PT-7710 Series
Quick Installation Guide
Moxa PowerTrans Switch
Edition 5.1, September 2015
Technical Support Contact Information
www.moxa.com/support
Moxa Americas:
Toll
-free: 1-888-669-2872
Tel:
1-714-528-6777
Fax:
1-714-528-6778
Moxa China (Shanghai office):
Toll
-free: 800-820-5036
Tel:
[phone]
Fax:
[phone]
Moxa Europe:
Tel:
[phone]
Fax:
[phone]
Moxa Asia-Pacific:
Tel:
[phone]
Fax:
[phone]
Moxa India:
Tel:
[phone]
Fax:
[phone]

2015 Moxa Inc. All rights reserved.
www.ipc2u.ru
www.moxa.pro

- 2 -
Package Checklist
The Moxa PowerTrans switch is shipped with the following items. If any of
these items are missing or damaged, please contact your customer
service representative for assistance.
•1 Moxa PowerTrans Switch
•RJ45 to DB9 console port cable
•2 rack-mount ears or wall-mount ears
•Hardware installation guide
•CD-ROM with User’s Manual and SNMP MIB file
•Warranty card
Panel Layout
1. System status LEDs
2. Interface module mode LEDs
3. Interface module port LEDs
4. Push-button switch to select mode for Interface Module
5. Model name
6. Fast Ethernet interface modules
7. Gigabit Ethernet interface modules
8. Serial console port
9. 10-pin terminal block for power inputs, and relay output
10. Rack mounting kit
11. Wall mounting kit
www.ipc2u.ru
www.moxa.pro

- 3 -
Dimensions (unit = mm)
Fast Ethernet Interface Modules (slot 1)
www.ipc2u.ru
www.moxa.pro

- 4 -
Gigabit / Fast Ethernet Interface Modules (slot 2)
Rack Mounting
Use four screws to attach the PT switch to a
standard rack.
Wall Mounting
Use four screws to attach the PT switch to a Moxa wall mounting kit.
Wiring Requirements
WARNING
Safety First!
•
Be sure to disconnect the power cord before installing and/or
wiring your Moxa PowerTrans Switch.
•
Calculate the maximum possible current in each power wire
and common wire. Observe all electrical codes dictating the
maximum current allowable for each wire size.
•
If the current goes above the maximum ratings, the wiring
could overheat, causing serious damage to your equipment.
Grounding the Moxa PowerTrans Switch
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from the
ground screw to the grounding surface prior to connecting devices.
www.ipc2u.ru
www.moxa.pro

- 5 -
Wiring the Power Input (110/220 VDC/VAC
models)
The PT-7710 (110/220
VDC/VAC
models) has one
set of power inputs,
referred to as power input
1. The front view of the
terminal block connector is
shown here.
STEP 1: Insert the L/N AC wires into the PWR1 terminals (L pin 1, N 
pin 2).
STEP 2: To keep the AC wires from pulling loose, use a screwdriver to
tighten the wire-clamp screws on the front of the terminal block.
Wiring the Redundant Power Inputs (12/24/48
VDC models)
The PT-7710 (12/24/48
VDC models) has two sets
of power inputs, referre
d
to as power input 1 and
power input 2. The front
view of the terminal block
connector is shown here.
STEP 1: Insert the dual set positive/negative DC wires into PWR1 and
PWR2 terminals (+ pins 1, 9; - pins 2, 10).
STEP 2: To keep the DC wires from pulling loose, use a screwdriver to
tighten the wire-clamp screws on the front of the terminal block.
Wiring the Relay Contact
Each PT switch has one
relay output. Refer to the
next section for detailed
instructions on how to
connect the wires to the
term
inal block connector,
and how to attach the
terminal block connector to the terminal block receptor.
FAULT: The RELAY contacts of the 10-pin terminal block connector are
used to detect user-configured events. The two wires attached to the
RELAY contacts form an open circuit when a user-configured event is
triggered. If a user-configured event does not occur, the RELAY circuit will
be closed.
www.ipc2u.ru
www.moxa.pro

- 6 -
LED Indicators
The front panel of the PT switch contains several LED indicators. The
function of each LED is described in the table below.
LED
Color
State
Description
System LEDs
STAT
GREEN
On
System has passed self-diagnosis test
on boot-up and is ready to run.
Blinking System is undergoing the
self-diagnosis test.
RED On
System failed self-diagnosis on
boot-up.
PWR1 AMBER
On
Power is being supplied to the main
module’s power input PWR1.
Off Power is not being supplied to the main
module’s power input PWR1.
PWR2 AMBER
On
Power is being supplied to the main
module’s power input PWR2.
Off
Power is not being supplied to the main
module’s power input PWR2.
FAULT RED
On
The corresponding PORT alarm is
enabled and a user-configured event
has been triggered.
Off
The corresponding PORT alarm is
enabled and a user-configured event
has not been triggered, or the
corresponding PORT alarm is disabled.
MSTR/HEAD
GREEN
On
This PT switch is set as the Master of
the Turbo Ring, or as the Head of the
Turbo Chain.
Blinking
The PT switch has become the Ring
Master of the Turbo Ring, or the Head
of the Turbo Chain, after the Turbo
Ring or the Turbo Chain went down.
Off
The PT switch is not the Master of this
Turbo Ring or is set as a Member of the
Turbo Chain.
CPLR/TAIL GREEN
On
When this PT switch is enabled to form
a back-up path, or it is set as the Tail of
the Turbo Chain.
Blinking
Turbo Chain is down.
Off
This PT switch disabled the coupling
function, or is set as a Member of the
Turbo Chain.
www.ipc2u.ru
www.moxa.pro

- 7 -
LED
Color
State
Description
Mode LEDs
LNK/ACT GREEN
On
The corresponding module port’s link is
active.
Blinking
The corresponding module port’s data
is being transmitted.
Off
The corresponding module port’s link is
inactive.
SPEED GREEN
Off The corresponding module port’s data
is being transmitted at 10 Mbps.
On
The corresponding module port’s data
is being transmitted at 100 Mbps.
Blinking
The corresponding module port’s data
is being transmitted at
1000 Mbps.
FDX/HDX GREEN
On
The corresponding module port’s data
is being transmitted in full duplex
mode.
Off
The corresponding module port’s data
is being transmitted in half duplex
mode.
RING/CHAI
N PORT GREEN
On
The corresponding module’s port is the
ring or chain port of this PT switch.
Off The corresponding module’s
port is not
the ring or chain port of this PT switch.
COUPLER
PORT GREEN
On
The corresponding module’s port is the
coupler port of this PT switch.
Off
The corresponding module’s port is not
the coupler port of this PT switch.
*Slot 2 (M2) is mainly used for Gigabit modules. If 100BaseFX modules
are used in Slot 2 (M2), the modules will not support “Far End Fault”. The
Link/ACT LED indicator will stay at “Green (ON)” status when Fiber TX
cable is unplugged.
Specifications
Technology
Standards
IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x,
802.1D, 802.1W, 802.1Q, 802.1p, 802.1X, 802.3ad
Flow control
IEEE 802.3x flow control, back pressure flow control
Interface
Fast Ethernet
Slot 1 (M1) for any combination of 4-,6-, 7-, or
8-port PM-7200 fast Ethernet modules with
10/100BaseT(X) (TP/M12 interface) or 100BaseFX
(SC/ST connector), or 100BaseSFP; Slot 2 (M2)
for a
1- or 2-port interface modules with 100BaseFX
(SC/ST connector)
Gigabit Ethernet
Slot 2 (M2) for 2-port PM-7200 Gigabit Ethernet
combo module with 100/1000BaseT(X) or
1000BaseSFP slots (Slot 2 does not support 10M
FDX/HDX)
Console
RS-232 (RJ45)
System LED
Indicators
STAT, PWR1, PWR2, FAULT, MSTR/HEAD, CPLR/TAIL
www.ipc2u.ru
www.moxa.pro

- 8 -
Mode LED
Indicators
LNK/ACT, FDX/HDX, RING/CHAIN PORT, COUPLER
PORT, SPEED
Alarm Contact
One relay output with current carrying capacity of 3A
@ 30 VDC or 3A @ 240 VAC
Optical Fiber (100BaseFX)
Distance
Multi-mode:
0 to 5 km, 1300 nm (50/125 μm, 800 MHz*km)
0 to 4 km, 1300 nm (62.5/125 μm, 500 MHz*km)
Single-mode:
0 to 40 km, 1310 nm (9/125 μm, 3.5 PS/(nm*km))
Min. TX Output
Multi-mode: -20 dBm; single-mode: -5 dbm
Max. TX Output
Multi-mode: -10 dBm; single-mode: 0 dbm
RX Sensitivity
Multi-mode: -32 dBm; single-mode: -34 dbm
Power
Input Voltage
12/24/48 VDC (9 to 60 V), or 110/220 VDC/VAC (88
to 300 VDC and 85 to 264 VAC)
Input Current
Max. 0.81 A @ 24 VDC
Max. 0.42 A @ 48 VDC
Max. 0.17/0.10 A @ 110/220 VDC
Max. 0.38/0.20 A @ 110/220 VAC
Physical Characteristics
Housing
IP30 protection, metal case
Dimensions
(W x H x D)
266.7 x 44 x 195 mm (10.5 x 1.73 x 7.68 in.)
Weight
2200 g
Environmental Limits
Operating Temp.
-40 to 85°C (-40 to 185°F)
Cold start of min. 100 VAC at -40°C
Storage Temp.
-40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity.
5 to 95% (non-condensing)
Regulatory Approvals
Safety
EN 60950-1
Power Automation
IEC 61850-3, IEEE 1613
Road Traffic
NEMA TS2
Rail Traffic
EN 50121-4
EMI
FCC Part 15, CISPR (EN 55022) class A
Warranty
Warranty Period
5 years
Details
See www.moxa.com/warranty
