MSI MS-CF02 User manual

MS-CF02
Industrial Computer Board
User Guide
SKU1 (Intel® R680E)
SKU2 (Intel® Q670E)
SKU3 (Intel® H610E)

2Contents
Revision
V1.0, 2023/05
Contents
Regulatory Notices....................................................................................................... 5
Safety Information........................................................................................................ 8
Specifications................................................................................................................ 9
SKU1/ SKU2............................................................................................................. 9
SKU3 ...................................................................................................................... 12
Rear I/O Panel............................................................................................................. 15
SKU1/ SKU2........................................................................................................... 15
SKU3 ...................................................................................................................... 15
Line-Out Jack ........................................................................................................ 15
Mic-In Jack ............................................................................................................ 15
2.5 GbE RJ-45 LAN Jack........................................................................................ 16
USB 3.2 Gen 2 Port ................................................................................................ 16
USB 3.2 Gen 1 Port ................................................................................................ 16
USB 2.0 Port .......................................................................................................... 16
DisplayPort ............................................................................................................ 16
Connector ....................................................................................... 16
RS232/422/485 Serial Port .................................................................................... 17
Motherboard Overview............................................................................................... 18
SKU1/ SKU2........................................................................................................... 18
SKU3 ...................................................................................................................... 19
CPU Socket ................................................................................................................. 21
Introduction to the LGA1700 CPU ..................................................................................................... 21
CPU & Heatsink Installation.................................................................................. 22
Memory ....................................................................................................................... 23
DIMM1~2: DDR4 SO DIMM Slots.......................................................................................................23
Installing DDR4 Memory................................................................................................................... 23

3
Contents
Storage........................................................................................................................ 24
JSATA1: SATA 3.0 6Gb/s Ports.......................................................................................................... 24
M2_M1: M.2 Slot (M Key, 2242, 2280) ...............................................................................................25
Installing M.2 SSD............................................................................................................................. 25
Expansion Slots .......................................................................................................... 26
PCIE1: PCIe Expansion Slots ............................................................................................................26
JUSIM1: Nano SIM Holder (SKU1,2 Only).................................................................................26
M2_E1: M.2 Slot (E Key, 2230)........................................................................................................... 27
M2_B1: M.2 Slot (B Key, 3042) (SKU1,2 Only) ...........................................................................27
Connectors.................................................................................................................. 28
Power Connectors ................................................................................................. 28
JPWR1: ATX 24-Pin Power Connector.............................................................................................. 28
JPWR3: ATX 4-Pin 12V Power Connector.........................................................................................29
Audio Connectors .................................................................................................. 30
JAUD1: Front Audio Header ............................................................................................................30
JAMP1: Audio Amplifier Header ....................................................................................................... 30
Graphics Connectors............................................................................................. 31
JINV1: LVDS Inverter Box Header.................................................................................................... 31
JLVDS1_EDP1: LVDS+eDP Wafer Connector ................................................................................... 32
Other Connectors .................................................................................................. 33
CPUFAN1, SYSFAN1: CPU/ System Fan Box Headers....................................................................33
JFP1: Front Panel Connector...........................................................................................................34
JCOM3_4: COM Port Box Header...................................................................................................... 35
JGPIO1: GPIO (DIO) Box Header........................................................................................................ 37
JI2C1: I2C Box Header......................................................................................................................37
JUSB1: USB 2.0 Box Header............................................................................................................ 38
JUSB2: USB 3.2 Gen 1 Box Header (SKU1,2 Only).....................................................................38
JBAT1: CMOS Battery Header...........................................................................................................39
Replacing CMOS battery ...................................................................................................................39
Jumpers ...................................................................................................................... 40
BIOS Setup .................................................................................................................. 42
Entering Setup....................................................................................................... 42

4Contents
The Menu Bar ............................................................................................................. 47
Main ............................................................................................................................. 48
Advanced..................................................................................................................... 49
Boot.............................................................................................................................. 57
Security........................................................................................................................ 58
Chipset......................................................................................................................... 75
Power .......................................................................................................................... 76
Save & Exit .................................................................................................................. 77
GPIO WDT BKL Programming .................................................................................. 78
Abstract ................................................................................................................. 78
General Purpose IO ............................................................................................... 79
Watchdog Timer .................................................................................................... 81
LVDS Backlight Control - BKL .............................................................................. 83
SMBus Access ....................................................................................................... 84

5
Regulatory Notices
Regulatory Notices
FCC-B Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and radiates radio frequency energy, and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
∙Reorient or relocate the receiving antenna.
∙Increase the separation between the equipment and receiver.
∙Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
NOTE
∙The changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
∙Shield interface cables and AC power cord, if any, must be used in order to comply
with the emission limits.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
∙This device may not cause harmful interference.
∙This device must accept any interference received, including interference that may
cause undesired operation.
CE Conformity
Hereby, Micro-Star International CO., LTD declares that this device is in
compliance with the essential safety requirements and other relevant
provisions set out in the European Directive.
WEEE Statement
Under the European Union (“EU”) Directive on Waste Electrical and
Electronic Equipment, Directive 2012/19/EU, products of “electrical and
electronic equipment” cannot be discarded as municipal waste anymore
and manufacturers of covered electronic equipment will be obligated to
take back such products at the end of their useful life.

6Contents
Battery Information
Please take special precautions if this product comes with a battery.
∙Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type recommended by the manufacturer.
∙Avoid disposal of a battery into fire or a hot oven, or mechanically crushing or
cutting of a battery, which can result in an explosion.
∙Avoid leaving a battery in an extremely high temperature or extremely low air
pressure environment that can result in an explosion or the leakage of flammable
liquid or gas.
∙Do not ingest battery. If the coin/button cell battery is swallowed, it can cause
severe internal burns and can lead to death. Keep new and used batteries away
from children.
European Union:
Batteries, battery packs, and accumulators should not be disposed of as
unsorted household waste. Please use the public collection system to
return, recycle, or treat them in compliance with the local regulations.
BSMI:
廢電池請回收
For better environmental protection, waste batteries should be collected
separately for recycling or special disposal.
California, USA:
The button cell battery may contain perchlorate material and requires
special handling when recycled or disposed of in California.
For further information please visit:
http://www.dtsc.ca.gov/hazardouswaste/perchlorate/
Chemical Substances Information
In compliance with chemical substances regulations, such as the EU REACH
Regulation (Regulation EC No. 1907/2006 of the European Parliament and the
Council), MSI provides the information of chemical substances in products at:
https://csr.msi.com/global/index
Environmental Policy
∙The product has been designed to enable proper reuse of parts and
recycling and should not be thrown away at its end of life.
∙Users should contact the local authorized point of collection for recycling
and disposing of their end-of-life products.
∙Visit the MSI website and locate a nearby distributor for further recycling
information.
∙Users may also reach us at [email protected] for information regarding proper
Disposal, Take-back, Recycling, and Disassembly of MSI products.

7
Contents
Green Product Features
∙Reduced energy consumption during use and stand-by
∙Limited use of substances harmful to the environment and health
∙Easily dismantled and recycled
∙Reduced use of natural resources by encouraging recycling
∙Extended product lifetime through easy upgrades
∙Reduced solid waste production through take-back policy
Copyright and Trademarks Notice
Copyright © Micro-Star Int’l Co., Ltd. All rights reserved. The MSI logo used is
a registered trademark of Micro-Star Int’l Co., Ltd. All other marks and names
mentioned may be trademarks of their respective owners. No warranty as to accuracy
or completeness is expressed or implied. MSI reserves the right to make changes to
this document without prior notice.
The terms HDMI™, HDMI™ High-Definition Multimedia Interface, HDMI™ Trade dress
and the HDMI™ Logos are trademarks or registered trademarks of HDMI™ Licensing
Administrator, Inc.
Technical Support
If a problem arises with your product and no solution can be obtained from the user’s
manual, please contact your place of purchase or local distributor. Alternatively,
please visit https://www.msi.com/support/ for further guidance.

8Safety Information
Safety Information
∙The components included in this package are prone to damage from electrostatic
discharge (ESD). Please adhere to the following instructions to ensure successful
computer assembly.
∙Ensure that all components are securely connected. Loose connections may cause
the computer to not recognize a component or fail to start.
∙Hold the motherboard by the edges to avoid touching sensitive components.
∙It is recommended to wear an electrostatic discharge (ESD) wrist strap when
handling the motherboard to prevent electrostatic damage. If an ESD wrist strap
is not available, discharge yourself of static electricity by touching another metal
object before handling the motherboard.
∙Store the motherboard in an electrostatic shielding container or on an anti-static
pad whenever the motherboard is not installed.
∙Before turning on the computer, ensure that there are no loose screws or metal
components on the motherboard or anywhere within the computer case.
∙Do not boot the computer before installation is completed. This could cause
permanent damage to the components as well as injury to the user.
∙If you need help during any installation step, please consult a certified computer
technician.
∙Always turn off the power supply and unplug the power cord from the power outlet
before installing or removing any computer component.
∙Keep this user guide for future reference.
∙Keep this motherboard away from humidity.
∙Make sure that your electrical outlet provides the same voltage as is indicated on
the PSU, before connecting the PSU to the electrical outlet.
∙Place the power cord such a way that people can not step on it. Do not place
anything over the power cord.
∙All cautions and warnings on the motherboard should be noted.
∙If any of the following situations arises, get the motherboard checked by service
personnel:
• Liquid has penetrated into the computer.
• The motherboard has been exposed to moisture.
• The motherboard does not work well or you can not get it work according to user
guide.
• The motherboard has been dropped and damaged.
• The motherboard has obvious sign of breakage.
∙Do not leave this motherboard in an environment above 60°C (140°F), it may damage
the motherboard.

Specifications
SKU1/ SKU2
Model MS-CF02-SKU1 MS-CF02-SKU2
Form factor Mini-ITX
Dimensions 170 x 170mm (6.7 x 6.7 inches)
Processor
∙13th Gen Intel® Raptor Lake-S
i9/i7/i5/i3 Pentium®/ Celeron® IOTG Series Processor, Max 65W
-1.6 GHz~5.1 GHz (depends on CPU)
-Socket LGA 1700
∙12th Gen Intel® Alder Lake-S
i9/i7/i5/i3 Pentium®/ Celeron® IOTG Series Processor, Max 65W
-1.6 GHz~5.1 GHz (depends on CPU)
-Socket LGA 1700
Chipset Intel® R680E Intel® Q670E
Memory
∙2 x DDR4 SO-DIMM slots (260-pin, vertical)
-Up to 3200 MT/s
-Up to 64GB
-Dual-Channel DDR4,
ECC/ Non-ECC
-Dual-Channel DDR4,
Non-ECC
Network ∙3 x Intel® I225-LM PCIe 2.5GbE RJ45 LAN
-Co-Lay Intel® I225-V PCIe 2.5GbE RJ45 LAN
Expansion
Slots
∙1 x PCIe 4.0 x16 slot
∙1 x M.2 B Key slot (3042)
-Supports PCIe x1, USB 3.2 Gen 1 & USB 2.0 signal
-Support Nano SIM holder
∙1 x M.2 E Key slot (2230)
-Supports PCIe x1 & USB 2.0 signal
-Supports CNVi
-Support Intel® AX210 Wi-Fi 6E & BT-5.1 (vPro Supported)
∙1 x Nano SIM Holder
-Supported by M.2 B key (SIM) slot
Continued on next column
9
Specifications

Model MS-CF02-SKU1 MS-CF02-SKU2
Storage
∙3 x SATA 3.0 6Gb/s ports
-Support RAID 0/1/5
-Support AHCI mode
∙1 x M.2 M Key slot (2242/ 2280)
-Supports PCIe 3.0 x4 NVMe signal
-Supports B+M Key module
Audio ∙Realtek® ALC897 High Definition Audio Codec
-Co-lay Realtek® ALC888S-VD2
Graphics
∙2 x DP 1.4a up to 4096×2304 @60Hz
∙1 x HDMI™ 1.4b up to 4096x2304 @24Hz
∙1 x LVDS up to 1920x1200 @60Hz (Co-lay eDP)
-Switch between LVDS & eDP throuth BIOS settings.
-18/24-bit dual channel
∙1 x eDP up to 4096×2304 @60 Hz (Co-lay LVDS)
-Switch between eDP & LVDS throuth BIOS settings.
∙4 independent display modes supported
-DP1
-DP2
-HDMI™
-LVDS or eDP
Power ∙1 x 24-pin ATX power connector
∙1 x 4-pin 12V ATX power connector
Cooling ∙1 x 4-pin PWM CPU fan connector
∙1 x 4-pin PWM system fan connector
Rear I/O
∙1 x Line-out jack
∙1 x Mic-in jack
∙3 x 2.5 GbE RJ-45 LAN ports
∙6 x USB 3.2 Gen 2 Type-A ports (10 Gbps)
∙2 x DisplayPort (1.4a)
∙1 x HDMI™ connector (1.4b)
∙2 x DB-9 RS-232/422/485 Serial ports
-COM1: RI/0V/5V/12V, Auto-flow Control
-COM2: 0V/5V/12V, Auto-flow Control
Continued on next column
10 Specifications

Model MS-CF02-SKU1 MS-CF02-SKU2
Onboard
Connector
∙1 x ATX power connector (12-pin)
∙1 x 12V ATX power connector (4-pin)
∙1 x Front audio header (Headphone & Mic-in)
∙1 x Audio amplifier header
∙1 x LVDS Inverter box header
∙1 x LVDS + eDP Wafer Connector
∙1 x CPU fan box header
∙1 x System fan box header
∙1 x Front panel connector
∙1 x COM port box header
∙1 x GPIO (DIO) connector
∙1 x I2C box header
∙1 x USB 2.0 box header
∙1 x USB 3.2 Gen 1 box header
∙1 x CMOS battery header
∙4 x COM voltage select jumpers
∙1 x Clear CMOS jumper
∙1 x ME jumper
∙1 x AT/ ATX mode select jumper
∙1 x LVDS power jumper
∙1 x Chassis Intrusion jumper
OS Support
∙Windows 10 IoT Enterprise 2021 LTSC (64-bit)
∙Windows 11 IoT Enterprise LTSC (64-bit)
∙Linux Kernel 5.15 (ADL-S)/ Linux Kernel 5.19 (RPL-S) (by request)
Certification CE, FCC Class B, BSMI, RCM, VCCI, UKCA
Environment
∙Operating Temperature: 0 ~ 60°C (Thermal Test w/ Airflow: 0.7m/s)
∙Storage Temperature: -20 ~ 80°C
∙Operating Humidity: 10 ~ 90%, non-condensing
∙Storage Humidity: 10 ~ 90%, non-condensing
11
Specifications

SKU3
Model MS-CF02-SKU3
Form factor Mini-ITX
Dimensions 170 x 170mm (6.7 x 6.7 inches)
Processor
∙13th Gen Intel® Raptor Lake-S
i9/i7/i5/i3 Pentium®/ Celeron® IOTG Series Processor, Max 65W
-1.6 GHz~5.1 GHz (depends on CPU)
-Socket LGA 1700
∙12th Gen Intel® Alder Lake-S
i9/i7/i5/i3 Pentium®/ Celeron® IOTG Series Processor, Max 65W
-1.6 GHz~5.1 GHz (depends on CPU)
-Socket LGA 1700
Chipset Intel® H610E
Memory
∙2 x DDR4 SO-DIMM slots (260-pin, vertical)
-Dual-Channel DDR4, Non-ECC
-Up to 3200 MT/s
-Up to 64GB
Network ∙3 x Intel® I225-V PCIe 2.5GbE RJ45 LAN
-Co-Lay Intel® I225-LM PCIe 2.5GbE RJ45 LAN
Expansion
Slots
∙1 x PCIe 4.0 x16 slot
∙1 x M.2 E Key slot (2230)
-Supports PCIe x1 & USB 2.0 signal
-Supports CNVi
-Support Intel® AX210 Wi-Fi 6E & BT-5.1 (vPro Supported)
Storage
∙3 x SATA 3.0 6Gb/s ports
-Support AHCI mode
∙1 x M.2 M Key slot (2242/ 2280)
-Supports PCIe 3.0 x4 NVMe signal
-Supports B+M Key module
Audio ∙Realtek® ALC897 High Definition Audio Codec
-Co-lay Realtek® ALC888S-VD2
Continued on next column
12 Specifications

Model MS-CF02-SKU3
Graphics
∙2 x DP 1.4a up to 4096×2304 @60Hz
∙1 x HDMI™ 1.4b up to 4096x2304 @24Hz
∙1 x LVDS up to 1920x1200 @60Hz (Co-lay eDP)
-Auto switch between LVDS & eDP
-18/24-bit dual channel
∙1 x eDP up to 4096×2304 @60 Hz (Co-lay LVDS)
-Auto switch between eDP & LVDS
∙3 independent display modes supported
-DP1/ DP2
-HDMI™
-LVDS or eDP
Power ∙1 x 24-pin ATX power connector
∙1 x 4-pin 12V ATX power connector
Cooling ∙1 x 4-pin PWM CPU fan connector
∙1 x 4-pin PWM system fan connector
Rear I/O
∙1 x Line-out jack
∙1 x Mic-in jack
∙2 x 2.5 GbE RJ-45 LAN ports
∙2 x USB 3.2 Gen 2 Type-A ports (10 Gbps)
∙2 x USB 3.2 Gen 1 Type-A ports (5 Gbps)
∙2 x USB 2.0 Type-A ports (480 Mbps)
∙2 x DisplayPort (1.4a)
∙1 x HDMI™ connector (1.4b)
∙2 x DB-9 RS-232/422/485 Serial ports
-COM1 RI/0V/5V/12V, Auto-flow Control
-COM2 0V/5V/12V, Auto-flow Control
Continued on next column
13
Specifications

Model MS-CF02-SKU3
Onboard
Connector
∙1 x ATX power connector (12-pin)
∙1 x 12V ATX power connector (4-pin)
∙1 x Front audio header (Headphone & Mic-in)
∙1 x Audio amplifier header
∙1 x LVDS Inverter box header
∙1 x LVDS + eDP Wafer Connector
∙1 x CPU fan box header
∙1 x System fan box header
∙1 x Front panel connector
∙1 x COM port box header
∙1 x GPIO (DIO) connector
∙1 x I2C box header
∙1 x USB 2.0 box header
∙1 x CMOS battery header
∙4 x COM voltage select jumpers
∙1 x Clear CMOS jumper
∙1 x ME jumper
∙1 x AT/ ATX mode select jumper
∙1 x LVDS power jumper
∙1 x Chassis Intrusion jumper
OS Support
∙Windows 10 IoT Enterprise 2021 LTSC (64-bit)
∙Windows 11 IoT Enterprise LTSC (64-bit)
∙Linux Kernel 5.15 (ADL-S)/ Linux Kernel 5.19 (RPL-S) (by request)
Certification CE, FCC Class B, BSMI, RCM, VCCI, UKCA
Environment
∙Operating Temperature: 0 ~ 60°C
(Thermal Test w/ Airflow: 0.7m/s)
∙Storage Temperature: -20 ~ 80°C
∙Operating Humidity: 10 ~ 90%, non-condensing
∙Storage Humidity: 10 ~ 90%, non-condensing
14 Specifications

Rear I/O Panel
SKU1/ SKU2
LAN_USB3
DP_1_2 COM1
COM2
HDMI1
USB 3.2 Gen 2 Ports
Line-Out
Jack
Mic-in
Jack
2.5 GbE
RJ-45 LAN Jacks
DisplayPorts RS232/422/485
Serial Ports
LAN_USB2LAN_USB1
AUDIO1
SKU3
DP_1_2 COM1
COM2
HDMI1
USB 3.2
Gen 2
Ports
USB 3.2
Gen 1
Ports
USB 2.0
Ports
Line-Out
Jack
Mic-in
Jack DisplayPorts RS232/422/485
Serial Ports
AUDIO1
2.5 GbE
RJ-45 LAN Jacks
Line-Out Jack
This connector is provided for headphones or speakers.
Mic-In Jack
This connector is provided for microphones.
15
Rear I/O Panel

2.5 GbE RJ-45 LAN Jack
The standard single RJ45 LAN jack is provided for connection to the Local Area
Network (LAN). You can connect a network cable to it.
Link/ Activity LED
Status Description
Off No link
Yellow Linked
Blinking Data activity
Speed LED
Status Description
Off 10/100 Mbps
Green 1000 Mbps
Orange 2.5 Gbps
USB 3.2 Gen 2 Port
USB 3.2 Gen 2, the SuperSpeed USB 10Gbps, delivers high-speed data transfer for
various devices, such as storage devices, hard drives, video cameras, etc.
USB 3.2 Gen 1 Port
The USB (Universal Serial Bus) port is for attaching USB devices such as keyboards,
mouse, or other USB-compatible devices. USB 3.2 Gen 1 supports data transfer rates
up to 5 Gbps.
USB 2.0 Port
This connector is provided for USB peripheral devices. (Speed up to 480 Mbps)
⚠
Important
High-speed devices are recommended for USB 3.2 ports whereas low-speed devices,
such as mouse or keyboard, are suggested to be plugged into the USB 2.0 ports.
DisplayPort
DisplayPort is a digital display interface standard. This connector is used to connect a
monitor with DisplayPort inputs.
Connector
The High-Definition Multimedia Interface (HDMI™) is an all-digital audio/ video
interface capable of transmitting uncompressed streams. HDMI™ supports all TV
format, including standard, enhanced, or high-definition video, plus multi-channel
digital audio on a single cable.
16 Rear I/O Panel

RS232/422/485 Serial Port
The serial port is a 16550A high speed communications port that sends/receives 16
bytes FIFOs. It supports barcode scanners, barcode printers, bill printers, credit card
machine, etc.
1155
6699
RS232
PIN SIGNAL DESCRIPTION
1
2
3
4
5
6
7
8
9
NDCD
NSIN
NSOUT
NDTR
GND
NDSR
NRTS
NCTS
VCC_COM
Data Carrier Detect
Signal In
Signal Out
Data Terminal Ready
Signal Ground
Data Set Ready
Request To Send
Clear To Send
VCC_COM
RS422
PIN SIGNAL DESCRIPTION
1
2
3
4
5
6
7
8
9
422 TXD-
422 TXD+
422 RXD+
422 RXD-
GND
NC
NC
NC
NC
Transmit Data, Negative
Transmit Data, Positive
Receive Data, Positive
Receive Data, Negative
Signal Ground
No Connection
No Connection
No Connection
No Connection
RS485
PIN SIGNAL DESCRIPTION
1
2
3
4
5
6
7
8
9
TXD-
NC
TXD+
NC
GND
NC
NC
NC
NC
Transmit Data, Negative
No Connection
Transmit Data, Positive
No Connection
Signal Ground
No Connection
No Connection
No Connection
No Connection
17
Rear I/O Panel

Motherboard Overview
SKU1/ SKU2
JUSB2
JUSB1
JPWR1
JGPIO1
SYSFAN1
CPUFAN1
JCASE5
JI2C1
M2_B1
JFP1
JUSIM1
DIMM1
PCIE1
JPWR3
JINV1
JBAT1
DIMM2
JSATA1
JSATA3
JSATA2
JCMOS1
JCOM3_4
JAMP1
JAUD1
JME_DIS1
JESPI1
M2_M1
M2_E1
Rear I/O Panel
1
23 4
5 6
JLVDS1_EDP1
JCOMP2
JCOMP1
JVDD1
JCOMP3
JCOMP4
JATX1
4
1
5
6
2
3
18 Motherboard Overview

SKU3
JUSB1
JPWR1
JGPIO1
SYSFAN1
CPUFAN1
JCASE5
JI2C1
JFP1
DIMM1
PCIE1
JPWR3
JINV1
JBAT1
DIMM2
JSATA1
JSATA3
JSATA2
JCMOS1
JCOM3_4
JAMP1
JAUD1
JME_DIS1
JESPI1
M2_M1
M2_E1
Rear I/O Panel
1
23 4
5 6
JLVDS1_EDP1
JCOMP2
JCOMP1
JVDD1
JCOMP3
JCOMP4
JATX1
4
1
5
6
2
3
19
Motherboard Overview

Component Contents
Component Page
CPU Socket 21
CPU & Heatsink Installation 22
Memory 23
DIMM1~2: DDR4 SO DIMM Slots 23
Storage 24
JSATA1: SATA 3.0 6Gb/s Ports 24
M2_M1: M.2 Slot (M Key, 2242, 2280) 25
Expansion Slots 26
PCIE1: PCIe Expansion Slots 26
JUSIM1: Nano SIM Holder (SKU1,2 Only) 26
M2_E1: M.2 Slot (E Key, 2230) 27
M2_B1: M.2 Slot (B Key, 3042) (SKU1,2 Only) 27
Connectors 28
Power Connectors 28
JPWR1: ATX 24-Pin Power Connector 28
JPWR3: ATX 4-Pin 12V Power Connector 29
Audio Connectors 30
JAUD1: Front Audio Header 30
JAMP1: Audio Amplifier Header 30
Graphics Connectors 31
JINV1: LVDS Inverter Box Header 31
JLVDS1_EDP1: LVDS+eDP Wafer Connector 32
Other Connectors 33
CPUFAN1, SYSFAN1: CPU/ System Fan Box Headers 33
JFP1: Front Panel Connector 34
JCOM3_4: COM Port Box Header 35
JGPIO1: GPIO (DIO) Box Header 37
JI2C1: I2C Box Header 37
JUSB1: USB 2.0 Box Header 38
JUSB2: USB 3.2 Gen 1 Box Header (SKU1,2 Only) 38
JBAT1: CMOS Battery Header 39
Jumpers 40
20 Component Contents
