Blue Flame Ice House Heater
MHVFIH10LP
OPERATING INSTRUCTIONS AND OWNER’S MANUAL
READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions
in a safe place for future reference. Do not allow anyone who has not read these
instructions to assemble, light, adjust or operate the heater.
www.mrheater.com 800-251-0001
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
Model # MHVFIH10LP
MHVFIH10LPT
UNVENTED
LP-GAS FIRED
ROOM HEATER
WARNING: If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury, or loss of life.
-Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
-WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediatelycallyourgassupplierfromaneighbor’sphone.Followthegassupplier’sinstructions.
• If you cannot reach your gas supplier, call the fire department.
-Installation and service must be performed by a qualified installer, service agency or the gas supplier.
This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is in-
stalled. Provisions for adequate combustion and ventilation air must be provided. Refer to
Fresh Air for Combustion and Ventilation section on page 4 of this manual.
This appliance may be installed in an aftermarket permanently manufactured (mobile) home,
where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This appli-
ance is not convertible for use with any other gas.
Blue Flame Ice House Heater
MHVFIH10LPT
2
Mr. Heater | Unvented LP-Gas Fired Room Heater Operating Instructions and Owner’s Manual
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
CAUTION: Never connect heater directly to the Propane supply. This heater requires an
external regulator (not supplied). Install the external regulator between the heater and Propane/
LP supply.
The installer must supply an external regulator. The external regulator will reduce the incoming
gas pressure to between 11 and 14 inches of water. If you do not reduce incoming gas pressure
heater regulator damage could occur. Install external regulator with the vent pointing down.
Pointing the vent down protects it from freezing rain or sleet.
WARNING:
Do not use a blower insert,
heat exchanger insert or other
accessory not approved for use
with this heater.
Due to high temperatures,
heater should be kept out of
traffic and away from furniture
and draperies.
Do not place clothing or other
flammable material on or near
the appliance.
Children and adults should be
alerted to the hazard of high
surface temperature and should
stay away to avoid burns or
clothing ignition.
Young children should be
carefully supervised when they
are in the same room with
heater.
If the barrier becomes damaged,
the barrier shall be replaced with
the manufacturer’s barrier for
this appliance.
Any safety screen or guard
removed for servicing an
appliance must be replaced prior
to operating the heater.
Installation and repair should
be done by a qualified service
person. The appliance should be
inspected before use and at least
annually by a professional service
person. More frequent cleaning
may be required due to excessive
lint from carpeting, bedding
material, etc. It is imperative that
control compartments, burners,
and circulating air passageways
of the appliance be kept clean.
WARNING:
This appliance is equipped for
propane gas. Field conversion is
not permitted.
WARNING:
Fuels used in liquefied propane
gas appliances, and the products
of combustion of such fuel,
can expose you to chemicals
including benzene, which is
known to the state of California
to cause cancer and cause birth
defects or other reproductive
harm, for more information go
to www.P65Warnings.ca.gov
WARNING:
THIS PRODUCT CAN EXPOSE
YOU TO CHEMICALS INCLUDING
LEAD AND LEAD COMPOUNDS,
WHICH ARE KNOWN TO
THE STATE OF CALIFORNIA
TO CAUSE CANCER AND
BIRTH DEFECTS OR OTHER
REPRODUCTIVE HARM. FOR
MORE INFORMATION GO TO
WWW.P65WARNINGS.CA.GOV
WARNINGS
WARNING: FIRE, EXPLOSION,
AND ASPHYXIATION HAZARD
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Refer to this manual for correct
installation and operational
procedures. For assistance or
additional information consult
a qualified installer, service
agency, or gas supplier.
Read and follow instructions
andprecautionsinUser’s
Information Manual provided
with this heater.
3Operating Instructions and Owner’s Manual
Mr. Heater | Unvented LP-Gas Fired Room Heater
Specifications
MODEL MHVFIH10LP MHVFIH10LPT
BTU (Available) 7,000(Low)-10,000(High) 10,000
Type of Gas LP-Gas Only LP-Gas Only
Ignition Piezo Electronic Pulse (AAA
Battery)
Manifold Pressure 10 Inches of Water 10 Inches of Water
Inlet Gas Pressure (Maximum) 14 Inches of Water 14 Inches of Water
Inlet Gas Pressure (Minimum) 11 Inches of Water 11 Inches of Water
Burner/ Orifice Nozzles 1 1
Thermostatic Control No Ye s
Clearances: Inches (mm)
Top 36” (91.4 cm)
Sides 10” (25.4 cm)
Floor (min. to top of carpet) 3” (7.6 cm)
Fabric / flammable objects 36” (91.4 cm)
CONTENTS
2 Warnings
3 Specifications
3 Precautions
4 Installation
9 Operation
Lighting
Shutdown
11 Maintenance
12 Troubleshooting
16 Parts List
20 Ordering Parts/Warranty
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
PRECAUTIONS
PRECAUTIONS:
1. A 10,000 BTU (2931 W) unit may
be installed in a bedroom, but shall
not be installed in a bathroom or any
place where a strong wind would shut
down the appliance.
2. This heater needs outside ventilation
air to run properly. The Oxygen
Depletion Sensor (ODS) safety shutoff
system shuts down the heater if not
enough fresh air is available. See Fresh
Air for Combustion and Ventilation,
page 4.
3. Keep all air openings in heater clear,
free of debris or any blockage. This
will ensure that enough air for proper
combustion enters the heater.
4. If heater shuts off, do not relight
until you provide fresh, outside air. If
heater keeps shutting off, it requires
servicing.
5. Turn off and let cool before servicing.
Only a qualified service person should
service and repair heater.
6. Do not run heater:
• Where flammable liquids or vapors are
used or stored
• During dusty conditions.
7. Before using furniture polish, wax,
carpet cleaner or similar products, turn
heater off. If heated the vapors from
these products may create a white
powder residue within burner box or
on adjacent walls or furniture.
8. Do not use heater if any part has
been underwater. Immediately call a
qualified service technician to inspect
the room heater and to replace any
part of the control system and any gas
control which has been underwater.
9. Operating heater above elevations of
4,500 feet could cause pilot/ODS to
shutdown heater.
10. Always run heater with control knob
in a locked position. Never set control
knob between locked positions. Poor
combustion and higher levels of
carbon monoxide may result if control
knob is left between locked positions.
Carbon Monoxide Poisoning:
Early signs of carbon monoxide poisoning
resemble the flu, with headaches,
dizziness, or nausea. If you have these
signs, the heater may not be working
properly. Get fresh air at once! Have
heater serviced. Some people are more
affected by carbon monoxide than others.
These include pregnant women, persons
with heart or lung disease or anemia,
those under the influence of alcohol, and
those at high altitudes.
Propane/LP Gas:
Propane/LP gas is odorless. An odor
making agent is added to propane/
LP gas. The odor helps you detect a
Propane/LP gas leak. However, the odor
added to the gas can fade. Gas may
be present even though no odor exists.
Make certain you read and understand all
warnings. Keep this manual for reference.
It is your guide to safe and proper
operation of this heater.
Safety Device
This heater has a pilot with an Oxygen
Depletion Sensor (ODS) safety shut off
system. The ODS/pilot shuts off the
heater if there is not enough fresh air.
Ignition System
PIEZO: The heater is equipped with a
piezo manual ignitor. This system requires
no matches, batteries, or other source to
light heater.
Ignition System/Battery
Installation (If Equipped)
PIEZO: The heater is equipped with an
electronic manual ignitor. This system
requires no matches, batteries, or other
source to light heater but does require
one AAA battery to operate ignitor.
To install or replace battery unscrew the
ignitor cap (red button), insert battery
positive (+) terminal up and replace cap.
(AAA Battery included)
**Operating heater above elevations of 4,500 feet could cause pilot/ODS to shutdown heater.**
SOCIAL MEDIA
In order to provide the best service possible Mr. Heater is now giving you more
ways to get in touch with us:
WEBSITE: Mr. Heater’s full line of product are now at: www.mrheater.com
FACEBOOK: Find us on Facebook TWITTER: Find us on twitter
YouTube: There are now informational videos on Youtube.
DANGER: Carbon monoxide
poisoning may lead to death.
4
Mr. Heater | Unvented LP-Gas Fired Room Heater Operating Instructions and Owner’s Manual
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
Control
Knob
Heater
Cabinet
Front Panel
MHVFIH10LP
Grill
Burners
MHVFIH10LPT
Control
Knob
Igniter
Button
Heater
Cabinet
Front Panel
Grill
Burners
Figure 1
WARNING: This heater shall not be
installed in a confined space or unusually
tight construction unless provisions are
provided for adequate combustion and
ventilation air. Read the FRESH AIR FOR
COMBUSTION AND VENTILATION
section to insure proper fresh air for
this and other fuel-burning appliances
in your home.
WARNING: This heater shall not be
installed in a room or space unless the
required volume of indoor combustion
air is provided by the method described
in the National Fuel Gas Code, ANSI
Z223.1/NFPA 54, the International Fuel
Gas Code, or applicable local codes.
Thermostatic Control
(If Equipped)
These heaters have a control valve with
a thermostat sensing bulb. This results
in the greatest heater comfort and may
result in lower fuel bills.
Local Codes
Install and use heater with care.
Installation must conform to local codes
or in the absences of local codes, use the
latest edition of National Fuel Gas Code,
ANSI Z223.1/NFPA 54.
Unpacking
1. Remove heater from carton.
2. Remove all protective packaging
applied to heater for shipment.
3. Check heater for any shipping
damage. If heater is damaged,
promptly inform dealer where you
bought heater.
FRESH AIR FOR COMBUSTION
AND VENTILATION
Establishing Adequate
Ventilation
The following are excerpts from National
Fuel Gas Code, NFPA 54/ ANSI Z223.1,
Section 5.3, Air for Combustion and
Ventilation. All spaces in homes fall into
one of the three following ventilation
classifications:
1. Unusually Tight Construction
2. Unconfined Space
3. Confined Space
This heater must not be installed in
a confined space or unusually tight
construction unless provisions are
provided for adequate combustion and
ventilation air. The information on pages 4
and 5 will help you classify your space and
provide adequate ventilation.
Unusually Tight Construction
If your home meets all of the three
following criteria, you must provide
additional fresh air. See Ventilation from
Outdoors, page 5.
Unusually tight construction is defined as
construction where:
1. Walls and ceilings exposed to the
outside atmosphere have a continuous
water vapor retarder with a rating of
one perm (6 x 10- 11 kg per pa-sec-m2)
or less with openings gasketed or
sealed and
2. Weather stripping has been added on
operable windows and doors, and
3. Caulking or sealants are applied to
areas such as joints around windows
and door frames, between wall-
ceiling joints, between wall panels, at
penetrations for plumbing, electrical,
and gas lines, and at other openings.
If you home does not meet all of the
three criteria above, see Determining the
Type of Heater Location Space, below.
Confined Space and Unconfined
Space
The National Fuel Gas Code, NFPA
54/ ANSI Z223.1 defines a confined
space as a space whose volume is less
than 50 cubic feet per 1,000 Btu per
hour (4.8 m3per kW) of the aggregate
input rating of all appliances installed in
that space, and an unconfined space as
a space whose volume is not less than
50 cubic feet per 1,000 Btu per hour
(4.8 m3per kW) of the aggregate input
rating of all appliances installed in that
space. Rooms communicating directly
with the space in which the appliances
are installed*, through openings not
furnished with doors, are considered a
part of the unconfined space.
*Adjoining rooms are communication
only if there are doorless passageways or
ventilation grills between them.
Determining The Type Of
Heater Location Space
Use this method to determine if you have
a confined or unconfined space.
Note: The space includes the room in
which you install heater plus any adjoining
rooms with doorless passageways or
ventilation grills between the rooms.
1. Find the volume of the space by
multiplying room length x width x
height.
Example: Space size 18ft (length) x 18ft.
(width) x 8ft. (height) = 2592
If additional ventilation to adjoining room
is supplied with grills or openings, add
the volume of these rooms to the total
volume of the space.
2. Divide the space volume by 50 cubic
feet to determine the maximum Btu/
hr the space can support.
Example: 2592 cu.ft. (volume of space)
/ 50 cu.ft. = 51.8 or 51,800 (maximum
Btu/hr the space can support)
3. Add the Btu/hr of all the fuel-
burning appliances in the space such
as, Vent–free heater, Gas water
heater, Gas furnace, Vented gas
heater, Gas fireplace logs, and other
gas appliances*
Product Features
INSTALLATION
5Operating Instructions and Owner’s Manual
Mr. Heater | Unvented LP-Gas Fired Room Heater
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
Figure 2
Figure 3
INSTALLATION
WARNING: Rework worksheet,
adding the space of the adjoining
unconfined space. The combined space
must have enough fresh air to supply all
appliance in both spaces.
*IMPORTANT: Do not provide
openings for inlet or outlet into attic. If
attic has a thermostat-controlled power
vent, heated air entering the attic will
activate the power vent.
IMPORTANT: Vent-free heaters
add moisture to the air. Although
this is beneficial, installing heater in
rooms without enough ventilation air
may cause mildew to form from too
much moisture. See Fresh Air for
Combustion and Ventilation, pages
4 through 5.
WARNING: Any change to this
heater or its controls can be dangerous.
WARNING: A qualified service
person must install heater. Follow all
local codes.
*Do not include direct-vent gas
appliances. Direct-vent draws
combustion air from the outdoors
and vents to the outdoors.
Example:
Gas water heater 40,000 Btu/
hr
Vent Free Heater + 20,000 Btu/
hr
Total =60,000 Btu/hr
4. Compare the maximum Btu/hr the
space can support with the actual
amount of Btu/hr used.
Example: 51,800 Btu/hr (maximum
Btu/hr the space can support)
60,000Btu/hr (Actual
amount of Btu/hr used)
The space in the above example is a
confined space because the actual
Btu/hr used is more than the maximum
Btu/hr the space can support.
You must provide additional fresh
air. Your options are as follows:
a. Rework worksheet, and the space
of an adjoining room. If the extra
space provides an unconfined space,
remove door to adjoining room or add
ventilation grills between the rooms.
See Ventilation From Inside Building
(Fig. 2)
b. Vent room directly to the outdoors.
See Ventilation From Outdoors (Fig.
3).
c. Install a lower Btu/hr heater if lower
Btu/hr size makes room unconfined.
If actual Btu/hr used is less than
the maximum Btu/hr the space can
support, the space is an unconfined
space. You will need no additional
fresh air ventilation.
Ventilation Air
Ventilation from Inside Building
This fresh air would come from
an adjoining unconfined space.
When ventilation to an adjoining
unconfined space, you must provide
two permanent openings: one within
12” of the ceiling and one within 12”
of the floor on the wall connecting
the two spaces (see options 1 & 2 of
figure 2). You can also remove door
into adjoining room (see option3, fig
2). Follow the National Fuel Gas Code
NFPA 54/ ANSI Z223.1, Section 5.3,
Air for Combustion and Ventilation
for required size of ventilation grills or
ducts.
Ventilated
Attic
To Attic
To Crawl
Space
Inlet Air
Ventilation Crawl Space
Ventilation Air
Outlet Air
Ventilation Grills into Adjoining
Room-Option 2
Or remove
door into
Adjoining
Room-
Option 3
Ventilation
Grills into
Adjoining
Room-
Option 1
(30.5 cm) 12”
12” (30.5 cm)
Ventilation from Outdoors
If necessary provide extra fresh air
by using ventilation grills or ducts.
Connect these items directly to the
outdoors or spaces open to the
outdoors. These include attics* and
crawl spaces. Follow the National Fuel
Gas Code NFPA 54/ ANSI Z223.1,
Section 5.3, Air for Combustion
and Ventilation for required size of
ventilation grills or ducts.
INSTALLATION
NOTICE: This heater is intended for
the use as supplemental heat. Use
this heater along with your primary
heating system. Do not install this
heater as your primary heat source.
If you have a central heating system,
you may run system’s circulating
blower while using heater. This will
help circulate the heat throughout the
house. In the event of a power outage,
you can use this heater as your primary
heat source for the duration of the
outage.
Check Gas Type
Use only LP-gas. If your gas supply is
not LP-gas, do not install heater. Call
dealer where you bought heater for
proper type heater.
This Installation Requires:
Before installing heater, make sure you
have the items listed below:
• Piping (check local codes)
• Sealant (resistant to LP_Gas)
• Equipment shutoff valve*
• Ground joint union
• Test gauge connection*
• Sediment trap
• Tee joint
• Pipe wrench
*A CSA/AGA certified equipment
shutoff valve with 1/8” NPT tap is an
acceptable alternative to test gauge
connection. Purchase a CSA/AGA
certified equipment shutoff valve from
your dealer.
6
Mr. Heater | Unvented LP-Gas Fired Room Heater Operating Instructions and Owner’s Manual
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
CAUTION: If you install the heater
in a home garage:
• Heater pilot and burner must be
at least 18 inches above floor.
• Locate heater where moving
vehicle will not hit it.
CAUTION: This heater creates
warm air currents. These currents
move heat to wall surfaces next to
heater. Installing heater next to vinyl
or cloth wall covering or operating
heater where impurities (such as
tobacco smoke, aromatic candles,
cleaning fluids, oil or kerosene lamps,
etc.) are present in the air may discolor
walls.
WARNING: Never install the heater:
• In a recreational vehicle.
• Where curtains, furniture, clothing,
or other flammable objects are less
than 36 inches from the front, top,
or sides of the heater.
• As a fireplace insert
• In high-traffic areas
• In windy or drafty areas
WARNING: Heater must be mounted
to maintain the minimum clearances
shown in Figure 4. If possible, provide
greater clearances from the floor, ceiling,
and joining walls.
Locating Heater
This heater is designed to be mounted
on the wall. The heater can also be
located on a non-combustible floor,
away from a wall by using the floor
mounting stands included with the
heater. If installed on combustible
flooring such as carpeting, tile or other
combustible material other than wood
flooring, the heater must be placed on
a metal or wood panel extending the
full width and depth of the appliance.
For convenience and efficiency, install
the heater:
• Where there is easy access for
operation, inspection, and service.
• In the coldest part of the room.
Fastening Heater to Wall
Mounting Bracket
The mounting bracket in located on
the back panel of heater. See Figure 5.
It has been taped there for shipping.
Remove mounting bracket from back
panel.
Removing Front Panel of Heater
1. Remove (4) screws total there are (2)
screws on either side of the heater.
See Figure 6.
2. Pull the front panel and back panel
apart.
Attaching Mounting Bracket to Wall
Use holes on each end of mounting
bracket to attach bracket to wall.
These holes are 16 inches apart. Attach
mounting bracket to wall in one of two
following ways.
1. Attach to wall studs
2. Attach to wall anchor
Decide which way best suits your
needs. Either method will provide a
secure hold for the mounting bracket.
Attaching to Wall Stud
This way is the best providing the
strongest mounting in wood frame
houses.
For attaching mounting bracket to wall
studs:
1. Drill holes at marked locations using
9/64” drill bit.
2. Place mounting bracket onto wall.
Line up holes on each end of bracket
with hole drilled in wall.
3. Insert mounting screws through
bracket and into wall studs.
4. Tighten screws until mounting bracket
is firmly fastened to wall studs.
Attaching to Wall Anchor
This way allows you to attach
mounting bracket to hollow walls (wall
areas between studs) or to solid walls
(concrete or masonry).
1. Tape mounting bracket to wall where
heater will be located. Make sure
mounting bracket is level. For wall
stud mounting locate one end of the
mounting bracket over a wall stud.
2. Mark screw locations on wall.
See figure 7.
3. Remove tape and mount bracket to
wall.
Note: Wall anchors, mounting screws,
and spacer are in hardware package.
The hardware package is provided with
heater.
4. Drill holes at marked locations using
5/16” drill bit. For solid walls (concrete
or masonry), drill at least 1” deep.
Figure 4
Figure 5
Figure 6
Right
Side
Left
Side
Floor
10” (25.4 cm)
from sides
3” (7.62 cm) min. to top surface of carpet,
tile, or other combustible material
36” (91.4 cm)
min. from ceiling
(2)
Screws
(2)
Screws
Mounting
Bracket
INSTALLATION
7Operating Instructions and Owner’s Manual
Mr. Heater | Unvented LP-Gas Fired Room Heater
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
Figure 9
Figure 8
Figure 10
Figure 7
Horizontal
Slots
Mounting
Bracket
mounted
to wall
Mark mounting hole locations and drill
holes where indicated. Allow for minimum
clearances.
See clearance
specs on Pg. 3
Adjoining Wall
16” (Lg)
12-9/64” (Sm)
18” Min.
5. Fold wall anchor as shown in Figure 8
below.
6. Insert wall anchor (wings first) into
hole. Tap anchor flush to wall.
7. For thin walls (1/2” or less) insert red
key into wall anchor.
8. Place mounting bracket onto wall.
Line up holes on each end of bracket
with wall anchors.
9. Insert mounting screws through
bracket and into wall anchors.
10. Tighten screws until mounting bracket
is firmly fastened to wall.
Placing Heater on Mounting Bracket
1. Locate two horizontal slots on back
pane of heater. See Figure 9.
2. Place heater onto mounting bracket.
Slide horizontal slots onto stand-out
tabs on mounting bracket.
Installing Bottom Mounting Screws
1. Locate two bottom mounting holes.
These holes are near bottom on back
panel of heater. See Figure 10.
2. Mark screws locations on wall.
3. Remove heater from mounting
bracket.
4. If installing bottom mounting screw
into hollow or solid wall, install wall
anchors. Follow steps 1 through 4
under Attaching to Wall using Anchor.
If installing bottom mounting screw
into wall stud, drill holes at marked
locations using 9/64” drill bit.
5. Re-place heater onto mounting
bracket.
WARNING: Maintain minimum
clearances shown in Figure 7. If you
can, provide greater clearances from
the floor and joining wall.
Screw Hole
Screw Hole
6. Place spacers between bottom
mounting holes and wall anchor or
drilled hole.
7. Hold spacer in place with one hand.
With the other hand, insert mounting
screw through bottom mounting
hole and spacer. Place tip of screw in
opening of wall anchor or drilled hole.
8. Tighten both screws until heater is
firmly secured to wall. Do not over
tighten.
Note: Do not re-place front panel at
this time.
9. Replace front panel after making gas
connections and checking for leaks.
INSTALLATION
8
Mr. Heater | Unvented LP-Gas Fired Room Heater Operating Instructions and Owner’s Manual
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
Connecting to Gas Supply
Installation must include an equipment
shutoff valve, union and plugged 1/8”
NPT tap. Locate NPT tap within reach
of test gauge hookup. NPT tap must be
upstream from heater. See Figure 11.
*A CSA/AGA certified equipment
shutoff valve with 1/8” NPT tap is an
acceptable alternative to test gauge
connection. Purchase the CSA/AGA
certified equipment shutoff valve from
your dealer.
IMPORTANT: Install an equipment
shutoff valve in an accessible location.
The equipment shutoff valve is for
turning on or shutting off the gas to
the appliance.
Apply pipe joint sealant lightly to male
threads. This will prevent excess sealant
from going into pipe. Excess sealant in
pipe could result in clogged heater fuel
train.
Install sediment trap in supply line as
shown in Figure 11. Locate sediment
trap where it is within reach for
cleaning. A sediment trap traps
moisture and contaminants. This
keeps them from going into heater.
If sediment trap is not installed or is
installed improperly, heater may not
run correctly.
IMPORTANT: Hold pressure regulator
with wrench when connecting it to gas
piping and/or fittings.
PRESSURE TESTING GAS SUPPLY
PIPING SYSTEM
High Pressure
Test pressure in Excess of ½ psig
(3.5kPa)
1. The appliance and its appliance main
gas valve must be disconnected from
the gas supply piping system during
any pressure testing of that system at
test pressures in excess of ½ psi (3.5
kPa).
INSTALLATION
WARNING: A qualified service
person must connect heater to gas
supply. Follow all local codes.
WARNING: This appliance requires
a 3/8” NPT (National Pipe Thread) inlet
connection to the pressure regulator.
Use of floor mounting feet will require
you to use a 3/8 NPT street elbow to
make gas connection.
WARNING: Test all gas piping and
connections for leaks after installing or
servicing. Correct all leaks at once.
WARNING: Never use an open flame
to check for a gas leak. Apply a mixture
of liquid soap and water to all joints.
Bubbles forming show a leak. Correct
all leaks at once.
CAUTION: Never connect heater
directly to the Propane supply. This
heater requires an external regulator
(not supplied). Install the external
regulator between the heater and
Propane/LP supply.
The external regulator will reduce the
incoming gas pressure to between
11 and 14 inches of water. If you do
not reduce incoming gas pressure
heater regulator damage could occur.
Install external regulator with the vent
pointing down. Pointing the vent
down protects it from freezing rain
or sleet.
CAUTION: Use only new black iron
or steel pipe. Internally-tinned copper
tubing may be used in certain areas.
Check your local codes. Use pipe
of large enough diameter to allow
proper gas volume to heater. If pipe
is too small, undue loss of pressure
will occur.
Figure 11
Nipple
Tee Joint
Cap
Shutoff Valve
HEATER CABINET
Nipple
Nipple
Tee Joint
Ground Joint Union
3/8” NPT Pipe Nipple
Pressure
Regulator
Test Gauge
Connection
1/8” NPT Plug Tap
Reducer Bushing
to 1/8” NPT
Nipple
Sediment
Trap
3” minimum
Fuel line from
Regulated LP Tank
(11”W.C to 14” WC Pressure)
CAUTION: Use pipe joint sealant
that is resistant to LP-Gas.
2. Cap off open end of gas pipe
where equipment shutoff valve was
connected.
3. Pressurize supply piping system
by either using compressed air or
opening the propane/LP supply tank
valve.
4. Check all connections and joints in gas
supply piping system. Apply mixture
of liquid soap and water to gas joints.
Bubbles forming show a leak.
5. Correct all leaks at once.
6. Depressurize and relieve pressure in
supply piping system.
7. Reconnect heater and equipment
shutoff valve to gas supply.
8. Reconnected fittings must be checked
for leaks in next section.
9Operating Instructions and Owner’s Manual
Mr. Heater | Unvented LP-Gas Fired Room Heater
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
WARNING: If you do not follow
these instructions exactly, a fire or
explosion may result causing property
damage, personal injury or loss of life.
OPERATION
Low Pressure
Test Pressure Equal To or Less Than ½
psig (3.5 kPa)
1. The appliance must be isolated from
the gas supply piping system by
closing its equipment shutoff valve
during any pressure testing of the gas
supply piping system at test pressures
equal to or less than ½ psi (3.5 kPa).
See Figure 12.
2. Pressurize supply piping system
by either using compressed air or
opening propane/LP supply valve.
3. Check all joints from the propane/
LP supply valve to equipment shutoff
valve. See Figure 13. Apply mixture
of liquid soap and water to gas joints.
Bubbles forming show a leak.
4. Correct all leaks at once.
5. Depressurize and relieve pressure from
supply piping system.
Pressure Testing Heater Gas
Connections
1. Make sure that the heater supply
piping system is connected and has
been leak tested as described above.
2. Make sure control knob of heater is in
OFF position.
3. Open equipment shutoff valve. See
Figure 12.
4. Open propane/LP supply valve.
5. Check all joints from equipment
shutoff valve to control valve. See
Figure 13. Apply mixture of liquid
soap and water to gas joints. Bubbles
forming show a leak.
6. Correct all leaks at once.
7. Light heater. See Operating Your
Heater.
8. Turn off heater. See To Turn OFF Gas
to Appliance.
9. Replace lower front panel.
Figure 12
Figure 14
Figure 13
Equipment
Shutoff
Valve
Open
Closed
Igniter Button Control
Knob
Units w/ Thermostatic Control
Control Knob
To regulated
propane source
Control Valve
Equipment Shutoff Valve
OPERATING YOUR HEATER
For Your Safety Read Before
Lighting
A. This appliance has a pilot that must be
lit by hand. When lighting the pilot,
follow these instructions exactly.
B. BEFORE LIGHTING smell all around
the appliance area for gas. Be sure to
smell next to the floor because some
gas is heavier than air and will settle
on the floor.
WHAT TO DO IF YOU SMELL GAS
• Shut off gas supply.
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Immediately call you gas supplier from
a neighbor’s phone. Follow the gas
supplier’s instructions.
• If you can not reach your gas supplier,
call the fire department.
C. Use only your hand to push in or
turn the gas control knob. Never use
tools. If knob will not push in or turn
by hand, don’t try to repair it; call
a qualified service technician or gas
supplier. Force or attempted repair
may result in a fire or explosion.
D. Do not use this appliance if any part
has been underwater. Immediately call
a qualified service technician to inspect
the appliance and to replace any part
of the control system which has been
under water.
Lighting Instructions
1. STOP! Read the all safety information
included with and on the side of
heater.
2. Check that gas supply to heater is on.
3. Push in gas control knob and slightly
turn clockwise to the OFF position
See Figure 14.
Note: Knob cannot be turned from
PILOT to OFF unless knob is pushed in
slightly. Do not force.
4. Wait five (5) minutes to clear out any
gas. Then smell for gas, including
near the floor. If you smell gas, STOP!
Follow “B” in the safety information
above. If you do not smell gas, go to
the next step.
5. Push in gas control knob slightly and
turn counterclockwise to PILOT/
IGN and depress for five (5) seconds.
10
Mr. Heater | Unvented LP-Gas Fired Room Heater Operating Instructions and Owner’s Manual
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
Note: The first time that the heater
is operated after connecting the gas
supply, the control knob should be
depressed for about 30 seconds. This will
allow air to bleed from the gas system.
Units Without Thermostatic Control
6. Push in control knob and rotate control
knob back to OFF position then rotate
counterclockwise to PILOT/IGN
position. This will light pilot. If needed
gently keep rotating control knob back
and forth while depressed until pilot
lights.
7. Keep control knob depressed in for
ten (10) seconds after lighting pilot.
If pilot goes out, repeat steps 4, 5, 6
and 7.
If pilot does not stay lit, refer to
Troubleshooting, pages 12-14. Also,
contact a qualified service person or
gas supplier for repairs.
If control knob does not pop up when
released, contact a qualified service
person or gas supplier for repairs.
8. When the pilot is lit, turn the control
knob to “HI” position to light.
After flame is established on “HI”,
adjust heat output by turning control
knob to desired position (“LO” or
“HI”). Do not operate heater between
locked positions.
IMPORTANT: Release downward
pressure while turning control
knob. Control knob must be
locked at the desired position.
Units With Thermostatic Control
6. With control knob pressed in, push
down and release the ignition button.
This will light pilot. If needed keep
pressing igniter button until pilot
lights. If pilot does not stay lit, refer to
Troubleshooting, pages 12-15. Also,
contact a qualified service person or
gas supplier for repairs.
If control knob does not pop up when
released, contact a qualified service
person or gas supplier for repairs.
7. When the pilot is lit, turn the control
knob counterclockwise to heating
level. The main burner should light.
8. To select the desired heat level, turn
the temperature setting knob to
desired comfort setting from 1 to 5.
IMPORTANT: Release downward
pressure while turning control knob.
Control knob must be locked at the
desired position.
Figure 15
Correct Pilot Position
Incorrect Pilot Position
CAUTION: Do not try to adjust
heating level by using equipment
shutoff valve.
WARNING: (FOR UNITS WITHOUT
THERMOSTATIC CONTROL)
When running heater, set control
knob at “LO” or “HI” locked positions.
Poor combustion and higher levels of
carbon monoxide may result if heater is
operated with control knob positioned
between locked positions.
THERMOSTAT CONTROL
OPERATION (If Equipped)
The thermostatic control used
modulates the flame size as the
temperature gets closer to set point,
then it turns off the burner upon
reaching temperature.
The burner will cycle back on when
room temperature drops below the set
temperature. The control knob can be
set to any heat level between 1 and 5.
To Turn Off Gas To Appliance
SHUTTING OFF HEATER:
1. Turn off equipment shutoff valve.
2. Turn control knob clockwise to
the OFF position.
SHUTTING OFF BURNER ONLY
(PILOT STAYS LIT)
1. Turn control knob clockwise to the
PILOT/IGN position.
INSPECTING BURNER
Check pilot flame pattern and burner
flame pattern often.
PILOT FLAME PATTERN
Figure 15 show a correct pilot flame
pattern and also shows an incorrect
pilot flame pattern. The incorrect
pilot flame pattern is not touching
thermocouple. This will cause the
thermocouple to cool. When the
thermocouple cools, the heater will
shut down. If pilot flame pattern is
incorrect, as shown in Figure 15:
• Turn heater off (refer back to To Turn
OFF Gas to Appliance)
• See Troubleshooting, pages 12-15.
OPERATION
