Mr12volt CarPlay P2000-NTG30MM Instruction manual

Mr12Volt CarPlay interface for NTG3.0
Quick User Guide
Model No : P2000-NTG30MM
Ｗ２２１ Ｓ－ｃｌａｓｓ ２００６ － ２００８ （ ｐｒｅ－ｆａｃｅｌｉｆｔ）
1 - All you need to know before Installation
2 - Product Features
3 - Main Feature Operations
4 - Car Settings
5 - Sound Settings
6 - USB Supported Formats & Other Specs

1 - All you need to know before Installation
NTG 3.0
Mercedes-Benz 1 2 3 4 5
OFF OFF OFF OFF OFF
Mr12volt is selected through TV features of Mercedes NTG3.0
No coding Tools or Factory TV module is needed, once Mr12volt CarPlay
module is installed successfully (pressing both "DISC/RADIO" and "RETURN"
buttons will activate the "TV" option in menu
Dip Switch Configuration

2 - Product Features
Music & Video Playback ( Through USB Flash )
CarPlay
Android Auto
Mirroring
Bluetooth HF & Music Streaming
Reverse Camera Input ( Support up to AHD720P )
Front Camera Input
Passenger Side L/R Camera Input ( For the use of Blind Spot )
Reverse Grid Line
Digital Sound Processor (DSP) with 15 Band Equalizer Adjustment
Software Update available

3 - Main Feature Operations
CarPlay/Android Auto
Support both wired and wireless CarPlay
To connect to CarPlay wirelessly, both Bluetooth and Wi-Fi connection
are required
For wired CarPlay & Android Auto : Use a genuine cable to connect
through the USB/Lightening connector. Wi-Fi & Bluetooth connections
are NOT required in a wired connection.
How to connect CarPlay :Search for Mr12volt_xxxx and pair to make a
Bluetooth connection ---> Turn on Wi-Fi and & use CarPlay ---> it will
start CarPlay on your screen after few seconds, it could take up to a
minute for a first time connection.
How to connect Android Auto : Search for MR12volt_xxx and pair to
make a Bluetooth connection, Wi-Fi on phone will be on automatically
connected to Android Auto
Mirroring
iPhone
1. Disable CarPlay by turning off Bluetooth & Wi-Fi Connection on your
phone
2. Enter Mirroring menu on car display and choose iPhone

3. Turn on Wi-Fi on phone, connect to “carplay_xxxx” ( PW is 88888888)
4. Go to Apple quick menu bar, select Screen Mirroring and select Mirroring
again
5. Phone display will appear on Car Display now
Android Phone
It is necessary to install “MLink” application on your Android phone, it can
be downloaded on www.mr12volt.com ( Go to SUPPORT ---> Download
---> P2000 mirroring)
Both Bluetooth & Hotspot connection are needed at all time for mirroring
Hotspot Setting :
1. 5GHz band must be selected
2. Enter Mirroring menu on car display and choose “Android”
3. Network name & Password on phone must be set same as shown on
Mr12volt “Mirroring” menu
4. Open M-LInk app-->turn on Bluetooth and Hotspot
5. When both Bluetooth and Hotspot are successfully connected, Phone
display will appear on Car Display
It is always best to open mirroring menu on car display prior to the
connection of Bluetooth, so that Android Auto does not overtake the
function of mirroring when first connected to Bluetooth

Bluetooth
Phone contact list
Contact history
Dial Pad
Audio Streaming
Mr12Volt supports the integration of OEM microphone with a
BT Hands-free
When a call is incoming, answer and reject button will appear on display,
Mercedes-Benz Bluetooth HF and Mr12volt Bluetooth can be connected at the
split
cable provided in the package
same time. ( see below picture) When both are connected and a call is received
Mercedes-Benz HF will take over Mr12volt HF and it can be answered through
phone button on steering wheel.

4 - Car Settings
Car Setting
“Reverse Camera” settings
OE Camera (Default) - Select this when car is fitted with factory camera
AfterMarket 360 - Select this when car is installed with a aftermarket
camera ( support up to AHD720 only)
“Reverse condition” settings
Gear Position (Default) - Detects through CAN bus when car is in reverse.
Reverse State - Detects through 12v reverse light signal when reverse
(requires the manual wiring connection of a car reverse signal)

“Starting front view” - Front Camera timer setting with 5s, 10s, 30
When do i select “Reverse State” ?
Mr12volt detects Car CAN bus with most of the car models in the market,
however in some cases particularly in older generation cars,
when CAN bus can’t be detected,
it is necessary to manually detect camera through car
reverse light signal.
(Refer to the Mercedes Benz NTG 3.0 Installation Diagram for more details )
s
“Dedicated right view” - L/R Side camera setting (Blind Spot camera)
Can Active - Detects through CAN bus
12v Active - Detects through 12v side L/R light
“Reverse track” - Option to turn ON / OFF of a Parking Grid (For AfterMarket
camera only)
“Reverse Radar” - Option to turn ON / OFF of a Reverse Sensor (For
AfterMarket Reverse sensor only)

5 - Sound Settings
Sound Settings
DSP Built-In
Bass / Mid / Treble level adjustment with 15 bars customization
Factory default at Flat

6 - USB Supported Formats & Other Specs
Music and Video Playback File Format
USB file format FAT32
Support USB2.0 , Hard disk memory
Supported music format : MP3, WMA, AAC, AC3, DTS, OGG, FLAC, APE,
AMR
Supported video format : mkv, mp4, avi, wmv, rmvb, rm, mpg, mpeg, ts,
dat, asf, flv, vob
Supported Photo format : BMP, JPG, GIF, PNG
DOES NOT support folder management when browsing USB Music and
Video files
Other Data
Support Phone Charging through USB connector @ 500mAh
Support Loss-less Apple music through wireless
