CHAPTER 1 INTRODUCTION
1-1
Chapter 1
INTRODUCTION
TheK7TPro2(MS-6330)ATXVAmainboardisahigh-performance
computer mainboard based on VIA®KT133 chipset. The K7T Pro 2 is
designed for the AMD®Socket processor for inexpensive business/
personal desktop markets.
The KT133 chipset consists of the VT8363 system controller (552
pinBGA)andtheVT82C686APCItoISAbridge(352pinBGA). Thesystem
controller provides superior performance between the CPU, DRAM, AGP
bus, and PCI bus with pipelined burst, and concurrent operation.
The VT8363 supports six banks of DRAM’s up to 1.5 GB and full
AGPv2.0capabilityformaximumbus utilization including1x,2x and 4xmode
transfers, SBA (SideBand Addressing), Flush/Fence commands, and
pipelined burst. The chip also supports enhanced PCI bus commands such
asMemory-Read-Line,Memory-Read-Multipleand Memory-Write-Invalid
commands to minimize snoop overhead.
The VT82C686A integrates all system control functions such as
ACPI (Advanced Configuration and Power Interface). The ACPI provides
more Energy Saving Features for the OSPM (OS Direct Power Management)
function. The VT82C686A chipset also improves the IDE transfer rate by
supporting Ultra DMA-33/66 IDE that transfers data at the rate 33/66MB/
sec.
This mainboard which supports KT133 chipset coupled with
VT8363andVT82C686Ais idealforhighperformance,highquality,high
energy efficiency and high integration desktop AGP/PCI/ISA computer
systems.

CHAPTER 1 INTRODUCTION
1-2
Mainboard Features
CPU
lSocket A for AMD®PGA Duron/Athlon processor.
lSupport500MHz,550MHz, 600MHz, 650MHzorhigher processor.
Chipset
lVIA®KT133
-FSB@200MHz
- AGP 4x and PCI Advanced high performance memory controller
-Support PC100/133SDRAM,
lVIA®VT686Achipset (352BGA)
- Enhanced Power Management Features
-IntegratedSuperI/O(FDC,LPT,COM1/2,andIR)
- Dual bus Master IDE Ultra DMA33/66
- Integrated Hardware Soundblaster
- Direct Sound AC97 Audio
-ACPI
ClockGenerator
l100Mhz clocks are supported (200MHz Internal System Bus)
MainMemory
lSupport six memory banks using three 168-pin unbuffered DIMM.
lSupportamaximummemorysize of1.5GB(32Mx8).
lSupport 3.3v SDRAM DIMM.

CHAPTER 1 INTRODUCTION
1-3
Slots
lOne AGP (Accelerated Graphics Port) slot.
-AGP specification compliant
-SupportAGP 2.01x/2x/4x
lOneCNR(Communication Network Riser) slot.
lPCI/ISA Slots may be configured in 2 ways:
- Six 32-bit Master PCI bus slots
- Five 32-bit Master PCI bus slots and 1 ISA slot (wherein one PCI/ISA
slot is shared.
lSupports 3.3v/5v PCI bus Interface.
On-BoardIDE
lAnIDE controller on the VIA®VT686A Chipset provides IDE HDD/CD-
ROM with PIO, Bus Master and Ultra DMA 33/66 operation modes.
lCan connect up to four IDE devices.
On-BoardPeripherals
lOn-BoardPeripherals include:
- 1 floppy port supports 2 FDD with 360K, 720K, 1.2M, .44M and
2.88Mbytes.
- 2 serial ports (COMA + COM B) or 1 serial port with 1 VGA port
- 1 parallel port supports SPP/EPP/ECP mode
- 4 USB ports (2 Rear Connectors/USB Front Pin Header)
-1 IrDA connectorforSIR/CIR/ASKIR/HPSIR.
- 1 Audio/Game port
Audio
lChip Integrated
- Direct Sound AC97 Audio

CHAPTER 1 INTRODUCTION
1-4
BIOS
lThe mainboard BIOS provides “Plug & Play” BIOS which detects the
peripheral devices and expansion cards of the board automatically.
lThe mainboard provides a Desktop Management Interface (DMI) func-
tion which records your mainboard specifications.
Dimension
lATXFormFactor:30.4cmx20.3cm
Mounting
l6 mounting holes.

CHAPTER 1 INTRODUCTION
1-5
Mainboard Layout
PCI SLOT 2
PCI SLOT 1
ATX
Power Supply
VIA
KT133
Socket 462
DIMM 2
Top: mouse
Bottom:
keyboard
Top:Port 1
USB
IDE1
Bottom:
Port2
IDE2 FDD
VT82C686A
JMDM1
JBAT1
JWOL1
JCD1
JAUX1
C_FAN1
JGS1
Top:LPT
Bottom:
COMA
COMB
Top: Midi/
GamePort
Bottom:
Line-Out
Line-In
Mic
K7T Pro 2 (MS-6330) ATX VA Mainboard
J_PHN1
USB2
BIOS
AGP Slot
BATT
+
DiagnosticLED
DIMM 1
CNR
VIA
VT1611A
S_FAN1
DIMM 3
PCI SLOT 3
PCI SLOT 4
PCI SLOT 5
ISA SLOT/
PCI SLOT 6
JFP1
IR
J11
Smart
D-LED
