Motorola DCX700 User manual

HD Set-top
DCX700
Quick Start Guide

DCX700 Quick Start Guide 1
Before You Begin
Introduction
Congratulations on receiving a Motorola DCX700 HD Set-top. This document will help you set up your DCX700 Set-top to quickly get it up and
running.
READ THIS FIRST
1. Determine if you are connecting to a:
2. Determine if you are connecting the audio to a home theater receiver or directly to the TV:
For an HDMI or IEEE-1394 video connection, no additional audio connections to the TV are required.•
For a DVI video connection, additional audio connections to theTV are required.•
If the receiver orTV has a digital audio (S/PDIF) input, use the Optical Audio (S/PDIF) output. Otherwise, use the left and right (RCA•
phono) audio outputs.
3. Locate the cabling diagram(s) that best match the configuration.
4. Connect the audio and video cables in a manner matching that diagram.
5. Connect the Cable In terminal to the coaxial cable wall outlet.
6. Connect the power cord to the set-top and the AC wall outlet.
7. Perform the operational check for the remote control.
8. Optimize the high-definition settings.
High-Definition TV (HDTV) or
monitor
Use the HDMI, component video (YPbPr), or IEEE-1394 outputs. No other video connection supports HDTV.
If the TV has no HDMI input but does have a DVI input, connect a DVI-to-HDMI adapter or cable to the HDMI
out connector on the DCX set-top and the DVI input connector on the TV.
Standard-Definition TV Connect the composite video output using a composite video (RCA phono) cable.
Additional information for adjusting user settings
The DCX700 User Settings menu allows you to adjust the video, audio, and closed captioning configuration of the set-top.
With the set-top in the power on state, use the DCX700 remote to access the User Settings Menu by pressing Power followed by Menu (within
two seconds).
For more detailed instructions on changing the set-top configuration through the User Settings menu, please refer to the DCX700 User Guide
available online at http://motorola.com/homevideo/support.

2DCX700 Quick Start Guide
Front Panel
The front panel provides Power, Data, Home LAN, and Recording indicators, and a USB 2.0 HostType A port. The USB connector requires the
support of application software.
Rear Panel
The rear panel contains a power input; connectors for video, audio, and RF cabling; data output; and data interface connectors. Some
connectors are not enabled and require the support of application software.
Before You Begin
1 Power — Illuminates to indicate the power is on
2
Data — Dual function LED
• Flashes once per second to indicate unit is powering on
• Flashes once per second to indicate unit is provisioning
3LAN — Illuminates to indicate one or more set-top boxes are detected on
the home network
4 REC — Unit is in record mode on a home network device (DCX700-M only)
5USB* 2.0 — High-Speed peripheral device connection
6Digital Audio (optical) — Provides Dolby® Digital 5.1 audio or PCM output
7Ethernet* — Network connection
8Ext IR Input — Connects to a remote control set-top accessory cable
9IEEE-1394 — Audio and HDTV video device connection (US models only)
10 Power connector
POWER LAN REC
DATA
DCX700 M-
12345
1
2
3
LIEEE 1394 YPb Pr VIDEO
CABLE IN
RAUDIO
DIGITAL
AUDIO
OUT
EXT IR IN/
SERIAL
POWER
+5 VDC
61345278910
1Cable In — Connects to the signal from your service provider
2YPbPr — Component video output (HDTV)
3HDMI™ — High-Denition TV (HDTV) connector
(Provides Dolby® Digital Plus (7.1) audio)
4Video — Composite Video (SDTV) output
5 Audio — Composite Audio L/R outputs
*Feature is dependent upon application support
*Feature is dependent upon application support

3
Connecting Your Device
For the best possible HDTV video quality:
1. If the TV has an HDMI input, connect it to the
DCX700 HDMI output. If the TV has a DVI input,
connect it to the DCX700 HDMI output using an
HDMI-to-DVI converter cable or adapter.
2. If the TV has neither an HDMI nor a DVI input but has
an IEEE-1394 input, connect it to the DCX700 IEEE-
1394 output.
If you use IEEE-1394, on-screen graphics do not
display. Otherwise, use the component video (Y, Pb,
and Pr) connectors.
L/R Audio connection or digital audio S/PDIF
connection is required for sound with DVI and
component video.
Note: Be sure to match up each signal to the same
connection on the TV. Otherwise, the colors will not
appear correctly on your TV.
Note: Because HDMI provides both video and audio output, no
additional audio connections to the TV are required.
DCX700 Quick Start Guide
Cabling to an HDTV for Video

4
Connecting Your Device
Cabling to an HDTV for Audio
DCX700 Quick Start Guide

5
Connecting Your Device
Cabling to an HDTV and an A/V Receiver for Video
DCX700 Quick Start Guide
Note: If the A/V receiver includes
an HDMI input and output, the
DCX700 HDMI output can be
connected directly to the A/V
receiver’s input and the A/V
receiver’s HDMI output directly
to the TV. Because HDMI
provides both video and audio
output, no additional audio
connections to the A/V Receiver
and TV are required.

Note: If the A/V receiver includes
an HDMI input and output, the
DCX700 HDMI output can be
connected directly to the A/V
receiver’s input and the A/V
receiver’s HDMI output directly
to the TV. Because HDMI
provides both video and audio
output, no additional audio
connections to the A/V Receiver
and TV are required.
6
Connecting Your Device
Cabling to an HDTV and an A/V Receiver for Audio
DCX700 Quick Start Guide

7
Cabling to a Standard-Definition TV
Connecting Your Device
DCX700 Quick Start Guide
DCX700
1
2
3
LIEEE 1394 YPb Pr VIDEO
CABLE IN
RAUDIO
DIGITAL
AUDIO
OUT
EXT IR IN/
SERIAL
POWER
+5 VDC
CABLE/
ANTENNA IN
INPUT
S-VIDEO
VIDEO
AUDIO LEFT
AUDIO RIGHT
Standard-Definition TV
L/R audio
Video
(composite)
Cable in
RF audio/video
(coax)
Note: This connection method
does not support HDTV. For
information, see Cabling to an
HDTV for Video.

Cabling to a Standard-Definition TV, A/V Receiver, and VCR
Connecting Your Device
DCX700 Quick Start Guide 8
Note: This connection method
does not support HDTV. For
information, see Cabling to an
HDTV for Video.
If degraded picture quality is
observed while viewing copy-
protected limited view programs,
do not connect through a VCR.
Instead, connect the set-top
directly to the TV
(see illustration on page 7).
DCX700
1
2
3
LIEEE 1394 YPb Pr VIDEO
CABLE IN
RAUDIO
DIGITAL
AUDIO
OUT
EXT IR IN/
SERIAL
POWER
+5 VDC
To TV
CABLE/
ANTENNA IN
INPUT
AUDIO
R
L
VIDEO
OUTPUT
AUDIO
R
L
VIDEO
CABLE/
ANTENNA IN
INPUT
S-VIDEO
VIDEO
AUDIO LEFT
AUDIO RIGHT
Standard-Definition TV
VCR/DVD Recorder
DIGITALAUDIO
TV/MONITOR
OUTPUT
HDMI
IN
OUT
COAX IN CENTER
SUB-
WOOFER
SURROUNDFRONT
VIDEO S-VIDEO
R
DVD
CABLE/TV
VIDEO 2
IN
OUT
VCR
AUDIOVIDEO
LVIDEO S-VIDEO
OPTICAL IN
5.1 CH INPUT
L
R
COMPONENTVIDEO
IN OUT
Y
Pb
Pr
A/V Receiver
Alternate
L/R audio
Video
(composite)
Cable in
RF audio/video
(coax)

9DCX700 Quick Start Guide
Troubleshooting
Troubleshooting guidelines follow. If problems still occur after performing the diagnostics, call your service provider for assistance.
Problem — If this occurs: Solution — Then do one of the following:
The set-top will not
power on
The set-top may have received a software update and may not power on while the new software is being•
installed. Try again in a few minutes.
Verify that the AC power cord is connected to the set-top and an AC outlet. Unplug the set-top from the AC•
outlet and plug it back in.
If the set-top is connected to a switched outlet on another unit, verify that the unit is powered on. Unplug the•
power cord from the set-top’s AC outlet and plug it back in. Use an unswitched outlet, if possible.
The remote control does
not work
Verify that the remote control is in STB mode.•
Verify that there are no obstructions between the remote control and the set-top. Aim the remote control•
directly at the set-top front panel, not the TV or VCR.
The angle between the remote control and the set-top may be too large. Stand in front of the set-top and not•
too far to either side.
Press and release operation keys one at a time, firmly and deliberately.•
Check the batteries in the remote control. Install new batteries if needed.•
There is no audio when
viewing cable channels
Verify that the mute button on the remote control has not been pressed. Press MUTE on the remote control•
to restore sound.
If the set-top audio output is connected to the TV, verify that the mute button on the TV has not been pressed.•
If the set-top audio output is connected to a home theater receiver, verify that the receiver is set to the•
appropriate input source and the mute button on the receiver has not been pressed.
Verify that you have the correct cables for the audio connections.•
Verify that the audio cables are firmly connected between the set-top and the audio playback device (TV,•
receiver, DVD player, etc.).

DCX700 Quick Start Guide 10
Troubleshooting
Problem — If this occurs: Solution — Then do one of the following:
There is no audio
from the center and/or
surround speakers of a
home theater receiver
connected to the set-top
Not all Dolby Digital programs feature full 5.1 surround sound. In some cases, the programs may only contain•
left and right stereo audio.
Verify that the S/PDIF cable (coaxial or optical) is firmly connected to the set-top and the home theater•
receiver.
Verify that the home theater receiver is set to a surround sound audio mode (Dolby Digital, Dolby Pro Logic II,•
Dolby Pro Logic).
Verify that the receiver is properly configured to work with all connected speakers.•
There is no video on the TV
screen
Verify that the TV is powered on and set to the appropriate input source for the set-top.•
Verify that the set-top is powered on and tuned to an authorized cable channel.•
Verify that all video cables between the set-top and the TV are firmly connected.•
Verify that the coaxial cable feed is firmly connected to the set-top and the wall jack.•
If the set-top video output is connected to a home theater unit, verify that the home theater unit is powered•
on and set to the appropriate input source.
If the set-top video output is connected to a TV through an HDMI connection, power off theTV and then•
power off the set-top. Wait one second and then power on the devices.
Not all HDTVs can display every output format (1080i, 1080p, 720p, 480p, or 480i) available on the set-top. To•
select a different format:
Ensure that your set-top is plugged into a power outlet and is turned on.1.
Ensure the TV is turned on and tuned to the appropriate channel for the set-top.2.
Press the3. Power and then Menu key (within 2 seconds) on the remote. The User Settings menu will
appear on the TV.
Use the and keys on the remote to display the HDMI/YPbPr OUTPUT setting.4.
Press the key to cycle through the available output formats until a picture displays on theTV.5.
No graphics or program
guides appear on the TV
screen
If you use the IEEE-1394 connection, on-screen graphics, including closed captions and program guides, are
not displayed by the set-top. On-screen graphics and captions may still be overlaid by your TV, if enabled.
Alternatively, use HDMI or component video instead.

11DCX700 Quick Start Guide
Problem — If this occurs: Solution — Then do one of the following:
No closed captions display Verify on the User Settings menu that closed captions are enabled on the set-top.• With the Set-top in
the power on state, the User Settings menu is accessed using the DCX700 remote by pressing Power
followed by Menu (within two seconds).
Verify that closed captions are enabled on the TV.•
Note: Closed captioning may not be available on the current program.
There are black bars to the
right and left of the picture
Widescreen TVs display 4:3 programs in this format unless set to Stretch. Turn on the 4:3 OVERRIDE•
feature in the User Settings menu. This enables most widescreen TVs to stretch the video to fill the screen
(see yourTV manual for information about stretching 4:3 video).
If the set-top is connected to a widescreen TV, verify that the TV TYPE is set to 16:9 in the User Settings•
menu.
Many HD programs are broadcast in pillar-box format with black bars to the left and right of the picture.•
These programs are broadcast in 16:9 HD formats, even though the video is not 16:9.
There are black bars above
and below the picture
All 4:3 HDTVs display HD programs in letterbox format (black bars above and below the picture) because of
the shape of the display screen.
Turn on the 4:3 OVERRIDE feature in the User Settings menu. This enables most standard screen TVs to•
display a full screen picture when the set-top is tuned to a 4:3 program.
Set the TV TYPE to 4:3 Pan-Scan.This enables the set-top to remove the black bars above and below the•
picture when possible.
Some SD programs are broadcast in the letterbox format with black bars above and below the picture. Some
widescreen TVs offer a zoom feature that may be able to remove the black bars (see your TV manual for
information about zooming 4:3 video).
Troubleshooting

DCX700 Quick Start Guide 12
Troubleshooting
Problem — If this occurs: Solution — Then do one of the following:
There are black bars on all
four sides of the picture
This may occur on a 4:3 TV if the 4:3 OVERRIDE setting is OFF. To set 4:3 SD programming to fill the screen,
depending on the capabilities of the TV, set 4:3 OVERRIDE to 480i or 480p.
This may occur on a 16:9 TV if the active video for an SD broadcast is in letterbox format. To confirm, wait
for a commercial or look for a graphic, such as a network logo. If the commercial fills the screen from top to
bottom, or the graphic appears below the active video, the program is being
letterboxed by the broadcaster. You can minimize this by activating the zoom feature on the TV.
A broadcaster may include black bars on either side of a widescreen broadcast. This is called a “hybrid”
aspect ratio and results in a black border surrounding the video on a 4:3 TV. Because this is part of the
broadcast, the set-top cannot correct the video. You may be able to minimize the border using the zoom
feature on the TV.
Colors do not appear
correctly
Be sure to match up each signal to the same YPbPr connection on the TV.
Otherwise, colors will not appear correctly on your TV.

13DCX700 Quick Start Guide
Recording Your Connections
DCX700
1
2
3
LIEEE 1394 YPb Pr VIDEO
CABLE IN
RAUDIO
DIGITAL
AUDIO
OUT
EXT IR IN/
SERIAL
POWER
+5 VDC
IN
OUT
TAPE 1
R
CD IN
AUX IN
L
SPEAKER
CONNECTORS
To TV
CABLE/
ANTENNA IN
INPUT
AUDIO
LR
VIDEO
OUTPUT
AUDIO
LR
VIDEO
COAX
DIGITAL ANALOG
LR
AUDIO OUT
OPTICAL
VIDEO S-VIDEO
VIDEO OUT
COMPONENTVIDEO
IN OUT
Y
Pb
Pr
CENTER
SUB-
WOOFER
SURROUNDFRONT
5.1 CH INPUT
L
R
DIGITALAUDIO
COAX IN
OPTICAL IN
HDMI
IN
OUT
R
DVD
CABLE/TV
VIDEO 2
IN
OUT
VCR
AUDIOVIDEO
LVIDEO S-VIDEO
TV/MONITOR
OUTPUT
VIDEO S-VIDEO
VCR / DVD Recorder
A/V receiver
DVD player
Audio receiver
HDTV / Standard-DefinitionTV
CABLE/
ANTENNA IN
R
L
S-VIDEO IN
S-VIDEO OUT
VIDEO INAUDIOIN
AUDIO OUT VIDEO OUT
Y
Pb
Pr
IEEE 1394
OPTICAL
SPDIF
SPDIF
DVI-HDTV
HDMI
Use this diagram to record
connections between
your home entertainment
components. You can use
this diagram to reconnect
your system if you move
the equipment or add new
equipment.
Disconnect the power
from the DCX set-top
before connecting
or changing cable
connections. Do not place
another component or
object on top of the DCX
set-top.

DCX700 Quick Start Guide 14
Notes

© Motorola, Inc. 2010. All rights reserved.
www.motorola.com
MOTOROLA and the Stylized M Logo are registered in the U.S. Patent andTrademark Office. HDMI is a trademark of HDMI Licensing LLC. Dolby and the double-D symbol are
registered trademarks of Dolby Laboratories.This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights.
Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by
Macrovision. Reverse engineering or disassembly is prohibited. All other product or service names are the property of their registered owners. No part of the contents of this
document may be reproduced or transmitted in any form or by any means without the written permission of the publisher.
576033-001-a 01/10

Sistema HD
DCX700
Guía de inicio rápido

Guía de inicio rápido del sistema DCX700 1
Antes de comenzar
Introducción
Felicitaciones por recibir un sistema DCX700 HD de Motorola. Este documento le ayudará a configurar el sistema DCX700- para que pueda
comenzar a usarlo rápidamente.
LEA ESTO PRIMERO
1. Determine qué va a conectar:
2. Determine si va a conectar el audio a un receptor Home theater o directamente a la TV:
En el caso de una conexión de video HDMI o IEEE-1394, no es necesario realizar otras conexiones de audio a la TV.•
En el caso de una conexión de video DVI, no es necesario realizar otras conexiones de audio a laTV.•
Si el receptor o la TV tiene una entrada de audio digital (S/PDIF), utilice la salida de audio óptica (S/PDIF). De lo contrario, utilice las salidas•
de audio izquierda y derecha (conector RCA).
3. Ubique los diagramas de cableado que mejor coincidan con la configuración.
4. Conecte los cables de audio y video de la manera indicada en el diagrama.
5. Conecte el terminal de entrada de cable a la toma de cable coaxial.
6. Conecte el cable de alimentación al sistema y al tomacorriente de CA.
7. Compruebe el funcionamiento del control remoto.
8. Optimice las configuraciones de alta definición.
TV (HDTV) o monitor de alta
definición
Use las salidas HDMI, video componente (YPbPr) o IEEE-1394. Ninguna otra conexión de video admite HDTV.
Si la TV no tiene entrada HDMI pero tiene una entrada DVI, conecte un adaptador o cable DVI a HDMI al
conector de salida HDMI en el sistema DCX y el conector de entrada DVI en la TV.
TV de definición estándar Conecte la salida de video compuesto utilizando un cable de video compuesto (conector RCA).
Información adicional para ajustar las configuraciones de usuario
El menú User Settings (Configuraciones de usuario) del sistema DCX700 le permite ajustar la configuración de video, audio y subtítulos del
sistema.
Con el sistema en estado encendido, use el menú User Settings desde el control remoto del sistema DCX700 al oprimir los botones Power
seguido de Menu (antes de dos segundos).
Para obtener instrucciones más detalladas acerca de cómo cambiar la configuración del sistema a través de este menú, consulte la Guía de
usuario del sistema DCX700 disponible en línea en http://motorola.com/homevideo/support.

2
Guía de inicio rápido del sistema DCX700
Panel frontal
El panel frontal muestra indicadores de encendido, mensaje, datos, red LAN doméstica y de grabación, y un puerto de host USB 2.0 tipo A.
El conector USB requiere el soporte de software de aplicación.
Panel posterior
El panel posterior contiene una entrada de alimentación, conectores de video, audio y cables RF; conectores de salida de datos y de interfaz de
datos. Algunos conectores no están activados y necesitan el soporte de software de aplicación.
Antes de comenzar
1 Encendido: se ilumina para indicar que el equipo está encendido
2
Datos: LED de doble función
• Parpadea una vez por segundo para indicar que la unidad se está encen-
diendo
• Parpadea una vez por segundo para indicar que la unidad se está
aprovisionando
3LAN: se enciende para indicar que se detectaron uno o más sintonizadores
en la red doméstica
4 REC: la unidad está en el modo grabación en un dispositivo de la red domés-
tica (sólo DCX700-M)
5USB*2.0 — Conexión de dispositivos periféricos de alta velocidad
6Audio digital (óptico): proporciona salida de audio Dolby® Digital 5.1 o PCM
7Ethernet* — Conexión de red
8Entrada de IR Ext: se conecta a un cable accesorio del sistema para control remoto
9IEEE-1394 — Conexión del dispositivo de audio y video HDTV (sólo modelos
de EE.UU.)
10 Conector de alimentación
POWERLANREC
DATA
DCX700-M
12345
1
2
3
LIEEE 1394 YPb Pr VIDEO
CABLE IN
RAUDIO
DIGITAL
AUDIO
OUT
EXT IR IN/
SERIAL
POWER
+5 VDC
61345278910
1Entrada de cable — Se conecta a la señal de su proveedor de servicio
2YPbPr — Salida de video componente (HDTV)
3HDMI™: conector de TV de alta denición (HDTV)
(Proporciona audio Dolby® Digital Plus (7.1))
4Video — Salida de video compuesto (SDTV)
5Audio — Salidas de audio compuesto izquierda y derecha
*La función depende del soporte de la aplicación
*La función depende del soporte de la aplicación

3
Conexión del dispositivo
Para obtener la mejor calidad de video HDTV posible:
1. Si la TV tiene una entrada HDMI, conéctela a la salida
HDMI del sistema DCX700. Si la TV tiene una entrada
DVI, conéctela a la salida HDMI del sistema DCX700
utilizando un cable convertidor o un adaptador de
HDMI a DVI.
2. Si la TV no tiene entrada HDMI ni DVI, pero tiene una
entrada IEEE-1394, conéctela a la salida IEEE-1394
del DCX700.
Si utiliza IEEE-1394, no se muestran gráficos en la
pantalla. De lo contrario, utilice los conectores de
video componente (Y, Pb y Pr).
Se requiere una conexión de audio izquierda y
derecha o una conexión de audio digital S/PDIF para
obtener sonido con DVI y video componente.
Nota: Asegúrese de hacer coincidir cada señal con la
misma conexión en la TV. De lo contrario, los colores
no se mostrarán correctamente en la TV.
Nota: Debido a que HDMI proporciona salida de audio y video, no
se requieren conexiones de audio adicionales a la TV.
Guía de inicio rápido del sistema DCX700
Video
componente
HDMI
Escoja
uno
DCX700
Entrada
de cable Alterno
HDTV
Y
Pb
Pr
CABLE/
ANTENNA IN
HDMI
Component
Video Input
CABLE IN
VIDEO AUDIO
OUT AUDIO
DIGITAL EXT IR IN/
SERIAL
IEEE 1394
POWER
+5 VDC
Cableado de video para HDTV
