previous modem software.
11 Troubleshooting

If there is a problem making or receiving a call or transmitting data, and your communications
application does not explain the problem, check the following list of symptoms and tips.
•The modem installs at COM 5 (or higher)
Some ISP applications, such as America on-line, do not communicate with a COM port higher
than COM4. If the SM56 installs on COM5 or higher, force the modem to a lower COM port as
follows.
1. Open the SM56 Control Panel application.
2. Select the Advanced tab.
3. Click on the radio button for the desired COM port. Note that unavailable COM ports are
grayed out and not selectable.
Note: For SM56 ISA modems Build 58 and later include this feature on the Control Panel applet.
If using earlier builds, edit the PortName data in the Windows Registry HKLM-->Enum--
>ISAPNP-->nnnn, where nnnn corresponds to the modem's plug and play ID. Change PortName
data to the desired COM port. The changes take effect as soon as the Registry editor (REGEDIT)
is closed. There is no need to restart the PC.
•Windows 95/98 DOS box applications do not work with the modem
1. The SM56 PCI modem does not directly support Windows 95/98 DOS box applications. If you
are using the SM56 PCI modem you must use a third party application that traps and
virtualizes the COM ports. One such application is provided by Pacific Commware, Inc.
(Ashland, Oregon). They can be found on the Web at www.pacificcommware.com. The
application is called TurboCom/95 Pro, and works on Windows 95 and Windows 98
platforms. Note that Motorola have not completely tested and qualified this product for SM56
DOS box support, but have verified basic functionality.
2. If using the SM56 ISA modem, open the Control Panel.
3. Double click the System icon.
4. Expand the Modem branch.
5. Double click the Motorola SM56 modem.
6. Select the Modem tab. Make a note of the COM port number.
7. Select the Resources tab. Make a note of the IRQ number listed.
8. For DOS support to operate correctly, the SM56 modem cannot occupy the standard IRQ for
the COM port number.

9. Uncheck the Use Automatic Resources check box.
Double click on the Interrupt Request label and change the IRQ to a different level that is not
in conflict with another device. (If there is no free IRQ: free one, or change other device IRQ
levels to free a non-standard IRQ).
•There is no dial tone
1. Ensure that the telephone cable is securely connected at both ends.
2. Unplug the telephone line cable from the computer, and connect it directly to a telephone from
the wall outlet. Check for a dial tone. If there is none, the problem is in the telephone line or
system. Call the service provider.
•The modem cannot complete a connection to another modem
1. Ensure that your modem is dialing the correct number. Ensure that you've specified the correct
area code, if one is required.
2. Determine whether the remote modem is correctly configured to communicate with yours.
•The modem does not answer incoming calls
1. Ensure that the automatic answer parameter is set to one of the enabled options, using the
ATS0 command (ATS0=1 to answer after one ring, and so on).
2. Ensure that no other devices, such as fax or answering machines, are answering calls before the
modem does.
•The modem disconnects while transmission is in progress
1. Ensure that the telephone cable is securely connected at both ends.
2. Ensure that call-waiting is disabled. In most areas, the command *70 or #70 disables call-
waiting. Check with your telephone company for the correct key sequence. (With call-waiting,
the incoming call's click sound may be disrupting your call.)
•Data is not transmitted or received for unusually long periods of time
Re-dial the call. (The telephone line connection may be poor.)

•The computer runs slower than usual
1. Close any open applications that you are not using.
2. For the SM56 for ISA only: try adjusting the modem's CPU Usage option from High to
Medium; or Medium to Low. This is in the SM56 Control Panel application. This option is
not available for the PCI modem.
•You cannot enter tone selections successfully when calling tone-driven
applications
When dialing a remote system that requires you to enter selections using the telephone keys, such
as a voice-mail depot or bank-account information provider, you can lengthen the duration of the
tones your modem sends, so that the remote system can detect them better. To adjust DTMF tone
length, use the AT+VTDncommand, where nspecifies the tone duration.
•The modem does not respond to AT commands
1. Ensure that your communications software is configured to use the same COM port as the
modem's COM port.
2. Reset modem parameters to default options by entering AT&F; then re-enter custom options.
3. SM56 builds after Build 50 require setting the S46 register to 23 before AT&T1 will perform
the Local Analog Loop(LAL) back hardware test.
•The modem responds to commands, but they do not appear on the screen
Ensure that the Echo option is enabled by entering ATE1.
•You've installed a new peripheral device; now the modem does not work
1. In the Windows desktop tray, select Start. The start menu appears.
2. Select Help. The Windows Help Topics window appears.
3. Select the Contents tab.
4. Select If You Have a Hardware Conflict.
5. A series of troubleshooting actions appears. Follow the appropriate sequence.

•You hear feedback (noise) from the sound system
(Data/Fax/TAM/Speakerphone only)
1. Position the speakers at least three feet (1 M) away from the microphone.
2. Ensure that the speakers are facing away from the microphone.
3. Turn down the speaker volume.
4. Speak into the microphone at a distance of at least 12 inches (30 cm) from your mouth.
Minimize background noise.
5. If there is still feedback, turn off the microphone boost, under the volume control panel.
•The modem connects; then meaningless characters appear
1. Open the Control Panel. Double click the Modem icon.
2. Select the Motorola SM56 modem
3. Click on Properties.
4. Select Connection.
5. Click on Advanced.
6. Check the Use Error Control-Required to Connect box.
•The modem cannot connect; the Error Control option is selected
The modem may be connecting at a rate higher than appropriate for the line conditions.
1. Use the AT%B command to limit the SM56 maximum connection rate. (For a list of AT
commands, refer to the on-line User's Guide.)
2. Lower the rate, using AT commands, until the problem is corrected. You can add AT
commands to do this; refer to the next section .
How to Add AT Commands
1. Open the Control Panel.
2. Double-click the Modem icon.

3. Select the Motorola SM56 modem.
4. Click on Properties.
5. Select Connection.
6. Click on Advanced.
7. In the Extra Settings box, add commands as needed.
12 Reporting Problems and Contacting the Modem Supplier
If you have a problem with the modem, ensure that the problem and its solution are not shown in
the Troubleshooting section. If you cannot resolve it through troubleshooting, send the following
information in an email to your direct modem supplier, so that they can reproduce and resolve the
problem.
Information about your computer:
•Brand and model
•CPU type (Pentium, Pentium II, AMD, etc.) Specify if MMX
•CPU clock rate
•Amount of Level 2 cache memory
•Operating system and version (Windows 95 OSR revision level, Windows 98, etc.)
Information about your modem:
•SM56 modem card version; modifications to your SM56 modem card
•SM56 version number (find this with the ATI3 command; or with the More Info button in the
SM56 Control Panel)
Information about your setup:
•The telephone number you are calling from
•The telephone number you are calling to
•If performing a lab test, a detailed description of the equipment used
•The remote modem information
Information about the problem:
•The actions and steps that you performed
•A description of what you saw; be specific
•A description of what you expected to see
13 Understanding SM56 Windows Logo Certification
After rigorous testing at a Microsoft Windows Hardware Quality Lab (WHQL), the ISA bus-
based SM56 software modem met the stringent qualifications to receive the Designed for

Microsoft Windows logo. The PCI modem will be qualified later. The logo is targeted at
commercially marketed desktop applications that run on the latest released versions of Windows
95, Windows 98, and Windows NT Workstation. It is not intended for client/server or Windows
NT Server applications. The goals of the logo certification program are to improve Windows
hardware and software quality, increase end-user satisfaction, and reduce support costs.
To receive the logo, a product must show proof of compatibility with Windows 95/98 and NT. The
SM56 Software Modem passed the stringent tests to show that, among other capabilities, it:
•Installs and registers itself properly with the operating system
•Is reliably functional and stable
•Removes itself (minus its core components) using an automated uninstaller
•Supports Universal Naming Conventions (UNC) and Long File Names (LFN)
The modem also passed a host of other performance and feature-set tests of its data, fax, and voice
modes.
What does the logo mean for the SM56 ISA modem? It means that Motorola and its OEMs, system
integrators, and VARs can now use the Windows logo on their products and packaging, and on
advertising, collateral, and marketing materials. This signals end users that the SM56 software
modem is tested and fully functional on Windows 95/98 and Windows NT 4.0; that it is designed
to provide optimum usability and compatibility; and that it takes advantage of the latest
technologies provided by these operating systems. It makes users feel more comfortable about
purchasing the product, and it assures them of more complete satisfaction while using it.
The Windows logo also means that the SM56 software modem is included on Microsoft's Windows
Hardware Compatibility List (HCL) under "Logo," reinforcing to customers and end-users alike
that it meets Microsoft's strict requirements and operates properly with Windows operating
systems.
In summary, Windows Logo certification increases recognition and adoption of SM56 Software
Modem technology worldwide. It demonstrates Motorola's long-term commitment to providing high
performance, quality products.
14 An Overview of the V.90 Standard Protocol
In February 1998, the International Telecommunications Union (ITU) formulated the V.90
industry-standard protocol for 56K modems. Before the adoption of the V.90 standard, 56K
modems complied with one of two pre-standard implementations: K56flex or X2 technology.
Unfortunately for ISPs and end-users, these technologies were not compatible. ISPs had to worry
about which standard to employ. End users had to be sure to purchase modems compatible with
their ISP's equipment.
Upgrading Motorola's SM56 K56flex modems to V.90 is a software-only upgrade. There is no
change to the line interface hardware. This makes it easy for pre-V.90 users to upgrade their
system to V.90 compliance.

Note: sometimes V.90 is referred to as V.PCM. PCM is an acronym for Pulse Code Modulation.
With V.90, high-speed downstream (from Internet to personal computer) data transmission is
accomplished using PCM techniques. Before the ITU formulated its standard V.90 protocol, the
industry typically referred to it as V.PCM. This name is fading from use.
V.90 technology allows users to connect to the Internet at rates up to twice as fast as those of V.34
(33.6Kbps) modems. The maximum receive (downstream) rate is 56Kbps, while the return path
(upstream) connects at V.34 rates up to 33.6 Kbps. This is perfect for Internet connections, where
most data is transferred downstream.
The SM56 begins connections by attempting a V.90 connection to the headend. If the headend is
not V.90, the SM56 automatically switches to K56flex mode. If K56flex mode fails (when, for
example, the headend uses X2 technology, or there is a noisy phone line condition), the SM56
drops to V.34 rates. This auto-mode switching mechanism ensures maximum compatibility with all
remote headends.
On the Web you can visit www.v90.com for a wealth of information on V.90 technology,
including:
•A list of ISPs that support V.90
•The latest news on V.90
•White papers on the V.90 standard
•Technology descriptions
•Frequently asked questions (FAQs)
Appendix A: SM56 Specifications
•Full Windows 95/98 compatibility; received Microsoft Designed for Windows Logo
•Compatibility with Windows 95/98 communication applications
•Compatibility with communications applications that run in an MS-DOS® box
•An installation engine with country selection. (Selecting the correct country during installation
is important, since this selects between A-Law and µ-Law compansion)
•Plug and Play operation
•Support for various data modulation modes:
- V.90 connection rates if the headend is a true V.90 location. V.90 downstream rates to
56Kbps. Upstream rates to 33.6Kbps (V.34).
- Fallback to K56flex® mode if theheadend is K56flex, not V.90. K56flex® downstream
rates to 56Kbps. Upstream rates to 33.6Kbps(V.34).
- Connection at V.34 rates (33.6 Kbps) if the headend is not V.90 or K56flex®.
- V.32bis, V.32, V.22bis, V.23, V.22/B212, V.21, Bell 103.
•Error correction - V.42, LAPM, MNP2-4
•Data compression - V.42bis, MNP5
•Fax modes supported - V.17, V.27ter, V.29
•Full voice support on Data/Fax/TAM/Speakerphone modems...where TAM is Telephone
Answering Machine.

•Full-duplex speaker phone with acoustic and line echo cancellation
(Data/Fax/TAM/Speakerphone modems only)
•Answering machine capability with PCM and IMA ADPCM audio formats
•Caller ID (USA and Canada)
•Distinctive Ring (USA and Canada)
•Control Panel that provides general modem information and diagnostics
•Full pulse and tone dialing and call progress monitoring
•Adaptive rate re-negotiation (up and down) during a connection to compensate for line
dynamics
•Auto dial and answer
•On-line user's guide accessible through the Control Panel
Appendix B: Software License Agreement
THE FOLLOWING AGREEMENT IS A LEGAL AGREEMENT BETWEEN YOU (EITHER
AN INDIVIDUAL OR ENTITY), AND MOTOROLA, INC. (FOR ITSELF AND ITS
LICENSORS). THE RIGHT TO USE THIS PRODUCT IS SOLD ONLY ON THE
CONDITION THAT YOU AGREE TO THE FOLLOWING LICENSE. USING THIS
PRODUCT CONSTITUTES ACCEPTANCE OF THE TERMS AND CONDITIONS SET
FORTH IN THIS AGREEMENT.
The enclosed computer program(s) ("Software") is licensed, not sold, to you by Motorola, Inc.
("Motorola") for use only under the terms of this License, and Motorola reserves any rights not
expressly granted to you. You own the disk(s) on which the Software is recorded or fixed, but
Motorola and its licensors retain ownership of the Software itself and its accompanying written
materials, which are protected by the copyright laws of your country and international treaty
provisions.
1. License. This License allows you to use one copy of the Software on a single computer at a
time. To "use" the Software means that the Software is either loaded in the temporary memory
(e.g., RAM) of a computer or installed on the permanent memory of a computer (e.g., hard disk).
2. Restrictions. The Software contains trade secrets in a human or machine perceivable form
and, to protect them, you may not REVERSE ENGINEER, DECOMPILE, DISASSEMBLE OR
OTHERWISE REDUCE THE SOFTWARE TO ANY HUMAN OR MACHINE
PERCEIVABLE FORM. YOU MAY NOT MODIFY, ADAPT, TRANSLATE, RENT,
LEASE, LOAN OR CREATE DERIVATIVE WORKS BASED UPON THE SOFTWARE OR
ANY PART THEREOF.
3. Termination. This License is effective until terminated. This License will terminate
immediately without notice form Motorola or judicial resolution if you fail to comply with any
provision of this License. Upon such termination you must destroy the Software, all
accompanying written materials and all copies thereof, and Sections 5, 6, 7 and 8 will survive any
termination.
4. Export Law Assurances. You agree that neither the Software nor any direct product thereof is
being or will be shipped, transferred or re-exported, directly or indirectly, into any country
