MSI KT4M User manual

i
Version 1.1
G52-M6596X2-G22
KT4M/KT3M
MS-6596 (v1.X) M-ATX Mainboard

ii
Manual Rev: 1.1
Release Date: Dec. 2002
FCC-B Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a class
B digital device, pursuant to part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference when the equip-
ment is operated in a commercial environment. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accor-
dance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference, in which case the user will be required to correct
the interference at his own expense.
Notice 1
The changes or modifications not expressly approved by the party respon-
sible for compliance could void the user’s authority to operate the equipment.
Notice 2
Shielded interface cables and A.C. power cord, if any, must be used in order to
comply with the emission limits.
VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU
RESEAU.
Micro-Star International MS-6596
Tested to comply
with FCC Standard
For Home or Office Use

iii
Copyright Notice
The material in this document is the intellectual property of MICRO-STAR
INTERNATIONAL. We take every care in the preparation of this document,
but no guarantee is given as to the correctness of its contents. Our products
are under continual improvement and we reserve the right to make changes
without notice.
Trademarks
All trademarks are the properties of their respective owners.
AMD, Athlon™, Athlon™ XP, Thoroughbred™, and Duron™ are registered
trademarks of AMD Corporation.
PS/2 and OS®/2 are registered trademarks of International Business Machines
Corporation.
Windows®98/ME/2000/NT/XP are registered trademarks of Microsoft
Corporation.
Netware®is a registered trademark of Novell, Inc.
Award®is a registered trademark of Phoenix Technologies Ltd.
AMI®is a registered trademark of American Megatrends Inc.
Revision History
Revision Revision History Date
V1.1 PCB V1.0A1 Dec. 2002
Technical Support
If a problem arises with your system and no solution can be obtained from the
user’s manual, please contact your place of purchase or local distributor.
Alternatively, please try the following help resources for further guidance.
Visit the MSI website for FAQ, technical guide, BIOS updates, driver
updates, and other information: http://www.msi.com.tw/
Contact our technical staff at: [email protected]

iv
1. Always read the safety instructions carefully.
2. Keep this User’s Manual for future reference.
3. Keep this equipment away from humidity.
4. Lay this equipment on a reliable flat surface before setting it up.
5. The openings on the enclosure are for air convection hence protects the
equipment from overheating. DO NOT COVER THE OPENINGS.
6. Make sure the voltage of the power source and adjust properly 110/220V
before connecting the equipment to the power inlet.
7. Place the power cord such a way that people can not step on it. Do not
place anything over the power cord.
8. Always Unplug the Power Cord before inserting any add-on card or module.
9. All cautions and warnings on the equipment should be noted.
10. Never pour any liquid into the opening that could damage or cause electri-
cal shock.
11. If any of the following situations arises, get the equipment checked by a
service personnel:
zThe power cord or plug is damaged.
zLiquid has penetrated into the equipment.
zThe equipment has been exposed to moisture.
zThe equipment has not work well or you can not get it work according
to User’s Manual.
zThe equipment has dropped and damaged.
zThe equipment has obvious sign of breakage.
12. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT
UNCONDITIONED,STORAGETEMPERATUREABOVE600 C(1400F),IT
MAY DAMAGE THE EQUIPMENT.
Safety Instructions
CAUTION: Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer.

v
CONTENTS
Chapter 1. Getting Started ........................................................................ 1-1
Mainboard Specifications .................................................................... 1-2
Mainboard Layout ............................................................................... 1-4
Chapter 2. Hardware Setup ....................................................................... 2-1
Quick Components Guide .................................................................... 2-2
Central Processing Unit: CPU .............................................................. 2-3
CPU Core Speed Derivation Procedure ......................................... 2-3
CPU Installation Procedures for Socket 462 .................................. 2-4
Installing AMD Athlon CPU (Socket 462) Cooler Set ................... 2-5
Setting CPU Clock Frequency through Jumper ............................. 2-7
Memory ................................................................................................ 2-7
Memory Speed/CPU FSB Support Matrix ..................................... 2-7
DIMM Module Combination ......................................................... 2-8
Installing DDR Modules ............................................................... 2-8
Power Supply ....................................................................................... 2-9
ATX 20-Pin Power Connector: CONN1 ......................................... 2-9
Back Panel .......................................................................................... 2-10
Mouse Connector ....................................................................... 2-10
Keyboard Connector ................................................................... 2-11
USB Connectors .......................................................................... 2-11
Serial Port Connectors: COM A & COM B .................................. 2-12
RJ-45 LAN Jack (Optional) .......................................................... 2-12
Parallel Port Connector: LPT1 ...................................................... 2-13
Audio Port Connectors ............................................................... 2-14
Connectors ......................................................................................... 2-15
Floppy Disk Drive Connector: FDD1 ........................................... 2-15
Hard Disk Connectors: IDE1 & IDE2 ........................................... 2-16
Fan Power Connectors: CPUFA1/SYSFA1 .................................. 2-18
CD-In Connector: JCD1 ............................................................... 2-19

vi
Chassis Intrusion Switch Connector: JCI1 .................................. 2-18
Power Saving Switch Connector: JSLP1 ...................................... 2-19
IrDA Infrared Module Header: JIR1 ............................................ 2-19
Front Panel Connectors: JFP1, JFP2 ............................................ 2-20
Front Panel Audio Connector: JAUD1 ........................................ 2-21
SPDIF Connector: JSP1 (Optional) .............................................. 2-22
S-Bracket Connector: JSB1 (Optional) ......................................... 2-23
Front USB Connector: JUSB1 ...................................................... 2-24
Jumpers .............................................................................................. 2-25
Clear CMOS Jumper: JBAT1 ........................................................ 2-25
FSB Clock Jumper: SW1, SW2 .................................................... 2-26
Slots ................................................................................................... 2-27
AGP (Accelerated Graphics Port) Slot ......................................... 2-27
PCI (Peripheral Component Interconnect) Slots .......................... 2-27
CNR (Communication Network Riser) Slot .................................. 2-27
PCI Interrupt Request Routing .................................................... 2-28
Chapter 3. BIOS Setup .............................................................................. 3-1
Entering Setup ...................................................................................... 3-2
Control Keys ................................................................................. 3-2
Getting Help .................................................................................. 3-3
The Main Menu ................................................................................... 3-4
Standard CMOS Features .................................................................... 3-6
Advanced BIOS Features .................................................................... 3-8
Advanced Chipset Features ............................................................... 3-12
Integrated Peripherals ........................................................................ 3-16
Power Management Features ............................................................. 3-21
PNP/PCI Configurations ..................................................................... 3-25
PC Health Status ................................................................................ 3-27
Frequency/Voltage Control ................................................................ 3-28

vii
Load Fail-Safe/Optimized Defaults ..................................................... 3-29
Set Supervisor/User Password ........................................................... 3-30
Appendix: Using 4- or 6-Channel Audio Function .................................... A-1
Installing the Audio Driver ................................................................. A-2
Installation for Windows 98SE/ME/2000/XP ................................ A-2
Using 4- or 6-Channel Audio Function ............................................... A-5
Using the Optional S-Bracket ....................................................... A-5
Using the Back Panel only ......................................................... A-10
Testing the Connected Speakers ....................................................... A-14
Testing Each Speaker ................................................................. A-14
Playing KaraOK ................................................................................ A-16
Playing KaraOK .......................................................................... A-16
Troubleshooting ........................................................................................ T-1
Glossary .................................................................................................... G-1

1-1
Getting Started
Chapter 1. Getting
Started
Getting Started
Thank you for purchasing the KT4M/KT3M (MS-6596 v1.X)
series Micro ATX mainboard. The KT4M/KT3M is based on VIA®
Apollo KT400/KT333 & VT8235 chipsets for optimal system
efficiency.Designed tofittheadvancedAMD®Athlon™,Athlon™
XPor Duron™ processors, the KT4M/KT3M delivers a high per-
formance and professional desktop platform solution.

1-2
MS-6596 M-ATX Mainboard
Mainboard Specifications
CPU
hSupports Socket A (Socket-462) for AMD®Athlon™/Athlon™ XP /Duron™
processors.
hSupports up to 2600+ or higher speed.
Chipset
hVIA®KT400/KT333 North Bridge.
- Supports 200/266/333 MHz front side bus.
-SupportsDDR333/266/200 memory.
- Supports AGP 4X and AGP 8X (available only for KT400).
hVIA®VT8235 South Bridge
- Integrated Direct Sound AC97 audio.
- Dual channel Ultra DMA 33/66/100/133 master mode EIDE controller.
- ACPI & PC2001 compliant enhanced power management.
- Integrated USB 2.0 controller.
MainMemory
hSupports four memory banks using two 184-pin DDR DIMMs.
hSupports up to 2GB PC2700/2100/1600 DDR SDRAMs.
hSupports 2.5v DDR SDRAM.
Slots
hOne AGP (Accelerated Graphics Port) slot.
- Supports AGP 3.0 4X and 8X (available only for KT400).
hThree 32-bit PCI bus slots (support 3.3v/5v PCI bus interface).
hOne CNR (Communication Network Riser) slot.
On-BoardIDE
hAn IDE controller on the VT8235 chipset provides IDE HDD/CD-ROM with
PIO, Bus Master and Ultra DMA133/100/66/33 operation modes.
MSIRemindsYou...
1. To support CPU with 333MHz FSB, the onboard memory mod-
ules have to be DDR333 SDRAMs.
2. Support for DDR400 technology will be available later after
validation of DDR400 specifications.

1-3
Getting Started
hCan connect up to four IDE devices.
On-BoardPeripherals
hOn-Board Peripherals include:
- One floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and
2.88Mbytes
- Two serial ports (COM A + COM B)
- One parallel port supports SPP/EPP/ECP mode
- One RJ-45 LAN port
- Vertical audio ports
- One 3-pin SPDIF connector (Optional)
- One 12-pin S-Bracket connector (Optional)
- Six USB 2.0 ports (Rear * 4/ Front * 2)
Audio
hRealTek ALC650 6-channel audio.
LAN(Optional)
h10/100Mbps Ethernet onboard.
BIOS
hThe mainboard BIOS provides “Plug & Play” BIOS which detects the pe-
ripheral devices and expansion cards of the board automatically.
hThe mainboard provides a Desktop Management Interface (DMI) function
which records your mainboard specifications.
Dimension
hMicro ATX Form Factor: 24.5 cm x 22 cm.
Mounting
h6 mounting holes.
Others
hWake Up from S1/S3 (Power/Sleep Button, PS/2 Keyboard + Mouse, PME,
USBDevice,COM,RTCAlarm,CNR).
hWake Up from S4 (Power/Sleep Button, PME, COM, RTC Alarm, CNR).
hWake Up from S5 (Power Button, PME, COM, RTC Alarm).
hPC2001Compliance.

1-4
MS-6596 M-ATX Mainboard
Mainboard Layout
KT4M/KT3M (MS-6596 v1.X) Micro ATX Mainboard
SOCKET462
Mic
Line-In
Line-Out
AGP 1
Top : mouse
Bottom: keyboard
USB
Ports
T: RJ45 LAN jack
B: USB ports
JCD1
Codec
JAUD1
JSP1
(
Optional
)
BATT
+
BIOS
Winbond
83697HF
VIA
VT8235
IDE1
IDE2
FDD1
PCI 1
PCI 2
PCI 3
CNR
JUSB1
JFP1JFP2
CPUFA1
SYSFA1
ATX
PowerSupply
JBAT1
JCI1
JSLP1
Top :Parallel port
Bottom:
COM A
COM B
VIA
VT6103
DIMM1
DIMM2
SW1
SW2
JIR1
JSB1
(
Optional
)

2-1
Hardware Setup
Chapter 2. Hardware
Setup
Hardware Setup
This chapter provides you with the information about hard-
ware setup procedures. While doing the installation, be careful
in holding the components and follow the installation
procedures. For some components, if you install in the wrong
orientation, the components will not work properly.
Use a grounded wrist strap before handling computer
components. Static electricity may damage the components.

2-2
MS-6596 M-ATX Mainboard
Quick Components Guide
CPU, p.2-3
CONN1,
p.2-9
Back Panel
I/O, p.2-10
CPUFA1, p.2-17
DIMM1/2,
p.2-7
FDD1,
p.2-15
IDE1/2,
p.2-16
SW1,
p.2-26
JCI1,
p.2-18
SW2,
p.2-26
JBAT1,
p.2-25
JSLP1,
p.2-19
JUSB1,p.2-24
JFP1,p.2-20
JFP2,p.2-20
CNR Slot,
p.2-27
PCI Slots,
p.2-27
AGP Slot,
p.2-27
JSP1,p.2-22
JAUD1,p.2-21
SYSFA1
p.2-17
JCD1,p.2-18
JIR1,
p.2-19
JSB1,p.2-23

2-3
Hardware Setup
Central Processing Unit: CPU
The mainboard supports AMD®Athlon™, Athlon™ XP and Duron™
processors in the 462 pin package. The mainboard uses a CPU socket called
Socket A for easy CPU installation. When you are installing the CPU, make
sure the CPU has a heat sink and a cooling fan attached on the top to
prevent overheating. If you do not find the heat sink and cooling fan, contact
your dealer to purchase and install them before turning on the computer.
As processor technology pushes to faster speeds and higher performance, ther-
mal management becomes increasingly crucial when building computer
systems. Maintaining the proper thermal environment is key to reliable
operation. As such, the processor must be maintained in the specified thermal
requirements.
AMD Athlon™/Duron™/Athlon™ XP processor with a speed of 600MHz
and above requires a LARGER heatsink and fan. You also need to add ther-
mal grease between the CPU and heatsink to improve heat dissipation. Then,
make sure that the CPU and heatsink are securely fastened and in good con-
tact with each other. These are needed to prevent damaging the processor and
ensuring reliable operation. If you want to get more information on the proper
cooling, you can visit AMD’s website for reference.
WARNING! Thermal Issue for CPU
CPU Core Speed Derivation Procedure
If CPU Clock = 100MHz
Core/Bus ratio = 14
then CPU core speed = Host Clock x Core/Bus ratio
= 100MHz x 14
= 1.4 GHz

2-4
MS-6596 M-ATX Mainboard
1. Please turn off the power and
unplug the power cord before
installing the CPU.
2. Pull the lever sideways away
from the socket. Make sure
to raise the lever up to a 90-
degree angle.
3. Look for the gold arrow. The
gold arrow should point to-
wards the lever pivot. The
CPU can only fit in the cor-
rect orientation.
4. If the CPU is correctly
installed, the pins should be
completely embedded into the
socket and can not be seen.
Please note that any violation
of the correct installation pro-
cedures may cause permanent
damages to your mainboard.
5. Press the CPU down firmly
into the socket and close the
lever. As the CPU is likely to
move while the lever is being
closed, always close the lever
with your fingers pressing
tightly on top of the CPU to
make sure the CPU is prop-
erly and completely embed-
ded into the socket.
CPU Installation Procedures for Socket 462
Open Lever
Gold arrow
Gold arrow
90 degree
Correct CPU placement
Incorrect CPU placement
Gold arrow
Sliding
Plate
Close
Lever
Press down
the CPU
X
O

2-5
Hardware Setup
The following instructions will guide
you through the heat sink installation
procedures. Please consult your agent
for the proper CPU cooler set.
1. Position your CPU cooler set
onto the CPU.
2. Use one end of the clip to hook
the latch of the CPU sliding
plate.
3. Hook the other latch to fix the
cooling fan set. You may need a
screw drive to press down the
other side of the clip.
4. Connect the fan to the fan power
connector provided on your
mainboard.
Installing AMD Athlon CPU (Socket 462) Cooler Set
Apply some heat
sink paste
MSI Reminds You...
Please apply some heat sink paste on top of CPU to dissipate
the heat more effectively.

2-6
MS-6596 M-ATX Mainboard
Setting CPU Clock Frequency through Jumper
The hardware configuration for CPU clock frequency of the motherboard
is set to 133MHz by default. Therefore, to make a 100/166MHz CPU run at
100/166MHz when it is installed on the board, you have to adjust the CPU
clock frequency through .
To set the clock frequency for the installed CPU, refer to Jumpers/FSB
Clock Jumper: SW1, SW2 in later section of this chapter.
MSI Reminds You...
Overheating
Overheating will seriously damage the CPU and system, al-
ways make sure the cooling fan can work properly to protect
the CPU from overheating.
Replacing the CPU
While replacing the CPU, always turn off the ATX power sup-
ply or unplug the power supply’s power cord from grounded
outlet first to ensure the safety of CPU.
Overclocking
This motherboard is designed to support overclocking.
However, please make sure your components are able to toler-
ate such abnormal setting, while doing overclocking. Any at-
tempt to operate beyond product specifications is not
recommended. We do not guarantee the damages or risks
caused by inadequate operation or beyond product
specifications.

2-7
Hardware Setup
The mainboard provides 2 slots for 184-pin DDR SDRAM DIMM
(Double In-Line Memory Module) modules and supports the memory size up
to 2GB. You can install PC2700/DDR333, PC2100/DDR266 or PC1600/
DDR200 modules on the DDR DIMM slots (DIMM 1~2).
Memory
DDR DIMM Slots
(DIMM 1~2)
MSI Reminds You...
1. To support CPU with 333MHz FSB, the onboard memory mod-
ules have to be DDR333 SDRAMs.
2. Support for DDR400 technology will be available later after
validation of DDR400 specifications.
Memory Speed/CPU FSB Support Matrix
N/A: Not Available TBA: To Be Announced
DDR200 DDR266 DDR333 DDR400
100MHz FSB Yes Yes Yes TBA
133MHz FSB N/A Yes Yes TBA
166MHz FSB N/A TBA Yes TBA

2-8
MS-6596 M-ATX Mainboard
DIMM Module Combination
Install at least one DIMM module on the slots. Memory modules can be
installed on the slots in any order. You can install either single- or double-
sided modules to meet your own needs.
Memory modules can be installed in any combination as follows:
Installing DDR Modules
1. The DDR DIMM has only one notch on the center of module. The mod-
ule will only fit in the right orientation.
2. Insert the DIMM memory module vertically into the DIMM slot. Then
push it in until the golden finger on the memory module is deeply in-
serted in the socket.
3. The plastic clip at each side of the DIMM slot will automatically close.
S: Single Side D: Double Side
Slot Memory Module Total Memory
DIMM 1
(Bank 0 & 1)
S/D 64MB~1GB
DIMM 2
(Bank 2 & 3)
S/D 64MB~1GB
Maximum System Memory Supported 64MB~2GB
MSI Reminds You...
You can barely see the golden finger if the module is properly
inserted in the socket.
Volt Notch

2-9
Hardware Setup
Power Supply
The mainboard supports ATX power supply for the power system. Be-
fore inserting the power supply connector, always make sure that all compo-
nents are installed properly to ensure that no damage will be caused.
ATX 20-Pin Power Connector: CONN1
This connector allows you to connect to an ATX power supply. To
connect to the ATX power supply, make sure the plug of the power supply is
inserted in the proper orientation and the pins are aligned. Then push down
the power supply firmly into the connector.
CONN1
10
1
20
11
PIN SIGNAL
11 3.3V
12 -12V
13 GND
14 PS_ON
15 GND
16 GND
17 GND
18 -5V
19 5V
20 5V
PIN SIGNAL
1 3.3V
2 3.3V
3 GND
45V
5 GND
65V
7 GND
8 PW_OK
9 5V_SB
10 12V
Pin Definition
