Overview
The ToughNet TN-5508/5510 series M12 managed Ethernet switches are
designed for industrial applications in harsh environments. The TN series
switches use M12 and other circular connectors to ensure tight, robust
connections, and guarantee reliable operation against environmental
disturbances, such as vibration and shock. The wide selection of 12/24/36/48
VDC, 72/96/110 VDC, or 110/220 VDC/VAC dual redundant power supplies
increases the reliability of your communications. TN-5508 switches provide
up to 8 fast Ethernet M12 ports.
TN-5510 switches provide up to 16 fast Ethernet M12 ports, and 2 Gigabit
Ethernet ports on the bottom panel which provide an optional bypass relay
function. Models with an extended operating temperature range of -40 to
75°C are also available. The TN-5508/5510 series Ethernet switches are
compliant with EN50155/50121-3-2/50121-4 (railway applications), NEMA
TS2 (traffic control systems), and e-Mark (vehicles) requirements, making
the switches suitable for a variety of industrial applications.
Package Checklist
Your ToughNet TN-5508/5510 switch is shipped with the following items. If
any of these items is missing or damaged, please contact your customer
service representative for assistance.
y1 Moxa ToughNet switch.
yHardware installation guide.
yCD-ROM with user’s manual, Windows utility, and SNMP MIB file.
yMoxa product warranty statement.
yM12 to DB9 console port cable.
y2 protective caps for console and relay output ports.
yPanel mounting kit.
Features
Anti-Vibration Circular Connectors for Robust Links
yM12 D-coding 4 pins female connectors for Fast Ethernet 10/100BaseT(X)
ports.
yCircular connectors (RJ45-type) for Gigabit Ethernet
10/100/1000BaseT(X) ports.
yM12 A-coding 5 pins male connectors for console and relay output.
yM23 5 pins male connector for power input.
Dual, Isolated Redundant Power Inputs
y2 Gigabit Ethernet ports for flexibility with high bandwidth requirements.
yBypass relay function on the 2 Gigabit Ethernet ports to ensure data
communications even if an individual device fails.
ySupports 12/24/36/48 VDC (8.4–60 VDC).
ySupports 72/110 VDC (50.4–54 VDC), isolated.
ySupports 110/220 VDC/VAC (88–300VDC, 85–264 VAC), isolated.
yDual redundant, parallel load-sharing power supplies.

—2 —
High Performance Network Switching Technology
yIPv6 Ready logo awarded (IPv6 Logo Committee certified).
yIEEE 1588 PTP (Precision Time Protocol) for precise time
synchronization of networks.
yDHCP Option 82 for IP address assignment with different policies.
yModbus/TCP industrial Ethernet protocol.
yTurbo Ring, Turbo Chain,and RSTP/STP (IEEE802.1w/D).
yIGMP Snooping and GMRP for filtering multicast traffic from industrial
Ethernet protocols.
yPort-based VLAN, IEEE802.1Q VLAN, and GVRP protocol to ease
network planning.
yQoS (IEEE802.1p/1Q and TOS/DiffServ) to increase determinism.
y802.3ad, LACP for optimum bandwidth utilization.
yIEEE802.1X and https/SSL to enhance network security.
ySNMP v1/v2c/v3 for different levels of network management.
yRMON for efficient network monitoring and proactive capability.
yBandwidth management prevents unpredictable network status.
yLock port allows access by only authorized MAC addresses.
yPort mirroring for online debugging.
yAutomatic warning by exception through email, relay output.
yAutomatic recovery of connected device’s IP addresses.
yLine-swap fast recovery.
yLLDP for automatic topology discovery in network management software.
yConfigurable through Web browser, Telnet/Serial console, and Windows
utility.
Designed for Industrial-Specific Applications
yThree rotary switches for setting the last 3 digits of the IP address makes
maintenance even easier.
yEN 50155/50121-3-2/50121-4, NEMA TS2, and e-Mark compliant.
y-40 to 75°C operating temperature range (for “-T” models).
yIP54/IP67, rugged high-strength case.
yPanel mounting or DIN-Rail mounting installation capability.
Recommended Optional Accessories
yCBL-M23(FF5P)Open-BK-100-IP67: 1-meter M23-to-5-pin power cable
with IP67-rated female 5-pin M23 connector.
yCBL-M12D(MM4P)/RJ45-100 IP67: 1-meter M12-to-RJ45 Cat-5E UTP
Ethernet cable with IP67-rated male 4-pin M12 D-coded connector.
yCBL-M12(FF5P)/OPEN-100 IP67: 1-meter M12-to-5-pin power cable
with IP67-rated female 5-pin M12 A-coded connector.
yM12D-4P-IP68: Field-installable M12 D-coded screw-in connector, male
4-pin, IP68-rated.
yM12A-5P-IP68: Field-installable M12 A-coded screw-in connector,
female 5-pin, IP68-rated.
yA-CAP-M12F-MIP67-PAK04: Cap for M12 D-coded male 4-pin
connector, metal, IP67, 4 pieces in one pack.

—3 —
yDK-DC50131: DIN-Rail mounting kit, 50 x 131 mm.
yA-PLG-WPRJ-02: Field-installable circular connector kit for RJ45
twisted-pair cable, IP67-rated.
TN-5508 Panel Layouts
Top View
Front View
Botton View
Rear View
15
16
17
17
1
2
3
4
5
6
7
8 9 10 11 12
2
13
14
18
19
1. 3 Rotary switches and protective cover with Model name.
2. Screw holes for panel mounting kit.
3. Console port.
4. Grounding screw.
5. Relay output port.

—4 —
6. Power input voltage range indication.
7. Power input port (male 5-pin shielded M23 connector).
8. PWR1 LED: for power input 1.
9. PWR2 LED: for power input 2.
10. FAULT LED.
11. MSTR/HEAD LED: for ring master or chain head.
12. CPLR/TAIL LED: for ring coupler or chain tail.
13. TP port’s 10/100 Mbps LED.
14. 10/100BaseT(X) port (female 4-pin shielded M12 connector with D
coding).
15. Waterproof vent.
16. Product label.
17. 12 Screw holes for DIN-Rail mounting kit.
18. E1 LED: Not used by the TN-5508 series.
19. E2: LED: Not used by the TN-5508 series.

—5 —
TN-5510 Panel Layouts
Top View
Front View
Botton View
Rear View
15
16
17
17
1
2
3
4
5
6
7
8 9 10 11 12
2
13
14
18
19
20
21
1. 3 Rotary switches and protective cover with Model name.
2. Screw holes for panel mounting kit.
3. Console port.
4. Grounding screw.
5. Relay output port.
6. Power input voltage range indication.
7. Power input port (male 5-pin shielded M23 connector).

—6 —
8. PWR1 LED: for power input 1.
9. PWR2 LED: for power input 2.
10. FAULT LED.
11. MSTR/HEAD LED: for ring master or chain head.
12. CPLR/TAIL LED: for ring coupler or chain tail.
13. TP port’s 10/100 Mbps LED.
14. 10/100BaseT(X) port (female 4-pin shielded M12 connector with D
coding).
15. Waterproof vent.
16. Product label.
17. 12 Screw holes for DIN-Rail mounting kit.
18. E1 LED: Down-side E1 Gigabit port's 10/100/1000 Mbps LED.
19. E2: LED: Down-side E2 Gigabit port's 10/100/1000 Mbps LED.
20. Gigabit Ethernet port E1 (corresponding to port 17 in the TN-5510
User's Manual).
21. Gigabit Ethernet port E2 (corresponding to port 18 in the TN-5510
User's Manual).
ATTENTION
Please DO NOT open or remove vent 15. The warranty will be
invalid if the seal is removed.
All exposed connectors, including 3, 5, 7, and 14, should be
tightly covered by protective caps when they are not in use to
ensure for IP54/IP67 protection.
After setting rotary switch 1, the protective cover must be fixed
properly to ensure IP54/IP67 protection.

—7 —
Mounting Dimensions (unit = mm)
TN-5508 Series

—8 —
TN-5510 Series

—9 —
Panel/Wall Mounting
STEP 1:
Mounting the TN-5508/5510 to a wall requires 4 screws. Use the ToughNet
switch as a guide to mark the correct positions of the 4 screws.
STEP 2:
Use the 4 screws in the panel mounting kit. If you
would like to use your own screws, make sure the
screw head is between 6.0 mm and 7.0 mm in
diameter and the shaft is less than 4.0 mm in diameter,
as shown at the right.
Do not screw the screws in all the way—leave a space of about 2 mm to
allow room for sliding the ToughNet switch between the wall and the screws.
NOTE Before tightening the screws into the wall, make sure the screw
head and shaft size are suitable by inserting the screw through one
of the keyhole-shaped apertures of the ToughNet switch.
STEP 3:
Once the screws are fixed in the wall, hang the ToughNet switch on the 4
screws through the large opening of the keyhole-shaped apertures, and then
slide the switch downwards. Tighten the four screws for added stability.
NOTE To provide greater protection from vibrations and shocks, use
screws with shaft diameter between 6.0 mm and 7.0 mm, and fix
the ToughNet switch onto the wall directly through the large
opening of the keyhole-shaped apertures.
DIN-Rail Mounting (optional)
Use a pair of optional DK-DC50131
DIN-Rail mounting kits (must be
purchased separately) to mount the
TN-5508/5510 on a 35 mm DIN-Rail.
STEP 1:
Use 12 screws (6 screws per plate) to
attach the two DIN-Rail attachment
plates to the rear panel of the switch
Recessed button
Spring-loaded bracket
6.0 - 7.0 mm
< 4.0 mm

—10 —
STEP 2:
If the spring-loaded bracket is locked in place, push the recessed button to
release it. Once released, you should feel some resistance from the spring as
you slide the bracket up and down a few millimeters in each direction.
STEP 3:
Insert the top of the DIN-Rail into the
top slot of the DIN-Rail attachment
plates.
STEP 4:
The DIN-Rail attachment plates will
snap into position, as shown in the
figure below.
DIN-Rail
DIN-Rail
To remove the Moxa ToughNet Switch from the DIN-Rail, use a screwdriver
to pull down the bottom parts of the two spring-loaded brackets until they are
fixed in the “locked” position, and then reverse Steps 3 and 4 above.
DIN-Rail
Wiring Requirements
WARNING
Turn the power off before disconnecting modules or wires. The
correct power supply voltage is listed on the product label. Check
the voltage of your power source to make sure you are using the
correct voltage. Do NOT use a voltage greater than what is
specified on the product label.
These devices must be supplied by a SELV source as defined in
the Low Voltage Directive 2006/95/EC and 2004/108/EC.
ATTENTION
Safety First!
Observe all electrical codes dictating the maximum current
allowable for each wire size. If the current goes above the
maximum ratings, the wiring could overheat, causing serious
damage to your equipment.

—11 —
ATTENTION
Safety First!
Be sure to disconnect the power cord before installing and/or
wiring your Moxa switch.
This device has UL508 approval. Use copper conductors only,
60/75°C, and tighten to 4.5 pound-inches. For use in pollution
degree 2 environments.
Please read and follow these guidelines:
yUse separate paths to route wiring for power and devices. If power wiring
and device wiring paths must cross, make sure the wires are perpendicular
at the intersection point.
NOTE: Do not run signal or communications wiring and power
wiring through the same wire conduit. To avoid interference, wires
with different signal characteristics should be routed separately.
yYou can use the type of signal transmitted through a wire to determine
which wires should be kept separate. The rule of thumb is that wiring that
shares similar electrical characteristics can be bundled together.
yKeep input wiring and output wiring separated.
yIt is strongly advised that you label wiring for all devices in the system
when necessary.
Grounding the ToughNet Switch
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from the
grounding screw to the grounding surface prior to connecting devices.
ATTENTION
This product is intended to be mounted to a well-grounded
mounting surface such as a metal panel.

—12 —
Connecting the Power Supplies
The ToughNet TN-5508/5510 switches support two sets of power
supplies—power input 1 and power input 2.The M23 5-pin male connector
on the TN-5508’s front panel is used for the dual power inputs. Use a power
cord with an M23 5-pin female connector to connect the power inputs to the
switch. You may purchase an M23 power cable from Moxa. The model
number of this cable, which must be purchased separately, is CBL-M23
(FF5P) Open-BK-100-IP67.
Pinouts for the power input port on the TN-5508/5510
Pinouts for the power input port on the TN-5508/5510.
Pin Description Usage
1 PWR1 Live / DC +
Connect “PWR1 Live / DC +” to the Live
terminal when using an AC power source or
to the positive (+) terminal when using a DC
power source.
2 PWR1 Neutral / DC -
Connect “PWR1 Neutral / DC –“to the
Neutral terminal when using an AC power
source or to the negative (-) terminal when
using a DC power source.
3 Chassis Ground Connect the “Chassis Ground” to the safety
ground terminal for AC inputs or to the
equipment ground bus for DC inputs.
4 PWR2 Neutral / DC -
Connect “PWR2 Neutral / DC –”to the
Neutral terminal when using an AC power
source or to the negative (-) terminal when
using a DC power source.
5 PWR2 Live / DC +
Connect “PWR2 Live / DC +” to the (Live)
terminal when using an AC power source or
to the positive (+) terminal when using a DC
power source.
STEP 1:
Plug your power cord’s M23 connector to the power input port of the
TN-5508/5510 switch.
STEP 2:
Screw the nut on your power cord connector to the power input connector on
the switch to ensure a tight connection.

—13 —
ATTENTION
Before connecting the TN-5508/5510 to the power input, make
sure the power source voltage is stable.
Connecting the Relay Outputs
Each TN-5508/5510 switch has two sets of relay outputs—relay output 1 and
relay output 2. The M12 A-coded 5-pin male connector on the
TN-5508/5510’s front panel is used for the two relay outputs. Use a power
cord with an M12 A-coded 5-pin female connector to connect the relay
contacts from the switch. You may purchase an M12 power cable from Moxa.
The model number of the cable, which must be purchased separately, is
CBL-M12 (FF5P)/OPEN-100 IP67.
Pinouts for the relay output port on TN-5508/5510.
N.C.: Not connected
FAULT:
The two sets of relay contacts of the M12 A-coded 5-pin male connector are
used to detect user-configured events. The two wires attached to the fault
contacts form an open circuit when a user-configured event is triggered. If a
user-configured event does not occur, the fault circuit remains closed.
Connecting the Data Lines
10/100BaseT(X) Ethernet Port Connection
All TN-5508/5510 models have 8 10/100BaseT(X) Ethernet ports (4-pin
shielded M12 connector with D coding). The 10/100TX ports located on the
TN-5508/5510 front panel are used to connect to Ethernet-enabled devices.
Most users configure these ports for Auto MDI/MDI-X mode, in which case
the port’s pinouts are adjusted automatically depending on the type of
Ethernet cable used (straight-through or cross-over), and the type of device
(NIC-type or HUB/Switch-type) connected to the port.
In what follows, we give pinouts for both MDI (NIC-type) ports and MDI-X
(HUB/Switch-type) ports. We also give cable wiring diagrams for
straight-through and cross-over Ethernet cables.

—14 —
Pinouts for the 10/100BaseT(X) Ports on the TN-5508/5510.
Housing: shield
Pinouts for the RJ45 (8-pin) Port
RJ45 (8-Pin) MDI Port Pinouts MDI-X Port Pinouts
18
Pin Signal
1 Tx +
2 Tx -
3 Rx +
6 Rx -
Pin Signal
1 Rx +
2 Rx -
3 Tx +
6 Tx -
M12 (4-pin, M) to M12 (4-pin, M) Cross-Over Cable Wiring
Tx+
Rx+
Tx-
Rx-
Cross-Over Cable Wiring
1
2
3
4
1
2
3
4
Tx+
Rx+
Tx-
Rx-
M12 (4-pin, M) to M12 (4-pin, M) Straight-Trough Cable Wiring
Tx+
Rx+
Tx-
Rx-
Straight-through Cable Wiring
1
2
3
4
1
2
3
4
Rx+
Tx+
Rx-
Tx-
M12 (4-pin, M) to RJ45 (8-pin) Cross-Over Cable Wiring
Tx+
Rx+
Tx-
Rx-
Cross-Over Cable Wiring
1
2
3
4
1
2
3
6
Tx+
Tx-
Rx+
Rx-

—15 —
M12 (4-pin, M) to RJ45 (8-pin) Straight-Trough Cable Wiring
Tx+
Rx+
Tx-
Rx-
Straight-through Cable Wiring
1
2
3
4
1
2
3
6
Rx+
Rx-
Tx+
Tx-
10/100/1000BaseT(X) Ethernet Port Connection
The TN-5510-2GTX models have two Gigabit Ethernet ports with RJ45-type
circular connectors. The
10/100/1000BaseT(X) ports located on
the bottom of the TN-5510 are used for
connecting Ethernet-enabled devices.
These two ports support standard
Ethernet cables with RJ45 connectors;
however, they will not be vibration or
water-proof. To ensure a tight
connection, a mating circular plug
housing is necessary. You can purchase
the circular RJ45 plug connector kit
from Moxa; the model is
A-PLG-RJ-IP67.
1000BaseT Ethernet Port Connection
1000Base-T data is transmitted on differential TRD+/- signal pairs over
copper wires.
MDI/MDI-X Port Pinouts
Pin Signal
1 TRD(0)+
2 TRD(0)-
3 TRD(1)+
4 TRD(2)+
5 TRD(2)-
6 TRD(1)-
7 TRD(3)+
8 TRD(3)-
1 8

—16 —
Rotary Switch IP Address Settings
The ToughNet TN-5508/5510 switches have 3 rotary switches on the front
panel for configuring the IP address without using a PC, making onsite
configuration extremely convenient. This can be especially helpful when you
need to replace a faulty switch quickly.
STEP 1: Remove the protective cover by unscrewing the 2 screws with an
Allen wrench (also called an Allen key or hex key).
STEP 2: Use a flat-bladed screwdriver to rotate the 3 rotary switches to point
to the chosen numbers.
STEP 3: Replace the protective cover and then tighten the screws to the
proper torque.
STEP 4: Restart the ToughNet switch to enable the newly configured IP
address.
NOTE 1. “Hardware-based IP configuration” only supports IPv4
address settings.
2. “Hardware-based IP configuration” is enabled only when the
3 rotary switches are set to values ranging from 001 to 254.
The ToughNet switch’s IP address will be configured as
“192.168.127.xxx”, where “xxx” are valid value numbers set
by the rotary switches.
3. When enabled, “Hardware-based IP configuration” overrides
the “Auto IP Configuration” described in the “IP Settings”
section in the user’s manual.
4. Disable “Hardware-based IP configuration” by setting the 3
rotary switches to 000 (the factory default).
5. If the rotary switch numbers are set to an invalid combination
(255 to 999), the ToughNet switch will use the fixed IP
address 192.168.127.253 by default.
ATTENTION
The protective cover must be fixed properly to ensure IP54/IP67
protection. Use a torque wrench set to a torque of 4 kgf-m when
tightening the screws. Note that applying a larger torque may
damage the plastic protective cover.
Bypass Relay Function
The TN-5510-2GTXBP models’ two Gigabit Ethernet ports are equipped
with a bypass relay function. When the switch is operating normally, these
two Gigabit ports work in the same way as the other ports. That is, frame
ingressions are processed and then forwarded. In the event the switch stops
working due to a power failure, the bypass relay function will be triggered to
ensure non-stop data communication.
The figure below illustrates the bypass relay function. For example, if Switch
B loses power, then the two Gigabit ports will be bypassed through the relay
circuit and the transmission line from Switch A to B and the transmission line

—17 —
from Switch B to C will interconnect automatically; this way there is no
stoppage.
The bypass relay function helps the network recover from single-node
failures in a linear topology.
With the maximum segment length of category 5 twisted-pair cable being 100
meters, cable length must be considered when designing a network that
utilizes this function. For example, the total length of the cables from Switch
A to B and from B to C must be no more than 100 meters. This way, if the
two adjacent nodes (switch B and C for example) encounter a power failure,
there will be no stoppage, provided that the total length of the cables A-to-B,
B-to-C, and C-to-D are no more than 100 meters.
The bypass relay function works best for networks with linear topologies.
ToughNet™ switches with bypass relay function are not recommended to be
used in networks that employ ring topologies because network loops may
occur when redundancy protocols such as RSTP or TurboRing™ are applied.
LED Indicators
Several LED indicators are located on the ToughNet switch’s front panel.
The function of each LED is described in the table below.
LED Color State Description
System LEDs
ON Power is being supplied to power input
PWR1.
PWR1 AMBER OFF Power is not being supplied to power input
PWR1
ON Power is being supplied to power input
PWR2.
PWR2 AMBER OFF Power is not being supplied to power input
PWR2.
ON When the corresponding PORT alarm is
enabled, and a user-configured event is
triggered.
FAULT RED
OFF
When the corresponding PORT alarm is
enabled and a user-configured event is not
triggered, or when the corresponding PORT
alarm is disabled.
MSTR/
HEAD GREEN ON When the TN switch is either the Master of
this Turbo Ring, or the Head of this Turbo
Chain.
Bypassing
Switch A Switch B Switch C Switch D

—18 —
Blinking
When the TN switch is Ring Master of this
Turbo Ring and the Turbo Ring is broken, or
it is Chain Head of this Turbo Chain and the
Turbo Chain is broken.
OFF When the TN switch is neither the Master of
this Turbo Ring, nor the Head of this Turbo
Chain.
ON
When the TN switch enables the coupling
function to form a back-up path in this
Turbo Ring, or it is the Tail of this Turbo
Chain.
CPLR/
TAIL GREEN
OFF When the TN switch disables the coupling
function of Turbo Ring, or it is not the Tail
of the Turbo Chain.
Ports LEDs
ON TP port’s 10 Mbps link is active.
Blinking Data is being transmitted at 10 Mbps.
AMBER
Off TP port’s 10 Mbps link is inactive.
On TP port’s 100 Mbps link is active.
Blinking Data is being transmitted at 100 Mbps.
TP
(10/100M)
GREEN
off TP port’s 100 Mbps link is inactive.
On TP port’s 10 or 100 Mbps link is active.
Blinking Data is being transmitted at 10 or 100 Mbps.
AMBER
off TP port’s 10 or 100 Mbps link is inactive.
On TP port’s 1000 Mbps link is active.
Blinking Data is being transmitted at 1000 Mbps.
E1/E2
(10/100/
1000M) GREEN
off TP port’s 1000 Mbps link is inactive.
Specifications
Technology
Standards IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X)
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3x for Flow Control
IEEE 802.1D for Spanning Tree Protocol
IEEE 802.1w for Rapid STP
IEEE 802.1Q for VLAN Tagging
IEEE 802.1p for Class of Service
IEEE 802.1X for Authentication
IEEE 802.3ad for Port Trunk with LACP
Protocols IGMP v1/v2 device, GMRP, GVRP, SNMP
v1/v2C/v3, DHCP Server/Client, DHCP Option
66/67/82, BootP, TFTP, SNTP, SMTP, RARP,
RMON, HTTP, HTTPS, Telent, SSH, Syslog,
LLDP, IEEE 1588 PTP, Modbus/TCP, IPv6

—19 —
MIB MIB-II, Ethernet-like MIB, P-BRIDGE MIB,
Q-BRIDGE MIB, Bridge MIB, RSTP MIB, RMON
MIB Group 1, 2, 3, 9
Flow Control IEEE802.3x flow control, back pressure flow
control
Switch Properties
Priority Queues 4
Max. Number of
Available VLANs 64
VLAN ID Range VID 1 to 4094
IGMP Groups 256
Interface
Fast Ethernet Front cabling, M12 connector, 10/100BaseT(X) auto
negotiation speed, F/H duplex mode, and auto
MDI/MDI-X connection
Gigabit Ethernet Down cabling, circular connector (RJ45 inside),
10/100/1000BaseT(X) auto negotiation speed, F/H
duplex mode, auto MDI/MDI-X connection, with or
without bypass relay function
Console Port M12 A-coding 5-pin male connector
System LED Indicators PWR1, PWR2, FAULT, MSTR/HEAD,
CPLR/TAIL
Port LED Indicators 10/100M (fast Ethernet port), 10/100/1000M
(Gigabit Ethernet port)
Alarm Contact Two relay outputs in one M12 A-coding 5-pin male
connector with current carrying capacity of 3 A @
30 VDC or 3 A @ 240 VAC
Rotary Switches For setting the last 3 digits of the IP address
Power Requirements
Input Voltage LV: 12/24/36/48 VDC (8.4 to 60 VDC)
MV: 72/96/110 VDC (50.4 to 154 VDC)
HV: 110/220 VDC/VAC (88 to 300 VDC, 85 to 264
VAC)
Input Current TN-5508 Series:
0.234 A @ 24 VDC, 0.104 A @ 72 VDC, 0.072 A
@ 110 VDC, 0.18 A @ 110 VAC, 0.12 A @ 220
VAC
TN-5510-2GTX Series:
0.416A@24VDC, 0.187A@72VDC,
0.129A@110VDC, 0.316@A110VAC,
0.208A@220VAC
TN-5510-2GTXBP Series:
0.52@24VDC, 0.218A@72VDC, 0.150A@11VDC,
0.369A@110VAC, 0.243A@220VAC
Connection M23, 5-pin male connector
