Motorola Jazz Pager User manual

A
USER’S GUIDE
TM

CONTENTS
Introduction
Introduction...................................1
Controls ........................................2
Getting Started
Turning the Pager On/Off .............3
Backlight.......................................4
Setting the Time and Date............5
Messages
Types of Messages ......................6
Choosing the Scroll Speed...........6
Receiving/Reading Messages......7
Duplicate Messages .....................9
Alerts
Choosing the Alert Mode..............9
Choosing a Pleasing Alert ..........11
Alarms
Setting Alarms ............................12
Message Features
Storing Messages.......................20
Deleting Messages.....................21
Locking/Unlocking Messages..... 22
Information Services
Reading a Message................... 24
Turning the Alert On/Off............. 26
Deleting a Message ................... 26
Phone Directory
Entering an Entry ....................... 27
Adding a Received Message ..... 30
Deleting an Entry........................ 31
Optional Features
Travel Clock and Travel Alarm... 32
QuickNotes................................. 36
Other Features
Special Pager Displays.............. 38
Use and Care Information
Cleaning Your Pager.................. 39
Functionality and Use................. 39
Care and Maintenance............... 39
Battery
Battery Information..................... 40

1
Introduction
Congratulations on purchasing the Motorola® Jazz pager.The Jazz pager
incorporates the latest in paging technology.FLEX technology extends battery
life up to four times longer than ordinary pagers and improves the ability to
receive pages.
This compact pager combines messaging and time keeping functions in a
package that is convenient to carry. Full understanding of what this product
offers begins with reading this user’s guide. This user’s guide includes a
detachable Quick Reference Card on the back cover.
Effective Use of Your Pager
Your pager can help you keep in contact with everyone important to you.By
giving your pager number to your business associates, family, and friends, you
can be contacted when necessary.
If you have a cellular phone, give your pager number instead of your cellular
number.Then you can decide who to call back on your cellular phone without
paying for incoming calls.
Sending a Test Page to Yourself
After you have read this user’s guide and your pager has been activated by
your service provider, send yourself a test page.
INTRODUCTION

2
Controls
*
The Mode button can be pressed repeatedly, pressed and held to scroll
through available choices, or to increment a value.
+
The Select button is used to select and confirm a value.
)
The Read/Power On button is used to read a message, to save a setting,
to turn on the pager, or to turn on the backlighting.
ON/OFF
INTRODUCTION

3
Turning the Pager On/Off
ToTurn On
ToTurn Off
➊
•From the OFF mode, press ) .
➋
•This Startup screen displays momentarily
and the pager either alerts audibly or
vibrates.
Note: The Startup alert can be skipped by
pressing ) .
➌
•The Standby screen displays the time, date
and the AUDIBLE alert icon H (or VIBRATE
alert icon G ).
➊
•From the Standby screen, press and release * until CONTROLS? displays.
Press + to enter the CONTROLS menu.
12:00 A 1/01
HH
HH
MOTOROLA
HH
HH
12:00 A 1/01
BACKLIGHT/ TIME DATE
GETTING STARTED

4
Backlight
•Press and hold ) for one second or more to activate the LCD screen
backlight.When you have finished reading your messages and the Standby
screen is displayed, the backlight remains on for four seconds before
automatically turning off.
➋
•Press + to set the pager to OFF mode.
➌
•The OFF screen displays without any alert
icon.
HH
HH
OFF? d
12:00 A 1/01
ALERTS
GETTING STARTED

5
Setting the Time and Date
➊
•From the Standby screen, press and release * until CONTROLS? displays.
Press + to enter the CONTROLS menu. Then press *+ to enter
TIME–DATE mode.
➋
•Press * to set the hour to the desired value.
•Move to the Minute, A.M./P.M., Date and
Month fields by pressing + , then press *
to set the value for each field.
Note: To display a 24-hour clock, set the
AM/PM field to _.
•Press ) from any field to set and exit.
12:00 A 1/01
GETTING STARTED

6
Types of Messages
The message indicators define the type of message received and flash until
the message is read.
Choosing the Scroll Speed
You can choose the speed at which your messages scroll, or read them line by
line.
Message Type Unselected Selected
Personal §$
Phone Directory
Information services
when received º&
when selecting
when chirp is on j>
➊
•From the Standby screen, press and release * until CONTROLS? displays.
Press + to enter the CONTROLS menu, then press **+ to enter the
SCROLL SPEED menu.
~
~
-
!
MESSAGES

7
Receiving/Reading Messages
When a message is received, the pager either alerts audibly (AUDIBLE,
CHIRP, ESCALERT and all PLEASING modes except NO ALERT) or vibrates
(VIBRATE mode).If the NO ALERT mode is selected, no alert happens for
normal messages.The unread message indicator § (normal message)
flashes.The slot number of the latest message displays on top.
➋
•Press * to choose the SCROLL SPEED
you desire.
•Press ) to set and exit.
Note:
There are four scroll speeds: LINE-BY-
LINE, SLOW, MEDIUM and FAST.
➊
•Press ) to display the message status
screen. Press ) to read the latest
message.
Note: The flashing unread message
indicator § changes to $ when it is
selected.To read a different message,
press + to select the message slot
number, then press ) .
HH
HH
LINE BY LINE =
44
44 HH HH
§§§$
MESSAGES

8
➋
•The first screen of the message displays. If
the message is longer than one screen
display, a message continued indicator Q
appears on the top line until the last screen is
displayed.
➌
•If the pager is set to scroll the message
automatically (SLOW, MEDIUM or FAST
scroll speeds) the remainder of the message
is displayed at that speed.
•If the scroll speed is set to LINE-BY-LINE,
the remaining screens will automatically
display one line at a time every few seconds.
Note: To pause the message in any scroll
mode, press ) .Press again to continue.
In LINE-BY-LINE mode, continue pressing
) until the last screen is displayed.
➍
•The last screen displays the time and date
the message was received. After an interval,
the pager returns to the standby screen.
44
44 HH HH QQ QQ
DINNER AT 7:30PM
44
44 HH HH QQ QQ
MEET AT THE CLUB
44
44 HH HH
3:51P 9/29
MESSAGES

9
Duplicate Messages
Choosing the Alert Mode
You can choose one of four alert modes: AUDIBLE, VIBRATE, CHIRP, or
ESCALERT.
Note: In ESCALERT mode, the alert grows increasingly louder.In AUDIBLE
mode you can set a PLEASING alert or NO ALERT.
Note: If a message is unread and audible alerts are chosen, the pager
gives a periodic alert until all unread messages are read.This alert will
continue for up to 30 minutes. A message is considered read if any part
of the message is displayed.
➊
•If a duplicate personal message is received,
the Duplicate icon ¶ displays on top.
•Press ) to view the duplicate message.
➋
•The word DUPLICATE displays before the
duplicate message is displayed.
44
44 HH HH ¶¶ ¶¶
§§§$
44
44 HH HH ¶¶ ¶¶ QQ QQ
DUPLICATE 1
ALERTS

10
➊
•From the Standby screen, press and release * until ALERTS? displays.
Press + to enter the ALERTS menu. Press + again to enter the ALERT
MODE menu.
➋
•Press * until the desired alert mode
displays (e.g. VIBRATE).
➌
•The pager gives off a sample of each
displayed alert. Press ) to set and exit.
➍
•The Standby screen displays with either
HH
HH
(the audible alert icon) or GG
GG
(the vibrate
alert icon), depending on which alert mode
was chosen.
HH
HH
AUDIBLE? ww
ww
GG
GG
VIBRATE? xx
xx
GG
GG
9:05 P 9/28
ALERTS

11
Choosing a Pleasing Alert
If you select the AUDIBLE alert mode, you can choose the standard alert, NO
ALERT, or one of eight PLEASING alerts.
Note: If you choose NO ALERT orVIBRATE, the pager gives off an audible
alert only if a priority alert is received.To stop an alert, press any button.
➊
•From the Standby screen, press and release * until ALERTS? displays.
Press + to enter the ALERTS menu. Press *+ to enter the PLEASING
alert menu.
➋
•Press * until the desired alert mode
displays (e.g. ARPEGGIO).
➌
•The pager gives off a sample of each
displayed alert. Press ) to set and exit.
➍
•The Standby screen displays with the Audible
alert icon H .
HH
HH
STANDARD? hh
hh
HH
HH
ARPEGGIO? TT
TT
HH
HH
9:05 P 9/28
ALERTS

12
Setting Alarms
There are three types of alarms: REMINDER, GENERAL and EVENT. If the
pager is in OFF mode when an alarm expires, it turns on, alerts according to
the alert mode, and remains on. If the pager is in NO ALERT mode, an alarm
causes an audible alert.
REMINDER Alarm
A single REMINDER alarm can be set to expire within 60 minutes or less.
➊•From the Standby screen, press and release *until ALARMS? displays.
Press +to enter the ALARMS menu.Press +again to enter the
REMINDER menu.
➋•Press* to set the alert time. In this
example, the pager is set to alert 45 minutes
from the time the alarm is set.
Note: When setting the alert time, the
value starts with OFF, then 1 through 60,
then OFF again.
➌•Press )to set and exit.
HH
HH II II
REMIND OFF
HH
HH JJ JJ
REMIND 45 MIN
ALARMS

13
GENERAL Alarms
You can set one GENERAL alarm.This can be set to alert on a daily basis or
one-time only.
➍•The Standby screen displays with the Alarm
icon J.
➎•When a REMINDER alarm expires, this
displays and the pager alerts. Press any
button once to stop the alarm, and again to
clear the message.
➏•If the alarm is not stopped during activation,
the Alarm icon flashes. Press any button
once to read the message, and press again
to clear.
➊•From the Standby screen, press and release *until ALARMS? displays.
Press +to enter the ALARMS menu.Press *+ to enter GENERAL
alarms mode.
HH
HH JJ JJ
9:00 P 9/28
HH
HH JJ JJ
REMINDER s
HH
HH JJ JJ
9:45 P 9/28
ALARMS

14
➋•Press +,then press *until .,(the enable
alarm icon) displays. Press +to move to
the next field.
➌•Press *until J(the enable alert icon)
displays. Press +to move to the next field.
➍•Press *to set the hour to the desired value,
then press +to move to the Minute field.
•Press *to set the minutes to the desired
value. Move to the A.M./P.M., Day and Month
fields by pressing +, then press *to set
the value for each field.
•Press ) in any field to set and exit.
Note: To alert on a daily basis set the Day
and Month to --/--.
➎•The Standby screen displays with J(the
enable alert icon).
HH
HH II II
9:05 P 9/28
00
0011 11 .. .. ,, ,, HH HH II II
9:05 P 9/28
HH
HH JJ JJ
10:00 A 9/30
HH
HH JJ JJ
9:05 P 9/28
TRAVEL CLOCK
ALARMS

15
Note: You can temporarily disable a daily alert (for example, on a weekend).
To disable the alert, follow these steps.
1. From the Standby screen, press and release *until ALARMS? displays.
Press +to enter the ALARMS menu.Press *+ to enter GENERAL
alarms mode.
2. Press ++to move to the alert enable/disable field.
3. Press *until II
II (the disable alert icon) displays.
4. Press )to set and exit.The
alarm remains set and enabled, but the
alert won’t occur until it is re-enabled.
To re-enable the alert, follow these steps.
1. From the Standby screen, press and release *until ALARMS? displays.
➏•When a GENERAL alarm expires, this screen
displays and the pager alerts.
•Press any button once to stop the alarm, and
again to clear the message.
➐•If the GENERAL alarm is not stopped during
activation, the ALARM icon flashes.
•Press any button once to read the message,
and press again to clear.
HH
HH JJ JJ
GENERAL t1
HH
HH JJ JJ
10:00 A 9/30
TRAVEL ALARMPHONE DIRECTORY
ALARMS

16
Press +to enter the ALARMS menu.Press *+ to enter GENERAL
alarms mode.
2. Press ++to move to the alert enable/disable field. Press *until
JJ
JJ (the enable alert icon) displays.
3. Press )to set and exit.
To disable (erase) the alarm settings, follow these steps.
1. From the Standby screen, press and release *until ALARMS? displays.
Press +to enter the ALARMS menu.Press *+ to enter GENERAL
alarms mode.
2. Press +,then press *until -- (the disable alarm icon) displays. Press
)to set and exit.
EVENT Alarms
You can set up to three EVENT alarms.Each EVENT alarm allows you to keep
a special reminder message that displays when the alarm is activated and the
pager alerts. These can be set to alert either on a daily basis or one-time only.
➊•From the Standby screen, press and release *until ALARMS? displays.
Press +to enter the ALARMS menu.Press **+ to enter EVENT
alarm mode.
ALARMS

17
➋•Press *to choose EVENT alarm 01, 02 or
03.
•Press +,then press *until .,(the enable
alarm icon) displays. Press +to move to
the next field.
➌•Press *until J(the enable alert icon)
displays and press +to move to the
Message field.
➍•Press *to scroll through the characters
available, then press +to move to the next.
Note: You can enter up to 14 characters
(letters, numbers or spaces). If the
message is less than 14 characters long,
advance to the rubout character (®) and
press + to fill the remaining character
fields with blanks.
➎•At the last character field, press +to move
to the alarm Time-Date screen.
00
0011 11// //// // HH HH II II
AAAAAAAAAAAAAA
00
0033 33 .. .. ,, ,, HH HH II II
AAAAAAAAAAAAAA
00
0033 33 .. .. ,, ,, HH HH JJ JJ
AAAAAAAAAAAAAA
00
0033 33 .. .. ,, ,, HH HH JJ JJ
P I C K U P W E N D Y £
ALARMS

18
➏•Press *to set the hour to the desired value.
•Move to the Minute, AM/PM, Day and Month
fields by pressing +, then press *to set
the value for each field.
•Press ) in any field to set and exit.
Note: You may only set one EVENT alarm
at a time.You must press )to save
each event alarm prior to setting the next
alarm.
Note: To alert on a daily basis set the Day
and Month to --/--.
➐•The Standby screen displays with J(the
enable alert icon).
➑•When an EVENT alarm expires, the message
displays and the pager alerts. Press any
button once to stop the alarm, and again to
clear the message.
00
0033 33 .. .. ,, ,, HH HH JJ JJ
9:00 A 9/29
HH
HH JJ JJ
9:05 P 9/28
HH
HH JJ JJ
P I C K U P W E N D Y
ALARMS
