MrHeater MHVFIH10LPT Assembly instructions

1Installation Instructions and Owner’s Manual
Unvented Liquid Propane Fired Room Heater
Mr. Heater, 4560 W. 160TH ST., CLEVELAND, OHIO 44135 · 800-251-0001 2018-CB
Installer: Leave this manual with the appliance. Consumer: Retain this manual for future reference.
UNVENTED LP-GAS FIRED ROOM HEATER
MHVFIH10LPT
OPERATING INSTRUCTIONS
AND OWNER’S MANUAL
READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions in a safe
place for future reference. Do not allow anyone who has not read these instructions to assemble,
light, adjust or operate the heater.
Model #
Blue Flame Ice House Heater
MHVFIH10LPT
WARNING:
- WHAT TO DO IF YOU SMELL GAS
WARNING
WARNING

2Installation Instructions and Owner’s Manual
Unvented Liquid Propane Fired Room Heater
CONTENTS
WARNINGS ........................................................................2
SPECIFICATIONS ................................................................3
PRECAUTIONS ...................................................................3
THERMOSTATIC CONTROL ................................................4
DETERMINING THE TYPE OF HEATER LOCATION SPACE ....4
INSTALLATION ...................................................................5
FASTENING HEATER TO WALL ...........................................6
FLOOR MOUNTING AWAY FROM WALL ...........................8
CONNECTING TO GAS SUPPLY ..........................................8
OPERATING YOUR HEATER ..............................................10
CLEANING AND MAINTENANCE ......................................11
TROUBLESHOOTING ........................................................12
PARTS LIST AND DIAGRAM .............................................14
WARRANTY ....................................................................16
CAUTION: Never connect heater directly
to the Propane supply. This heater requires
an external regulator (not supplied). Install
the external regulator between the heater and
Propane/LP supply.
The installer must supply an external
regulator. The external regulator will reduce
the incoming gas pressure to between 11
and 14 inches of water. If you do not reduce
incoming gas pressure heater regulator
damage could occur. Install external
regulator with the vent pointing down.
Pointing the vent down protects it from
freezing rain or sleet.
WARNINGS
IMPORTANT
WARNING:
WARNING: Do not use any accessory not
WARNING:
•
•
•
•
•
•
•
•
SOCIAL MEDIA
In order to provide the best service possible Mr. Heater is now giving you
more ways to get in touch with us:
WEBSITE: Mr. Heater’s full line of product are now at:
WWW.MRHEATER.COM
FACEBOOK: Find us on Facebook
TWITTER: Find us on twitter
YouTube: There are now informational videos on YouTube.

3Installation Instructions and Owner’s Manual
Unvented Liquid Propane Fired Room Heater
DANGER
Carbon Monoxide Poisoning:
Propane/LP Gas:
Product Features
Figure 1
PRECAUTIONS:
Fresh Air for Combustion
and Ventilation
•
•
9. Operating heater above elevations of 4,500 feet
could cause pilot/ODS to shutdown heater.
Control Knob
Grill
Front Panel
Burners
Heater
Cabinet
SPECIFICATIONS
Model MHVFIH10LPT
10,000
LP-Gas Only
1
Yes
Clearances: Inches (mm)
Sides
Floor
**Operating heater above elevations of 4,500 feet could cause pilot/ODS to shutdown heater.**

4Installation Instructions and Owner’s Manual
Unvented Liquid Propane Fired Room Heater
-11 2
windows and doors, and
If you home does not meet all of the three criteria
Determing the Type of Heater Location
Space
The National Fuel Gas Code, NFPA 54/ ANSI Z223.1
3
3
DETERMINING THE TYPE OF HEATER
LOCATION SPACE:
Note:
WARNING:
National Fuel Gas Code, NFPA 54/ ANSI Z223.1,
SAFETY DEVICE
Sen
IGNITION SYSTEM
PIEZO:
(AA Battery included)
THERMOSTATIC CONTROL
LOCAL CODES
Installation must conform to local codes or in the
UNPACKING
FRESH AIR FOR COMBUSTION AND
VENTILATION
WARNING
a
ESTABLISHING ADEQUATE VENTILATION
National Fuel Gas
Code, NFPA 54/ ANSI Z223.1, Section 5.3, Air for
Combustion and Ventilation
Unusually Tight Construction
Ventilation Air
from Outdoors
where:

5Installation Instructions and Owner’s Manual
Unvented Liquid Propane Fired Room Heater
*IMPORTANT:
IMPORTANT: Vent-free heaters add moisture to
INSTALLATION
NOTICE: This heater is intended for the use as
You must provide additional fresh air. Your options
are as follows:
VENTILATION AIR
Ventilation from Inside Building
WARNING:
Ventilation from Outdoors
Ventilation
Gills into
Adjoining
Room - Op-
tion 1
Ventilation Gills into Ad-
joining Room - Option 2
12”
12”
Or remove
door into
Adjoining
Room -
Option 3
INLET
AIR
OUTLET
AIR
VENTILATION CRAWL SPACE
TO CRAWL
SPACE
TO ATTIC
VENTILATION AIR
VENTILATED
ATTIC
OUTLET AIR
Figure 2
Figure 3.

6Installation Instructions and Owner’s Manual
Unvented Liquid Propane Fired Room Heater
WARNING:
CHECK GAS TYPE
Use only LP-gas. LP-gas, do
THIS INSTALLATION REQUIRES:
•
•
•
•
•
•
•
•
LOCATING HEATER
•
•
CAUTION:
•
•
CAUTION:
WARNING:
•
• In windy or drafty areas
WARNING:
FASTENING HEATER TO WALL
Mounting Bracket
Figure 5
Mounting
Bracket
Left
Side
Side
3”
material
Floor
from sides
Figure 4

7Installation Instructions and Owner’s Manual
Unvented Liquid Propane Fired Room Heater
Figure 6
WARNING: Maintain minimum clearances
Figure 7
Figure 8.
Figure 9
Adjoining Wall
18” Min.
See clearance
specs on Pg 3
16” (Lg)
12-9/64” (Sm)
Mark mounting hole locations
and drill holes where indicated.
Allow for minimum clearances
Horizontal Slots
Mounting Bracket
mounted to wall

8Installation Instructions and Owner’s Manual
Unvented Liquid Propane Fired Room Heater
Figure 10
CONNECTING TO GAS SUPPLY
WARNING:
WARNING:
CAUTION: Never connect heater directly to the
Propane supply. This heater requires an external
regulator.(which is attached to the supplied hose).
Install the external regulator between the heater and
Propane/LP supply.
The external regulator will reduce the incoming gas
pressure to between 11 and 14 inches of water. If
you do not reduce incoming gas pressure heater
regulator damage could occur. Install external
regulator with the vent pointing down. Pointing the
vent down protects it from freezing rain or sleet.
CAUTION:
IMPORTANT:
CAUTION:
LP-Gas
IMPORTANT:
CHECKING GAS CONNECTIONS
WARNING:
WARNING:
PRESSURE TESTING GAS SUPPLY PIPING
SYSTEM
High Pressure
Screw
hole
Screw
hole

9Installation Instructions and Owner’s Manual
Unvented Liquid Propane Fired Room Heater
Figure 11
Low Pressure
Pressure Testing Heater Gas Connections:
-
Lighting Instructions
To Turn OFF Gas to
Appliance
OPERATING YOUR HEATER
FOR YOUR SAFETY READ BEFORE LIGHTING
WARNING: If you do not follow these instructions
WHAT TO DO IF YOU SMELL GAS
•
•
• Do not touch any electrical switch; do not use any
•
Figure 12
•
-
-
Figure 13
Equipment
Open
Closed

10 Installation Instructions and Owner’s Manual
Unvented Liquid Propane Fired Room Heater
LIGHTING INSTRUCTIONS
STOP!
Note:
STOP!
Figure 14
Note:
-
8.
9.
CAUTION:
TO TURN OFF GAS TO APPLIANCE
to the OFF
INSPECTING BURNER
PILOT FLAME PATTERN
• To Turn OFF Gas to
Appliance
•
Ignitor Button
Control Knob
Figure 15

11 Installation Instructions and Owner’s Manual
Unvented Liquid Propane Fired Room Heater
CLEANING AND MAINTENANCE
WARNING:
CAUTION:
WARNING:
•
Pilot Air Inlet Hole
Figure 16
•
clean
Exterior
•

12 Installation Instructions and Owner’s Manual
Unvented Liquid Propane Fired Room Heater
TROUBLESHOOTING
NOTE:
WARNING:
CAUTION:
TROUBLESHOOTING
WARNING:
•
•
•
•
•
IMPORTANT: -
for 30 seconds
Only]

13 Installation Instructions and Owner’s Manual
Unvented Liquid Propane Fired Room Heater

14 Installation Instructions and Owner’s Manual
Unvented Liquid Propane Fired Room Heater
MODEL: MHVFIH10LPT
ITEM P/N PART DESCRIPTION QTY ITEM P/N PART DESCRIPTION QTY
180040 Wire Guard 1
14
N/A Regulator Connection 1
280118 Front Panel 1
15
80119 Back Panel 1
380113 Steel Panel 1
16
80036 Wall Mounting Bracket 1
480024 Reflector 1
17
N/A Heat Shield 1
580026 Reflector Back Panel 1
18
N/A Back Heat Shield 1
6N/A Burner Left Bracket 1
19
80081 Thermostat Valve 1
780056 ODS Pilot Assembly w/ Thermocouple (LP) 1
20
80019 Ignitor Pulse 1
880017 Burner Assembly 1
21
80014 Ignitor Wire 1
980009-01 Orifice 1
22
80011 Ignitor Bracket 1
10 N/A Burner Right Bracket 1
23
80010 Thermostat Valve Mounting Bracket 1
11
24
N/A Steel Panel Bracket 1
12
80078 Regulator 1
70569 Hose Assembly w/ Regulator 1
13
80055 Regulator Mounting Bracket 1
70342 Hardware Kit (not shown) 1
1
2
3
4
5
6
7
8
910 11
12
13
14
15
16
17
18
19
20
21
24
22
23
25
PARTS LIST AND DIAGRAM
WARNING:
11
12
13 14
15
16
17
18
19
20
21
22
23
24

15 Installation Instructions and Owner’s Manual
Unvented Liquid Propane Fired Room Heater
PAGE LEFT INTENTIONALLY BLANK

Mr. Heater reserves the right to make changes at any time, without notice or obliga-
tion, in colors, specifications, accessories, materials and models.
WARNING:
USE ONLY MANUFACTURER’S REPLACEMENT PARTS. USE OF ANY OTHER PARTS
COULD CAUSE INJURY OR DEATH. REPLACEMENT PARTS ARE ONLY AVAILABLE
DIRECT FROM THE FACTORY AND MUST BE INSTALLED BY A QUALIFIED SERVICE
AGENCY.
REPLACEMENT PARTS ORDERING INFORMATION:
PURCHASING: Accessories may be purchased at any Mr. Heater local dealer or
direct from the factory
FOR INFORMATION REGARDING SERVICE
Please call Toll-Free 800-251-0001
www.mrheater.com
Our office hours are 8:00 AM – 5:00 PM, EST, Monday through Friday.
Please include the model number, date of purchase, and description of problem in
all communication.
LIMITED WARRANTY
Mr. Heater warrants its heaters and accessories to be free from defects in material
and workmanship for a period of 5 year from date of purchase. Mr. Heater will
repair or replace this product free of charge if it has been proven to be defective
within the 1-year period, and is returned at customer expense with proof of
purchase to Mr. Heater within the warranty period.
This warranty gives you specific legal rights, and you may also have other rights which
vary from state to state.
Mr. Heater, 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 800-251-0001
Mr. Heater is a registered trademarks of Mr. Heater, Inc.
© 2017 Mr. Heater. All rights reserved
PRODUCT REGISTRATION: Thank you for your purchase.
Please log in to http://www.egiregistration.com to register your product.
