Moxa Technologies MPC-2190X User manual

MPC-2190 Panel Computer Hardware
Manual
Second Edition, March 2015
www.moxa.com/product
© 2015 Moxa Inc. All rights reserved.

MPC-2190 Panel Computer Hardware
Manual
The software described in this manual is furnished under a license agreement and may be used only in accordance with
the terms of that agreement.
Copyright Notice
© 2015 Moxa Inc. All rights reserved.
Trademarks
The MOXA logo is a registered trademark of Moxa Inc.
All other trademarks or registered marks in this manual belong to their respective manufacturers.
Disclaimer
Information in this document is subject to change without notice and does not represent a commitment on the part of
Moxa.
Moxa provides this document as is, without warranty of any kind, either expressed or implied, including, but not limited
to, its particular purpose. Moxa reserves the right to make improvements and/or changes to this manual, or to the
products and/or the programs described in this manual, at any time.
Information provided in this manual is intended to be accurate and reliable. However, Moxa assumes no responsibility for
its use, or for any infringements on the rights of third parties that may result from its use.
This product might include unintentional technical or typographical errors. Changes are periodically made to the
information herein to correct such errors, and these changes are incorporated into new editions of the publication.
Technical Support Contact Information
www.moxa.com/support
Moxa Americas
Toll-free: 1-888-669-2872
Tel: [phone]
Fax: [phone]
Moxa China (Shanghai office)
Toll-free: 800-820-5036
Tel: [phone]
Fax: [phone]
Moxa Europe
Tel: [phone]
Fax: [phone]
Moxa Asia-Pacific
Tel: [phone]
Fax: [phone]

Table of Contents
1. Introduction...................................................................................................................................... 1-1
Overview ........................................................................................................................................... 1-2
Ordering Information ..........................................................................................................................1-2
Package Checklist ............................................................................................................................... 1-2
Product Features ................................................................................................................................ 1-3
MPC-2190 Hardware Specifications .......................................................................................................1-3
MPC-2190 Available Option Table ..................................................................................................1-5
Hardware Block Diagram .....................................................................................................................1-6
2. Hardware Introduction...................................................................................................................... 2-1
Appearance........................................................................................................................................2-2
Front View..................................................................................................................................2-2
Bottom View ...............................................................................................................................2-2
Dimensions ........................................................................................................................................2-3
SavvyTouch Display Control Buttons .....................................................................................................2-3
Real Time Clock..................................................................................................................................2-4
3. Hardware Connection Description ..................................................................................................... 3-1
Placement Notes.................................................................................................................................3-2
Desktop Mounting .......................................................................................................................3-3
Wall Mounting ............................................................................................................................. 3-3
VESA Mounting ........................................................................................................................... 3-5
Wiring Requirements...........................................................................................................................3-6
Temperature Requirements..................................................................................................................3-6
Important Safety Precaution .........................................................................................................3-6
Grounding the MPC-2190 Series ...........................................................................................................3-6
Powering on/off the MPC-2190 Series....................................................................................................3-7
SavvyTouch Display Control Buttons ..............................................................................................3-7
Extending the Displays ........................................................................................................................3-8
Connecting Data Transmission Cables ...................................................................................................3-9
Connecting to a Network ..............................................................................................................3-9
Connecting to a Serial Device ..................................................................................................... 3-10
Connecting to NMEA 0183 Devices .............................................................................................. 3-12
Connecting to a Speaker or a Headphone ............................................................................................ 3-12
Connecting a PS/2 Keyboard and Mouse .............................................................................................. 3-12
Connecting to USB Devices ................................................................................................................ 3-12
Installing a SATA HDD or SSD ............................................................................................................ 3-13
4. Display Resolution and Touch Calibration ......................................................................................... 4-1
Installing the VGA Driver .....................................................................................................................4-2
Adjusting Display Resolution ................................................................................................................ 4-6
Installing the Touchscreen Driver.......................................................................................................... 4-7
Screen Calibration ............................................................................................................................ 4-12
5. BIOS Setup........................................................................................................................................ 5-1
Entering the BIOS Setup Utility ............................................................................................................5-2
Main Information ................................................................................................................................5-3
Advanced Settings ..............................................................................................................................5-3
Boot Configuration.......................................................................................................................5-4
HDC Configuration.......................................................................................................................5-4
Video Configuration .....................................................................................................................5-5
Chipset Configuration...................................................................................................................5-7
Hardware Monitor........................................................................................................................5-8
Security Settings ................................................................................................................................5-8
Set Supervisor Password ..............................................................................................................5-9
Power Settings ...................................................................................................................................5-9
Boot Settings ................................................................................................................................... 5-10
Boot Type................................................................................................................................. 5-10
PXE Boot to LAN........................................................................................................................ 5-10
Add Boot Options ...................................................................................................................... 5-10
USB Boot ................................................................................................................................. 5-10
EFI Device First......................................................................................................................... 5-10
Boot Delay Time........................................................................................................................ 5-11
Legacy ..................................................................................................................................... 5-11
Exit Settings .................................................................................................................................... 5-12
Exit Saving Changes .................................................................................................................. 5-12
Save Change Without Exit .......................................................................................................... 5-12
Exit Discarding Changes............................................................................................................. 5-12
Load Optimal Defaults................................................................................................................ 5-12
Load Custom Defaults ................................................................................................................ 5-12
Save Custom Defaults................................................................................................................ 5-13

Discard Changes ....................................................................................................................... 5-13
Upgrading the BIOS .......................................................................................................................... 5-13
6. Display Control Interface .................................................................................................................. 6-1
Connecting to the Console Interface......................................................................................................6-2
Display Control Interface Command Format ...........................................................................................6-4
Command Format Description .......................................................................................................6-4
Downloading RGB Files ........................................................................................................................6-7
A. Regulatory Approval Statement ........................................................................................................ A-1
B. Display Control Interface Commands ................................................................................................ B-1
Display Control Interface Commands.....................................................................................................B-2
BRI (Brightness Minimum Value) ...................................................................................................B-2
BRL (Set LED Brightness of Touch Keypad).....................................................................................B-2
BRM (Brightness Maximum Value) .................................................................................................B-2
BRT (User Brightness Control) ......................................................................................................B-2
BRU (Glass Display Control-Brightness Button) ...............................................................................B-2
BZZ (Buzzer Control) ...................................................................................................................B-3
DLN (Download ECDIS RGB Package) ............................................................................................B-3
DL? (ECDIS RGB Package Query) ..................................................................................................B-3
ETC (Elapsed Time Counter Query)................................................................................................B-3
GMB (Glass Display Control - Minimum Brightness) .........................................................................B-4
POT (Potentiometer Control).........................................................................................................B-4
SWI (Scalar Firmware Version Query) ............................................................................................B-4
SWK (Touch Keypad Firmware Version Query) ................................................................................B-4
ADF (AC Input Power Detect Function) ...........................................................................................B-4
AD? (Query AC Input Power Detect Function Status)........................................................................B-5
BLI (Brightness Control)...............................................................................................................B-5
DUF (Disable UART Command Function).........................................................................................B-5
EMS (ECDIS Mode Select) ............................................................................................................B-5

1
1. Introduction
In this chapter, we give a general introduction to the features and specifications of MPC-2190 panel computers.
The following topics are covered in this chapter:

Overview

Ordering Information

Package Checklist

Product Features

MPC-2190 Hardware Specifications
MPC-2190 Available Option Table

Hardware Block Diagram

MPC-2190 Hardware Introduction
1-2
Overview
MPC-2190 panel computers feature advanced Intel processors—3rd generation Ivy Bridge Core or
Celeron—matched to 4 GB of system memory, to deliver a reliable, high-performance platform of wide
versatility for use in industrial marine environments. With its RS-232/422/485 serial, NMEA 0183, and Gigabit
Ethernet LAN ports, the MPC-2190 panel computer supports a wide variety of serial- and marine-specific
interfaces alongside high speed IT communications, all with native network redundancy.
The MPC-2190 series comes with a range of standard display enhancements useful in industrial environments
(including 0 to 100% full range dimming, 178°/178° wide viewing angles, optional optical bonding, and/or
multi-touch screen), as well as Moxa’s innovative SavvyTouch display controls.
MPC-2190 panel computers are compliant with several industrial marine standards, such as IEC 60945 4th, IEC
61174, IEC 61162, DNV2.4, and IACS E10, verifying their resilient durability in marine operations. An optional
IP65-rated unibody shell provides strong additional protection against the harsh conditions found in marine
environments. The MPC-2190 delivers a rugged, type approved, high-performance and user-friendly panel
computer perfect for ECDIS navigation systems and other marine IBS applications.
Ordering Information
The MPC-2190 series includes the following models:
•MPC-2190X: 19-inch fanless panel computer with Intel Celeron 1047UE 1.4 GHz processor, NMEA 0183,
RS-232/422/485 serial ports, Gigabit Ethernet LAN ports, USB 2.0 ports, dual AC/DC power inputs, and
tape bonding
•MPC-2190Z: 19-inch fanless panel computer with Intel Celeron 1047UE 1.4 GHz processor, NMEA 0183,
RS-232/422/485 serial ports, Gigabit Ethernet LAN ports, USB 2.0 ports, dual AC/DC power inputs, and
tape bonding, projected capacitive touchscreen
•MPC-2197X: 19-inch fanless panel computer with Intel Core i7 2610UE 1.5 GHz processor, NMEA 0183,
RS-232/422/485 serial ports, Gigabit Ethernet LAN ports, USB 2.0 ports, dual AC/DC power inputs, and
tape bonding
The following optional accessory packages are available on request:
•Desktop mounting kit
•Wall mounting clamps
•VESA mounting kit
Package Checklist
The MPC-2190 panel computer is shipped with the following items:
•1 MPC-2190 series panel computer
•1 terminal block for DC power input
•4 5-pin Euroblock terminals for NMEA 0183 v2 interfaces
•2 HDD installation brackets
•Documentation and driver DVD
•Quick installation guide (printed)
•Warranty card
NOTE Notify your sales representative if any of the above items are missing or damaged.

MPC-2190 Hardware Introduction
1-3
Product Features
The MPC-2190 series panel computer has the following features:
•19-inch panel
•Color calibrated for ECDIS compliance
•Fanless design
•SavvyTouch display controls
•3rd Generation Intel® Core™ or Celeron® processor (default: Celeron® 1047UE, 1.40 GHz with Intel® HD
Graphics)
•Built-in NMEA 0183 and software selectable RS-232/422/485 interfaces (DI/DO and LPT available on
request)
•Dual AC/DC power supply units
•Optically bonded and touch panel models available on request
MPC-2190 Hardware Specifications
Computer
CPU:lntel Celeron® Processor 1047UE (2M Cache, 1.4 GHz)
OS: Windows 7 Professional, Windows Embedded Standard 7, Windows XP Embedded, Windows XP SP3
(models with OS pre-installed available on request)
System Chipset: Intel BD82HM65 platform controller hub
System Memory: 4 GB pre-installed: 1 slots of 4 GB DDR3-1066 204 pin SO-DIMM SDRAM
USB: USB 2.0 hosts x 4, type A connectors, supporting system boot up
Storage: 2 SATA-III connectors
BIOS: 64 Mbit Flash BIOS SPI type, ACPI function supported
Graphics Controller: Intel HM65 Express chipset built-in
Video Output: DVI-D x 1, VGA x 1 (female)
Digital Input/Output: 4 DIs, 4 DOs, or 8 DIs, 8 DOs (optional)
LPT Port: 1 (available on request)
Buzzer: 75 to 85 db (IEC 60945 complied)
Other Peripherals
Audio: Line-in and line-out interface, with 3.5 mm mini jack
KB/MS: 2 PS/2 interface supporting standard PS/2 keyboard and mouse
Display
Panel Size: 19 inch wide viewable image size
Panel Type: MVA
Aspect Ratio: 5:4
Pixels: 1280 x 1024 (SXGA)
Response Time: 20 ms
Contrast Ratio: 2000:1
Light Intensity: 300 cd/m^2
Viewing Angles: 178°/178°
Active Display Area: 376.32 (H) x 301.06 (V) mm
Max Colors: 16.7M (8 bits/color)
Display Interface: Dual channel LVDS
Resolution:
• VGA: 640 x 480
• SVGA: 800 x 600
• XGA: 1024 x 768
• SXGA: 1280 x 1024
Ethernet Interface

MPC-2190 Hardware Introduction
1-4
LAN: 2 auto-sensing 10/100/1000 Mbps ports (RJ45)
Magnetic Isolation Protection: 1.5 kV built-in
Serial Interface
Serial Standards: 2 RS-232/422/485 ports, software-selectable (DB9 male)
Serial Communication Parameters
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
Parity: None, Even, Odd, Space, Mark
Flow Control: RTS/CTS, XON/XOFF, ADDC® (automatic data direction control) for RS-485
Baudrate: 50 bps to 115.2 Kbps (supports non-standard baudrates; see user’s manual for details)
Serial Signals
RS-232: TxD, RxD, DTR, DSR, RTS, CTS, DCD, GND
RS-422: TxD+, TxD-, RxD+, RxD-, GND
RS-485-4w: TxD+, TxD-, RxD+, RxD-, GND
RS-485-2w: Data+, Data-, GND
NMEA Interface
Serial Standards: 4 NMEA 0183 ports
Base Serial Standard: RS-422
Optical Isolation Protection: ±6kV contact discharge, ±8kV air discharge
Voltage Differential: -15 V to + 15 V
Baudrate: 4800 bps
Data Bits: 8
Stop Bits: 1, 1.5, 2
Parity: None
Handshake: None
LEDs
System: Storage, Power
LAN: 100M/Link x 2, 1000M/Link x 2 (on connector)
Front Panel
LEDs: MENU, Brightness, INFO, ECDIS, Day/Dusk/Night, Storage
Smart OSD: Yes
Physical Characteristics
Housing: Aluminum sheet metal
Weight: 7.8 kg
Dimensions: 429 x 387 x 74.5 mm (16.89 x 15.24 x 2.93 in)
Mounting: Flush mounting
System Cooling: Fanless thermal design
Environmental Limits
Operating Temperature: -15 to 55°C (5 to 131°F)
Storage Temperature: -20 to 60°C (-4 to 140°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
IP Rating:
• Front: IP 54
• Rear: IP 22
Anti-Vibration:
• 0.7 g @ DNV 2.4 (Class A), sine wave, 2-100 Hz, 1 Oct./min., 1.5 hr per axis
• 1 g @ DNV 2.4, random wave, 3-100 Hz, 2.5 hr per axis
• 1 g @ DNV 2.4 (Class C), sine wave, 2-50 Hz, 1 Oct./min., 1.5 hr per axis
Power Requirements
Input Voltage: 115 to 230 VAC, 50/60 Hz, 24 VDC
Power Consumption: 40 W to 125 W (max.)
Standards and Certifications
Safety: UL 60950-1, CCC

MPC-2190 Hardware Introduction
1-5
EMC: EN 55022 Class B, EN 55024-4-2, EN 55024-4-3, EN 55024-4-4, FCC Part 15 Subpart B Class A
Marine Standard: IEC-60945 4th, IEC-61162, IEC-61174
Marine Type Approval: DNV 2.4 and IACS E10, ABS, MR-A003
Green Product: RoHS, cRoHS, WEEE
Reliability
MTBF (mean time between failures): 202,309 hrs
Automatic Reboot Trigger: Built-in WDT (watchdog timer) supporting 1-
255 levels for time interval system
reset, software programmable
Warranty
Warranty Period: 1 year
Details: See www.moxa.com/warranty
MPC-2190 Available Option Table
The MPC-2190 can be customized with different hardware specifications. Refer to the following table for details.
CPU Default lntel Celeron® processor 1047UE (2M Cache, 1.40GHz), TDP 17 watts
Options lntel Core™ i3 processor 3217UE (3M Cache, 1.60GHz), TDP 17 watts
lntel Core™ i7 processor 3517UE (4M Cache, 2.80GHz), TDP 17 watts
RAM Default 4 GB
Option 8 GB (max.)
OS Default N/A
Options Windows 7 Professional
Windows XP Embedded
Windows Embedded Standard 7
Windows XP SP3
Linux Debian 7
Factory
Options
Projected capacitive touch screen (multi-touch, USB interface)
Optical bonding
Customized options for SSD drives

MPC-2190 Hardware Introduction
1-6
Hardware Block Diagram

2
2. Hardware Introduction
The MPC-2190 Series computer is compact, well-designed, and ruggedized for marine applications. The
intelligent SavvyTouch display control buttons allow you to indicate control buttons easily in low light
environment and identify system hardware failure easily. Multiple serial ports allow you to connect different
devices for data operation, and the reliable and stable hardware platform lets you devote your attention to
developing your applications.
The following topics are covered in this chapter:

Appearance
Front View
Bottom View

Dimensions

SavvyTouch Display Control Buttons

Real Time Clock

MPC-2190 Hardware Hardware Introduction
2-2
Appearance
Front View
Bottom View

MPC-2190 Hardware Hardware Introduction
2-3
Dimensions
SavvyTouch Display Control Buttons
The MPC-2190 comes with SavvyTouch display control buttons located at the lower right corner of the front
surface. These intelligent buttons will light up automatically when your fingers draw near. Refer to the following
table for the function of each button.
Name Displayed
Color
Control Function / Color Legend
Power
Green Computer is powered on and functioning
normally
Red Power standby and system shut down
Off Power is off.
Brightness White +: To increase brightness of panel
-: To decrease brightness of panel
Info Off System functioning normally
Red System hardware error
Storage
Red (on) Storage drive is functioning properly
Red (blinking) Drive is accessing or writing data
Off Drive is offline.
Display
mode
White Displays the brightness mode
Off Panel brightness out of ECDIS standard range

MPC-2190 Hardware Hardware Introduction
2-4
Real Time Clock
The computer’s real-time clock is powered by a lithium battery. We strongly recommend that you NOT replace
the lithium battery on your own. If the battery needs to be changed, please contact the Moxa RMA service
team.
ATTENTION
There is a risk of explosion if the wrong type of battery is used. To avoid this potential dan
ger, always be sure
to use the correct type of battery. Contact the Moxa RMA service team if you need to replace your battery.

3
3. Hardware Connection Description
In this chapter, we show how to connect the panel computer to the network and to various devices.
The following topics are covered in this chapter:

Placement Notes
Desktop Mounting
Wall Mounting
VESA Mounting

Wiring Requirements

Temperature Requirements
Important Safety Precaution

Grounding the MPC-2190 Series

Powering on/off the MPC-2190 Series
SavvyTouch Display Control Buttons

Extending the Displays

Connecting Data Transmission Cables
Connecting to a Network
Connecting to a Serial Device
Connecting to NMEA 0183 Devices

Connecting to a Speaker or a Headphone

Connecting a PS/2 Keyboard and Mouse

Connecting to USB Devices

Installing a SATA HDD or SSD

MPC-2190 Hardware Hardware Connection Description
3-2
Placement Notes
Before installing and mounting the MPC-2190 panel computer, please read the following notes:
1. The MPC-2190 series is designed for various installation or mounting methods, for example: desktop
mounting, wall mounting, and VESA mounting. Please refer to the relevant mechanical drawings in the next
sections before attempting to mount the panel.
2. It is advised that good ventilation is necessary to prolong the computer’s lifespan. The chassis’ heat-sink
area MUST be kept clear from other heat generating items, as this may damage the system motherboard.
The minimal distance is 150 mm.
3. Allow sufficient physical space for proper ventilation, cable connectors, wiring passage, and pracitcal
maintenance purposes.
4. DO NOT install the unit in a horizontal position (laying down), as the heat inside of the unit is not dissipated
effectively and will damage the LCD panel. It is recommended to install the unit in a vertical position (±30
degrees) for better heat dissipation.
5. Exposure to extreme direct sunlight may cause a considerable increase in the temperature of the unit, and
under certain circumstances might lead to overheating. Please take this point into consideration when the
bridge equipment is being planned (sun shades, distance from the windows, ventilation, etc.)
6. Exposure to strong vibration or acoustic noise might affect the functionality and expected lifetime of the
computer. Take consideration of these factors during system assembly and installation, to ensure the
mounting position avoids exposure to strong vibrations.
7. For maximum safety, at least two persons should work together to lift, place, and fasten the computer to its
mounting point. Before you lift or move the computer, first verify the computer is disconnected from any
power source, and turned off. In addition, make sure you have prepared the correct screws for a wall
mounting.

MPC-2190 Hardware Hardware Connection Description
3-3
Desktop Mounting
The MPC-2190 comes with optional brackets that allow you to temporarily install the panel computer on a
horizontal surface, such as a desktop. Three round screws are required for each bracket. See the figure below
for detailed screw specifications and their torque value.
Desktop mounting of this sort is intended as a temporary workaround when configuring or testing the computer
before permanent installation. The desktop mounting brackets should not be used for permanent installations.
Place your MPC-2190 Series panel computer on a clean, flat, well-ventilated desktop. For better ventilation,
leave some space between the MPC-2190 Series and other equipment. Do not place equipment or objects on
top of the MPC-2190 Series panel computer, as this might damage the computer’s internal components.
Wall Mounting
The MPC-2190 Series comes with 14 optional clamp mounts that allow for installation onto a wall (where space
has been cut out to accommodate the rest of the hardware) or into computing stations where a flush mount is
desired. The maximum thickness of the surface to which the computer will be clamped is 11 mm. For
a secure mounting, all 14 clamps must be used. The clamp arms are fastened into slots on all four sides of the
MPC-2190. Use the short M4 SUS (stainless) screws to fasten the clamp arms to the MPC-2190 mounting slots,
as shown in the magnified inset in the diagram at the top of the next page. Next, use the clamps to fasten the
computer to its mounting point; please note the torque value that is shown in the figure inset below.

MPC-2190 Hardware Hardware Connection Description
3-4

MPC-2190 Hardware Hardware Connection Description
3-5
VESA Mounting
The MPC-2190 also comes with an optional VESA mounting kit. Six flat screws and four round screws are
required to fasten the VESA mounting bracket. See the figure below for detailed screw specifications and torque
values.
An additional four screws (not included in the kit) are required to mount the computer on a VESA rack. For this
purpose, use M6 screws with a length between 10 and 12 mm.

MPC-2190 Hardware Hardware Connection Description
3-6
Wiring Requirements
This section describes how to connect peripheral devices to the panel computer.
You should read and follow these common safety precautions before proceeding with the installation of any
electronic device:
•Use separate paths to route wiring for power and devices. If power wiring and device wiring paths must
cross, make sure the wires are perpendicular at the intersection point.
NOTE Do not run signal or communication wiring together with power wiring in the same wire conduit. To avoid
interference, wires with different signal characteristics should be routed separately.
•Use the type of signal transmitted through a wire to determine which wires should be kept separate. The
rule of thumb is that wiring that shares similar electrical characteristics can be bundled together.
•Keep input wiring and output wiring separate.
•It is advisable to label the wiring to all devices in the system.
ATTENTION
Safety First!
Be sure to disconnect the power cord before installing and/or wiring your MPC-2190 Series.
Wiring Caution!
Calculate the maximum possible current in each power wire and common wire. Observe all electrical codes
dictating the maximum current allowable for each wire size.
If the current goes above the maximum ratings, the wiring could overheat, causing serious damage to your
equipment.
Temperature Requirements
Be careful when handling the unit. When the unit is plugged in, the internal components generate heat, and
consequently the outer casing may feel hot to the touch.
We recommend taking the following precautions to minimize heat build-up within the display:
•Position the display within ±40° of the vertical.
•Install an external fan to increase airflow upwards through the display if (a) the display is not positioned
within ±40° of the vertical, (b) the ambient temperature exceeds 25°C, or (c) the display is used in a
location with minimal ventilation.
Important Safety Precaution
Even though the display is rated to operate within the IEC 60945 standard of -15 to 55°C for marine
applications, it is best to ensure that the ambient temperature does not exceed 25°C. Doing so will increase the
life of your display and minimize service costs.
Grounding the MPC-2190 Series
Before you power on the MPC-2190 Series, please ground the MPC-2190 as grounding and wire routing help
limit the effects of noise due to electromagnetic interference (EMI). Run the ground connection from the ground
screw to the grounding surface prior to connecting the power.
