MSI MAG Series User manual

MAG Series
PC Case
MAG PANO M100R PZ
MAG PANO M100R PZ WHITE
User Guide

2
Contents
Specifications.....................................................................................................3
Accessories........................................................................................................5
Case Features....................................................................................................6
Side and Front View...........................................................................................7
I/O and Buttons..................................................................................................8
Side Panel Removal...........................................................................................9
Front Bezel Removal .......................................................................................10
Top Panel Removal..........................................................................................11
Motherboard Installation.................................................................................12
Graphics Card Installation...............................................................................13
SSD Installation ...............................................................................................14
PSU Installation ...............................................................................................15
Top Panel I/O Connection ................................................................................16
Control Board Connection...............................................................................17
General Information ........................................................................................19

3
Specifications
Basic Information
Case Type Mid Tower
Dimensions (DxWxH) 440 x 235 x 405 mm
Supported Motherboard Sizes Micro-ATX*, Mini-ITX
* Supports Micro-ATX back-connect motherboard
Cooling Fan Support
Top 3 x 120mm or 2 x 140mm
Front No
Rear 1 x 120mm or 1 x 140mm
(Pre-installed 1 x 120mm ARGB fan)
Side 3 x 120mm
(Pre-installed 3 x 120mm ARGB fans)
Bottom 1 x 120mm
PSU Shroud 2 x 120mm
Expansion Slots
PCIe Slots 5 slots
Drive Bays
2.5" SSD 1
3.5” HDD 1
Combo 3.5"/2.5" 2 x 2.5” or 1 x 2.5” + 1 x 3.5”

4
I/O Ports and Buttons
USB Ports 1 x USB 3.2 Gen1 Type-A
1 x USB 3.2 Gen 2x2 Type-C
Audio Ports 1 x Audio/Microphone combo jack
Buttons 1 x Power button
1 x LED switch button
Chassis Clearances
Maximum CPU Cooler Height 175 mm
Maximum GPU Length 390 mm
Top Radiator Support 120 / 240 / 360 mm
Rear Radiator Support 120 / 140 mm
PSU Support 200mm
Materials
Metal Specification SPCC 0.7 mm
Front Bezel Material 4mm tempered glass
Left Side Panel 4mm tempered glass
Top Bezel Internal plastic structure enclosed in metal
Dust Filter Top: Plastic filter
Bottom: Plastic, magnetic frame
GPU holder Aluminum

5
Accessories
Item Name / Q’ty Used for
Cable ties
x5 Cable management
Screw M3 5mm
x20 Motherboard / SSD
Screw #6-32 5mm
x8 3.5” HDD
Screw #6-32 6mm
x6
Securing PSU / PCIe
Card
Stand-off #6-32 6.5mm
x4 Motherboard Stud
Screw #6-32 30mm
x8
Securing fans on the PSU
shroud
Stand-off Mounting Tool
x1 Securing stand-off
Spare U Clip
x2 Securing side panel
GPU Holder
x1
Reinforcing the graphics
card
Spirit level
x1
Adjusting the horizontal
of GPU
Hook-and-loop fastener
x2 Cable management

6
Case Features

7
Side and Front View
440mm 235mm
405mm

8
I/O and Buttons
1122334455
Item Description
1 USB 3.2 Gen 2 2x2 Type-C port
2 USB 3.2 Gen 1 Type-A port
3 Audio/Microphone combo jack
4 LED switch button
5 Power button

9
Side Panel Removal
2
2
1
1
The side panel is held in place by
snap-fit clips

10
Front Bezel Removal
Before removing the front bezel, please remove the side panels on both sides and
gently pull out the front panel with your hand.

11
Top Panel Removal
3
2
1
1

12
Motherboard Installation

13
Graphics Card Installation
1
2
3

14
SSD Installation

15
PSU Installation

16
Top Panel I/O Connection
HD AUDIO
JUSB
(USB 3.2 Gen2)
JUSB
(USB 3.2 Gen1)
JAUD1 JFP1
F_PANEL

17
1
D
+5V
Control Board Connection
ARGB LED
Motherboard ARGB connector and
Power supply’s SATA connector
ARGB connector
ARGB connector
Fan connector
ARGB extension cable
ARGB strip
Addressable RGB LED Strip Connection
Addressable RGB LED Fan Connection
ARGB Fan
ARGB ARGB RGB
Fan
LED Switch button
Motherboard fan connector

18
⚠
IMPORTANT
∙ Please always turn off the power supply and unplug the power cord from the power
outlet before installing or removing the ARGB LED Strip/Fan.
∙ Supports a maximum of 80 LEDs. Exceeding this limit may result in overheating,
abnormal colors, or malfunctions.
∙ Please ensure all cables are securely connected before powering on.
LED Switch Button Function
∙Single press to toggle between LED effects.
∙Long press for three seconds to sync with the motherboard.
∙Long press for six seconds to turn off the lights. The lights will flash four times. To
turn the lights back on, press the button once.
LED Effect Sequence
After pressing the LED Switch button, the LED effect sequence is as follows:
1 Rainbow
2 Rainbow trail
3 Rainbow gradient
4 Purple
5 White
6 Blue
7 Cyan
8 Green
9 Yellow
10 Red
11 Rainbow breathing
12 Red breathing
13 Yellow breathing
14 Green breathing
15 Cyan breathing
16 Blue breathing
17 White breathing
18 Purple breathing
19 Static rainbow
20 Red
21 Yellow
22 Green
23 Cyan
24 Blue
25 White
26 Purple

19
General Information
Copyright and Trademarks Notice
Copyright © Micro-Star Int’l Co., Ltd. All rights reserved.
The MSI logo used is a registered trademark of Micro-Star Int’l Co., Ltd. All other
marks and names mentioned may be trademarks of their respective owners. No
warranty as to accuracy or completeness is expressed or implied. MSI reserves the
right to make changes to this document without prior notice.
All text, images, illustrations, and other content in this manual are the property of
MSI. No part of this manual may be reproduced, distributed, or used in any form
without the written permission of MSI.
Revision History
∙Version 1.0, 2024/01, First release.
