MTD BL110 Manual

Item Part No. Description
19 791-182723 Crankcase Bolt
20 753-06275 Crankcase O-Ring
21 753-06189 Insulator Assembly (includes 22 & 23)
22 753-06184 Insulator O-Ring
23 753-06185 Carburetor O-Ring
24 753-06190 Carburetor
25 753-06191 Aircleaner Cover Assembly (includes 26)
26 753-06085 Aircleaner Filter
27 753-06188 Throttle Cable
28 753-06187 Lead Wires
29 791-182519 Anti-rotation Screw
30 753-04003 Clamp Screw
31 791-180217 Clamp Nut
32 753-06253 Air Cleaner Gasket
33 753-06294 Muffle Screws
* 753-06192 Short Block Assembly
(includes Crankcase, Cylinder, Piston, 4-7 & 17-20)
* Items Not Shown
3
1
4
17
18
23
28
22
10
24
16
15
19
30
29
26
14
20
3
5
Item Part No. Description
1 753-06194 Rear Cover Assembly (includes 2 & 3)
2 791-181345 Cover Screw
3 791-181862 Housing Screw
4 753-06174 O-Ring
5 753-06175 Flywheel Assembly
6 753-06247 Washer
7 753-06218 Spacer
8 753-06195 Starter Housing (includes 3 & 13)
9 753-06180 Starter Clutch Assembly
10 753-06181 Clutch Cover (includes 2)
11 753-06182 Muffler Assembly (includes 12 & 33)
12 753-04619 Muffler Gasket
13 791-182366 U-shaped Nut
14 753-06183 Fuel Tank Assembly (includes 15 & 16)
15 791-181930 Tank Screw
16 791-182612 Fuel Cap
17 753-06186 Module Assembly
18 753-06193 Spark Plug
27
7
31
12
11
8
13
2
2
6
9
21
25
REPLACEMENT PARTS - MODEL BL110
2-CYCLE GAS TRIMMER
PPN 41AD110G965
PARTS LIST PART NO. 769-05091 P00 10/09
32
33

Item Part No. Description
1 753-04234 Throttle Housing Assembly (includes 2-4)
2 791-182405 Switch
3 753-04119 Throttle Trigger
4 791-182690 Throttle Trigger Spring
5 753-06065 Flexible Drive Shaft
6 753-05748 Drive Shaft Housing Assembly (includes 5)
7 753-06198 D-Handle (includes 8)
8 753-06199 D-Handle Hardware Assembly
9 753-04282 Shield Mounting Hardware
10 753-06200 Shield Assembly (includes 9 & 11)
11 753-05033 Blade Assembly
12 753-04284 Outer Spool w/Retainer
13 791-610317B Spring
14 753-1155 Inner Reel
15 791-153066B Bump Head Knob Assembly
* 791-153577B Reel & Line Assembly
* Items Not Shown
1
1
4
2
6
8
8
10
11
9
11
12
13
14
15
3
7
9
REPLACEMENT PARTS - MODEL BL110
2-CYCLE GAS TRIMMER
PPN 41AD110G965
Issued 10/09
5
