MQ POWER
MODEL DCA-150SSKII
PORTABLE GENERATOR
PARTS AND OPERATION MANUAL

PAGE 2 —DCA-150SSKII— PARTS AND OPERATION MANUAL — REV. #2 (05/08/01)

DCA-150SSKII — PARTS AND OPERATION MANUAL— REV. #1 (05/08/01) — PAGE 3
HERE'S HOW TO GET HELP
PLEASE HAVE THE MODEL AND SERIAL NUMBER
ON-HANDWHEN CALLING
PARTS DEPARTMENT
800/427-1244 or 310/537-3700
FAX: [phone] or 310/637-3284
SERVICE DEPARTMENT
800/835-2551 or 310/537-3700
FAX: [phone]
WARRANTY DEPARTMENT
800/835-2551 or 310/537-3700
FAX: [phone]
MAIN
800/421-1244 or 310/537-3700
FAX: [phone]

PAGE 4 —DCA-150SSKII—PARTS AND OPERATION MANUAL —REV. #2 (05/08/01)
TABLE OF CONTENTS
Here's How To Get Help...........................................3
Table Of Contents ....................................................4
Parts Ordering Procedures ......................................5
Rules For Safe Operation .................................... 6-9
Towing ....................................................................10
Trailer Safety Guidlines ..........................................11
Trailer Specifications ........................................ 12-13
Trailer Braking System ..................................... 14-15
Trailer Tires & Suspension ............................... 16-17
Trailer Wire Diagram ..............................................18
Trailer Electric Brakes Troubleshooting..................19
Trailer Hydraulic Brakes Troubleshooting...............20
Operation And Safety Decals........................... 21-22
Specifications .........................................................23
General Information...............................................24
MQ Power DCA-150SSKII
ACGenerator
Major Components ................................................26
Dimensions (Top, Side And Rear)..........................27
Control Panel.................................................... 28-29
Engine Operating Panel ................................... 30-31
Output Terminal Panel...................................... 32-39
Installation........................................................ 40-41
Pre-Setup......................................................... 42-45
Load Application ....................................................46
Generator Start-Up Procedure (Manual)......... 47-49
Generator Start-Up Procedure (Auto) ...................50
Generator Shut-Down Procedure ..........................51
Maintenance .................................................... 51-53
Troubleshooting (Engine)................................. 54-55
Troubleshooting (Generator/Engine) .....................56
Troubleshooting (MPEC)........................................57
Explanation Of Codes In Remarks Column ...........58
Suggested Spare Parts..........................................59
NOTE
Specification and part
number are subject to
change without notice.
Generator Assembly .......................................... 60-61
Control Box Assembly........................................ 62-65
Engine Radiator Assembly................................. 66-69
Engine Operating Panel Assembly .................... 70-73
Battery Assembly ............................................... 74-75
Muffler Assembly ............................................... 76-77
Fuel Tank Assembly ........................................... 78-79
Enclosure Assembly........................................... 80-83
Enclosure (Rubber Seals).................................. 84-85
Name Plate and Decals ..................................... 86-89
Terms and Conditions Of Sale — Parts ...................90

DCA-150SSKII —PARTS AND OPERATION MANUAL—REV. #1 (05/08/01) —PAGE 5
PARTS ORDERING PROCEDURES
Get special freight allowances
when you order 10 or more
line items via FAX!**
■■
■■
■ UPS Ground Service at no charge for freight
■■
■■
■ PS Third Day Service at one-half of actual freight cost
No other allowances on freight shipped by any other carrier.
**Commonnuts, bolts and washers (allitems under $1.00 list price)
do not count towards the 10+ line items.
*DISCOUNTS ARE SUBJECT TO CHANGE*
Fax order discount and UPS special programs revised June 1, 1995
For faxed orders only
UPS
Special
Earn Extra Discounts when
you order by FAX!
All parts orders which include complete part numbers
and are received by fax qualify for the following extra
discounts:
Number of
line items ordered Additional Discount
1-9 items 3%
10+ items** 5%
Now! DirectTOLL-FREE access
to our Parts Department!
Toll-free nationwide:
800-421-1244
Toll-free FAX:
800/6-PARTS-7 • 800-672-7877
■■
■■
■Dealer account number
■■
■■
■Dealer name and address
■■
■■
■Shipping address (if different than billing address)
■■
■■
■Return fax number
■■
■■
■Applicable model number
■■
■■
■Quantity, part number and description of each part
■■
■■
■Specify preferred method of shipment:
•UPS Ground
•UPS Second Day or Third Day*
•UPS Next Day*
•Federal Express Priority One (please provide us with your Federal
Express account number)*
•Airborne Express*
•Truck or parcel post
*Normally shipped the same day the order is received, if prior to 2PM west coast time.
Extra Fax Discount
for Domestic USA
Dealers Only

PAGE 6 —DCA-150SSKII—PARTS AND OPERATION MANUAL —REV. #2 (05/08/01)
RULES FOR SAFE OPERATION
■ NEVER touch the hot exhaust
manifold, muffler or cylinder. Allow
these parts to cool before servicing
engineorgenerator.
■ The engine of this generator requires an adequate free
flow of cooling air. Never operate the generator in any
enclosed or narrow area where free flow of the air is
restricted. If the air flow is
restricteditwillcauseserious
damage to the generator or
engineandmay cause injury
to people. Remember the
generator engine gives off
DEADLY carbon monoxide
gas.
■ High Temperatures –Allow the engine to cool before
adding fuel or performing service and maintenance
functions.Contact withhot componentscancauseserious
burns.
CAUTION:
Failure to follow instructions in this manual
may lead to serious injury or even death!
Thisequipmentisto be operated by trained
andqualifiedpersonnelonly!Thisequipment
is for industrial use only.
Thefollowingsafety guidelinesshouldalwaysbe used when
operating the DCA-150SSKII portable generator:
GENERAL SAFETY
■ DONOToperateorservicethisequipmentbefore
readingthisentiremanual.
■ This equipment should not be operated by
persons under 18 years of age.
■ NEVERoperatethisequipment withoutproper
protective clothing, shatterproof glasses,
steel-toed boots and other protective
devices required by the job.
■ NEVER operate this equipment when not
feeling well due to fatigue, illness or taking
medicine.
■ NEVERoperatethisequipmentunderthe
influence or drugs or alcohol.
■ NEVER use accessories or attachments, which are not
recommendedby MQPower for this equipment.Damage
to the equipment and/or injury to user may result.
■ Manufacture does not assume responsibility for any
accident due to equipment modifications.
■ Whenever necessary, replace nameplate, operation and
safety decals when they become difficult read.
■ Always check the machine for loosened threads or bolts
before starting.
CAUTION :
■ Alwaysuseextremecautionwhen
working with flammable liquids. When
refueling, stop the engine and allow it
to cool.DO NOT smoke around or near
the machine. Fire or explosion could
resultfrom fuelvapors,oriffuel isspilled
on a hot engine.
■ NEVERoperatethegenerator inan explosiveatmosphere
or near combustible materials. An explosion or fire could
result causing severe bodily harm or even death.
■ Topping-off to filler port is dangerous, as it tends to spill
fuel.
Always refuel in a well-ventilated area,
away from sparks and open flames.

DCA-150SSKII — PARTS AND OPERATION MANUAL— REV. #1 (05/08/01) — PAGE 7
RULES FOR SAFE OPERATION
■ DO NOT touch output terminals during operation.This is
extremely dangerous when your hands are wet. Always
stop the machine when contact with the output terminals
isrequired.
CAUTION :
■ Backfeed to a utility system can cause electrocution
and.or property damage. Do not connect to any
building'selectrical system exceptthrough an approved
device or after building main switch is opened.
■ Never use damaged or worn cables when connecting
power tools or equipment to the generator.Make sure the
power connecting cables are securely connected to the
generator’soutputterminals. Insufficient tightening ofthe
terminalconnectionsmay causedamagetothe generator
and electrical shock.
CAUTION :DO NOT touch or open any of the below
mentioned components while the
generator is running. Always allow
sufficienttimefortheengineandgenerator
to cool before performing maintenance.
Radiator
1. Radiator Cap - Removing the radiator cap while the
engine is hot will result in boiling water to gush out of
the radiator, therefore causing severe scalding to any
persons in the general area of the generator.
2. Coolant Drain Plug - Removing the coolant drain plug
while the engine is hot will result in hot coolant to gush
out of the coolant drain plug, therefore causing severe
scalding to any persons in the general area of the
generator.
3. Engine Oil Drain Plug - Removing the engine oil drain
plug while the engine is hot will result in hot oil to gush
out of the oil drain plug, therefore causing severe
scalding to any persons in the general area of the
generator.
CAUTION :
CAUTION :

PAGE 8 —DCA-150SSKII—PARTS AND OPERATION MANUAL —REV. #2 (05/08/01)
■ NEVER Run engine without an air filter. Severe engine
damage may occur.
■ Alwaysservice aircleanerfrequentlytoprevent carburetor
malfunction.
■ Always disconnect the battery before performing service
onthegenerator.
■ Always be sure the operator is familiar with proper safety
precautions and operations techniques before using
generator.
■ Always store equipment properly when not in use.
Equipmentshouldbestoredin a clean, dry location out of
the reach of children.
■ DO NOT leavethe generatorrunninginthemanual mode
unattended.
■ DO NOT allow unauthorized people to operate this
equipment.
■ Always read, understand, and follow procedures in
Operator’sManualbeforeattemptingtooperateequipment.
■ Refertothe Komatsu EngineOwner's Manual forengine
technical questions or information.
Loading and Unloading (Crane)
■ Before lifting, make sure the generator's lifting hook is
secure and that there is no apparent damage to the
generator itself (loose screws, nuts and bolts). If any
part is loose or damaged, please take corrective action
before lifting.
■ Always drain fuel prior to lifting.
■ Always make sure crane or lifting device has been
properlysecuredto thehook ofguardframeongenerator.
■ NEVER lift the machine while the engine is running.
■ Use adequate lifting cable (wire or rope) of sufficient
strength.
■ When lifting the generator, always use the balanced
center-point suspension hook and lift straight upwards.
■ NEVER allow any person or animal to stand underneath
the machine while lifting.
■ When loading the generator on a truck, be sure to use
the front and back frame bars as a means to secure the
generatorduringtransport.
Battery
Neveroverfillthebatterywithwaterabove
the upper limit.
CAUTION :
The battery contains acids that can cause injury to the eyes
and skin.To avoid eye irritation, always wear safety glasses.
Use well insulated gloves when picking up the battery. Use
the following guidelines when handling the battery:
1. DO NOT drop the battery. There is the possibility the
battery may explode.
2. DO NOT expose the battery to open flames, sparks,
cigarettes etc. The battery contains combustible gases
and liquids. If these gases and liquids come in contact
with a flame or spark, an explosion could occur.
3. Always keep the battery charged. If the battery is not
charged, a buildup of combustible gas will occur.
4. Alwayskeep batterychargingandboostercables ingood
working condition. Repair or replace all worn cables.
5. Always recharge the battery in an open air environment,
toavoidriskofadangerousconcentrationofcombustible
gases.
6. In case the battery liquid (dilute sulfuric acid) comes in
contact with clothing or skin , rinse skin or clothing
immediately with plenty of water.
7. In case the battery liquid (dilute sulfuric acid) comes in
contact with your eyes, rinse eyes immediately with
plentyofwater,thencontactthenearestdoctororhospital,
and seek medical attention.
RULES FOR SAFE OPERATION

DCA-150SSKII —PARTS AND OPERATION MANUAL—REV. #1 (05/08/01) —PAGE 9
RULES FOR SAFE OPERATION
Transporting
■ Always shutdown engine before transporting.
■ Tighten fuel tank cap securely.
■ Drainfuelwhentransportinggeneratoroverlongdistances
or bad roads.
■ Always tie-down the generator during transportation by
securing the generator.
■ If generator is mounted on a trailer, make sure trailer
complies with all local and state safety transportation
laws. See page 10 for basic towing procedures.
Emergencies
■ Alwaysknow the locationofthe nearest fire extinguisher
and firstaidkit .Knowthelocationofthenearesttelephone.
Alsoknow the phonenumbersof thenearest ambulance ,
doctor and fire department .
Maintenance Safety
■ NEVER lubricate components or attempt service on a
runninggenerator.
■ Always allow the engine proper amount of time to cool
before servicing.
■ Keep the generator in proper running condition.
■ Fix damage to the generator immediately and always
replace broken parts.
■ Dispose of hazardous waste properly. Examples of
potentiallyhazardous waste areusedmotor oil, coolant,
fuel, and fuel filters.
■ DO NOT use plastic containerstodispose of hazardous
waste.
■ DO NOT pour waste, oil, coolant or fuel directly onto
the ground, down a drain or into any water source.

PAGE 10 —DCA-150SSKII—PARTS AND OPERATION MANUAL —REV. #2 (05/08/01)
DCA-150SSKII —TOWING
Figure 1. Generator with Trailer
To reduce the possibility of an accident while transporting
the generator on public roads, always make sure that the
trailer that supports the generator and the towing vehicle
are in good operating condition and both units are
mechanically sound.
Thefollowing listofsuggestionsshouldbe usedwhentowing
yourgenerator:
CAUTION :
Towing Safety Precautions ■ ALWAYS attachtrailer'ssafetychain tobumperoftowing
vehicle.
■ ALWAYS make sure that the vehicle and trailer
directional, backup, brake, and trailer lights are
connected properly and are working properly.
■ Rememberthemaximumspeedunlessotherwiseposted
for highway towing is 45 MPH. Recommended off-road
towing is not to exceed 10 MPH or less depending on
type of terrain.
■ Place chocked blocks underneath wheel to prevent
rolling, while parked.
■ Place support blocks underneaththetrailer'sbumper to
prevent tipping , while parked.
■ Use the trailer's hand winch to adjust the height of the
trailer, then insert locking pin to lock wheel stand in
place, while parked.
■ Avoidsuddenstopsand starts.Thiscancauseskidding,
or jackknifing. Smooth, gradual starts and stops will
improve gas milage.
■ Avoid sharp turns to prevent rolling.
■ Remove wheel stand when transporting.
■ DO NOT transport generator with fuel in tank.
Check with your county or state safety
towing regulations department before
towingyourgenerator.
■ Make sure the hitch and coupling of the towing vehicle
areratedequalto,orgreaterthan thetrailer"grossvehicle
weightrating"(GVWR).
■ ALWAYS inspect thehitchandcouplingforwear. NEVER
tow a trailer with defective hitches, couplings, chains
etc.
■ Check the tire air pressure on both the towing vehicle
and the trailer. Also check the tire tread wear on both
vehicles.
■ ALWAYS makesurethe trailerisequipped witha"Safety
Chain".

DCA-150SSKII —PARTS AND OPERATION MANUAL—REV. #1 (05/08/01) —PAGE 11
Explanation of Chart:
This section is intended to provide the user with trailer ser-
vice and maintenance information. The service and main-
tenance guidelines referenced in this section apply a wide
rangeoftrailers. Rememberperiodicinspectionofthetrailer
will ensure safe towing of the equipment and will prevent
damage to the equipment and personal injury.
It is the purpose of this section to cover the major mainte-
nance components of the trailer. The following trailer com-
ponents will be discussed in thie section:
! Brakes
! Tires
! LugNutTorquing
! Suspension
! Electrical
! BrakeTroubleshootingTables
Use the following definitions while readingTable1.
1. Fuel Cell - Provides an adequate amount of fuel for
the equipment in use. Fuel cells must be empty when
transportingequipment.
2. Braking System - System employed in stopping the
trailer. Typical braking systems are electric, surge, hy-
draulic, hydraulic-surge and air.
3. GVWR- Gross Vehicle Weight Rating (GVWR), is the
maximum number of pounds the trailer can carry, in-
cluding the fuel cell (empty).
4. Frame Length - Thismeasurmentisfromtheball hitch
to the rear bumper (reflector).
5. Frame Width - This measurement is from fender to
fender.
6. Jack Stand - Trailer support device with maximum
pound requirement from the tongue of the trailer.
DCA-150SSKII —TRAILER-SAFETY GUIDELINES
CAUTION:
ALWAYS make sure the trailer is in good
operating condition. Check the tires for
proper inflation and wear. Also check the
wheel lug nuts for proper tightness.
7. Coupler - Type of hitch used on the trailer for towing.
8. Tire Size - Indicates the diameter of the tire in inches
(10,12,14, etc.), and the width in millimeters
(175,185,205, etc.). The tire diameter must match the
diameter of the tire rim.
9. Tire Ply - The tire ply (layers) number is rated in letters;
2-ply,4-ply,6-ply, etc.
10. Wheel Hub -The wheel hub is connected to the trailer’s
axle.
11. Tire Rim - Tires are mounted on a tire rim. The tire rim
must match the size of the tire.
12. Lug Nuts - Used to secure the wheel to the wheel hub.
Always use a torque wrench to tighten down the lug
nuts. SeeTable4 and Figure 5 forlugnuttightening and
sequence.
13. Axle - Indicates the maximum weight the axle can sup-
port in pounds, and the diameter of the axle expressed
in inches (see Table 3 on page 17). Please not that
some trailers have a double axle. This will be shown as
2-6000 lbs., meaning two axles with a total weight ca-
pacity of 6000 pounds.
14. Suspension - Protects the trailer chassis from shock
transmitted through the wheels. Types of suspension
used are leaf, Q-flex, and air ride.
15. Electrical - Electrical connectors (looms) are provided
with the trailer so the brake lights and turn signals can
be connected to the towing vehicle. See page 16 for
properwiringconnections.
16. Application - Indicates which units can be employed
on a particular trailer.

PAGE 12 —DCA-150SSKII—PARTS AND OPERATION MANUAL —REV. #2 (05/08/01)
snoitacificepS.1elbaT
LEDOM NOITACILPPA LEUF LLEC EKARB METSYS RWVG EMARF HTGNEL EMARF HTDIW KCAJ DNATS
51-01-RLRT ,51ACD,21-GLT 003-WLT ONONSBL0091"69"05.BL008 LEEHWTLITLLUF
X01-RLRT ,51ACD,21-GLT 003-WLT ONONSBL0091"69"05.BL008 LEEHWTLITLLUF
FX01-RLRT ,51ACD,21-GLT 003-WLT LAG15ONSBL0091"69"05.BL008 LEEHWTLITLLUF
W522-RLRT 01-ACDONONSBL0022"58"24.BL008 LEEHWTLITLLUF
004-WLB 004-WLBONCIRTCELESBL0072"451TSAM/W "421O/W "55 )LLAT"87( .BL008 LEEHWTLITLLUF
FX51-RLRT 51-ACDLAG14ONSBL0072"421"55.BL008 LEEHWTLITLLUF
X05-RLRT 52-ACDONONSBL0072"421"55.BL008 LEEHWTLITLLUF
FX05-RLRT 52-ACDLAG14ONSBL0072"421"55.BL008 LEEHWTLITLLUF
TBS52-RLRT 52-ACDONONSBL0992"021"66.BL008 LEEHWTLITLLUF
W07-RLRT 07,06-,54-ACDONEGRUSSBL0007"681"77.BL0002 DAPTALF
X07-RLRT 07,06-,54-ACDTPOEGRUSSBL0007"831"66.BL0002 DAPTALF
FX07-RLRT 07,06-,54-ACDLAG35EGRUSSBL0007"831"66.BL0002 DAPTALF
FX001-RLRT 521,001-ACDLAG051EGRUSCILUARDYHSBL0007"091"67.BL0002 DAPTALF
521/58-RLRT ,001,58-ACD 521 LAG541CILUARDYHSBL00001"681"77.BL0002 DAPTALF
FX051-RLRT 081,051-ACDLAG002EGRUSCILUARDYHSBL06111"402"48.BL0005 DAPTALF
FX022-RLRT 022-ACDLAG052EGRUSCILUARDYHSBL00041"222"38.BL0005 DAPTALF
FX003-RLRT 003-ACDLAG052EGRUSCILUARDYHSBL00081"832"38.BL0005 DAPTALF
FX004-RLRT 004-ACDLAG053CIRTCELESBL00081"832"38.BL0005 DAPTALF
FX006-RLRT 008,006-ACDLAG055RIASBL00003"483"69.BL0005 DAPTALF
XS008-RLRT 008,006-ACDLAG055RIASBL00003"483"69.BL0005 DAPTALF
DCA-150SSKII —TRAILER-SPECIFICATIONS

DCA-150SSKII —PARTS AND OPERATION MANUAL—REV. #1 (05/08/01) —PAGE 13
)t'noC(snoitacificepS.1elbaT
LEDOM RELPUOC SERIT SLEEHW ELXA SBUH NOISNEPSUS LACIRTCELE
W51-01-RLRT SSALCLLAB"2 ELBATSUJDA2 C31-571"05.4X"312X2#0022GUL5FAEL3/WMOOLERIW4 TALFELOP4
X01-RLRT SSALCLLAB"2 ELBATSUJDA2 C31-571"5.4X"312X2#0022GUL5FAEL3TALFELOP4
FX01-RLRT SSALCLLAB"2 ELBATSUJDA2 C31-571"5.4X"312X2#0022GUL5FAEL3TALFELOP4
W522-RLRT SSALCLLAB"2 ELBATSUJDA2 B31-571"5.4X312X2#0022GUL5XELFQTALFELOP4
004WLB SSALCLLAB"2 ELBATSUJDA2 C31-571"5.4X312X2#0022GUL5FAEL3TALFELOP4
FX51-RLRT SSALCLLAB"2CRL31-87B"05.4X"31"2/1-2#0053GUL5FAEL4REBBURELOP4 TALF
X05-RLRT SSALCLLAB"2CRL31-87B"05.4X"31.sbl0053 "8/3-2 GUL5FAEL4REBBURELOP4 TALF
FX05-RLRT SSALCLLAB"2CRL31-87B"05.4X"31.sbl0053 "8/3-2 GUL5FAEL4REBBURELOP4 TALF
W07-RLRT SSALCLLAB"2 ELBATSUJDA"3 C41-502 )4(SAIB "5X"41.sbl0053 "3 GUL5FAEL5REBBURELOP4 TALF
X07-RLRT SSALCLLAB"2 ELBATSUJDA"3 C41-502 )4(SAIB "5X"41sbl0053 "3 GUL5FAEL5REBBURELOP4 TALF
FX07-RLRT SSALCLLAB"2 ELBATSUJDA"3 C41-502 )4(SAIB "5X"41.sbl0053 "3 GUL5FAEL5REBBURELOP4 TALF
FX001-RLRT 6/5-2ELBATSUJDA EYE"3TPO C51-502 )4(SAIB "5.5X"41sbl0053 "3 GUL5FAEL5MOOLERIW4
521/58-RLRT 6/5-2ELBATSUJDA EYE"3TPO D51R57/522TS )4(LAIDAR "6x"41sbl0006-)2(GUL6FAEL7MOOLERIW4
FX051-RLRT EYELLAB"3E61-057 )4(SAIB "7X"61sbl0006-)2(GUL8FAEL7MOOLERIW4
FX022-RLRT EYE"3 ELBATSUJDA E61R58/532TS )4(LAIDAR "7X"61sbl0007-)2(GUL8XELFQMOOLERIW4
FX003-RLRT EYE"3 ELBATSUJDA E61R58/532TS )6(LAIDAR "7X"61sbl0006-)2(GUL8XELFQMOOLERIW4
FX004-RLRT EYE"3 ELBATSUJDA E61R58/532TS )6(LAIDAR "7X"61.sbl0007-)3(GUL8XELFQMOOLERIW4
FX006-RLRT LEEHWHT5H5.71R57/512TS )8(LAIDAR "7X"61sbl00001-)3(GUL8FAEL7MOOLERIW6
RA008-RLRT LEEHWHT5H5.71R57/512TS )8(LAIDAR "7X"61sbl00001-)3(GUL8EDIR-RIAMOOLERIW6
DCA-150SSKII —TRAILER-SPECIFICATIONS

PAGE 14 —DCA-150SSKII—PARTS AND OPERATION MANUAL —REV. #2 (05/08/01)
DCA-150SSKII —TRAILER BRAKING SYSTEM
Brakes
If your trailer has a braking system, the brakes should be
inspected the first 200 miles of operation. This will allow
the brake shoes and drums to seat properly. After the first
200 mile interval, inspect the brakes every 3,000 miles. If
driving over rough terrain, inspect the brakes more
frequently.
Electric Brakes
Electrically actuated brakes (Figure 2) are similar to
hydraulic brakes. The basic difference is that hydraulic
brakes are actuated by an electromagnet.
Listed below are some of the advantages that electric
brakes have over hydraulic brakes:
! An electric brake system can be manually adjusted to
providethecorrectedbrakingcapabilityforvaryingroad
and load conditions.
! An electric brake system can be modulated to provide
more or less braking force, thus easing the brake load
on the towing vehicle.
! An electricbrakesystemhasvery littlelag timebetween
the time the vehicle’s brakes are actuated and the
trailer’s brakes are actuated.
! An electric brake system can provide an independent
emergency brake system.
Roadtestingis necessarryinorderto properly synchronize
the towing vehicle’s braking to the trailer’s braking. Brake
lockup, grabbiness, or harshness is due to lack of
synchronization between the tow vehicle and the trailer
beingtowedor under-adjusted brakes.
Before any brake synchronizations adjustments can be
made,the trailerbrakesshould beburnished-inby applying
the brakes 20-30 times with approximately a 20 m.p.h.
decreasein speed,e.g. 40m.p.h.to20m.p.h.. Allowample
time for brakes to cool between application. This allows
the brake shoes to slightly be seated into the brake drum
surface.
Figure2displays the major electric brakecomponentsthat
will require inspection and maintenance. Please inspect
thesecomponentsasrequired. RefertoTable 5 forelectric
braketroubleshootingguidelines.
Electric Brake Adjustment
1. Place the trailer on jack stands. Make sure the jack
stands are placed on secure level ground.
2. Check the wheel and drum for free rotation.
3. Remove the adjusting hole cover from the adjusting
slot at the bottom brake backing plate.
4. With a screwdriver or standard adjusting tool, rotate
the star wheel of the adjuster assembly to expand the
brake shoes.
5. Adjust the brake shoes outward until the pressure of
the lining against the wheel drum makes the wheel
difficult to turn.
6. Rotate the star wheel in the opposite direction until the
wheel rotates freely with slight lining drag.
7. Replace the adjusting hole cover and lower the trailer
to the ground.
8. Repeat steps 1 through 6 on the remaining brakes.

DCA-150SSKII —PARTS AND OPERATION MANUAL—REV. #1 (05/08/01) —PAGE 15
DCA-150SSKII —TRAILER BRAKING SYSTEM
Hydraulic/Air/Surge Brakes
Hydraulic brakes (Figure 3) should not require any special
attention with the exception of routine maintenance such
as shoe and lining replacement. These brakes can be
adjusted in the same manner as electric brakes. Brake
lines should be periodically checked for cracks, kinks, or
blockage.
Figure3 below displaysthe majorhydraulic/air/surgebrake
components that will requrie inspection and maintenance.
Inspect these components as required using steps 1
through 6 as referenced in the electric brake adjustments
section. Refer toTable6forhydraulicbraketroubleshooting
guidelines.
Figure 2. Electrical Brake Components
Figure 3. Hydraulic Brake Components

PAGE 16 —DCA-150SSKII—PARTS AND OPERATION MANUAL —REV. #2 (05/08/01)
Tires/Wheels/Lug Nuts
Tires and wheels are a very important and critical
components of the trailer. When specifying or replacing
the trailer wheels it is important the wheels, tires, and axle
are properly matched.
CAUTION:
DO NOT attempt to repair or modify a
wheel. DONOT install aninnertubeto
correct a leak through the rim. If the
rim is cracked, the air pressure in the
innertubemaycause pieces of the rim
to explode (break off) with great force and cause serious
eye or bodily injury.
Tire Wear/Inflation
Tire inflation pressure is the most important factor in
preservingtirelife. Pressureshouldbecheckedcoldbefore
operation. DO NOT bleed air from tires when they are hot.
Check inflation pressure weekly to insure the maximum
tire life and to prevent premature tread wear.
Table 2 (Tire Wear Troubleshooting) will help pinpoint the
causes and solutions of tire wear problems.
CAUTION:
NOTE
ALWAYSwearsafetyglasseswhenremoving
or installing force fitted parts. Failure to
comply may result in serious injury.
Suspension
The leaf suspension springs and associated components
(Figure 4) should be visually inspected every 6,000 miles
for signs of excessive wear, elongation of bolt holes, and
loosening of fasteners. Replace all damaged parts
(suspension)immediately. Torquedsuspensioncomponents
as detailed in Table 3.
DCA-150SSKII —TRAILERTIRES & SUSPENSION
Figure 4. Suspension Components

DCA-150SSKII —PARTS AND OPERATION MANUAL—REV. #1 (05/08/01) —PAGE 17
stnemeriuqeReuqroTnoisnepsuS.3elbaT
metI ).sbL-.tF(euqroT
TLOB-U"8/353-XAM03-NIM
TLOB-U"61/706-XAM54-NIM
TLOB-U"2/106-XAM54-NIM
SHACKLE BOLT
SPRING EYE BOLT
SNUG I T ONLY.PARTS MUST ROTATE REELY.
LOCKING NUTS OR COTTER PINS ARE PROVIDED TO
RETAIN NUT-BOLT ASSEMBLY.
SHOULDER TYPE
SHACKLE BOLT
05-XAM03-NIM
stnemeriuqeReuqroTeriT.4elbaT
eziSleehWssaPtsri
SBL-T
ssaPdnoceS
SBL-T
ssaPdrihT
SBL-T
"2152-0204-5356-05
"3152-0204-5356-05
"4152-0206-05021-09
"5152-0206-05021-09
"6152-0206-05021-09
Lug NutTorque Requirements
Itis extremelyimportanttoapplyandmaintainproperwheel
mounting torque on the trailer. Be sure to use only the
fasteners matched to the cone angle of the wheel. Proper
procedure for attachement of the wheels is as follows:
1. Start all wheel lug nuts by hand.
2. Torque all lug nuts in sequence. See Figure 5. DO
NOT torquethewheellugnutsallthewaydown. Tighten
each lug nut in 3 separate passes as defined byTable
4.
3. After first road use, retorque all lug nuts in sequence.
Checkall wheel lugnutsperiodically forcontinuedsafe
operaion.
NOTE
NEVER use an pneumatic air gun to
tighten wheel lug nuts.
DCA-150SSKII —TRAILERTIRES & SUSPENSION
Figure 5. Lug Nut Tightening Sequence

PAGE 18 —DCA-150SSKII—PARTS AND OPERATION MANUAL —REV. #2 (05/08/01)
NOTE:
LIGHTS ARE ORIENTED FROMTHE DRIVER’S SEAT
DCA-150SSKII —TRAILERWIRING DIAGRAMS

DCA-150SSKII —PARTS AND OPERATION MANUAL—REV. #1 (05/08/01) —PAGE 19
gnitoohselbuorTekarBcirtcelE.5elbaT
motpmyS esuaCelbissoP noituloS
sekarBtnettimretnIrosekarBoN?seriwnekorbrostiucricnepoynA.tcerrocdnadniF
?stiucrictrohsynA.tcerrocdnadniF
?rellortnocytluaF.tcerrocdnatseT
?snoitcennocesoolynA.riaperdnadniF
?eruceseriwdnuorG.erucesdnadniF
otlluPsekarBrosekarBkaeW
ediSen
?sgninilrostengamnolioroesaerG.ecalperronaelC
?dedorrocsnoitcennoCesuactcerrocdnanaelC
.noisorrocfo
?devoorgroderocssmurdekarB.ecalperroenihcaM
?dezinorhcnyssekarB.tcerroC
sekarBgnikcoL?nekorbrotneb,esoolstnenopmocekarB.stnenopmocecalpeR
?dnuor-fo-tuosmurdekarB.ecalpeR
sekarBysioN?detacirbulmetsyS.etacirbuL
?tcerrocstnenopmocekarB.tcerrocdnaecalpeR
sekarBgniggarD?detsujdaleehwehtfosgniraeB.tsujdA
DCA-150SSKII —TRAILER-BRAKETROUBLESHOOTING

PAGE 20 —DCA-150SSKII—PARTS AND OPERATION MANUAL —REV. #2 (05/08/01)
gnitoohselbuorTekarBciluardyH.6elbaT
motpmyS esuaCelbissoP noituloS
sekarBoN?deknikronekorbenilekarB.ecalperroriapeR
otlluPsekarBrosekarBkaeW
ediSenO
?dezalggninilekarB.ecalperrohsinrubeR
?dedaolrevoreliarT.thgiewtcerroC
?devoorgroderocssurdekarB.ecalperroenihcaM
?tcerrocerusserperiT.yllauqeseritllaetalfnI
?elxaeasehtnodehctanuseriT.serithctaM
sekarBgnikcoL?nekorbrotneb,esoolstnenopocekarB.stnenopocecalpeR
?dnuor-fo-tuosurdekarB.ecalpeR
sekarBysioN?detacirbuletsyS.etacirbuL
?tcerrocstnenopocekarB.tcerrocdnaecalpeR
sekarBgniggarDthgirnirotcerrocssenkcihtgninilekarB
?noitisopgnorw
dnaseohswenllatsnI
.sgninil
?diulftcerrocrodiulfekarbhguonEstraprebburecalpeR
.diulf4todhtiwllif
DCA-150SSKII —TRAILER-BRAKETROUBLESHOOTING
