mr. steam Feel Good Steam Home SAH3000 Instruction manual

mr
.steam®Feel Good Inc.®
Installation, Operation and Maintenance Manual
Linear Steam Head
Residential Model: 104480
____________________
MP
_
O
_
RT
_
AN
_
T:_ Le
_
ave
_
th
_
is
_
ma
_
teri
_
al
_
wit
_
h t
_
he
_
ho
_
me
_
ow
_
ner
_
.
Steam@Home®
RESIDENTIAL STEAM GENERATOR SYSTEMS
Models: SAH3000, SAH4500, SAH6000
mr
.steam
®
Feel Good Inc.
Installation, Operation & Maintenance Manual

When installing and using this electrical equipment, basic safety precautions
should always be followed, including the following:
IMPORTANT SAFETY INSTRUCTIONS
1. READ & FOLLOW ALL INSTRUCTIONS
2. To reduce the risk
of injury, children under the age of
16 should not use the steam bath.
3. Steam is hot and
can cause injury or death if
improperly used. Steam rooms
contain steam and elevated
temperatures. Please read and
observe all warnings in this
manual before installing or using
a steam room.
4 To reduce the risk
of injury:
A. The wet surfaces of steam
enclosures may be slippery. Use
care when entering or leaving.
B. The steam head is hot. Do not
touch the steamhead and avoid
the steam near the steamhead.
C. Prolonged use of the steam system
can raise excessively the internal
human body temperature and
impair the body’s ability to
regulate its internal temperature
(hyperthermia). Limit your use of
steam to 10-15 minutes until you
are certain of your body’s reaction.
D. Excessive temperatures have a
high potential for causing fetal
damage during the early months
of pregnancy. Pregnancy or
possibly pregnant women should
consult a physician regarding
correct exposure.
E. Obese persons and persons with
a history of heart disease, low or
high blood pressure, circulatory
system problems, or diabetes
should consult a physician before
using a steambath.
F. Persons using medication should
consult a physician before using a
steambath since some
medication may induce
drowsiness while other
medications may affect heart rate,
blood pressure and circulation.
SAVE THESE
INSTRUCTIONS
READ ME FIRST!
As you follow
these instructions, you will notice
warning and caution symbols.
This blocked information is impor-
tant for the safe and efficient
installation and operation of this
generator. These are types of
potential hazards that may occur
during installation and operation:
Indicates a
potentially hazardous situation,
which, if not avoided, could result
in death or serious injury.
Indicates a
potentially hazardous situation,
which, if not avoided may result in
minor or moderate injury or
product damage.
IMPORTANT NOTE: This
highlights information that is
especially relevant to a problem-
free installation.
All information in these
instructions is based on the latest
product information available at
the time of publication. MrSteam
reserves the right to make changes
at any time without notice.
HYPERTHERMIA occurs when the
internal temperature of the body
reaches a level several degrees above
the normal body temperature of 98.6° F.
The symptoms of hyperthermia include
an increase in the internal temperature
of the body, dizziness, lethargy,
drowsiness, and fainting. The effects of
hyperthermia include:
a) Failure to perceive heat;
b) Failure to recognize the need to exit
the steambath;
c) Unawareness of impending risk;
d) Fetal damage in pregnant women;
e) Physical inability to exit the
steambath;
and
f) Unconsciousness.
The use of alcohol,
drugs, or medication can greatly
increase the risk of hyperthermia.
REDUCE THE RISK OF OVERHEATING AND SCALDING
1. EXIT IMMEDIATELY IF UNCOMFORTABLE, DIZZY OR SLEEPY.
STAYING TOO LONG IN A HEATED AREA IS CAPABLE OF CAUSING OVERHEATING.
2. SUPERVISE CHILDREN AT ALL TIMES.
3. CHECK WITH A DOCTOR BEFORE USE IF PREGNANT, DIABETIC, IN POOR HEALTH
OR UNDER MEDICAL CARE.
4. BREATHING HEATED AIR IN CONJUNCTION WITH CONSUMPTION OF ALCOHOL,
DRUGS, OR MEDICATION IS CAPABLE OF CAUSING UNCONSCIOUSNESS.
5. DO NOT CONTACT STEAM HEAD OR STEAM AT THE STEAM HEAD.
REDUCE THE RISK OF SLIPPING AND FALL INJURY
1. USE CARE WHEN ENTERING OR EXITING THE STEAM ROOM. FLOOR MAY BE SLIPPERY
NOTE: FOR ADDITIONAL SAFETY CONSIDERATIONS SEE OWNER”S MANUAL
WHICH IS KEPT:_______________________________________
THE OWNER’S MANUAL CAN BE FOUND AT WWW.MRSTEAM.COM
USE OF STEAM ROOM IN CONJUNCTION WITH CONSUMPTION OF ALCOHOL CAN BE
DANGEROUS AND CAN RESULT IN INJURY THROUGH SLIP AND FALL OR OTHERWISE.
mr
.
steam®
43-20 34th Street , Long Island City NY 11101 1 800 76 STEAM www.mrsteam.com PUR100378 8.18
PUR100378 3.22
1
A peel-off warning label has been provided in the Information envelope. This label is to be
applied to the wall of the installed shower or steam enclosure in a conspicuous location.

2
®INSTALLATION, OPERATION, & MAINTENANCE
Steam@Home®
TABLE OF CONTENTS:
INFORMATION FOR INSTALLERS & HOMEOWNERS
Read Me First! & Warning Sticker . . . . . . . . . . . . . . .1
Select Your Mr.Steam Model . . . . . . . . . . . . . . . . . . .3
Generator Specification Chart . . . . . . . . . . . . . . . . .3
INSTALLER’S SECTION
Before Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Steam Room Guidelines . . . . . . . . . . . . . . . . . . . . . .4
Water Quality Information . . . . . . . . . . . . . . . . . . . . .5
Locating the Steam Generator Unit . . . . . . . . . . . . .5
Typical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Generator Diagram . . . . . . . . . . . . . . . . . . . . . . . . . .6
Installation: Plumbing, Water Supply,
Steam Outlet, Safety Valve, Condensation Pan . .7
Steam Head Installation . . . . . . . . . . . . . . . . . . . . . .8
Electrical Specifications & Field Power Wiring . . . . .9
Initial Start-Up & Checkout . . . . . . . . . . . . . . . . . . .10
Troubleshooting/System Status Codes . . . . . . . . . .10
Wiring Diagrams / Liquid Level Control Board . . . .11
Replacement Parts Diagram & Parts List . . . . . . . . .12
SteamStart™
Dimensions & Installation Instructions . . . . . . . .13
HOMEOWER’S SECTION
Care Tips, Safety & Operating Information . . . . . . .14
AromaSteam™ Essential Oils . . . . . . . . . . . . . . . . .14
Residential Steambath Generator Systems
MODELS: SAH3000, SAH4500, SAH6000
MODEL ____________________ SERIAL NO.____________________
All drawings are for illustrative
[email protected] • www.mrsteam.com
43-20 34th Street, Long Island City, NY 11101 Tel: 1 800 76 STEAM
9410 S. La Cienega Blvd. Inglewood CA 90301 Tel: 1 800 72 STEAM
®
PUR100467 Rev 1.23
MADE IN USA
2

3
®
Steam@home Generator Specification Chart
Amps
†
Wire Water Usage Shipping
Model No. KW (for 240v/1PH) Size
‡
Gallons
††
Dimensions* Weight (lbs)
SAH3000 3.0 13 12
3
⁄ 8 14
3
⁄ 8 "L x 14
7
⁄ 8 "H x 5
3
⁄ 16 "D 25
SAH4500 4.5 19 10
1
⁄ 2 14
3
⁄ 8 "L x 14
7
⁄ 8 "H x 5
3
⁄ 16 "D 25
SAH6000 6.0 25 8
3
⁄ 4 14
3
⁄ 8 "L x 14
7
⁄ 8 "H x 5
3
⁄ 16 "D 25
All drawings are for illustrative purposes only.
INSTALLATION, OPERATION, & MAINTENANCE
Steam@Home®
INSTALLER
CORRECT SIZING IS IMPORTANT
Selection of the appropriate model is im-
portant to effectively match the heating requirements of
the steam room to the steam bath generator. Do not use a
particular SAH model steam generator with a room whose
“total room volume” is less than the range shown in the
SAH model steam generator sizing chart below. Selection
of a model with a “total room volume” rating greater than
the “total room volume” may cause excessive tempera-
ture. Do not use SAH model steam generators in a room
with a “total room volume” of less than 60 cubic feet.
SELECT YOUR STEAM@HOME
Materials of construction and room size affect the steam
generator model selection.
To determine the “total room volume” multiply length x
width x height of the steam room.
STEAM@HOME GENERATOR SIZING CHART
Total Room Volume* Acrylic/Fiberglass Ceramic
Tile**
60 – 75 cu. ft. SAH3000 SAH3000
76 – 110 cu. ft. SAH3000 SAH4500
111 – 150 cu. ft. SAH3000 SAH6000
* For rooms with “total room volumes” greater than 150
cu. ft. refer to Mr.Steam MS series of residential steam
bath generators
** For all other room materials refer to Mr. Steam MS
series of residential steam bath generators.
In considering a purchase of this steam-
bath system, please note that if you are pregnant, have a
coronary condition, are in poor health, are being treated
for any other medical condition, or are using medication
or drugs, Mr.Steam recommends that you obtain the ap-
proval of a physician before use. For information about
this product and safety issues, please call us at
1.800.76.STEAM or log onto www.mrsteam.com for a
copy of the Installation, Operation & Maintenance Manual.
IMPORTANT NOTE: SAH Model steam generators
should not be used for rooms constructed of natural
stone, glass block and/or glass tile and/or for rooms hav-
ing a ceiling height in excess of 8 feet.
IMPORTANT NOTE: The “total room volume” allows
for a maximum of 60 feet of insulated steam line from
the SAH generator to the steam room. If the 60 foot line
is exceeded refer to Mr.Steam MS series of residential
steam bah generators. When locating the steam gener-
ator consideration of control location must be taken into
account. The maximum length for a control cable is 60
feet. A 30 foot cable is standard. Contact Mr.Steam to
purchase the optional 60 ft. cable (PN 103978-60)
Consult with supplier of acrylic and fi-
berglass enclosures for recommended steamhead loca-
tion. Use supplied Acrylic Shield PN MS-103938. See
instructions on page 8.
IMPORTANT NOTES:
• Add C1 suffix to Model No. for 240V/1Ph;
• Add B1 suffix to Model No. for 208V/1Ph
• All Mr.Steam SAH Models are cULus Listed & CE approved.
*Dimensions are for generator only, without plumbing features.
†† Approximate water usage based on 20 minutes of operation.
NOTES: All SAH Generators available in 240v/1PH and 208v/1PH. SAH units are not available in 3 phase. Specify voltage with order.
† Amps are for 240v/1PH rated units.
‡ Wire size (AWG) based on minimum 90°C rated THHN copper conductors.
Refer to the National Electrical Code for other types of conductors.
See page 9 for complete dimensional information.

4
®INSTALLATION, OPERATION, & MAINTENANCE
Steam@Home®
INSTALLER
BEFORE INSTALLING
Carefully inspect the Steam Generator and
packaging for shipping damage. Please
contact the carrier in the event of shipping
damage, please contact the carrier for claim
information. Our customer service department
can assist you with any missing or damaged
parts.
Never use damaged equip-
ment, doing so may result in an inoperative
or hazardous installation.
IMPORTANT NOTES:
• This document contains important safety,
operation and maintenance information.
Leave this document with the homeowner.
Do not discard this document.
IMPORTANT NOTE:
The following general information should be
used in conjunction with consultations with
an architect, designer and contractor in de-
termining factors necessary in providing a
suitable and safe steam room.
REDUCE THE RISK OF OVERHEATING AND SCALDING
1. EXIT IMMEDIATELY IF UNCOMFORTABLE, DIZZY OR SLEEPY.
STAYING TOO LONG IN A HEATED AREA IS CAPABLE OF CAUSING OVERHEATING.
2. SUPERVISE CHILDREN AT ALL TIMES.
3. CHECK WITH A DOCTOR BEFORE USE IF PREGNANT, DIABETIC, IN POOR HEALTH
OR UNDER MEDICAL CARE.
4. BREATHING HEATED AIR IN CONJUNCTION WITH CONSUMPTION OF ALCOHOL,
DRUGS, OR MEDICATION IS CAPABLE OF CAUSING UNCONSCIOUSNESS.
5. DO NOT CONTACT STEAM HEAD OR STEAM AT THE STEAM HEAD.
REDUCE THE RISK OF SLIPPING AND FALL INJURY
1. USE CARE WHEN ENTERING OR EXITING THE STEAM ROOM. FLOOR MAY BE SLIPPERY
NOTE: FOR ADDITIONAL SAFETY CONSIDERATIONS SEE OWNER”S MANUAL
WHICH IS KEPT:_______________________________________
THE OWNER’S MANUAL CAN BE FOUND AT WWW.MRSTEAM.COM
USE OF STEAM ROOM IN CONJUNCTION WITH CONSUMPTION OF ALCOHOL CAN BE
DANGEROUS AND CAN RESULT IN INJURY THROUGH SLIP AND FALL OR OTHERWISE.
mr
.steam®
43-20 34th Street , Long Island City NY 11101 1 800 76 STEAM www.mrsteam.com PUR100378 8.18
Not actual size
PUR100378 3.22
Read these instructions before installation or service.
Although this SAH steambath generator has been fully qualified for
shipment by Mr.Steam®, the following must be reviewed for proper,
safe and enjoyable steam bathing:
• Verify that the model and accessories are correct, including incom-
ing line voltage.
• Insure steambath generator has been correctly sized for the steam-
bath room. Pay particular attention to room volume and construc-
tion. If any questions, please refer to Mr. Steam sizing and
selection guide on page 3.
• The physical size of the unit, clearance for plumbing servicing, and its dis-
tance from the steam room must all be considered before installation.
IMPORTANT NOTE: Mr.Steam SAH units are intended to be oper-
ated with a Mr.Steam SteamStart™ control only, and are to be in-
stalled strictly in accordance with the specific instructions contained
in this manual.
ELECTRICAL SHOCK HAZARD: Mr.Steam steam
generators are intended to be connected to 208V or 240V line volt-
age and contain live electrical components. All installation and serv-
ice to be performed by qualified and licensed electricians and
plumbers only. Installation or service by unqualified persons or failure
to use Mr. Steam parts may void the warranty.
STEAM ROOM GUIDELINES
IMPORTANT NOTES:
1.Steam room must be completely enclosed, with full walls,
door, floor and ceiling.
2.It is recommended that a gasketed door is used for heat
sealing and steam containment.
3.If smooth surfaced flooring is used, provide suitable anti-skid
strips or equivalent to prevent user slipping and injury.
4.Walls and ceilings must be constructed of water-resistant, non-
corrosive surface, such as tile, molded acrylic, or fiberglass.
The ceiling should be sloped to prevent dripping of
condensate.
If acrylic or fiberglass are used as part of the
steam room enclosure. Consult with the material manufacture
and see pg. 7 for additional details.
5.Provide a floor drain.
6.No heating, venting or air conditioning devices should be
installed inside the steam room.
7.Steam room tile construction information is available from the
Tile Council of America, Inc. by purchasing the TCA
Handbook for Ceramic Tile Installation. Tel: [phone] or
www.tileusa.com.
8.Windows that are part of the steam room should be double
paned and tempered safety glass.
9.Limit steam room ceiling height to 8 feet.
10. A peel-off warning label has been provided in
the Information envelope (see Warning facsimile
below). This label is to be applied to the wall of
the installed shower or steam enclosure.
The SAH series of steam gener-
ators are for residential use only. Commercial
or other nonresidential applications void the
warranty and may adversely affect product per-
formance.

5
®INSTALLATION, OPERATION, & MAINTENANCE
Steam@Home®
INSTALLER
WATER QUALITY INFORMATION
IMPORTANT NOTE: For optimum results, the water supply should be tested prior to initial startup. If the mineral content
exceeds the following recommended limits, various external treatment processes may be used to correct the problem.
NOTE: An analysis of the on-site water must be made by a recognized and reliable water treatment
company to ascertain the existing condition and treatment required.
RECOMMENDED FEEDWATER QUALITY
Hardness, ppm 8 – 85 (~0.5 – 5 gpg)
P-Alkalinity, ppm 85 – 410 (~5 – 24 gpg)
T. Alkalinity, ppm 200 – 500 (~7 – 0 gpg)
pH (strength of alkalinity) 8.0 – 11.4
Every 2 months, or more often in “hard” water areas, the manual drain valve should be opened fully flushing out accumulated
materials, salts and other particles which are natural by-products of boiling water. See page 14 for draining information.
Water quality can affect efficiency or result in boiler damage if neglected. Water contains impurities in solution and
suspension. These impurities concentrate within the steam generator tank. The concentration of these impurities
increases as more feedwater is introduced into the steam generator tank and steam is produced. If the impurities are
allowed to concentrate beyond certain limits, a deposit or “scale” will form on the steam generator tank’s internal
surfaces. This deposit can interfere with the proper generator operation and cause generator failure. The concentration
of these impurities is generally controlled by the feed water quality and periodically by draining the generator.
LOCATING THE STEAM GENERATOR UNIT
Select a location as near as practical to the steam room.
Typical locations include: closet, vanity cabinet, heated attic or basement.
NOTE: The standard length of the cable for connecting the control to the steam generator is 30 feet. The steam
generator and control must be located accordingly. A 60 foot cable (PN 103978-60) is available as a special order
part if the installation requires a longer cable.
(ITEMS 1-7)
1. DO NOT install steambath generator or plumbing lines in
unheated attic or any locations where water could freeze.
2. DO NOT install steambath generator inside steam
room.
3. DO NOT install steambath generator outdoors or
wherever environmental conditions may affect the
safety and/or performance of the generator.
4. DO NOT install steambath generator near flammable
or corrosive materials or chemicals such as gasoline,
paint thinners, or the like. Installation in areas having
high concentrations of chlorine (such as pool
equipment room) must be avoided.
5. Install steambath generator on a solid and level
surface. Keyhole slots are provided for wall mounting.
Insure the steam generator is properly secured and
level when mounting with keyhole slots.
6. Install steambath generator in an upright position only.
7. Steam line, safety valve, drain valve, plumbing and
steamheads become hot during operation and remain
hot after shutdown for a period of time. Provide
appropriate protection, including insulating plumbing
lines. Avoid plumbing runs and steamhead locations
that can come in contact with bathers.
IMPORTANT NOTES: (ITEMS 8-12)
8. Install anti-water hammer device as necessary.
9. Provide a minimum of (12) inches on the plumbing
side and top of the steam generator or as required
for servicing. See page 6.
10. Provide unions to facilitate installation and
disconnection of piping.
11. The SteamStart™ control may be located inside the
steam room or outside of the steam room. See
SteamStart Installation section (pg. 13) for specific
details.
NOTE: Mr.Steam Generators (inclusive of the
SteamStart™ series controls) are CE and UL listed.
The Steam@home®steam generator is
suitable for operation in ambient temperature not
exceeding 45°C (113° F)
The SAH series of steam generators are
for residential use only. Commercial or other non-
residential applications void the warranty and may
adversely affect product performance. Use only
Mr.Steam SteamStart™ control.

Steam
Generator
Field installed
power supply
Field installed 1/2” insulated
steam supply pipe
Drain Valveshouldbeclosed
SeePage1fordraininginformation
Control cable
(located behind the wall)
Steam Head(shownwithacrylicshield)
SeepageforSteamHeadInstallation
information
SteamStart™Control
See page1
for installation
information.
Field installed
water supply line
IMPORTANT NOTE: Install cable in a dedi-
cated conduit to allow for replacement. Be
careful not to strain, staple, pinch or other-
wise damage the control cable. Do not
route in conduit with power wires.
55⁄8”
(138)
73⁄4”
(197)
11⁄4”
(32)
12”
(305)
147⁄8”
(378)
1⁄”
(8)
33⁄8”
(86)
53⁄16”
(132)
21⁄2”
(64)
143⁄8”
(365)
11⁄2”(38)
GENERATOR DIAGRAM
WATER INLET 3/8” NPT
STEAM OUTLET

/”NPT
SAFETY VALVE 3/4” NPT
MANUAL DRAINVALVE1/”NPT
Water Inlet
SteamStart™
Connection
Steam Outlet
Manual
Drain
Valve
Safety Valve
®
6
All drawings are for illustrative purposes only.
INSTALLATION, OPERATION, & MAINTENANCE
Steam@Home®
INSTALLER
TYPICAL MR.STEAM INSTALLATION
GENERATOR DIAGRAM
NOTE: For illustrative purposes only. Consult
with qualified designer, architect or contractor
for steam room construction details.
Provide unions to facilitate
installationand disconnect of
piping.
NOTE: All units in inches (mm)
IMPORTANT NOTE: Provide a minimum of (12) inches
at plumbing end and top of the steam generator or as
required for servicing. Alternately, provide unions as
required to facilitate installation and disconnection of the
steam generator.
IMPORTANT NOTE: The minimum clearance from
com-bustible surfaces is zero all around.
TO AVOID EQUIPMENT DAMAGE DO NOT
CONNECT POWER SUPPLY DIRECTLY TO ELEMENT
TERMINALS !!!
NOTE: FOR ILLUSTRATIVE PURPOSES ONLY.
To avoid unintentional steambath operation, do not
locate the control where other controls, shower heads, valves, body
sprays or similar accessories within the shower could cause confusion
or interfere with the Mr.Steam control’s intended use and function.
Consult with supplier of acrylic, fiberglass and
other non-heat resistant enclosures for recommended steamhead
location. Use Acrylic Shield PN MS-103938. See instructions provided
with steam shield.

7
®
All drawings are for illustrative purposes only.
INSTALLATION, OPERATION, & MAINTENANCE
Steam@Home®
INSTALLER
INSTALLING
Plumbing
All plumbing shall be performed by a qualified licensed plumber and in
accordance with applicable National and local codes.
• Use unions on all pipe connections.
• Use only brass piping or copper tubing as permitted by codes.
• Do not use black, galvanized, PVC pipe or PEX.
Water Supply (3⁄8" NPT)
1. Connect hot or cold water line. If hot water line is used water temperature should not exceed 130° F.
2. Provide a shut off valve in the water supply line upstream of the steambath generator.
3. Do not overheat inlet solenoid valve with solder connections. Overheating will damage the valve.
4. Flush inlet water line thoroughly before making connection to unit.
5. Strainer recommended upstream of feed water connection.
6. For best performance water pressure should be 15 to 20 psig. Reduce pressure as required using a
suitable pressure reducing valve.
7. Provide anti-water hammer device as required.
8. Install an approved backflow preventer as required by code.
Steam Outlet (1⁄2" NPT)
1. Do not install any valve in steam line. Flow of steam must be unobstructed.
2. Use 1/2-inch brass pipe or copper tubing from unit to steam head as permitted by codes.
3. Insulate steam line using pipe insulation rated 250° F minimum.
4. Pitch steam line 1/4" per foot towards steam head or steam generator to avoid valleys and trapping of
condensate.
IMPORTANT NOTE: Running the steam line down and then up will create a trap blocking the flow of steam.
NOTE: A 1.5" diameter hole in the steam room is required to mount the steamhead.
Safety Valve (3⁄4" NPT)
Where permitted by local codes, provide an outlet plumbing connection for safety valve.
To insure proper and automatic safety valve operation: DO NOT connect a shut off valve or
a plug at safety valve outlet. DO NOT connect a shut off valve or any obstruction in steam supply pipe. DO
NOT connect the safety-valve output into the steam line
Manual Drain Valve (1⁄2" NPT)
Unit drains by gravity. See page 14 for draining
instructions
Condensation Pan (PN 103867)
Mr. Steam strongly recommends the use of a
condensation pan in the unlikely event of a plumbing
leak.
Locate the condensation pan on a solid level surface
and place the steam generator inside the condensation
pan. Insure the steam generator is level (see page 4 for
locating the steam generator). The condensation pan is
equipped with an integral female 3⁄4" NPT fitting.
All plumbing shall be performed by a qualified licensed
plumber and in accordance with applicable national
and local codes. Check local plumbing code for
receptor, trap and vent requirements. Condensation
pans drain by gravity.
#ONDENSATION Pan
PN: MS103867

®INSTALLATION, OPERATION, & MAINTENANCE
Steam@Home®
INSTALLER
STEP 2
STEP 3
STEP 4
Steam Supply Pipe
Use Teflon or equal
sealant on pipe threads
End of pipe to be
recessed 1/8"
(with Acrylic Shield)
Apply with silicone or
equal sealant as required
for moisture seal.
Acrylic Shield
(PN 103938)
Steamhead
with Acrylic Shield
Locating Nipple
Apply silicone
in groove.
Oil Well
Oil Well
Acrylic Shield
(PN 103938)
All drawings are for illustrative purposes only.
INSTALLATION OF THE STEAM HEAD
(1⁄2” NPT, PN 103937)
WITH ACRYLIC SHIELD (PN 103938)
The Acrylic Shield (PN 103938) is for use when acrylic or other non-heat
resistant materials are used for the steamroom enclosure.
INSTALLER: Because the steam head and direct steam
emissions are very hot, locate the steam head where incidental contact
by bather with the steam head or direct steam emission cannot occur.
IMPORTANT NOTE: These instructions are only for use in installations
using an Acrylic Shield (pur 103938).
STEP 1
Locate steam head at least 12 inches from an adjacent wall or bench
and 6-12 inches above floor, except for tub/shower enclosures, install
6 inches above tub top edge. The steamhead shall be installed with
the oil well facing up as shown. Hand tightening is sufficient when
teflon or equal pipe thread sealing compound is used.
IMPORTANT NOTE: to preserve steam head finish, do not use wrench
or other tools to tighten. DO NOT use abrasive cleansers or chemicals.
Use only water with mild soap and a non-abrasive sponge.
Consult with supplier of acrylic, fiberglass and other
non-heat resistant enclosures for recommended steamhead location.
STEP 2
Secure a bronze drop ear fitting to a header and run a 1⁄2" copper
steam line from the steam generator to the drop ear fitting. Install a
temporary nipple (6" or longer)in the drop ear fitting to locate the
steamhead after the wall is finished.
STEP 3
After the wall has been finished, mark on the nipple where the
surface of the wall is. Remove the nipple and measure the portion
that was in the wall (the end to your mark). Subtract 1⁄8" from that
dimension and select a brass nipple of that length to finish the
installation.
STEP 4
Wrap teflon tape around the threads of the new nipple and screw the
nipple into the steamhead. Do not use wrenches or tools which
would damage the steamhead's finish.
Slide the acrylic shield onto the nipple-steamhead assembly so the
steam head sits in the acrylic shield.
Apply clear silicone in the groove on the back of the acrylic shield.
Wrap teflon tape around the threads of the nipple and screw the
nipple and steamhead assembly you just made into the drop ear
fitting in the wall. The steamhead should be flush with the wall and
the well must be facing up.
The acrylic shield will be sandwiched between the wall and steam head.
8

®
Contactor
Power Supply
Opening
Control Connection
Seepage12forWiring
Field Wiring
Ground Conductor
Terminal
INSTALLATION, OPERATION, & MAINTENANCE
Steam@Home®
INSTALLER
ELECTRICAL
All electrical wiring to be installed by a qualified
licensed electrician in accordance with National
Electrical Code and local electrical code.
Power Wiring
See “Field Power Wiring” Diagrams (below)
1. Check power voltage. Use 240V rated unit when
supply is greater than 208V. (Most homes have 240V,
1PH service). Use 208V rated unit for 208V power.
2. Use minimum 90°C/300V rated insulated copper
conductors only, sized in accordance with National
Electrical Code and local electrical code for the
current in Ampere Chart. If allowed by codes, NM
cable may require a larger wire size than as listed on
the chart.
3. Connect suitably sized equipment grounding wire to
ground terminal provided.
4. Install a separate circuit breaker between supply and
unit. Provide a power supply disconnect within sight
of the steam generator or one that is capable of
being locked in the open position.
5. Use two-wire supply source and equipment
grounding wire. Neutral (white) wire is not required.
IMPORTANT NOTE: Provide a power supply
disconnect within sight of the steam generator or one
that is capable of being locked in the open position as
permitted by code.
CHART
_____________________________________________________________________________
Max Room Wire Size
Model Volume KW Volts† Phase AMPS (AWG) for up to
No. (Cu. Ft.*) 45˚ C Ambient
_____________________________________________________________________________
208 1 15 12
SAH3000 65 3.0 240 1 13 12
_____________________________________________________________________________
208 1 22 10
SAH4500 100 4.5 240 1 19 10
_________________________________________________________________________ ____
208 1 29 8
SAH6000 150 6.0 240 1 25 8
_________________________________________________________________________ ____
*See pageforroomsizing.
SAH units are not available in 3 phase.
9
FIELD POWER WIRING
Models SAH3000, SAH4500 & SAH6000
TO AVOID EQUIPMENT DAMAGE DO NOT CONNECT POWER
SUPPLY DIRECTLY TO ELEMENT TERMINALS!!!
L1, L2, GROUND TO BE FIELD WIRED
Side View Showing Element
Access Panel
TO AVOID EQUIPMENT
DAMAGE DO NOT
CONNECT POWER SUPPLY
DIRECTLY TO ELEMENTS !!!
All drawings are for illustrative purposes only.

1
2
4
6
7
83
5
10
®
All drawings are for illustrative purposes only.
INSTALLATION, OPERATION, & MAINTENANCE
Steam@Home®
INSTALLER
INITIAL START-UP & CHECKOUT
Troubleshooting
ELECTRICAL SHOCK HAZARD.
Mr.Steam steam generators are connected to
240V line voltage and contain live electrical
components. All installation and service to be
performed by qualified and licensed
electricians and plumbers only. Installation or
service by unqualified persons or failure to use
Mr. Steam parts may void the warranty.
STEP 1 Check your main incoming power to
the unit.
STEP 2 Verify the transformer is receiving
208/240 VAC.
STEP 3 Verify that you have 24VAC coming out
of the transformer, WHT & WHT/BLU wires, into
the board.
SYSTEM STATUS
The control STEAMSTART™ may blink if the steam generator is not functioning properly.
MEANING PROBABLE CAUSE SUGGESTED REMEDY
Water level is not Water Supply is off Turn on Water Supply
satisfied within 5 min. Defective water feed solenoid Check/replace water solenoid valve
Water feed probe not functioning Check/clean probe.
Check probe wiring.
Drain Valve Open Check/Close drain valve
Incorrect Field Supply Voltage Incorrect voltage supplied Supply steam generator with the correct
(green light on liquid level to Generator voltage noted on the data plate label.
control board will be off)
Button on control is pressed Debris behind overlay cover Replace SteamStart button
for more than 5 minutes
Liquid Level Control Board malfunction Memory error in LLCB Press SteamStart button
Replace LLCB if code remains.
1. Turn on control. Follow specific instructions pages 14.
2. Steam will begin to appear in approximately 5
minutes at the steam head.
3 .Steam will shut off automatically when 20 minute
timer is up. To shut steam off manually, press
SteamStart™ again. To clear steam from enclosure
area, turn shower on before opening door.
4. If unit does not start and SteamStart backlight does
not turn on, then turn breaker off for 2 seconds and
try again.
STEP 4 Verify that you have the green light on
the PC board.
STEP 5 Verify that you have 24 VAC to the
water feed solenoid, GRY & WHT/GRY wires
(will fill when needed).

_________________________________________________________________________________________________
GREEN LED is ON when there is 208/240 Volt incoming power connected, 24 Volt
transformer secondary output and on-board 5 Volt DC control power are present.
_________________________________________________________________________________________________
YELLOW Water level indicator–LED is OFF when no water is detected (for more that 5 seconds).
ON when water level is satisfactory.
__________________________________________________________________________________________________
RED Contactor relay indicator–LED is ON when relay is closed and sending 24 Volts to the
contactor coil. (This LED comes ON if the generator is ON.)
__________________________________________________________________________________________________
Liquid LevelControlBoard
PN 104288B
(shownwithoutwiring)
FACTORY
WIRING
FIELD
WIRING
LEGEND
(All Diagrams)
SteamStart™
11
®
All drawings are for illustrative purposes only.
INSTALLATION, OPERATION, & MAINTENANCE
Steam@Home®
INSTALLER
SINGLE PHASE 208/240 VOLT WIRING DIAGRAMS
SAH units are not available in 3 phase
MODELS:
SAH3000
SAH4500
SAH6000
LIQUID LEVEL CONTROL BOARD Explanation of LED Indicators
GREEN (Power)
YELLOW (Water Level)
RED (Heater)

Transformer Liquid Level
Control Board Water Feed
Solenoid
SteamStart™
Safety Valve
Drain Valve
(shown in closed position)
Stainless Steel Tank
Heating Element
Contactor
Power Supply
Opening
Steam Outlet
12
®
All drawings are for illustrative purposes only.
INSTALLATION, OPERATION, & MAINTENANCE
Steam@Home®
INSTALLER
NOTE: FOR ILLUSTRATIVE PURPOSES ONLY.
Some components may be omitted or altered for clarity.
Do not use for wiring, repair or other purposes not related to
component identification.
REPLACEMENT PARTS LIST
Please call Technical Support at 800-76-STEAM (East Coast)
or 800-72-STEAM (West Coast) for Service Information
MODELS SAH3000, SAH4500, SAH6000
Shown with cover removed
Part # Description
99178FMS
99297
100479
10477-3
104288B
100476-2
100471-2
103938
103978-30
103978-60
19031BM
19031CM
19041BM
19041CM
19061BM
19061CM
Drain Valve
Safety Valve 15PSI
Water Feed Solenoid Valve with filter
Transformer 24VAC
Liquid Level Control Board
Contactor 50A 2-pole
Probe Assembly
Acrylic Shield
Cable for SteamStart™ (30 ft.)
Cable for SteamStart™ (60 ft.)
ELEMENT 3KW/208/1 BUILDERS
ELEMENT 3KW/240/1 BUILDERS
ELEMENT 4.5KW/208/1 BUILDERS
ELEMENT 4.5KW/240/1 BUILDERS
ELEMENT 6KW/208/1 BUILDERS
ELEMENT 6KW/240/1 BUILDERS

®INSTALLATION, OPERATION, & MAINTENANCE
Steam@Home®
INSTALLER
STEAMSTART™ On/Off Switch
Box Contents:
• SteamStart™ Control
• Control Cable
Installing The Steamstart™ Control
The SteamStart has a 30 foot cable with a Plug & Play connector
at both ends. (Diagram 1).
A 60 foot control cable is available (103978-60). Contact a Mr.
Steam technical representative if the 60 foot cable is required.
To avoid unintentional steambath operation, do
not locate the control where other controls, shower heads, valves,
body sprays or similar accessories within the shower could cause
confusion or interfere with the Mr.Steam control’s intended use
and function.
STEP 1 - Diagram 2
Drill a 7/8 inch diameter hole in a preferred wall location. Do not
oversize or undersize the hole.
STEP 2 - Diagram 3
Route the cable from the wall to the steam generator. Be careful
not to strain, pinch or otherwise damage the control cable.
STEP 3 - Diagram 4
Remove and discard the peel-off paper from the switch housing
to expose the adhesive as shown in Diagram 4.
STEP 4 - Diagram 5
Apply silicone (provided with SteamStart control) to the hole in
the wall as required to create a moisture seal. Apply silicone to
the back of the switch as required to seal grout lines or as
required for additional adhesion.
IMPORTANT NOTE: Use care not to apply silicone to the
adhesive gasket.
STEP 5
Push cable and switch housing into the hole firmly.
STEP 6 - Diagram 6
Firmly connect the Plug & Play connector to the steam generator
connector labeled SteamStart.
NOTE: The connector is keyed and will only connect in one
orientation with the tab facing up.
IMPORTANT NOTE: Install cable in a dedicated conduit to
allow for replacement. Be careful not to strain, staple, pinch or
otherwise damage the control cable. Do not route in conduit with
power wires.
30'CABLE
SWITCH PLUG&PLAY
CONNECTOR
DIAGRAM 1
DIAGRAM 2
DIAGRAM 3
DIAGRAM 4
DIAGRAM 5
DIAGRAM 6
13
All drawings are for illustrative purposes only.
1/8"
1 1/8"
1 1/2"
DIMENSIONAL INFORMATION

14
®
All drawings are for illustrative purposes only.
INSTALLATION, OPERATION, & MAINTENANCE
Steam@Home®
HOMEOWNERR
SAFETY & OPERATING INFORMATION
Use the SteamStart™ control to turn the steam generator on.
The SteamStart control will only light up when the steam gener-
ator is on.
The steam generator will automatically shut off at 20 minutes, to
turn the steam generator off manually prior to the automatic
shut off, press the button on the SteamStart control.
The SteamStart control may blink if the steam generator is not
functioning properly (see page 10).
Do not install or use any SteamStart™ control
without reading and understanding the Mr.Steam steam gener-
ator Installation and Operation Manual (PN 100467 Rev 3.12 or
higher). Failure to read and understand these instructions may
result in an inoperative or hazardous installation. A peel-off warn-
ing label has been provided in the Information envelope This
label is to be applied to the wall of the installed shower or steam
enclosure in a conspicuous location.
AromaSteam steam head
(install per instructions on pg.7)
Steam emission slot
AromaSteam™
10ml bottle with
integrated dropper
Recess for
essential oil
Do not alter or modify any Mr. Steam products
including the steam generator or SteamStart™
controls. Doing so may result in an inoperative or
hazardous installation and will void the warranty.
IMPORTANT NOTE: Do not operate any
SteamStart™ control with other than a Mr.
Steam SAH steam generator. Doing so may
result in an inoperative installation.
This document contains important safety,
operation and maintenance information. Do not
discard this document.
Malfunction due to power spikes, lightning, fire,
freezing or flooding is not covered under the
warranty. Discontinue use of the steam
generator or control if the steam generator is
damaged or otherwise not functioning
Steam Generator Maintenance
Other than periodic draining, maintenance procedures
are minimal. Every 2 months, or more often in “hard”
water areas, the manual drain valve should be opened
fully flushing out accumulated materials, salts and other
particles which are natural by-products of boiling water.
Flush a minimum of two-three hours
after the control has been turned off to insure that the
water has cooled.
Draining immediately after a steam cycle
may expose user to scalding water and may expose PVC
and other piping to high temperature water. Check local
codes. The unit will refill automatically when the control
is activated again.
Using Mr.Steam®Essential Oils
Enjoy AromaSteam™ essential oils by placing a drop or two into an
unheated AromaSteam steamhead as shown in the illustration.
Only use Mr.Steam®AromaSteam essential oils in the Mr.Steam®
AromaSteam steamhead.
•Use essential oils with caution. Essential oils are for external use
only. Keep out of reach of children. Essential oils are highly con-
centrated and are potent substances and should not be applied
directly to the skin as they can be irritants. Use essential oils with
caution.
• Place the drops into the Mr.Steam AromaSteam steamhead re-
cess prior to turning on the steambath. Do not place drops in a
hot steam head as SERIOUS INJURY CAN RESULT IF YOU DO
NOT FOLLOW THIS WARNING.
• Start with one drop to gauge strength and suitability. Limit to a
maximum of a few drops for a steam bathing session.
• The bather should exit the steambath IMMEDIATELY if dizziness
occurs. If skin irritation occurs stop using the oils immediately.
Remove any excess oil by washing in mild soap and water. If
ingested, rinse mouth with water. Administer water or milk to
dilute. Contact a physician immediately.
Aromatic oils should be added to
steamhead before turning on the steambath unit.
DO NOT add oil during steam bathing or when
the steam head is heated.
Tightly close bottles when storing oils. Keep bot-
tles away from sources of ignition.
Care Tips For Steam/Start & SteamHeads
1. Use only mild soap and water on a soft cloth to clean the control and steamhead.
2. Do not use abrasive cleansers

mr
.steam®
Feel Good Inc.
®
www.mrsteam.com
Products, information and specifications are subject to change without notice.
Please call Technical Support at 1.800.76.STEAM (East Coast) or 1.800.72.STEAM (West Coast) for more information.
The model and serial number is printed on the data plate on the front of the steam bath generator.
Have this information available when contacting Technical Service.
mr.steam®
[e-mail] I www.mrsteam.com
43-20 34th Street, Long Island City, NY 11101 TEL: 1 800 76 STEAM I 9410 S. La Cienega Blvd. Inglewood CA 90301 TEL: 1 800 72 STEAM
2020 © MrSteam and des., A Lifetime of Pleasure, AirTempo, AromaFlo, AudioWizard, AutoFlush, AutoSteam, Butler Package, ChromaSteam, Clean Steam...Every Time, Club Therapy, CT Day Spa,
Digital 1, Express Steam, Feel Good Inc., From Bathroom to Spa, HomeWizard, iButler, iGenie, iSpa Package, iSteam, iTempo, iTempo/Plus, Linear Steamhead, Making Wellness a Way of Life,
Music Therapy, My Steam, SmartSizing, Spa Package, Steam Genie, Steam on Demand, Steam in a Box, Steam@Home, SteamStart, SteamTherapy, Tala, Tala Bath & Body, Tempo, The Intelligent
Steambath, Valet Package, and Virtual Spa System are registered trademarks of MrSteam.
PUR103936 Rev 5.22
PUR100467 Rev 1.23
