MSI Z490M-S01 User manual

1
󸛚󳿜 Contents
Contents
2
3
 7
LAN Port LED Status Table........................................................................................7
Audio Ports Configuration..........................................................................................7
8
CPU Socket.................................................................................................................9
DIMM Slots................................................................................................................10
PCI_E1~3: PCIe Expansion Slots..............................................................................11
JFP1: Front Panel Connector...................................................................................12
JAUD1: Front Audio Connector ................................................................................12
SATA1~4: SATA 6Gb/s Connectors...........................................................................13
M2_1~2: M.2 Slots (Key M) .......................................................................................13
ATX_PWR1, CPU_PWR1~2: Power Connectors.......................................................14
JUSB1~2: USB 2.0 Connectors.................................................................................15
JUSB3~4: USB 3.2 Gen 1 5Gbps Connector .............................................................15
CPU_FAN1, PUMP_FAN1, SYS_FAN1~3: Fan Connectors......................................16
JTPM1: TPM Module Connector...............................................................................16
JCI1: Chassis Intrusion Connector...........................................................................17
JTBT1: Thunderbolt Add-on Card Connector ..........................................................17
JRTD3: Intel RTD3 Connector ..................................................................................17
JBAT1: Clear CMOS (Reset BIOS) Jumper...............................................................18
EZ Debug LED (Z490M PLUS/ Z490M PLUS WIFI only) ...........................................18
JRGB1: RGB LED connector.....................................................................................18
19
BIOS Setup................................................................................................................20
Entering BIOS Setup.................................................................................................20
Resetting BIOS..........................................................................................................21
Updating BIOS...........................................................................................................21
22
Installing Windows® 10.............................................................................................22
Installing Drivers......................................................................................................22
Installing Utilities .....................................................................................................22
Thank you for purchasing the MSI® 
motherboard. This User Guide
gives information about board layout, component overview,
BIOS setup and software installation.

2

The components included in this package are prone to damage from electrostatic
discharge (ESD). Please adhere to the following instructions to ensure successful
computer assembly.
Ensure that all components are securely connected. Loose connections may cause
the computer to not recognize a component or fail to start.
Hold the motherboard by the edges to avoid touching sensitive components.
It is recommended to wear an electrostatic discharge (ESD) wrist strap when
handling the motherboard to prevent electrostatic damage. If an ESD wrist strap is
not available, discharge yourself of static electricity by touching another metal object
before handling the motherboard.
Store the motherboard in an electrostatic shielding container or on an anti-static
pad whenever the motherboard is not installed.
Before turning on the computer, ensure that there are no loose screws or metal
components on the motherboard or anywhere within the computer case.
Do not boot the computer before installation is completed. This could cause
permanent damage to the components as well as injury to the user.
If you need help during any installation step, please consult a certified computer
technician.
Always turn off the power supply and unplug the power cord from the power outlet
before installing or removing any computer component.
Keep this user guide for future reference.
Keep this motherboard away from humidity.
Make sure that your electrical outlet provides the same voltage as is indicated on
the PSU, before connecting the PSU to the electrical outlet.
Place the power cord such a way that people can not step on it. Do not place
anything over the power cord.
All cautions and warnings on the motherboard should be noted.
If any of the following situations arises, get the motherboard checked by service
personnel:
Liquid has penetrated into the computer.
The motherboard has been exposed to moisture.
The motherboard does not work well or you can not get it work according to
user guide.
The motherboard has been dropped and damaged.
The motherboard has obvious sign of breakage.
Do not leave this motherboard in an environment above 60°C (140°F), it may
damage the motherboard.

3
 


Supports Intel® new generation processors for LGA 1200
socket*
* Please go to www.intel.com for more compatibility
information.
* Onboard graphics output are disabled when using F SKU
processors.
 Intel® Z490 Express Chipset

4x DDR4 memory slots, support up to 128GB*
Supports 1R 2133/2666/2933 MHz*
1DPC 1R Max speed up to 4000+ MHz
1DPC 2R Max speed up to 4000+ MHz
2DPC 1R Max speed up to 4000+ MHz
2DPC 2R Max speed up to 4000+ MHz
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile (XMP)
* Please refer to www.msi.com for more information on
compatible memory.
 2x PCIe 3.0 x16 slots, support x16/ x4 mode
1x PCIe x1 slot
 Supports AMD® 2-Way Crossfire™


1x HDMI port, supports a maximum resolution of 4096x2160
@30Hz
1x DisplayPort, supports a maximum resolution of
4096x2304 @60Hz
 Realtek® ALC892 Codec
7.1-Channel High Definition Audio
 1x Intel® I219-V 1Gbps LAN controller
Continued on next page

4
Continued from previous page




Intel® Wireless-AC 9462 card
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports Wi-Fi 802.11 a/b/g/n/ac
Supports Bluetooth® 5
1x CNVI_1 Socket with E key (Wi-Fi mode)

Intel® Z490 Chipset
4x SATA 6Gb/s ports*
2x M.2 slots (Key M)
M2_1 supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/
2260/ 2280/ 22110 storage devices*
M2_2 supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/
2260/ 2280 storage devices
Intel® Optane™ Memory Ready**
Supports Intel® Smart Response Technology for Intel
Core™ processors
* SATA2 will be unavailable when installing M.2 SATA SSD in
the M2_1 slot.
** Before using Intel® Optane™ memory modules, please
ensure that you have updated the drivers and BIOS to the
latest version from MSI website.

Intel® Z490 Chipset
Supports RAID 0, RAID1, RAID 5 and RAID 10 for SATA
storage devices
Supports RAID 0 and RAID 1 for M.2 PCIe storage devices

Intel® Z490 Chipset
2x USB 3.2 Gen 2 10Gbps ports, 1 Type-A port and 1 Type-C
port on the back panel
8x USB 3.2 Gen 1 5Gbps ports (4 Type-A ports on the back
panel, 4 ports available through the internal USB 3.2 Gen 1
5Gbps connectors)
4x USB 2.0 ports are available through the internal USB 2.0
connectors
 NUVOTON NCT6687 Controller Chip
Continued on next page

5
 
Continued from previous page


CPU/System temperature detection
CPU/System fan speed detection
CPU/System fan speed control
 mATX Form Factor
9.6 in. x 9.6 in. (24.4 cm x 24.4 cm)

Single BIOS
1x 128 Mb flash
UEFI AMI BIOS
ACPI 6.2, SMBIOS 3.2
Multi-language


1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
1x 4-pin ATX 12V power connector
4x SATA 6Gb/s connectors
2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
2x USB 3.2 Gen1 5Gbps connectors (support additional 4
USB 3.2 Gen1 5Gbps ports)
1x 4-pin CPU fan connector
1x 4-pin water-pump fan connector
3x 4-pin system fan connector
1x Front panel audio connector
1x Front panel connector
1x TPM module connector
1x Chassis Intrusion connector
1x Clear CMOS jumper
1x 4-pin RGB LED connector
1x M.2 E key connector (for CNVi)
1x TBT connector*
1x RTD3 connector
4x EZ Debug LED (Z490M PLUS/ Z490M PLUS WIFI)
* Thunderbolt card needs to support RTD3.
Continued on next page

6
Continued from previous page


1x PS/2 keyboard/ mouse combo port
4x USB 3.2 Gen1 5Gbps Type-A ports
1x HDMI port
1x DisplayPort
1x USB 3.2 Gen2 10Gbps Type-A ports
1x USB 3.2 Gen2 10Gbps Type-C ports
1x LAN (RJ45) port
5x audio jacks
1x Optical S/PDIF Out connector

Drivers
DRAGON CENTER
CPU-Z MSI GAMING
Intel® Extreme Tuning Utility
Google Chrome™, Google Toolbar, Google Drive
Norton™ Internet Security Solution


LAN Manager
Mystic Light
User Scenario
Hardware Monitor
True Color
Live Update
DPC Latency Tuner
Speed Up
Smart Tool
Super Charger
Please refer to http://
download.msi.com/manual/
mb/DRAGONCENTER2.pdf for
more details.

7
 


Status 
Off No link
Yellow Linked
Blinking Data activity

Status 
Off 10 Mbps connection
Green 100 Mbps connection
Orange 1 Gbps connection

PS/2 Mouse/
Keyboard 1Gbps LAN
Audio ports
USB 3.2 Gen 1
5Gbps Type-A
USB 3.2 Gen 1
5Gbps Type-A
USB 3.2 Gen 2
10Gbps Type-C
DisplayPort
Optical S/PDIF-Out
USB 3.2 Gen 2
10Gbps Type-A

 
2468
Center/ Subwoofer Out  
Rear Speaker Out 
Line-In/ Side Speaker Out 
Line-Out/ Front Speaker Out 
Mic In
: empty)

8
BAT1
CPU_FAN1
CPU Socket
SYS_FAN1
SYS_FAN3
JUSB4
PCI_E3
JBAT1
CNVI_1
PCI_E1
DIMMA1
DIMMA2
DIMMB1
DIMMB2
JTBT1
JUSB2
M2_1
JTPM1
JFP1
JAUD1
ATX_PWR1
CPU_PWR1
CPU_PWR2
SATA2
JUSB1 JUSB3
JRGB1
JRTD3
JCI1
SYS_FAN2

50.77mm*
* Distance from the center of the CPU to the nearest DIMM slot.

PUMP_FAN1
SATA1
PCI_E2
M2_2

9
 

Please install the CPU into the CPU socket as shown below.


 Always unplug the power cord from the power outlet before installing or removing
the CPU.
 Please retain the CPU protective cap after installing the processor. MSI will deal
with Return Merchandise Authorization (RMA) requests if only the motherboard
comes with the protective cap on the CPU socket.
 When installing a CPU, always remember to install a CPU heatsink. A CPU heatsink
is necessary to prevent overheating and maintain system stability.
 
your system.
 Overheating can seriously damage the CPU and motherboard. Always make sure
the cooling fans work properly to protect the CPU from overheating. Be sure to apply
an even layer of thermal paste (or thermal tape) between the CPU and the heatsink to
enhance heat dissipation.
 Whenever the CPU is not installed, always protect the CPU socket pins by covering
the socket with the plastic cap.
 If you purchased a separate CPU and heatsink/ cooler, Please refer to the docu-
mentation in the heatsink/ cooler package for more details about installation.
1
4
6
5
78
9
3
2

10 
DIMMB2
DIMMA2 DIMMA2

Please install the memory module into the DIMM slot as shown below.

DIMMB2
DIMMB1
DIMMA2
DIMMA1
1
1
2
3
3
2

11
 


 
 To ensure system stability for Dual channel mode, memory modules must be of the
same type, number and density.
 Some memory modules may operate at a lower frequency than the marked value
when overclocking due to the memory frequency operates dependent on its Serial

frequency if you want to operate the memory at the marked or at a higher frequency.
 󽙎
installation or overclocking.
 The stability and compatibility of installed memory module depend on installed
CPU and devices when overclocking.
 Please refer www.msi.com for more information on compatible memory.



 󽙋
unplug the power supply power cable from the power outlet. Read the expansion
card’s documentation to check for any necessary additional hardware or software
changes.
 If you install a large and heavy graphics card, you need to use a tool such as 
 to support its weight to prevent deformation
of the slot.
 For a single PCIe x16 expansion card installation with optimum performance, using
the  slot is recommended.
BAT1
: PCIe 3.0 x16 (CPU lanes)
: PCIe 3.0 x4 (PCH lanes)
: PCIe 3.0 x1 (PCH lanes)

12 

This connector connects to the switches and LEDs on the front panel.
1
2 10
9
+
+
+- -- -
+
Power LED
HDD LED Reset Switch
Reserved
Power Switch 1 HDD LED + 2 Power LED +
3 HDD LED - 4 Power LED -
5 Reset Switch 6 Power Switch
7 Reset Switch 8 Power Switch
9 Reserved 10 No Pin
HDD LED
RESET SW
HDD LED HDD LED -
HDD LED +
POWER LED -
POWER LED +
POWER LED
JFP1

This connector allows you to connect audio jacks on the front panel.
1
2 10
9
1 MIC L 2 Ground
3 MIC R 4 NC
5 Head Phone R 6 MIC Detection
7 SENSE_SEND 8 No Pin
9 Head Phone L 10 Head Phone Detection

13
 

These connectors are SATA 6Gb/s interface ports. Each connector can connect to one
SATA device.
SATA1
SATA3
SATA2
SATA4


 Please do not fold the SATA cable at a 90-degree angle. Data loss may result
during transmission otherwise.
 SATA cables have identical plugs on either sides of the cable. However, it is

saving purposes.

Please install the M.2 solid-state drive (SSD) into the M.2 slot as below.
1
3
Standoff
Supplied
M.2 screw 30º30º
2

14 

These connectors allow you to connect an ATX power supply.


Make sure that all the power cables are securely connected to a proper ATX power
supply to ensure stable operation of the motherboard.
24
131
12
ATX_PWR1
1 +3.3V 13 +3.3V
2 +3.3V 14 -12V
3 Ground 15 Ground
4 +5V 16 PS-ON#
5 Ground 17 Ground
6 +5V 18 Ground
7 Ground 19 Ground
8 PWR OK 20 Res
9 5VSB 21 +5V
10 +12V 22 +5V
11 +12V 23 +5V
12 +3.3V 24 Ground
3
2 1
4CPU_PWR2 1 Ground 3 +12V
2 Ground 8 +12V
5
41
8
CPU_PWR1
1 Ground 5 +12V
2 Ground 6 +12V
3 Ground 7 +12V
4 Ground 8 +12V

15
 

These connectors allow you to connect USB 3.2 Gen 1 5Gbps ports on the front panel.
1 10
1120
1 Power 11 USB2.0+
2 USB3_RX_DN 12 USB2.0-
3 USB3_RX_DP 13 Ground
4 Ground 14 USB3_TX_C_DP
5 USB3_TX_C_DN 15 USB3_TX_C_DN
6 USB3_TX_C_DP 16 Ground
7 Ground 17 USB3_RX_DP
8 USB2.0- 18 USB3_RX_DN
9 USB2.0+ 19 Power
10 Ground 20 No Pin


Note that the Power and Ground pins must be connected correctly to avoid possible
damage.

These connectors allow you to connect USB 2.0 ports on the front panel.


 Note that the VCC and Ground pins must be connected correctly to avoid possible
damage.
 In order to recharge your iPad,iPhone and iPod through USB ports, please install
MSI® DRAGON CENTER utility.
1
2 10
9
1 VCC 2 VCC
3 USB0- 4 USB1-
5 USB0+ 6 USB1+
7 Ground 8 Ground
9 No Pin 10 NC

16 

PWM Mode fan connectors provide constant 12V output and adjust fan speed with
speed control signal. When you plug a 3-pin (Non-PWM) fan to a fan connector in
PWM mode, the fan speed will always maintain at 100%, which might create a lot of
noise.


You can adjust fan speed in 
1

1 Ground 2 +12V
3 Sense 4 Speed Control Signal
   
CPU_FAN1 PWM mode 2A 24W
PUMP_FAN1 PWM mode 2A 24W
SYS_FAN1~3 PWM mode 1A 12W
1
212
11
1 SPI Power 2 SPI Chip Select
3
Master In Slave Out (SPI
Data)
4
Master In Slave In (SPI
Data)
5 Reserved 6 SPI Clock
7 Ground 8 SPI Reset
9 Reserved 10 No Pin
11 Reserved 12 Interrupt Request

This connector is for TPM (Trusted Platform Module). Please refer to the TPM
security platform manual for more details and usages.

17
 

This connector allows you to connect the chassis intrusion switch cable.
Normal
(default) Trigger the chassis intrusion event

 Connect the  connector to the chassis intrusion switch/ sensor on the
chassis.
 Close the chassis cover.
 Go to .
 Set  to .
 Press F10 to save and exit and then press the  key to select .
 Once the chassis cover is opened again, a warning message will be displayed on
screen when the computer is turned on.

 Go to .
 Set  to Reset.
 Press to save and exit and then press the  key to select .

This connector allows you to connect the add-on Thunderbolt I/O card.

This connector allows you to connect the RTD3 connector on the add-on Thunderbolt
I/O card that supports RTD3.
11 FORCE_PWR 2 SCI_EVENT
3 SLP_S3# 4 SLP_S5#
5 Ground
11 WAKE 2 PWR EN
3 GND

18 

There is CMOS memory onboard that is external powered from a battery located on
the motherboard to save system configuration data. If you want to clear the system
configuration, set the jumpers to clear the CMOS memory.
Keep Data
(default) Clear CMOS/ Reset BIOS

 Power off the computer and unplug the power cord.
 Use a jumper cap to short JBAT1 for about 5-10 seconds.
 Remove the jumper cap from JBAT1.
 Plug the power cord and power on the computer.

These LEDs indicate the status of the motherboard.
 - indicates CPU is not detected or fail.
 - indicates DRAM is not detected or fail.
 - indicates GPU is not detected or fail.
 - indicates booting device is not detected or fail.

The JRGB connector allows you to connect the 5050 RGB LED strips 12V.


 The JRGB connector supports up to 2 meters continuous 5050 RGB LED strips
(12V/G/R/B) with the maximum power rating of 3A (12V).
 󽙋
before installing or removing the RGB LED strip.
 Please use MSI’s software to control the extended LED strip.
11 +12V 2 G
3 R 4 B

19
 

MSI UEFI BIOS is compatible with UEFI (Unified Extensible Firmware Interface)
architecture. UEFI has many new functions and advantages that traditional BIOS
cannot achieve, and it will completely replace BIOS in the future. The MSI UEFI
BIOS uses UEFI as the default boot mode to take full advantage of the new chipset’s
capabilities. However, it still has a CSM (Compatibility Support Module) mode to be
compatible with older devices. That allows you to replace legacy devices with UEFI
compatible devices during the transition.


The term BIOS in this user guide refers to UEFI BIOS unless otherwise noted.

Fast booting - UEFI can directly boot the operating system and save the BIOS self-
test process. And also eliminates the time to switch to CSM mode during POST.
Supports for hard drive partitions larger than 2 TB.
Supports more than 4 primary partitions with a GUID Partition Table (GPT).
Supports unlimited number of partitions.
Supports full capabilities of new devices - new devices may not provide backward
compatibility.
Supports secure startup - UEFI can check the validity of the operating system to
ensure that no malware tampers with the startup process.

 - this motherboard supports only 64-bit
Windows 10 operating system.
  - the system will detect your graphics card. When display a
warning message 



We recommend that you to use a GOP/ UEFI compatible graphics card.

After entering the BIOS, find the BIOS Mode at the top of the screen.











CSM

20 

The default settings offer the optimal performance for system stability in normal
conditions. You should  to avoid possible system
damage or failure booting unless you are familiar with BIOS.


 BIOS items are continuous update for better system performance. Therefore, the
󽙋
reference only. You could also refer to the  information panel for BIOS item
description.
 The BIOS items will vary with the processor.

Press  key, when the
Menu message appears on the screen during the boot process.

F1: General Help
F2: Add/ Remove a favorite item
F3: Enter Favorites menu
F4: Enter CPU Specifications menu
F5: Enter Memory-Z menu
F6: Load optimized defaults
F7: Switch between Advanced mode and EZ mode
F8: Load Overclocking Profile
F9: Save Overclocking Profile
F10: Save Change and Reset*
F12: Take a screenshot and save it to USB flash drive (FAT/ FAT32 format only).
: Enter Search page
* When you press F10, a confirmation window appears and it provides the
modification information. Select between Yes or No to confirm your choice.
