MSI N460GTX Hawk Series User manual

Fan Connector
V-Check Points
Power Connector
1G GDDR5 memory
NVIDIA
GeForce GTX 460
PCI Express Interface
SLI Interface
Mini HDMI Port
Dual DVI-I Ports
- HDMI supported
- HDCP supported
- Dual dual-linkDVI
output supported
Overview
Card Features For reference only
Unpacking
Please check out the following items to make sure that you get the complete product:
>VGA card
>Disk: Drivers, documentation, and applications
Consult your dealer immediately if anything is missing or damaged.
System Requirements
To install the VGA card, your computer system needs to meet the following requirements:
>PCI Express or PCI Express 2.0 - compliant motherboard with one dual-width x16 graphics slot.
>Two 6-pin PCI Express supplementary power connectors.
>Minimum 450W or greater system power supply (with a minimum 12V current rating of 24A) is
recommended.
>CD-ROM / DVD-ROM for driver installation.
>Visit MSI website for further information of operating system support.
Getting Started Getting Started
Hardware
Follow the steps below to install the VGA card:
1. Remove the computer case.
2. Locate the expansion slot on your mainboard.
Warning: Inserting the VGA card into a wrong
slot may damage your card (refer to your
mainboard manual for more Information).
3. Put the card directly over the expansion slot
and press one end of the card into the slot
first. Gently but firmly press the other end
until the card is fully seated in the slot.
4. Secure the card with a bracket screw.
5. Install all other cards and devices and connect
all the cables, and then install the case.
6. Connect the monitor. Now, you are ready to
install the software on your computer.
To install the driver of the VGA card to your computer, please follow the steps below:
1. Turn on the computer.
2. Insert the CD into the CD-ROM drive. The Autorun program will start the Setup
program, and show the setup screen as follows:
Tip: If, on your computer, the Autorun
program does not execute
automatically, please 1) enable the
CD-ROM drive Auto-detect function
from Control Panel; or 2) find and run
the setup.exe file manually from the
CD.
To operate the overclocking function, it is required to install the Hawk Afterburner
application in advance.
To install the Afterburner application, please click the Utility tag, and follow the
on-screen instructions to complete the installation.
The Afterburner function includes:
1) GPU overclocking
2) Memory overclocking
3) GPU, Memory, and PLL Overvoltage
4) Fan Speed Control(%)
Hawk
Software
3. Click the Driver tag, and follow the on-
screen instructions to complete the
installation.
4. After finishing the installation, restart
the computer as instructed.
Quick Installation
123 4
> NVIDIA GeForce Unified Driver Architecture (UDA)
Delivers a proven record of compatibility, reliability, and stability with the widest range of
games and application. NVIDIAGeForce drivers provide the best out-of-box experience for
every user and deliver continuous performance and feature updates over the life of NVIDIA
GeForce GPUs.
> Microsoft Windows 7 Support
Windows 7 is the next generation operating system that will mark a dramatic improvement in
the way the OS takes advantage of the graphics processing unit (GPU) to provide a more
compelling user experience. By taking advantage of the GPU for both graphics and
computing, Windows 7 will not only make today's PCs more visual and more interactive but
also ensure that they have the speed and responsiveness customers want.
> NVIDIA PhysX - Technology
Full support for NVIDIA PhysX technology, enabling a totally new class of physical gaming
interaction for a more dynamic and realistic experience with GeForce.
> Microsoft DirectX 11 Support
DirectX 11 GPU with Shader Model 5.0 support designed for ultrahigh performance in the
new API's key graphics feature, GPU-accelerated tessellation.
TM
> NVIDIA CUDA Technology
CUDA technology unlocks the power of the GPU's processing cores to accelerate the most
demanding system tasks -such as video transcoding -delivering up to 7x performance over
traditional CPUs.
TM
> NVIDIA 3D Vision Surround Ready
Expand your games across three displays in full stereoscopic 3D for the ultimate "inside the
game" experience with the power of NVIDIA 3D Vision and SLI technologies. NVIDIA 3D
Vision Surround also supports triple screen gaming with non-stereo displays.
NVIDIA 3D Version surround requires (1) specific drivers released by NVIDIA, (2) two or
more graphic cards in NVIDIA SLI configuration, (3) 3D vision glasses, and (4) three
identical displays in support of 3D version. See www.nvidia.com/surround for more
information.
> Dual-link HDCP Capable
Designed to meet the output protection management (HDCP) and security specifications of
the Blu-ray Disc and HD DVD formats, allowing the playback of encrypted movie content on
PCs when connected to HDCP-compliant displays.
The VGA card shown here
is for reference, and may
vary from the actual card.
For further information,
please visit msi website at
www.msi.com
TM
> NVIDIA SLI Technology
Industry leading NVIDIA SLI technology offers amazing performance scaling by implementing
AFR(Alternate frame Rendering) for the world's premier gaming solution under Windows 7
with solid, state-of-the-are drivers.
> PCI Express 2.0 Support
Designed for the new PCI Express 2.0 bus architecture offering the highest data transfer
speeds for the most bandwidth-hungry games and 3D applications, while maintaining
backwards compatibility with existing PCI Express motherboards for the broadest support.
> DirectCompute and OpenCL Support
Full support for DirectCompute and OpenCL.
> 32x Anti-aliasing Technology
Lightning fast, high-quality anti-aliasing at up to 32x sample rates obliterates jagged edges.
> Dual-link DVI Support
Able to drive industry's largest and highest resolution flat-panel displays up to 2560x1600
and with support for High-bandwidth Digital Content Protection (HDCP).
TM
> NVIDIA PureVideo HD Technology
The combination of high-definition video decode acceleration and post-processing that
delivers unprecedented picture clarity, smooth video, accurate color, and precise image
scaling for movies and video.
> Hardware Decode Acceleration
Provides ultra-smooth playback of H.264, VC-1, WMV, DivX, MPEG-2 and MPEG-4 HD and
SD movies without the need for a dual or quad-core CPU.
> OpenGL 4.0 Optimization and Support
Ensures top-notch compatibility and performance for OpenGL applications.
> Triple Over Voltage (by Afterburner)
The World's First graphics card supports voltage adjustment of GPU, Memory, and PLL by
Afterburner. With more options to adjust, the maximum performance of GTX 460 can be
totally unleashed!
> 7+1 Phase PWM Design
N460GTX Hawk uses 7+1 Phase PWM design which increases the maximum current value
up to 120A. With extra 30A current output, overclocking power capability of N460GTX Hawk
will be largely improved!
> Military Class Components
MSI graphics cards adopt the high quality components that meet the Military Class standard,
ensuring the best stability, longest life span, and no buzz noise under full load.
> V-Check Points
V-Check point is the overclocker's favorite. Use MultiMeter to read the exact GPU and
Memory voltage value from the V-Check points directly.
> Dual PWM Fans
Dual Ultra Quiet fans provide 50% better thermal efficiency and direct airflow to cool down
GPU, memory, and power module at once.
> Multiple Heatpipes
Multiple Heatpipes can transfer heat much faster to the fins under the dual PWM fans, and
the fans dissipate heat directly from the fins.
> High-Density Heatsink
Ultra high-density aluminum heatsink has large area for heat dissipation. Heat of GPU will
be dissipated to each fin equally.
> Nickel-plated Copper base
Large copper based coated with nickel provides the fastest heat dissipation and the bigger
contact area with GPU.
> Direct Contact Design
Copper base, heasink and heatpipe are all connected together and directly contacted,
creating the shortest path to dissipate the heat of GPU and to improve cooling efficiency.
HAWK Features
1
2
4
3
6
5
8
7
9
1
2
7
89
3
4
5
6
9

Hardware
Hardware
Hardware
Hardware
5
Using MSI Live Update Online
Features
1. Link to MSI's website at http://www.msi.com
2. Find Live Update Online under the selection of Downloads on the web page.
3. Select CLICK HERE to continue.
4. Select Yes, I would like to try it at my own risk to continue.
5. Follow the on-screen instructions to complete the utility downloading and installing
procedures.
6. Enter the page of MSI Live
Update Online [Search
Results]
7. Select the tag of Live VGA
Driver to download and
update the latest VGA driver,
if available.
8. Select the tag of Live VGA
BIOS to download and
update the latest VGA BIOS,
if available.
6
Installing MSI Live Update
MSI Live Update offers you with brand-new update service experience, which can
significantly save your time while searching files. MSI Live Update is capable to
automatically analyze and list drivers, BIOS, and utilities you need. With the easy-to-
use updating approaches, you can increase the performance of your system easily and
quickly. Follow the instructions below, with a few mouse clicks, you can acquire the
related files for the system updating.
Features
1. Insert the supplied disk into the
CD-ROM drive, and start the
Setup program.
2. Click the Utility tab on the setup
screen.
3. Click the MSI Live Update.
Follow the on-screen instructions
to complete the installation.
4. Launch MSI Live Update utility to
proceed the updating function.
Using Live VGA Driver Update
This service enables you to update the latest VGA driver for your VGA card.
TM
1. Click the selection of Live VGA Driver .
2. Click the green button on the left lower side of the main page to connect to the MSI
Live Update Series Server.
3. The utility will automatically detect and download the latest driver, if available.
4. Follow the on-screen instructions to complete the updating procedure.
Using MSI Live VGA BIOS Update
This service enablesyou to updatethe latest VGABIOS for your VGA card.
TM
1. Click the selection of Live VGA BIOS .
2. Follow the on-screen instructions to continue the procedures.
3. Click the green button on the left lower side of the main page to connect to the MSI Live
Update Series Server.
4. The utility will automatically detect and download the latestBIOS, if available.
5. Follow the on-screen instructions to complete the updating procedure.
