NPort 1220/1240 USB-to-Serial Hub
User’s Manual
Second Edition, January 2004
Moxa Technologies Co., Ltd.
Tel: [phone]
Fax: [phone]
www.moxa.com
[e-mail] (Worldwide)
[email protected] (The Americas)

NPort 1220/1240 USB-to-Serial Hub
User’s Manual
The software described in this manual is furnished under a license agreement and may be used only in accordance
with the terms of that agreement.
Copyright Notice
Copyright 2004 Moxa Technologies Co., Ltd.
All rights reserved.
Reproduction without permission is prohibited.
Trademarks
MOXA is a registered trademark of Moxa Technologies Co., Ltd.
All other trademarks or registered marks in this manual belong to their respective manufacturers.
Disclaimer
Information in this document is subject to change without notice and does not represent a commitment on the part of
Moxa.
Moxa provides this document “as is,” without warranty of any kind, either expressed or implied, including, but not
limited to, its particular purpose. Moxa reserves the right to make improvements and/or changes to this manual, or to
the products and/or the programs described in this manual, at any time.
Information provided in this manual is intended to be accurate and reliable. However, Moxa Technologies assumes
no responsibility for its use, or for any infringements on the rights of third parties that may result from its use.
This product might include unintentional technical or typographical errors. Changes are periodically made to the
information herein to correct such errors, and these changes are incorporated into new editions of the publication.

Table of Contents
Chapter 1 Introduction ......................................................................................1-1
Overview ................................................................................................ 1-2
Package Checklist.................................................................................. 1-2
Product Features.................................................................................... 1-2
Product Specifications............................................................................ 1-3
NPort 1240...................................................................................... 1-3
NPort 1220...................................................................................... 1-4
Panel Layout .......................................................................................... 1-5
Dimensions............................................................................................. 1-6
DIP Switch Settings................................................................................ 1-6
Chapter 2 Driver Installation.............................................................................2-1
Installing the Driver ................................................................................ 2-2
Checking the Installation ........................................................................ 2-9
Configuring the Ports ........................................................................... 2-10
Windows 98 .................................................................................. 2-10
Windows 2000/XP ........................................................................ 2-11
Uninstalling the Driver .......................................................................... 2-12
Chapter 3 Serial Programming Tools ..............................................................3-1
Overview ................................................................................................ 3-2
PComm Installation ................................................................................ 3-2
PComm Programming Library................................................................ 3-2
Utilities.................................................................................................... 3-2
Diagnostic (for MOXA boards only)........................................................ 3-3
Monitor (for MOXA boards under Windows NT Only)............................ 3-3
Terminal Emulator.................................................................................. 3-4
Appendix A Technical Reference ....................................................................... A-1
Win32 API Function Compatible List......................................................A-2
Windows 98 ....................................................................................A-2
Windows 2000/XP ..........................................................................A-3
General Technical Reference ................................................................A-4
Appendix B Service Information ........................................................................ B-1
MOXA Internet Services.........................................................................B-2
Problem Report Form.............................................................................B-3
Product Return Procedure .....................................................................B-4
Revision History…………………………………………………………….. B-5

1
1
Chapter 1 Introduction
Welcome to MOXA NPort 1220/1240 USB-to-Serial Hub. NPort 1220 provides 2 RS-422/485 serial
ports and NPort 1240 provides 4 RS-232 serial ports.
The following topics are covered in this chapter:
 Overview
 Package Checklist
 Product Features
 Product Specifications

Overview
Connect a compact NPort 1200 Series product to your computer—you don’t even have to
power-down—install the supplied software, and then connect your serial devices directly to the NPort.
In minutes, and with state-of-the-art accuracy, you’re capturing data—temperature, pressure, sound
level, whatever you need. And you’ve done this without programming, without opening up your PC,
without even thinking about IRQs, board configuration, power requirements, or connection schemes.
NPort 1200 Series products are compliant with both USB 1.0 and 1.1 specifications, are compatible
with USB 2.0, and meet the 12 Mbps full speed requirement.
More and more peripherals are connected by the Ethernet or USB interface. The problem is how to
integrate these different interfaces. Today’s solution is to connect all devices using the open standard
Ethernet and USB. The total cost of ownership is reduced, not only in short term hardware investment,
but also in long term management and integrating cost.
The NPort 1200 Series supports both bus power and external power via an adapter. Bus power is
adapted for laptop or workstation connections that support 500 mA output for USB devices. External
power is adapted for those USB hubs that can only output 100 mA of current.
Package Checklist
MOXA NPort 1220/1240 products are shipped with the following items:
Standard Accessories
 1 NPort 1240 4-port USB to RS-232 HUB, or NPort 1220 2-port USB to RS-422/485 Hub
 NPort 1200 Series Document & Software CD
 NPort 1220/1240 Quick Installation Guide
 Product Warranty Booklet
Optional Accessories
 DK-35A DIN-Rail Mounting Kit (35 mm)
 CB-USBAMB-1M USB A type to B type Cable, 1m
NOTE: Notify your sales representative if any of the above items is missing or damaged.
Product Features
NPort 1240 Series products enjoy the following features:
 Expand to 4 RS-232 ports (NPort 1240) or 2 RS-422/485 ports (NPort 1220) through USB
 Hot plug and play
 No additional I/O or IRQ required
 RS-232 (NPort 1240) and RS-422/485 (NPort 1220) speed up to 115.2 Kbps
 Supports USB 1.1, full rate speed up to 12 Mbps
 Built-in 16 KV ESD Surge Protection
 Supports Windows 98/ME/2000/XP drivers
 Supports both bus power and external power
 NPort 1220/1220I: Supports 4-wire RS-422/485 and 2-wire RS-485 applications
 NPort 1220I: Supports 2 KV Isolation Protection
NPort 1220/1240 USB-to-Serial Hub User’s Manual
1-2

Introduction
Product Specifications
NPort 1240
USB
Compliant with USB 1.1, 1.0
USB 2.0 backwards compatible
Connector USB type B
Speed Full speed 12 Mbps
Serial
No. of Ports 4
Interface RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
Connector DB9 Male
FIFO 128 bytes
Serial line protection 16 KV ESD for all signals
Serial Communication Parameters
Parity None, Even, Odd
Data bits 7, 8
Stop bit 1, 2
Flow Control RTS/CTS, XON/XOFF
Speed 600 to 115.2 Kbps
Power Requirements
Power Input 12 to 48 VDC (External) or 5 VDC (Bus power)
Power Consumption BUS: 172 mA @ 5 VDC
Ext. PWR: 117 mA @ 12 VDC
Mechanical Specifications
Material ABS
Gross Weight 220±5 g (0.48 lb)
Environmental
Operating Temperature 0 to 55°C (32 to 131°F)
Storage Temperature -20 to 85°C (-4 to 185°F)
Operating Humidity 5 to 95% RH
Agency Approvals
EMC FCC (class B), CE (Class B)
Safety UL, CUL, TÜV
Warranty 5 years
NPort 1220/1240 USB-to-Serial Hub User’s Manual
1-3

NPort 1220
USB
Compliant with USB 1.1, 1.0
USB 2.0 backwards compatible
Connector USB type B
Speed Full speed 12 Mbps
Serial
No. of Ports 2
Interface 4-wire RS-422: TxD+/-, RxD+/-, GND
4-wire RS-485: TxD+/-, RxD+/-, GND
2-wire RS-485: Data+, Data-, GND
Connector Terminal Block
FIFO 128 bytes
Serial line protection 16 KV ESD for all signals
Serial Communication Parameters
Parity None, Even, Odd
Data bits 7, 8
Stop bit 1, 2
RS-485 Data Direction ADDC™ (Auto Data Direction Control)
Speed 600 to 115.2 Kbps
Power Requirements
Power Input 12 to 48 VDC (external) or 5 VDC (Bus power)
Power Consumption BUS: 140 mA @ 5 VDC
Ext. PWR: 306 mA @ 12 VDC
Mechanical Specifications
Material ABS
Gross Weight 215±5 g (0.48 lb)
Environmental
Operating Temperature 0 to 55°C (32 to 131°F)
Storage Temperature -20 to 85°C (-4 to 185°F)
Operating Humidity 5 to 95% RH
Agency Approvals
EMC FCC (class B), CE (Class B)
Safety UL, CUL, TÜV
Warranty 5 years
NPort 1220/1240 USB-to-Serial Hub User’s Manual
1-4

Introduction
Panel Layout
NPort 1240 Top Panel
NPort 1220 Top Panel
NPort 1240
serial interfaces
NPort 1220
serial interfaces
NPort 1220/1240 USB-to-Serial Hub User’s Manual
1-5

Dimensions
NPort 1240
NPort 1220
DIP Switch Settings
This example shows DIP Switch settings for
port 1, which uses DIP Switches 1 and 2.
The settings for port 2, which uses DIP
Switches 3 and 4, are similar. You can refer
to the DIP Switch diagrams at the right, or to
the table on the next page for the correct
settings.
NPort 1220/1240 USB-to-Serial Hub User’s Manual
1-6

Introduction
DIP Switch No. DIP Switch Setting Interface & Termination
Resistor Setting
On 4-wire RS-422/485
1 Off 2-wire RS-485
On Termination Resistor on
2 Off Termination Resistor off
NPort 1220/1240 USB-to-Serial Hub User’s Manual
1-7

2
2
Chapter 2 Driver Installation
This chapter includes information about installing the driver for NPort 1220/1240. We present the
installation procedure for both Windows 98 and Windows 2000 (the procedure for Windows XP is
essentially the same as for Windows 2000):
 Installing the Driver
 Checking the Installation
 Configuring the Ports
 Windows 98
 Windows 2000/XP
 Uninstalling the Driver
NOTE For best results, we recommend that you install the USB driver for NPort 1220/1240 before
connecting the product to your computer’s USB port.
To do this, insert the software CD (included in the NPort 1220/1240 package) into your computer’s
CD drive, and click on Install Software.

Installing the Driver
1. Connect NPort 1220/1240’s USB Port to your computer’s USB port. Make sure NPort 1220/1240
and your computer is properly connected.
2. After you connect NPort 1220/1240 to your computer, a Found New Hardware window will
automatically open.
3. When the Found New Hardware Wizard starts up, click Next to continue installing the USB
driver.
4. The setup program will prompt you with an Install Hardaware Device Drivers window. Select
Search for a suitable driver for my device (recommended), and then click Next.
NPort 1220/1240 USB-to-Serial Hub User’s Manual
2-2

Driver Installation
5. A window will open asking you where you want to locate the driver files. Check Specify a
location box, .and then click Next.
6. A window will open asking you to insert the installation disk. Insert the installation disk into your
CD drive,and then click Browse to locate the installation file.
NPort 1220/1240 USB-to-Serial Hub User’s Manual
2-3

7. Select klsibus.inf, and then click OPEN.
8. Click OK to continue.
NPort 1220/1240 USB-to-Serial Hub User’s Manual
2-4

Driver Installation
9. A window will open showing the Driver Files Search Results. Click Next to install the driver.
10. When the Completing the Found New Hardware Wizard window opens, click Finish to close
the wizard.
NPort 1220/1240 USB-to-Serial Hub User’s Manual
2-5

11. A welcome message will appear. Click Next to continue installing Moxa [Port 1].
12. A window will open asking you to insert the installation disk. Insert the installation disk into your
CD drive, and then click Browse to locate the installation file. Select klsiw2k.inf and then click
OPEN. Click OK to continue.
NPort 1220/1240 USB-to-Serial Hub User’s Manual
2-6

Driver Installation
13. A window will open showing the Driver Files Search Results. Click Next to install the driver.
14. When Completing the Found New Hardware Wizard window opens, click Finish to close this
wizard.
NPort 1220/1240 USB-to-Serial Hub User’s Manual
2-7

NOTE If you wish to install the driver using “Install Driver” program, you will need to follow the
instructions below.
1. Insert the software CD (included in the NPort 1220/1240 package) into your computer’s CD
drive, and then click on Install Software.
2. When the Install Driver window opens, click on Install to install the driver files in the default
folder (C:\Program Files\Moxa USB to Serial\drivers), or click on Browse to select a different
folder.
3. Click OK to complete the installation.
4. Connect NPort 1220/1240’s USB port to your computer’s USB port. NPort 1220/1240’s serial
ports will be installed automatically.
NPort 1220/1240 USB-to-Serial Hub User’s Manual
2-8
