Motorola FW200L User manual

Warning: Charge the phone for 24 hours before use.
Fixed Wireless Telephone
Model: FW200L

Welcome...
to your new Motorola FW200L Fixed Wireless Telephone!
• GSM quad band (850 / 900 / 1800 / 1900MHz).
• Unlocked to all GSM (2G) networks.1
• Send and receive SMS.
• Store up to 200 SMS messages on the FW200L base, messages can also be stored on
the SIM card.2
• Battery back up (long rechargeable battery life).
• Store up to 1000 name and numbers in the FW200L phonebook, contacts can also be
stored on the SIM card.2
• Bright backlit display.
• Facility to block up to 20 phone numbers.
• Speakerphone for hands-free conversations.
• 8 speed dial memory keys for easy dialling.
• Choose from 20 dierent ringer melodies.
• Date, time and alarm facility.
• Caller ID shows you who’s calling and see details of the last 20 callers in a calls list.
• Redial up to 20 of the last numbers called.
• FM radio.
• Screen lock.
• Calendar and calculator.
Need help?
If you have any problems setting up or using your FW200L, please contact Customer
services: xxxxxxxxxxxxxxx
Alternatively, you may nd the answer in the ‘Help’ section at the back of this guide.
1A 4G SIM is compatible with the FW200L but it will only work with 2G networks.
2Number dependent on the capacity of the SIM card. SIM card not included.

This User Guide provides you with all the information you need to get the
most from your phone.
Before you make your rst call you will need to set up your phone. Follow
the simple instructions in ‘Getting Started’, on the next few pages.
Got everything?
• Corded handset and curly cord.
• Corded base with antenna.
• 3 x 550 mAh NiMH battery pack.
• Micro USB cord.
• User guide.
ECOMOTO: a convergence of eorts by marketing, design, research, engineering
and supply chain management that leads to better products for everyone. A holistic
view that focuses on both social and environmental responsibility. A passion and a
shared point of view.
The right thing to do.
• Meets and / or exceeds EMEA environmental regulatory requirements.
• Eco friendly packaging with a minimum 20% post consumer recycled content.
• Phone housing is built with a minimum of 25% post consumer recycled content plastic.
• Energy eicient charger that meets EU Code of Conduct requirements.

4
1. Getting started .....................................................................6
2. Getting to know your phone ................................................9
3. Using the phone .................................................................14
3.1 Inserting the SIM............................................................................................14
3.3 Calls ...............................................................................................................14
3.3.1 Make a call...........................................................................................14
3.3.2 Preparatory dialling.............................................................................14
3.3.3 Make a call using speed dial keys.......................................................14
3.3.4 End a call.............................................................................................14
3.3.5 End a single call ..................................................................................15
3.3.6 Receive a call ......................................................................................15
3.4 Adjust the earpiece or hands-free volume ....................................................15
3.5 Mute...............................................................................................................15
3.6 Hold................................................................................................................15
4. Phonebook .........................................................................16
4.1 Entering names and writing tips ...................................................................16
4.2 Storing contacts.............................................................................................16
4.2.1 Preferred storage - SIM or phone.......................................................16
4.2.2 Store contacts .....................................................................................16
4.2.3 Move or copy individual contacts ......................................................17
4.2.4 Move or copy all contacts...................................................................17
4.3 View contacts.................................................................................................17
4.4 Dial contacts ..................................................................................................17
4.5 Edit a contact.................................................................................................18
4.6 Delete a contact ............................................................................................18
4.7 Delete all contacts .........................................................................................18
4.8 Turn the speed dial memory on/o...............................................................18
4.9 Store a speed dial memory number..............................................................19
4.10 Edit a direct memory number.......................................................................19
4.11 Delete a direct memory number...................................................................19
4.12 Memory status ...............................................................................................20
4.13 Send text message to a phonebook contact ................................................20
4.14 Add to blacklist ..............................................................................................20
5. Text messaging...................................................................21
5.1 Write a message ...........................................................................................21
5.2 Send a message.............................................................................................21
5.3 Message boxes ..............................................................................................22
5.4.1 Use a template ....................................................................................24
5.4.2 Create a template...............................................................................24
5.4.3 Edit a template....................................................................................24
5.4.4 Delete a template ...............................................................................25
5.5 SMS settings ..................................................................................................25

5
5.5.1 Prole settings.....................................................................................25
5.5.2 Validity period.....................................................................................25
5.5.3 Message type......................................................................................26
5.5.4 Delivery report....................................................................................26
5.5.5 Reply path ...........................................................................................26
5.5.6 Voicemail server..................................................................................26
5.6 Memory status ...............................................................................................27
5.7 Save sent messages.......................................................................................27
5.8 Preferred storage...........................................................................................27
6. Call history..........................................................................28
6.1 View a call log entry.......................................................................................28
6.2 Call a number in the call log..........................................................................28
6.3 Send a message.............................................................................................28
6.4 Add to blacklist ..............................................................................................28
6.5 Edit a number before you call .......................................................................29
6.6 Delete an entry ..............................................................................................29
6.7 Delete a call log .............................................................................................29
6.8 Call duration ..................................................................................................29
6.9 Reset the call duration ...................................................................................30
7. Organizer............................................................................31
7.1 Calendar ........................................................................................................31
7.2 Alarm..............................................................................................................31
7.3 Calculator ......................................................................................................32
7.3.1 Enter calculator mode ........................................................................32
7.3.1 Calculations ........................................................................................32
8. Settings ...............................................................................33
8.1 Phone settings ...............................................................................................33
8.1.1 Time and date .....................................................................................33
8.1.2 Language ............................................................................................34
8.1.3 Writing input methods........................................................................34
8.1.4 Turn o the display date and time.......................................................34
8.1.5 Screen lock .........................................................................................35
8.1.6 Dedicated keys ...................................................................................35
8.1.7 Display contrast...................................................................................35
8.1.8 Backlight timeout................................................................................36
8.2 Call settings ...................................................................................................36
8.2.1 Call waiting .........................................................................................36
8.2.2 Call divert............................................................................................36
8.2.3 Call barring .........................................................................................38
8.2.4 Blacklist ...............................................................................................39
8.2.5 Call time reminder..............................................................................40
8.2.6 Answer mode......................................................................................40
8.2.7 Delay dial.............................................................................................41
8.3 Network settings............................................................................................41

6
8.4 Security settings ............................................................................................41
8.5 Restore settings .............................................................................................43
9. Prole settings ....................................................................44
9.1 Ringer.............................................................................................................44
9.1.1 Ringtone..............................................................................................44
9.1.2 Ring volume........................................................................................44
9.1.3 Ring type.............................................................................................44
9.2 Message.........................................................................................................44
9.2.1 Message tone......................................................................................44
9.2.2 Message tone volume ........................................................................45
9.3 Keypad...........................................................................................................45
9.3.1 Keypad tone........................................................................................45
9.3.2 Keypad tone volume...........................................................................45
9.4 Power on/o ..................................................................................................45
9.4.1 Power on/o tone ...............................................................................45
9.4.2 Power on/o tone volume ..................................................................46
9.5 Error tone .......................................................................................................46
9.6 Alarm volume.................................................................................................46
9.7 Silent mode....................................................................................................46
10. FM Radio ............................................................................47
10.1 Turn the FM radio on......................................................................................47
10.2 Turn the FM radio o......................................................................................47
10.3 Manually input radio channels.......................................................................47
10.4 Auto search radio channels ...........................................................................47
10.5 Channel list ....................................................................................................48
11. Help.....................................................................................49
12. General information ...........................................................50

6 Getting started
1. Getting started
IMPORTANT
Do not place your FW200L in the bathroom or other humid areas.
SIGNAL STRENGTH
The icon on your display indicates that you have a strong signal. When the signal
strength reduces the number of bars reduces.
If you are on a call, the line will hang up if the base loses signal.
Underside of the base and inserting the SIM
A Antenna
B Base curly cord socket
Plug the curly cord with the longer straight section and hook the cord into the cord
track.
C Microphone
D Battery compartment
E SIM card slot
F SIM bracket
G Battery plug socket
H Handset curly cord socket
Plug the curly cord with the shorter straight section into the handset.
A
B
C
D
E
H
F
G
1. Place the SIM
card so that the
bottom of the
SIM lines up with
the SIM bracket
(F).
2. Using your
nger slide the
SIM card down
until it won’t go
any further.

7Getting started
NOTE
Once the SIM card is installed, place the battery in (D) and plug the battery wire into (G)
and then replace the battery cover.
Connecting the base to a PC / Charging the battery
1. Plug the USB cable into socket (A) on the side of the base.
2. Insert the other end into either (a) an AC adapter and connect to the wall socket or (b)
an active computer USB port.
3. The battery symbol on the display will scroll while charging and will be displayed
once the battery is fully charged.
NOTE
You do not need to have the battery installed for the phone to work. If the battery is not
installed plug the base into a power source, the icon will be displayed instead of the
battery symbol.
BATTERY LOW WARNING
If you hear a warning beep every 30 seconds during a call or every 3 minutes in standby,
you will need to recharge the battery or plug the phone into a power source before you
can use it again.
BATTERY PERFORMANCE
In ideal conditions, a fully charged battery should give up to 8 hours talk time or up to 7
day standby time on a single charge.1
Note that a new battery does not reach the full capacity until it has been put to normal use
for several days.
Running the battery right down at least once a month will help it last as long as possible.
The charge capacity of the rechargeable battery will reduce with time as it wears out,
giving less talk / standby time. Eventually it will need to be replaced.
After charging your phone for the rst time, subsequent charging time is about 6–8 hours a
day. The battery and phone may become warm during charging. This is normal.
1All talk and standby times are approximate and depend on features selected and usage
pattern.
A
(a) (b)

8 Getting started
Date and time
You can set the date and time for your FW200L. When setting the date and time check
whether the time format setting is 12 or 24 hours. The default is 24 hours. To change the
format, see ”Set the time and date format” on page 33.
1. Press
Menu , scroll dto Settings and press OK .
2.
Phone settings is highlighted. Press OK .
3.
Time and date is highlighted. Press OK .
4. Scroll dto
Set time/date and press OK .
5. Enter the time using the keypad, e.g. 14:45 for 02.45pm (24 hours).
If the time format is set to 12 hours, enter 02:45 for 02:45pm, then scroll dto
AM/PM
and press uto select
AM or PM .
6. Scroll dto
YYYY/MM/DD and enter the date using the keypad e.g. 2015/12/10 for 10
December 2015 and press
Save .
7. Press oto return to standby.
Your FW200L is now ready for use.

9Getting to know your phone
2. Getting to know your phone
Overview of your handset
A Antenna
B Display
For display icons, see “Display” on page 11.
C Scroll up / FM Radio
Scroll up through lists and settings.
Press to turn on the FM Radio.
Press to move the cursor up.
D Scroll left / Add phonebook contact
Press to move the cursor to the left.
Press to enter the phonebook list.
E Menu / OK
Enter the main menu.
Select the option displayed on screen.
Conrm a menu option.
F Scroll down / Inbox
Scroll down through lists and settings.
Press to go straight to the messaging Inbox.
Press to move the cursor down.
A
B
C
D
E
F
G
H
O
N
M
L
K
I
J

10 Getting to know your phone
G *
Press to dial a *.
Keep pressing to dial +, p or w.
H OK
Press this key to select the lower left corner function on the screen.
I Phonebook / Clear / Back
Enter the phonebook menu.
Delete characters on screen when entering names and numbers.
Go back to the previous menu,
Back is displayed on the screen.
J Scroll right / Write a text message
Press to move the cursor to the left.
Press to go straight to the new message box.
K Charging light
L Power on/o / Exit
Press and hold for 3 seconds to switch the phone o or on.
When in the menu press to return to standby.
M Hands-free
Press to make, answer or end a hands-free call.
Press to switch hands-free on during a call.
N Redial list / Send call
Press to enter the redial list.
Once a telephone number is pre-dialled press to dial.
O # / Silent mode
Dial a #.
Press and hold to enter silent mode.

11Getting to know your phone
Display
Signal icon
Displays when in hands-free mode
Roaming
Mute is activated
Displays when you have new text messages
Indicates the ringer is on
Phone is in silent mode (replaces the ringer on icon)
USB cable is connected
Alarm is set
Indicates a missed call
Displays when you have new voicemails
Keypad is locked
Battery is fully charged
Battery is partially charged
Battery is running low
Battery is almost fully discharged
Battery is empty
Charger is connected with no battery installed (replaces the battery icon)

12 Getting to know your phone
NOTE
The icons will always align to the left and as higher priority icons appear the other icons
will shift to the right. Some icons replace others along the top of the display depending on
which function is activated.
If there are too many icons to view at the top of the display the battery icon will disappear.
Navigating the menus
Your phone menu has 7 sub-menus. Each sub-menu contains options that allow you to
use the phonebook, change the ring tone, etc. You can use menus and sub-menus in two
ways: by scrolling or by using shortcuts.
Scrolling through menus
1. From the standby screen, press
Menu or O.
The main menu is opened.
2. Use the u/dkeys to scroll through the menu.
3. Left softkey or O- press to action the corresponding word prompt shown in the lower
left corner of the display.
Right softkey - press to action the corresponding word prompt in the lower right
corner of the display.
4. Press oto return to standby.
Shortcut keys
You can use a shortcut key to go to the preset option directly without scrolling through
lists. To change one of the shortcuts, see “Dedicated keys” on page 35.
1. From the standby screen, press u/d/ t/ uto get to the preset shortcuts.

13Getting to know your phone
Menu map
Phonebook
Add new contact
When no contact is
stored
Add new contact
is highlighted, press
Options to add a
contact.
If contacts are stored
the rst contact is
highlighted, either
scroll uto
Add new
contact
and press
Options to add a
contact. Or scroll dto
the required contact
and press
Options .
View
Send text message
Call
Edit
Delete
Copy
Add to blacklist
Phonebook settings
Preferred storage
Speed dial
Memory status
Copy contacts
Move contacts
Delete all contacts
Messaging
Write message
Inbox
Drafts
Outbox
Sent messages
SMS templates
SMS settings
SIM
Memory status
Save sent message
Preferred storage
Call history
Missed calls
Dialled calls
Received calls
Delete call logs
Call timers
Organizer
Calendar
Alarm
Calculator
Settings
Phone settings
Time and date
Language
Pref. input method
Show date and time
Screen auto lock
Dedicated keys
Contrast
Backlight Time
Setting(sec)
Call settings
Call waiting
Call divert
Call barring
Advanced settings
Blacklist
Call time reminder
Answer mode
Delay dial
Network settings
Network selection
Security settings
SIM security
Phone security
Restore settings
Proles
Tone settings
Ring
Ringtone volume
Ring type
Message
Tone
Message volume
Key tone
Keypad
Keytone volume
Power on / o
Power on
Power o
Volume settings
System alert
Alarm volume
FM radio
Once in the menu
press
Options :
Power o
Power on
Channel list
Manual input
Auto search

14 Using the phone
3. Using the phone
NOTE
Your phone will automatically time the duration of all external calls, the call timer will
display on the screen. When the call ends, the total duration of your talk time is shown for
1 second.
3.1 Inserting the SIM
Make sure the phone is turned o (see below) and not connected to the power when you
insert or remove the SIM card. Do not touch the metal plate area of the SIM card and keep
away from electromagnetic elds.
3.2 Switch the handset on / o
1. Press and hold ofor 3 seconds to switch the handset on / o.
2. Once turned on the phone will search for the network. After the phone is registered
to the network, the signal will be displayed at the top left corner of the screen. The
phone is now in standby and you can make or answer a call. Your phone remains in a
searching state if it fails to nd the available network.
3.3 Calls
3.3.1 Make a call
1. Lift the handset or press hto make a hands-free call.
2. Dial the number .If you make a mistake press
Clear to delete the last digit.
Either press cto dial or it will dial automatically after a set time. To set the time for
automatic dialling, see “Delay dial” on page 41.
3.3.2 Preparatory dialling
1. Dial the number rst. If you make a mistake press
Clear to delete the last digit.
2. Lift the handset or press hto dial.
3.3.3 Make a call using speed dial keys
1. Press and hold the relevant keypad number to dial the pre-stored number directly.
NOTE
Key 1 will automatically be assigned with the voicemail number for your network provider.
Make sure the speed dial memory is set to on, see “Turn the speed dial memory on/o” on
page 18.
To assign a speed dial number, see “Store a speed dial memory number” on page 19.
3.3.4 End a call
Either press
End , place the handset back on the base or press hto end a hands-free call.
NOTE
If before the line connects, you decide that you want to end the call, replace the handset
on the base or press
Abort . To end a hands-free call press hor press Abort .

15Using the phone
3.3.5 End a single call
1. During a call press
Options and scroll dto End a single call and press Select .
2. The call will end.
3.3.6 Receive a call
When you receive an external call, the phone rings,
Incoming call and the phone number
(or name if stored in the phonebook) is displayed.
1. Lift the handset or press
Answer / hto answer the call hands-free.
2. If you don’t want to answer the call, press
Reject and the caller will be redirected.
3.4 Adjust the earpiece or hands-free volume
1. During a call, press uto increase and tto decrease the volume level. There are 8
levels to choose from, volumes 1-7 and o.
NOTE
You can also adjust the volume during a call by pressing
Options scrolling uto Volume ,
pressing
Select and then pressing uto increase and tto decrease the volume level.
3.5 Mute
1. During a call press Options and scroll dto Mute and press Select .
2. To turn mute o, press
Options and scroll dto Unmute and press Select .
3.6 Hold
You can place your caller on hold if your network operator provides the service.
1. During a call press
Options, Hold is highlighted, press Select .
2. To turn hold o, press
Options , Unhold is highlighted, press Select .

16 Phonebook
4. Phonebook
The FW200L phonebook has a capacity of up to 1000 contacts in the base and you can
also store additional contacts on the SIM (the number is dependent on the SIM capacity).
Numbers can be up to 40 digits long and names can be up to 20 characters long. Contacts
are stored in alphabetical order.
NOTE
All phonebook features can also be accessed while on a call. Press
Options and scroll d
to
Phonebook and press Select .
4.1 Entering names and writing tips
Use the alphanumeric keypad to enter names in the phonebook.
For instance to enter the name TOM.
T Press once
O Press three times
M Press once
To enter a space press .
Press
Clear to delete a character or press and hold Clear to delete characters quickly.
When entering a name into the phonebook you can scroll through the character input
methods (abc, ABC, 123 etc) by pressing the button repeatedly.
4.2 Storing contacts
The FW200L can be set so it stores contacts either to the SIM card or the phone and you
can copy or move individual contacts or the whole phonebook from the SIM card to the
phone or from the phone to the SIM card.
4.2.1 Preferred storage - SIM or phone
1. Press
Names . The rst contact is highlighted. Press Options .
2. Scroll uto
Phonebook settings and press Select .
3.
Preferred storage is highlighted, press OK .
4. Scroll uor dto
SIM or Phone and press OK .
5. Press oto return to standby.
4.2.2 Store contacts
1. Press
Names . The rst contact is highlighted.
2. Scroll uto
Add new contact and press Options .
3. Press
Select and enter the name using the keypad.
4. Scroll d and enter the number and press
Options .
5. Press
Save to store.
6. Press oto return to standby.

17Phonebook
NOTE
Cancel storing a contact by pressing oat any time during the process.
4.2.3 Move or copy individual contacts
1. Press
Names . The rst contact is highlighted.
2. Scroll uor dto the contact you want to copy and press
Options . Scroll dto Copy
and press Select .
3. Scroll uor dto
To Phone or To SIM and press Select .
4. Press oto return to standby.
4.2.4 Move or copy all contacts
1. Press
Names . The rst contact is highlighted. Press Options .
2. Scroll uto
Phonebook settings and press Select .
3. Scroll dto
Copy contacts or Move contacts and press OK .
4. Scroll uor dto
To Phone or To SIM and press OK.
5. Press Ye s to conrm or No to cancel.
6. Press oto return to standby.
NOTE
When moving or copying contacts the FW200L will move / copy all contacts even if that
contact is already saved.
4.3 View contacts
1. Press Names . The rst contact is highlighted.
2. Scroll uor dto the contact you want to view and press
Options . View is highlighted,
press
Select .
3. The name is highlighted, press dto view the number.
4. Press oto return to standby.
4.4 Dial contacts
1. Press Names . The rst contact in the phonebook is highlighted.
2. Scroll uor dto the contact you want to dial and press
Options . Scroll dto Call and
press
Select to dial the contact.

18 Phonebook
4.5 Edit a contact
1. Press Names . The rst contact is highlighted.
2. Scroll uor dto the contact you want to edit and press
Options . Scroll dto Edit and
press
Select .
3. Edit the name. Press
Clear to delete characters.
4. Scroll dand edit the number. Press
Options and then Save to conrm.
5. Press oto return to standby.
4.6 Delete a contact
1. Press Names . The rst contact is highlighted.
2. Scroll uor dto the contact you want to delete and press
Options .
3. Scroll dto
Delete and press Select .
4. Display shows
Delete? . Press Ye s to delete or No to cancel.
5. Press oto return to standby.
4.7 Delete all contacts
1. Press Names . The rst contact is highlighted. Press Options .
2. Scroll uto
Phonebook settings and press Select .
3. Scroll uto
Delete all contacts and press OK .
4. Press uor d to select either
From SIM or From Phone and press OK .
5. Display shows
Delete all? . Press Ye s to delete or No to cancel.
6. Press oto return to standby.
4.8 Turn the speed dial memory on/o
1. Press Names . The rst contact is highlighted. Press Options .
2. Scroll uto
Phonebook settings and press Select .
3. Scroll dto
Speed dial and press OK .
4.
Status is highlighted, press OK .
5. Scroll uor dto
On or O and press OK .
6. Press oto return to standby.

19Phonebook
4.9 Store a speed dial memory number
1. Press Names . The rst contact is highlighted. Press Options .
2. Scroll uto
Phonebook settings and press Select .
3. Scroll dto
Speed dial and press OK .
4. Scroll dto
Set numbers and press OK .
If no number is stored
Empty is displayed. If a number is stored the name will be
displayed.
5. Scroll dto an available keypad number 2-9 where the contact will be stored.
Press
Edit, the rst contact is displayed. Enter the rst letter of the name to search
alphabetically then scroll uor dto the exact contact, then press
OK .
6. Press oto return to standby.
NOTE
Only numbers that have been stored in the phonebook can then be stored as direct
memory numbers.
To dial direct memory numbers, see “Store a speed dial memory number” on page 19.
4.10 Edit a direct memory number
1. Press Names . The rst contact is highlighted. Press Options .
2. Scroll uto
Phonebook settings and press Select .
3. Scroll dto
Speed dial and press OK .
4. Scroll dto
Set numbers and press OK .
5. Scroll dto the contact you want to edit. Press
Options .
6.
Edit is highlighted, press Select the rst contact in the phonebook is displayed. Enter
the rst letter of the name to search alphabetically then scroll uor dto the exact
contact, then press
OK .
7. Press oto return to standby.
4.11 Delete a direct memory number
1. Press Names . The rst contact is highlighted. Press Options .
2. Scroll uto
Phonebook settings and press Select .
3. Scroll dto
Speed dial and press OK .
4. Scroll dto
Set numbers and press OK .
5. Scroll dto the contact you want to delete. Press
Options .
6. Scroll dto
Remove and press Select .
7. Press oto return to standby.
