MPPT M2430C User manual

M2430C
MPPT Solar Charge Controller
Flush Mount
Negative Grounded
User Manual
*We may modify these specifications without prior notice.

Icons Name Description
1. Warnings and Tools Icon Chart 2. Safety Tips
High Voltage
High Temperature
Environmental
Hazard
Wire Cutter
Multi-meter
Anti-static Glove
Electrical Tape
Screwdriver
High voltage device.
Installation should be
performed by an electrician.
This device will produce heat.
Mount device away from other
items.
Electronic Equipment.
Do not put in landfill.
A wire cutter is needed for
cutting and stripping prior
wires to connect.
A multi-meter is needed for
testing equipment and verifying
polarity of cables.
Anti-static gloves are
recommended to prevent
controller damage caused by
static electricity.
Electrical tape is recommended
to safely insulate spliced or bare
wires.
A common size screwdriver is
needed to attach wires to the
controller.
· It is very important to review this manual thoroughly before attempting installation.
· Beware of any nearby electrical equipment that may interfere with installing this
device. And please don’t plug in any AC source to this DC-DC product, or it may cause
a fire or burn to the device.
· Connecting wires to this device can generate sparks, please wear proper insulation
gear while installing this device.
· To avoid damage to the battery or controller, use proper fuses in wiring. Please do
not hesitate to contact the professions if you need help with fuse sizing.
· This device is common negative designed, please wiring negative grounded if
grounding job is required.
· Please don’t keep the battery side open for long time, while the PV input keeps
plugging in, or it may cause a screen failure in this device.
· Always keep children away from this device.
· Be certain to use the correct gauge of wire, see below for a table of recommended
wire size for various current loads.
· Solar panels can generate high voltages and currents, make sure your solar panels
are completely covered from sunlight during installation. It is recommended that
installation be performed by a qualified electrician.
01 02
Solar Input Current 5A 10A 20A 30A
Wire Cross Section Area (mm²) 1.5 2.5 5 8
Wire AWG 15 13 10 8

3. Product Features
Thank you for choosing our products. This solar charge controller is a device for solar charge
regulation with the latest MPPT algorithm technology. This device is flush mount designed,
mainly used in small and medium sized o-grid solar power systems, especially for system
cabinet or RV use installation.
This MPPT charge controllers have features as follows:
1. Aluminum casing + tempered glass cover + color screen displaying
2. Flush mount design for cabinet or RV use installation
3. Great charge performance in high temperature environment
4. Built-in BT communication module for mobile phone APP operation
5. Inside filled in with silicon/polyurethane for better cooling and waterproof
4. Device Diagram
M2430C
# Description # Description
1 6
2 7
3 8
4 9
5
Touch Screen Button ([SET], [UP],
[DOWN], [ESC])
Color LCD Display Screen
Solar Input Terminals
Battery Terminals
External Temperature Sensor Port 10
03 04
· Aluminum casing plus inside filled in complex silicon & polyurethane for a great
cooling and waterproof system, ensures better charge performance in
environment of high temperature and high humidity.
· By continuously checking solar panel power output changes, the controllers
employ multiple MPPT charge algorithms in combination to boost charging
eciency in dierent weather and temperature conditions.
· Built-in buer, allows max 25% exceeding rated power input.
· Industrial grade design with full range of electronic protections, like reverse
polarity protection for solar panels and battery wiring.
· Auto recognition of 12V/24V battery system voltage. Lithium battery excluded
from this feature.
· Charging modes available for most common deep-cycle battery types in the
market, including AGM (sealed lead acid batteries/SLD), GEL, Flooded, and Lithium.
For more advanced settings, please operate in the mobile phone APP.
· Supports recording of system running data including power generated and
power utilized for up to 300 days, compatible with monitoring App through IOS
and Android.
· Tempered glass cover with back-lighted color LCD display, touch screen
operation for better user experience. More advanced operations are available in
mobile phone APP, or in the external remote LCD display device (DS, optional
accessory, not in the standard package list)
· With built-in BT communication module in this controller, we provide APP
PVChargePro for mobile phone monitoring and operation. You can
search“PVChargePro”and download the APP at IOS APP Store and Google Play
Store.
10
10
1
2
3456 7
3 4
8
9
Rs485 Communication Port
Grounded Terminal
Magnetic Cover
Magnetic Cover
Installation Mounting Holes

5. Fixture & Wiring Instructions 7. RS485 connection diagram (Rj12)
6. Wiring sequence
8. LCD screen and indicator light introduction
RS485 PIN
VDD
PIN-1
VDD
PIN-2 PIN-3 PIN-4 PIN-5 PIN-6
GND GND D- D+
05 06
① ⑥
①
⑥
1. Remove the magnetic covers. 2. Check and confirm the screwing condition
in the fixture surface, and tighten the screws
according to the instruction in the picture.
3. Check the fixture condition of the installation. 4. Put the magnetic cover back and clean the surface.
PV+/- BAT+/-
1. Unscrew the terminals completely, before inserting
any wiring leads.
2. Insert the bare wire side of the cable to the terminals
according to the right consequences.
3. Tighten the terminal screws as much as possible
Installation Remarks:
· Please make sure the battery wires would be connected first, and
then connect the PV wires.
· For dierent installation conditions and requirements, we may either
fix the controller first, then connect the wires, or we also may connect
the wires first before we fix the controller.
· If you need to re-wiring the device, please disconnect the PV side
firstly before loose battery cables.
The backlight in the screen will be on for 20 seconds with any button operation, or the screen
would enter stand-by/power saving mode.
8.1 LCD Display Interface
Display Items
Working
Status
Parameters
View
System
Error Status
Description
System Working Status
Parameter Value
Displaying
System Error
Information
Displaying

8.2 LCD Status Information
MPPT
BST
FLT
PV Input Status
Charge Status
Error Icon
Normal Icon
Battery Icon
Setting Icon
Temperature Icon
Parameter
Displaying Values
Unit Icon
Status
Steady On
O
Steady On
O
Flowing
Steady On
On
On
Steady On
O
Fast Flash
Steady On
O
In Setting
Not in Setting
In Setting
Not in Setting
On
Status Icon Indication Description
In Daytime
Not in Daytime
In Nighttime
Not in Nighttime
Charging
In MPPT Charge
Or in Boost Charge
Or in Float Charge
System in Error
System Normal
No Battery Error
No Battery Input or
Battery Reverse Polarity
Battery Over Voltage
In Set Mode
In View Mode
Set Value of
Temperature in ℉ or ℃
View Temperature
Set Parameter Value
View Parameter Value
Unit of the Relevant Value
8.3 Displaying Cycle Information
The screen displaying cycles through dierent views page by page as following
pictures (with temperature unit Celsius C by default )
8.3 Displaying Cycle Information
4 LED indicators are placed underneath the below four touch screen operation keys.
--
Screen Status
Not in Sleep
Mode
In Sleep Mode
System Error
Solar Input Not
in Charging
Charging &
Battery
SOC <50%
Charging &
Battery
SOC <75%
Charging &
Battery
SOC >75%
Indicator lights on while being touched;
lights o when no touches.
O Flash
O Steady On
Steady On Three indicators flashing in a flow
Steady On Two indicators
flashing in a flow
Steady On Flash
PV Input Voltage &
Battery Voltage
Charging Power &
Charging Current
Battery Type & Battery
System Voltage
Error & Battery SOC
Error & Temperature
The screen displaying cycles through dierent views page by page as following
pictures (with temperature unit set on F )
PV Input Voltage &
Battery Voltage
Charging Power &
Charging Current
Battery Type & Battery
System Voltage
Error & Battery SOC
Error & Temperature
07 08

USE
FLD
SEL
GEL
LI
9. Button Instruction
Button Current mode Type Description
View Mode
View Mode
View Mode
View Mode
Long Press
Short Press
Short Press
Short Press
Enter setting mode
View the previous page
View the next page
–
Button Current mode Type Description
Set Mode
Set Mode
Set Mode
Set Mode
Long Press
Short Press
Short Press
Short Press
Short Press
Save the setting value and exit
the setting mode
Set the next parameter item
Set parameters by increasing
value
Set parameters by decreasing
value
Exit the setting mode without
saving the setting value
10. Setting Parameters
10.1 Battery Type Setting
Battery Type Battery Description
Lead-acid Battery
Sealed Battery SLD / AGM
Gel Battery
Lithium Battery
Advanced User Mode.
For professions only
Description
Parameters set on default, not adjustable.
Battery system voltage automatically
recognized.
Battery system voltage and parameter
settings are only allowed to set by APP
operation or in the remote display.
Battery system voltage and advanced
parameter settings are only allowed to set
by APP operation. Part of the parameters
could be set in the remote display.
10.2 Temperature unit setting:
10.3 Advanced USER Mode Battery Setting
In the 【Temperature】page, to set the temperature unit.
℉ = ℃*1.8 + 32。
09 10

– –
10.4 LI Mode Battery setting
10.5 Other battery settings (GEL as an example)
11. Button Instruction
10.6 Error Code
Code
E00
E02
E06
E07
E10
E13
E14
Error
No Error
Battery
Over-voltage
Equipment
Overheating
Environment
Over-temperature
Solar
Over-voltage
Solar Reverse
Polarity
Battery Reverse
Polarity
Description
Battery voltage has
exceeded controller
limit.
Controller exceeds
operating temperature
limit.
The device working
surrounding temperature
is too high, and the
controller would stop
charging anytime.
Solar array voltage exceeds
controller rated input
voltage.
Solar array input wires
connected with reverse
polarity.
Battery connection wires
connected with reverse
polarity.
Quick Troubleshoot
-
Check battery bank voltage
for compatibility with
controller.
Ensure the controller is placed
in a well-ventilated cool,
dry place.
Try to lower the working
surrounding temperature.
Decrease the voltage of solar
panels connected to the
controller.
Disconnect and re-connect
with correct wire polarity.
Disconnect and re-connect
with correct wire polarity
*Note: the missing error codes in the above chart indicates that this controller has no such
error or alarm condition
11 12

180
250 53.2
9.5
215
145
230
110
164 130
4x 4.5
M2430C
FLD
14 8V n. *
14 6V n. *
SEL
14 6V n. *
14 4V n. *
GEL
( )default
–
14 2V n. *
USER
( )adjustable
Default
Default GEL:
LI
( )adjustable
–
Default 14 2V n: . *
13 8V n. *
13 2V n. *
- / /3mV 2V ºC
Default GEL:
Default GEL:
Default GEL:
–
–
–
–
-35ºC ~ +45ºC
IP34
2.2 kg
No-load Loss
Max Solar Input Voltage
Rated Solar Charge Current
Max Solar Input Power
Operating Temperature
IP Protection
Net Weight
Communication Port
Operating Altitude
Controller Dimension
Controller Parameter
Model No.
Battery System Voltage
Battery Voltages
Battery Types
Equalize Charge Voltage
Boost Charge Voltage
Float Charge Voltage
Boost Charge Recovery Voltage
Over-discharge Recovery Voltage
Over-discharge Voltage
Auto Temperature Compensation
12V/24V
Auto (FLD/GEL/SLD)
Manual (Li/User)
12ma/ 12V; 10ma/24V;
<100Voc
30A
≤ 3000 meters
450W/12V;900W/24V;
250*180*50mm
Value
Battery Parameters
Accessory List Package Status
Yes
Optional
Yes
Yes
External Temperature Sensor
Remote LCD Meter
Bluetooth Module
Parallel Charge Use Cable
Installation Guidance Paper
User Manual
Optional
–
–
–
–
–
Yes/Inbuit
System Wiring
Grounded Negative Grounded
RS485+Bluetooth(APP)
12. Controller Specification
For example, the equalize charge voltage for a 12V FLD (Flooded) battery bank is 14.8V*1=14.8V. The
equalizing charge voltage for a 24V FLD (Flooded) battery bank is 14.8V*2=29.6V.
The variable “n” is adopted as a multiplying factor when calculating parameter voltages, the rule for “n”
is listed as: if battery system voltage is 12V, n=1; 24V, n=2.
13. Size
Installation Area Dimension: 164*215mm
Installation Hole Size: 4.5mm
Connection Socket Size: 7.5*7.5mm
Product Dimension: 250*180*53,2mm
13 14
