MSI IM-HM65 User manual

IM-HM65
MS-9897 (v1.x) Industrial Computer Board

ii
Preface 󰀩
Copyright Notice
The material in this document is our intellectual property. We take every
care in the preparation of this document, but no guarantee is given as to the
correctness of its contents. Our products are under continual improvement
and we reserve the right to make changes without notice.
Trademarks
All trademarks are the properties of their respective owners.
NVIDIA®is registered trademark of NVIDIA Corporation.
ATI®is registered trademark of ATI Technologies, Inc.
AMD®is registered trademarks of AMD Corporation.
Intel®is registered trademarks of Intel Corporation.
Windows®is registered trademarks of Microsoft Corporation.
AMI®is registered trademark of Advanced Micro Devices, Inc.
Award®is a registered trademark of Phoenix Technologies Ltd.
Realtek®is registered trademark of Realtek Semiconductor Corpora-
tion.
Revision History
Revision Revision History Date
V1.0 For PCB v1.x 2012/ 06
󰩛
󰩛
󰩛
󰩛
󰩛
󰩛
󰩛
󰩛

iii
MS-9897
Safety Instructions
Always read the safety instructions carefully.
Keep this User’s Manual for future reference.
Keep this equipment away from humidity.
Lay this equipment on a reliable at surface before setting it up.
The openings on the enclosure are for air convection hence protects the
equipment from overheating. DO NOT COVER THE OPENINGS.
Make sure the voltage of the power source and adjust properly 110/220V
before connecting the equipment to the power inlet.
Place the power cord such a way that people can not step on it. Do not
place anything over the power cord.
Always Unplug the Power Cord before inserting any add-on card or mod-
ule.
All cautions and warnings on the equipment should be noted.
Never pour any liquid into the opening that could damage or cause electri-
cal shock.
If any of the following situations arises, get the equipment checked by ser-
vice personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well or you can not get it work according
to User’s Manual.
The equipment has dropped and damaged.
The equipment has obvious sign of breakage.
DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT UNCONDI-
TIONED, STORAGE TEMPERATURE ABOVE 60oC (140oF), IT MAY DAM-
AGE THE EQUIPMENT.
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer.
󴶖󱙺󱆯󳝘󴈵
󵉉󲡟󳝢󵪎󴻷󴰺󳝒󱛱󰦉󱥘󱹵󱅿󳢴󳛠󱪳󱁝󱆯󳝘󲡲󰦉󱘟󴌭󲤳󵉐󲑀󳍑󴀊󵤫󲂢󲜮󰦉󱥘󵉉󳱞󲋵
󲻱󱀻󰦉󱆯󳝘󴈵󲤳󴫛󴮱󲹲󲗑󱘆󲨀󱃋󵊙󳞦󳢴󱸽󳶆󰆎
󲄒󵤫󲺐󴳻󱤎󲝦
For better environmental protection, waste batteries should be
collected separately for recycling or special disposal.
󰩛
󰩛
󰩛
󰩛
󰩛
󰩛
󰩛
󰩛
󰩛
󰩛
󰩛
󰂁
󰂁
󰂁
󰂁
󰂁
󰂁
󰩛

iv
Preface 󰀩
CE Conformity
Hereby, we declare that this device is in compliance with the
essential safety requirements and other relevant provisions set
out in the European Directive.
FCC-B Radio Frequency Interference
Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equip-
ment generates, uses and can radiate radio frequency energy and, if not in-
stalled and used in accordance with the instruction manual, may cause harmful
interference to radio communications. However, there is no guarantee that in-
terference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the measures listed below:


󰘯



The changes or modications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.

Shielded interface cables and AC power cord, if any, must be used in order to
comply with the emission limits.
VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU RESEAU.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
this device may not cause harmful interference, and
this device must accept any interference received, including interference
that may cause undesired operation.
󰩛
󰩛
󰩛
󰩛
1.
2.

v
MS-9897
WEEE Statement
ENGLISH
Under the European Union (“EU”) Directive on Waste Electrical and Electronic Equipment,
Directive 2002/96/EC, which takes effect on August 13, 2005, products of “electrical and
electronic equipment” cannot be discarded as municipal waste anymore and manufactur-
ers of covered electronic equipment will be obligated to take back such products at the
end of their useful life.
DEUTSCH
Gemäß der Richtlinie 2002/96/EG über Elektro- und Elektronik-Altgeräte dürfen Elektro-
und Elektronik-Altgeräte nicht mehr als kommunale Abfälle entsorgt werden. Wir haben
europaweit verschiedene Sammel- und Recyclingunternehmen beauftragt, die in die Eu-
ropäische Union in Verkehr gebrachten Produkte, am Ende seines Lebenszyklus zurück-
zunehmen. Bitte entsorgen Sie dieses Produkt zum gegebenen Zeitpunkt ausschliesslich
an einer lokalen Altgerätesammelstelle in Ihrer Nähe.
FRANÇAIS
Au sujet de la directive européenne (EU) relative aux déchets des équipement électriques
et électroniques, directive 2002/96/EC, prenant effet le 13 août 2005, que les produits élec-
triques et électroniques ne peuvent être déposés dans les décharges ou tout simplement
mis à la poubelle. Les fabricants de ces équipements seront obligés de récupérer certains
produits en n de vie. Par conséquent vous pouvez retourner localement ces matériels
dans les points de collecte.
РУССКИЙ
В соответствии с директивой Европейского Союза (ЕС) по предотвращению
загрязнения окружающей среды использованным электрическим и электронным
оборудованием (директива WEEE 2002/96/EC), вступающей в силу 13 августа 2005
года, изделия, относящиеся к электрическому и электронному оборудованию, не могут
рассматриваться как бытовой мусор, поэтому производители вышеперечисленного
электронного оборудования обязаны принимать его для переработки по окончании
срока службы.
ESPAÑOL
Bajo la directiva 2002/96/EC de la Unión Europea en materia de desechos y/o equipos
electrónicos, con fecha de rigor desde el 13 de agosto de 2005, los productos clasicados
como “eléctricos y equipos electrónicos” no pueden ser depositados en los contenedores
habituales de su municipio, los fabricantes de equipos electrónicos, están obligados a
hacerse cargo de dichos productos al termino de su período de vida.
NEDERLANDS
De richtlijn van de Europese Unie (EU) met betrekking tot Vervuiling van Electrische en
Electronische producten (2002/96/EC), die op 13 Augustus 2005 in zal gaan kunnen niet

vi
Preface 󰀩
meer beschouwd worden als vervuiling. Fabrikanten van dit soort producten worden
verplicht om producten retour te nemen aan het eind van hun levenscyclus.
SRPSKI
Po Direktivi Evropske unije (“EU”) o odbačenoj ekektronskoj i električnoj opremi, Di-
rektiva 2002/96/EC, koja stupa na snagu od 13. Avgusta 2005, proizvodi koji spadaju
pod “elektronsku i električnu opremu” ne mogu više biti odbačeni kao običan otpad i
proizvođači ove opreme biće prinuđeni da uzmu natrag ove proizvode na kraju njihovog
uobičajenog veka trajanja.
POLSKI
Zgodnie z Dyrektywą Unii Europejskiej (“UE”) dotyczącą odpadów produktów elektry-
cznych i elektronicznych (Dyrektywa 2002/96/EC), która wchodzi w życie 13 sierpnia
2005, tzw. “produkty oraz wyposażenie elektryczne i elektroniczne “ nie mogą być trak-
towane jako śmieci komunalne, tak więc producenci tych produktów będą zobowiązani
do odbierania ich w momencie gdy produkt jest wycofywany z użycia.
TÜRKÇE
Avrupa Birliği (AB) Kararnamesi Elektrik ve Elektronik Malzeme Atığı, 2002/96/EC Kara-
rnamesi altında 13 Ağustos 2005 tarihinden itibaren geçerli olmak üzere, elektrikli ve
elektronik malzemeler diğer atıklar gibi çöpe atılamayacak ve bu elektonik cihazların
üreticileri, cihazların kullanım süreleri bittikten sonra ürünleri geri toplamakla yükümlü
olacaktır.
ČESKY
Podle směrnice Evropské unie (“EU”) o likvidaci elektrických a elektronických výrobků
2002/96/EC platné od 13. srpna 2005 je zakázáno likvidovat “elektrické a elektronické
výrobky” v běžném komunálním odpadu a výrobci elektronických výrobků, na které se
tato směrnice vztahuje, budou povinni odebírat takové výrobky zpět po skončení jejich
životnosti.
MAGYAR
Az Európai Unió („EU”) 2005. augusztus 13-án hatályba lépő, az elektromos és elektron-
ikus berendezések hulladékairól szóló 2002/96/EK irányelve szerint az elektromos és
elektronikus berendezések többé nem kezelhetőek lakossági hulladékként, és az ilyen
elektronikus berendezések gyártói kötelessé válnak az ilyen termékek visszavételére
azok hasznos élettartama végén.
ITALIANO
In base alla Direttiva dell’Unione Europea (EU) sullo Smaltimento dei Materiali Elettrici
ed Elettronici, Direttiva 2002/96/EC in vigore dal 13 Agosto 2005, prodotti appartenenti
alla categoria dei Materiali Elettrici ed Elettronici non possono più essere eliminati come
riuti municipali: i produttori di detti materiali saranno obbligati a ritirare ogni prodotto alla
ne del suo ciclo di vita.

vii
MS-9897
Contents
Copyright Notice ................................................................................. ii
Trademarks .........................................................................................ii
Revision History .................................................................................. ii
Safety Instructions ............................................................................. iii
CE Conformity.................................................................................... iv
FCC-B Radio Frequency Interference Statement ..............................iv
WEEE Statement ................................................................................v
Chapter 1 Overview ������������������������������������������������������������������������������� 1-1
Mainboard Specications................................................................ 1-2
Mainboard Layout ........................................................................... 1-4
Chapter 2 Hardware Setup�������������������������������������������������������������������� 2-1
Quick Components Guide............................................................... 2-2
Memory ........................................................................................... 2-3
Power Supply.................................................................................. 2-4
Back Panel I/O ................................................................................ 2-5
Connector ....................................................................................... 2-7
Jumper .......................................................................................... 2-13
Slot................................................................................................ 2-16
Chapter 3 BIOS Setup ��������������������������������������������������������������������������� 3-1
Entering Setup ................................................................................ 3-2
The Menu Bar ................................................................................. 3-4
Main ................................................................................................ 3-5
Advanced ........................................................................................ 3-7
Boot............................................................................................... 3-12
Security ......................................................................................... 3-13
Chipset.......................................................................................... 3-16
Power............................................................................................ 3-18
Save & Exit ................................................................................... 3-20
Chapter 4 System Resources��������������������������������������������������������������� 4-1

Chapter 1
Overview
Thank you for choosing the IM-HM65, an excellent in-
dustrial computer board.
Based on the innovative Intel®HM65 chipset for op-
timal system efciency, the IM-HM65 accommodates
the Intel®Sandy Bridge mobile processor and sup-
ports up to 2 DDR3 1066MHz Non-ECC, unbuffered
SO-DIMM slots to provide the maximum of 8GB mem-
ory capacity.
In the advanced-level and mid-range market segment,
the IM-HM65 provides a high-performance solution for
today’s front-end and general purpose workstation, as
well as in the future.

1-2
Overview 󰀩
Mainboard Specications
CPU Intel Sandy Bridge mobile processor󰀲
Chipset Intel HM65 PCH󰀲
Memory 2 unbuffered non-ECC DDR3 800/ 1066/ 1333 SO-
DIMM slots
Supports the maximum of 8GB
Supports Dual Channel
󰀲
󰀲
󰀲
LAN 1 Intel 82574L GbE controller
1 Intel 82579LM GbE controller
󰀲
󰀲
Storage 2 SATA 3Gb/s ports by Intel HM65 PCH󰀲
Audio HDA Codec by Realtek®ALC886
Compliant with Azalia 1.0 specs
󰀲
󰀲
Graphics 1 HDMI port
1 DVI-I port
󰀲
󰀲
Back
Panel I/O
1 HDMI port
1 DVI-I port
4 USB ports
2 RJ-45 LAN jacks
1 microphone audio jack
1 Line-Out audio jack
󰀲
󰀲
󰀲
󰀲
󰀲
󰀲
Onboard
Connec-
tors/ Pin-
headers/
Switch
1 USB 2.0 pinheader (2 ports)
3 serial port connectors (supports 6 ports)
1 SPI Flash ROM pinheader (for debugging)
1 LVDS connector
1 chassis intrusion connector
1 amplier pinheader
󰀲
󰀲
󰀲
󰀲
󰀲
󰀲
Slot 2 Mini PCIe slots󰀲
Form Fac-
tor
Mini-ITX: 170mm x 170mm󰀲

1-3
MS-9897
Environ-
mental
Operating Temperature: 0oC to 60oC
Storage Temperature: -20oC to 80oC
Humidity: 0% ~ 90% RH, non-condensing
󰀲
󰀲
󰀲

1-4
Overview 󰀩
Mainboard Layout
DVI-I Port
LAN Jack
USB 2�0
Port
Mic-In Jack
LAN Jack
HDMI Port
USB 2�0
Port
Back Panel I/O
Serial Port
Pinheader
DIMM Slot
SATA Connector
SATA Power
Connector
Front USB
Pinheader
Fan Power
Connector
Mini PCIe
Slot
Clear CMOS
Jumper
LVDS
Connector
Amplier
Pinheader
Front Panel
Pinheader
DC Power
Connector
Deep Sleep
Mode Jumper
Chassis Intrusion
Pinheader
LVDS Power Jumper
Fan Power
Connector
Serial Port
Pinheader AT/ATX Power
Select Jumper
Line-Out Jack
Port 80 pinheader
Serial Port
Power Jumper

1-5
MS-9897
DIMM1
MINI_PCIE2
JUSIM1
DIMM Slot
Mini PCIe
Slot
SIM card
holder

This chapter provides you with the information on
mainboard hardware congurations. Incorrect setting
of jumpers and connectors may damage your main-
board. Please pay special attention not to connect
these headers in wrong direction. DO NOT adjust any
jumper while the mainboard is powered on.
Chapter 2
Hardware Setup

2-2
Hardware Setup 󰀩
Quick Components Guide
Back Panel
I/O, p�2-5
COM2/1, p�2-10
DIMM Slot,
p�2-3
SATA1/2, p�2-7
JSATA_PWR1,
p�2-4
JUSB1, p�2-9
SYSFAN1, p.2-8
MINI_PCIE1, p�2-16
JCMOS1, p�2-13
JLVDS1, p�2-11
JAMP1, p�2-9
JFP1, p�2-8
JPWR1, p�2-4
JCOMP1, p�2-14
JCASE1, p�2-11
J1, p�2-14
CPUFAN1, p�2-8
COM3_1, p�2-10
JAT_ATX, p�2-13
JDP1, p�2-12
JDSW1, p2-15

2-3
MS-9897
Memory
Installing Memory Modules
Locate the SO-DIMM slot. Align the notch on the DIMM with the key on
the slot and insert the DIMM into the slot.
Push the DIMM gently downwards until the slot levers click and lock
the DIMM in place.
To uninstall the DIMM, ip the slot levers outwards and the DIMM will
be released instantly.
Important
You can barely see the golden nger if the memory module is properly in-
serted in the DIMM slot.
󰁈
1.
2.
3.

2-4
Hardware Setup 󰀩
Power Supply
DC Power Connector: JPWR1
This connector provides 12/19/24V DC power input.
4.DC Power
2.Ground
3.DC Power
1.Ground
SATA Power Connector: JSATA_PWR1
This connector provides power to SATA hard drives.
4+12V
3.GND
2.GND
1.VCC5

2-5
MS-9897
Back Panel I/O
DVI-I Port
HDMI Port
LAN
USB 2�0
Port
Line-Out Jack
Mic-In Jack
LAN
USB 2�0
Port
HDMI Port
The High-Denition Multimedia Interface (HDMI) is an all-digital audio-video
interface that is capable of transmitting uncompressed streams. HDMI
supports all types of TV formats, including standard, enhanced, or high-
denition video, plus multi-channel digital audio on a single cable.
DVI-I Port
The DVI-I (Digital Visual Interface-Integrated) connector allows you to
connect an LCD monitor. It provides a high-speed digital interconnection
between the computer and its display device. To connect an LCD monitor,
simply plug your monitor cable into the DVI connector, and make sure that
the other end of the cable is properly connected to your monitor (refer to
your monitor manual for more information.)
USB 2�0 Port
The USB 2.0 port is for attaching USB 2.0 devices such as keyboard,
mouse, or other USB compatible devices.
󰁈
󰁈
󰁈

2-6
Hardware Setup 󰀩
LAN
The standard RJ-45 LAN jack is for connection to the Local Area Network
(LAN). You can connect a network cable to it.
Speed IndicatorActivity Indicator
Left LED
(Active LED)
Right LED
(100M/1000M Speed LED)
LED Color Yellow Green/Orange
10M Cable
Plug-in
No Transmission Yellow (Lighting) OFF
Transmission Yellow (Blinking) OFF
100M Cable
Plug-in
No Transmission Yellow (Lighting) Green (Lighting)
Transmission Yellow (Blinking) Green (Lighting)
1000M Cable
Plug-in
No Transmission Yellow (Lighting) Orange (Lighting)
Transmission Yellow (Blinking) Orange (Lighting)
In S3/S4/S5 Standby State Yellow (Lighting) OFF
Audio Jack
Line-Out (Green) - for speakers or headphones
Mic-In (Pink) - for microphones
󰁈
󰁈
󰀲
󰀲
